User Instructions

ADJ Products, LLC - www.adj.com - Galaxian 3D MKII Instruction Manual Page 2

Unpacking: Thank you for purchasing the Galaxian 3D MKII by ADJ

Products, LLC. Every Galaxian 3D MKII has been thoroughly tested

and has been shipped in perfect operating condition. Carefully check

the shipping carton for damage that may have occurred during ship-

ping. If the carton appears to be damaged, carefully inspect your x-

ture for any damage and be sure all equipment necessary to operate

the unit has arrived intact. In the event damage has been found or parts

are missing, please contact our toll free customer support number for

further instructions. Please do not return this unit to your dealer with-

out contacting customer support rst.

Introduction: The Galaxian 3D MKII is an incredible five channel

DMX intelligent, green and red laser fixture. The red and green laser

beams rotate back and forth creating amazing aerial effect on a ceiling

or wall. The Galaxian 3D MKII can operate as a stand alone fixture, or

in a Master/Slave configuration. Galaxian 3D MKII can be a sound The

active fixture or it can also be controlled via DMX This fixture is suit. -

able for theaters, studios, retail stores, and other similar locations. For

best results use fog or special effects smoke to enhance the beams

projections.

Customer Support: ADJ Products, LLC provides a toll free cus-

tomer support line, to provide set up help and to answer any question

should you encounter problems during your set up or initial operation.

You may also visit us on the web at www.adj.com for any comments

or suggestions. For service related issue please contact ADJ Products,

LLC. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.

Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

ADJ customer support.

PLEASE recycle the shipping carton whenever possible.

Galaxian 3D MKII General Introduction

3/13

GALAXIAN 3D MKII

ADJ Products, LLC - www.adj.com - Galaxian 3D MKII Instruction Manual Page 4ADJ Products, LLC - www.adj.com - Galaxian 3D MKII Instruction Manual Page 3

Please carefully read and understand the instructions in this manual

thoroughly before attempting to operate this unit. These instructions

contain important safety information regarding the use and mainte-

nance of this unit. Please keep this manual with the unit, for future

reference.

CAUTION IMPORTANT! When installing this projector, make sure

that it is mounted in a manner that prevents the audience from

looking directly into the beam, and the beam from striking the

audience.

Galaxian 3D MKII General Instructions Galaxian 3D MKII Safety Precautions

Safety Issues: This unit may “pop” the fuse if the maximum allotted

load of 7 amps is reached.

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture.

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to remove or break o the ground prong from the

electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short. Do not attempt to oper-

ate this unit if the power cord has been frayed or broken.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power cords should be routed so they are not likely to be walked

on, pinched by items placed upon or against them.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 18 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances

(including amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.

D. The unit does not appear to operate normally or exhibits a

marked change in performance.

• 30mW Green Laser & 80mW Red Laser

• 5 Channel DMX Control

• 2 Operating Modes - Sound Active & DMX Control

• Fan Cooled

• Digital Display for Address and Function Setting

• UC3 Controller (Not Included)

• Power Cord Daisy Chain up to 14 units max. See page 16

Galaxian 3D MKII Features

Galaxian 3D MKII Warranty Registration

The G Please alaxian 3D MKII carries a 90 day limited warranty. fill out

the enclosed warranty card to validate your purchase. All returned

service items whether under warranty or not, must be freight pre-

paid and accompany a return authorization (R.A.) number. If the unit

is under warranty you must provide a copy of your proof of purchase

invoice. Please contact ADJ customer support for a R.A. number.

! !

The unit should be mounted using a mounting clamp (not provided),

axing it to the mounting bracket that is provided with the unit.

Always ensure that the unit is rmly xed to avoid vibration and slip-

ping while operating. Always ensure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10

times the unit’s weight. Also, always use a safety cable that can hold

12 times the weight of the unit when installing the xture.

The equipment must be installed by a professional, and it must be

installed in a place where it is out of the reach of people’s grasp.

Galaxian 3D MKII Installation

DANGER

VISIBLE LASER RADIATION

-AVOID DIRECT EYE EXPOSURE

LASER DIODE

WAVELENGTH : 635~650 nm

Max Output : <4.9mW

Class IIIa Laser Product

ADJ Products, LLC - www.adj.com - Galaxian 3D MKII Instruction Manual Page 5 ADJ Products, LLC - www.adj.com - Galaxian 3D MKII Instruction Manual Page 6

Galaxian 3D MKII Laser Warnings and Safety

NON-INTERLOCKED HOUSING WARNING

The Galaxian 3D MKII contains high power laser devices internally.

Do not open the laser housing, due to the potential exposure to

unsafe levels of laser radiation. The laser power levels, if the unit is

opened, can cause instant blindness, skin burns and res.

