Sida 1/35

CHRONOGRAPH TWO EYE OS11

TIME SETTING

1. Pull crown out to position 3.

2. Turn crown to set the desired time.

3. Return crown to position 1.

DATE SETTING

1. Pull crown out to position 2 (the watch continues to run).

2. Turn crown until yesterday’s date appears.

3. Pull crown out to position 3 (the watch stops).

4. Turn crown until correct date appears.

5. Continue to turn crown until correct time appears.

6. Return crown to position 1.

CHRONOGRAPH OPERATION

1. Press

A to start/stop the chronograph.

2. Press B for reset.

ADJUSTING THE CHRONOGRAPH

1. Pull crown to position 3.

2. Press

A to reset the second hand to “0.”

3. Press B to reset the chronograph minute hand.

4. Return crown to position 1.

ENGLISH

Minute hand

Chronograph

minute hand

Chronograph

second hand

Hour hand

Date

321

Second

hand

NOTE: If you do not find your watch movement here, please go to www.

adidas.com/watches.

321

CHRONOGRAPH OS62

SETTING THE TIME

1. Pull crown out to position 3, so that the second hand stops at the zero position.

2. Turn crown to set hour and minute hands.

3. When crown is pushed back to position 1, in synchronization with a time signal,

small second hand begins to run.

321

Hour Hand

Chrono Hour Hand

Chrono Second Hand

Minute Hand

Chrono Minute Hand

Date

1/20 Second Chrono Hand

CHRONOGRAPH STOPWATCH OS10 (no date - OS30)

(1 crown/2 pushers)

TIME SETTING

1. Pull crown out to position 3.

2. Turn crown to set the desired time.

3. Return crown to position 1.

DATE SETTING

1. Pull crown out to position 2.

2. Turn crown counter-clockwise until the correct date is shown in the date window.

3. Return crown to position 1.

CHRONOGRAPH OPERATION

1. Press

A to start/stop the chronograph.

2. Press B for reset.

ADJUSTING THE CHRONOGRAPH

1. Pull crown to position 3.

2. Press

A to reset the second hand to “0.”

3. Press B to reset the chronograph minute and hour hands.

4. Reset the watch to the current time and return crown to position 1.

321

Minute Hand

Hour Hand

Second Hand

SETTING THE DATE

1. Pull crown out to position 2.

2. Turn crown counter-clockwise to set the date.

NOTE: If the date is set between the hours of around 9:00 PM and 1:00 AM, the date

may not change on the following day.

3. After the date has been set, push crown back to position 1.

USING THE CHRONOGRAPH

This chronograph is able to measure and display time in 1/20(1/1) second united up

to maximum of 12 hours. The retrograde chronograph 1/20(1/1) second hand runs

continuously for 60 seconds after starting, and then stops at the zero position.

Measuring time with the chronograph

1. Press B to change the watch to chronograph mode. The second hand stops at zero,

and changes to the chronograph 1/20(1/1) second hand.

2. The chronograph can be started and stopped each time A is pressed. The

chronograph 1/20(1/1) second hand stops at zero, 60 seconds after starting. When

A is pressed to stop the chronograph, the chronograph 1/20(1/1) second hand

advances rapidly to display the measured time.

3. Pressing B resets the chronograph and all hands return to their zero positions.

NOTE: Moving of the retrograde chronograph is a demo. Actual measurement will be

shown when it is stopped / STOP button is pushed.

CHRONOGRAPH RESET (including after replacing battery)

This procedure should be performed when the chronograph second hand and

chronograph 1/20(1/1) second hand do not return to zero after the chronograph has

been reset, and including after the battery has been replaced.

1. Pull crown out to position 3.

2. Press A to set the chronograph second hand to zero.

3. Press B to set the chronograph 1/20 second hand to zero. The chronograph hands

can be advanced rapidly by continuously pressing A or B.

4. Once the hands have been set to zero, reset the time and return the crown to

position 1.

5. Press B to check that the chronograph hands are reset to zero.

NOTE: Do not return crown to position 1 while chronograph second hand and 1/20

chronograph second hand are returning to zero. Each hand stops on the way when

crown is returned to position 1, and these positions are recognized as zero positions.
