OPERATING MANUAL
Electronic counting scale
Counting scale of HWZ series
HWZ- -Rev008-221128 UM- en
2 HWZ- -Rev008-221128 UM- en
Content
1. Applications ............................................................................................................... 3
2. Warnings ................................................................................................................... 3
3. Delivery contents ....................................................................................................... 4
4. Set up of the scales ................................................................................................... 4
5. Overview .................................................................................................................... 5
6. Key functions ............................................................................................................. 5
7. Display description ..................................................................................................... 6
7.1 Weight window (WEIGHT) ......................................................................................... 6
7.2 Unit weight window (UNIT WEIGHT) ......................................................................... 7
7.3 Count window (COUNT) ............................................................................................ 7
7.4 Battery status indicator .............................................................................................. 7
8. Operation ................................................................................................................... 8
8.1 Switching on the scale ............................................................................................... 8
8.2 Setting display to zero ................................................................................................ 8
8.3 Taring ........................................................................................................................ 8
8.4 Determine / enter reference weight ............................................................................ 9
8.5 Piece counting ..........................................................................................................10
8.6 Acoustic alarm ..........................................................................................................10
8.7 Totaliser ....................................................................................................................11
9. Backlight and parameter setting ................................................................................12
9.1 Backlight of the LCD display .....................................................................................12
9.2 Scale-specic parameters .........................................................................................12
10. Care, maintenance and guarantee ............................................................................14
10.1 Care and cleaning .....................................................................................................14
10.2 Error messages ........................................................................................................14
10.3 Storage and Transport Conditions ............................................................................14
10.4 Disposal ....................................................................................................................14
10.5 Garantie ....................................................................................................................15
11. Technical Data ..........................................................................................................16
12. Declaration of Conformity .........................................................................................17
HWZ- -Rev008- - 3 221128 UM en
1. Applications
This symbol means: "Follow the instructions for use". To achieve precise re-
sults, read the instruction manual carefully and follow the instructions it con-
tains. Keep the instructions for use for future reference.
The digital oers precise, fast and diverse counting and checkweighing and is HWZ series
intended for use in areas that are not regulated by law.
− Scales of HWZ series are represented by 3 models with capacities up to 30 kg.
− All models are equipped with weighing platforms made of stainless steel and with housings
made of ABS plastic.
− All scales have sealed keypads with colour-coded membrane switches and three large,
very easy- -read liquid crystal displays (LCD). The LCD display is equipped with a back-to
light that can be activated or deactivated.
− All scales have an auto zero function, an audible alarm for preset weights, an automatic
taring, a preset taring and a totaliser that allows to save and recall the number of pieces
as a total sum.
− Power is supplied via a 230 V mains connection and a 6 V 4 Ah rechargeable battery.
2. Warnings
The scale complies with the directives and standards for electrical equipment, electromagnetic
compatibility and the stipulated safety regulations. However, improper use may cause personal
injury and damage to property.
Read the operating manual carefully before putting the device into operation. This will prevent
damage to the device. Keep the operating manual in a safe place.
The following instructions must be observed for safe and trouble-free operation of the scale:
Protect the weighing platform from impacts and vibrations and do not over-
load the scale. Handle the scale with care when it is carried around and al-
ways keep in mind that it is a precision measuring instrument.
Do not expose the scale to high temperatures, whether from neighbouring
devices or direct sunlight. The liquid crystal display may suer damage.
Electronic scales must be protected from possible ingress of water. Use the
scale in a dry place. Clean the scale with a damp cloth. If water accidentally
penetrates the device, switch o the scale immediately and allow it to dry
well.
Never clean the scale with abrasive or aggressive cleaning agents. The
housing thereby loses its shiny surface and is more susceptible to dirt.
In this case, before connecting the supplied power cord to the scale, make
sure that the voltage on the nameplate matches the local power supply.
Connect the power cord to the local power supply.
Do not tamper with the scale! In case of problems, consult your competent
customer service representative.
Safe operation is no longer guaranteed
• if the power cord or the supply cable shows visible damages,
• after prolonged storage in humid areas.
In these cases, for your own safety, notify your service provider.
Attention: No other power cords than those supplied by the manufacturer may be used!