STOP AND READ ALL LASER SAFETY DATA

OPERATION INSTRUCTIONS AND LASER SAFETY

The light source emitted from this product can potentially cause eye

injury if not set up and used properly. The light source emitted from a

laser is very dierent from any other light sources with which you may

be aware of. Laser light is thousands of times more concentrated

than any light from any other kind of light source. This concentration

of light can cause instant eye injuries, primarily by burning the retina

(the back of your eyeball contatining cells that are sensitive to light).

Even if you cannot feel “heat” from a laser beam, it can still poten-

tially injure or blind you or your audience. Even very small amounts

of laser beam light are potentially hazardous even at long distances.

Laser eye injuries can be sustained faster than you can blink.

Do not think that because this laser splits the laser beam into hun-

dreds of beams and that the laser beam is scanned out in high

speed, that an individual laser beam is safe for eye exposure. This

laser uses dozens of milliwatts of laser power (Class 3B levels inter-

nally) before it splits into multiple beams (Class 3R levels). Many of

the individual beams are potentially hazardous to the eyes.

Do not that because the laser light is moving, it is safe. This is not

true. Nor, do the laser beams always move. Since eye injuries can

occur instantly, it is critical to prevent even the smallest possibility of

any direct eye exposure. In the laser safety regulation, it is not legal

to aim Class 3R lasers in areas which people can get exposed. This

is true even if it is aimed below people’s faces, such as on a dance

oor.

Do not operate the laser without rst reading and understanding

all safety and technical data in this manual.

Always set up and install all laser eects so that all laser light is at

least 3 meters (9.8 feet) above the oor on which people can stand.

After setting up, and before public use, test laser to ensure proper

function. Do not use if any defect is detected. Do not use if laser

emits only one or two laser beams rather than dozens/hundreds, as

this could indicate damage to the diraction grating optic, and could

allow emission of higher laser levels above Class 3R.

Do not point lasers at people or animals. Never look into the laser

aperture or laser beams.

Do not point lasers in areas in which people can potentially get

exposed, such as uncontrolled balconies, etc.

Do not point lasers at highly reective surfaces, such as windows,

mirrors and shiny metal. Even laser reections can be hazardous.

Never point a laser at aircraft, this is a federal oense.

Never point un-terminated laser beams into the sky.

Do not expose the output optic (aperture) to cleaning chemicals.

Do not use laser if the laser appears to be emitting only one or two

beams.

Do not use the laser if the housing is damaged, the housing is open,

or if the optics appear damaged in any way.

Never open the laser housing. The high laser power levels inside of

the protective housing can start res, burn skin and will cause instant

eye injury.

Never leave this device running unattended.

The operation of a class 3R laser show is only allowed if the show

is controlled by a skilled and well- trained operator, familiar with the

data included in this manual.

The legal requirements for using laser entertainment products vary

from country to country. The user is responsible for the legal require-

ments at the location/country of use.

Always use proper lighting safety cables when hanging lights and

eects overhead.

Galaxian 3D MKII Laser Warnings and Safety

Produktspecifikationer

Varumärke:	Adj
Kategori:	Inte kategoriserad
Modell:	Galaxian 3D MKII

Behöver du hjälp?

Om du behöver hjälp med Adj Galaxian 3D MKII ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Inte kategoriserad Adj Manualer

Adj PIXIE DRIVER 2000 V3 Bruksanvisning

24 September 2024

Adj Jolt Panel FX2 Bruksanvisning

23 September 2024

Adj Wifi Net 2 Bruksanvisning

23 September 2024

Adj Par Z100 3K2 Bruksanvisning

23 September 2024

Adj H2O Two Bruksanvisning

23 September 2024

Adj Jolt Panel FXIP Bruksanvisning

23 September 2024

Adj Pixie Curve 60 Bruksanvisning

23 September 2024

Adj ElectraPix Par 7 Bruksanvisning

23 September 2024

Adj RDM XS8 Bruksanvisning

23 September 2024

Adj Jolt Bar FXIP Bruksanvisning

20 September 2024

Inte kategoriserad Manualer

Nyaste Inte kategoriserad Manualer

Philips 43PUL7672 Bruksanvisning

27 Oktober 2024

Manhattan 461504 Bruksanvisning

27 Oktober 2024

Sungrow SG125HV Bruksanvisning

27 Oktober 2024

Schneider CCT724319 Bruksanvisning

27 Oktober 2024

Technoline WS 250 Bruksanvisning

27 Oktober 2024

Livarno IAN 354423 Bruksanvisning

27 Oktober 2024

Kupper 12152 Bruksanvisning

27 Oktober 2024

JennAir CARBON24L Bruksanvisning

27 Oktober 2024

Medion Life E74001 (MD 81035) Bruksanvisning

27 Oktober 2024

POLARIS Sportsman Touring 850 SP (2015) Bruksanvisning

27 Oktober 2024
