Sida 1/6

www.agneovo.com

The X-Series durable displays are designed for reliable 24/7 operation in the demanding environments. With

the selectable gamma curves and versatile connectivity, the enhanced X-Series provides an optimal visual

experience with excellent colour, brightness, and contrast ratio. NeoV™ Optical Glass and metal casing

shield it from scratches and other damages which make it ideal for public, retail, laboratory, and industrial

applications.

X-Series LED-backlit Display 15” | 17” | 19” | 22” | 24”

Versatility Beyond Limitations

X-22E / X-24E X-15E / X-17E / X-19E

www.agneovo.com

Enhanced Gamma Selection

Selectable gamma curves visually optimise dierent

kinds of images. e AG Neovo specialised image settings

enhance colour, brightness, sharpness and contrast ratio,

allowing the X-Series to improve the light, shadows and

colour balance of videos.

Versatility, Productivity and Compatibility

Visualize critical data and engage with multiple video

sources and PC applications with versatile connectivity

options, including DisplayPort and HDMI, and PiP/PbP to

increase productivity and eciency. Selectable aspect ratio

and zoom functions provide compatibility with dierent

video sources.

High Reliability

Designed for 24/7 operation, these durable metal-housed

displays protected with NeoV™ Optical Glass take

advantage of superior components to ensure a long product

lifetime.

Features

• LED-backlit technology with 1920 x 1080 / 1280 x 1024 / 1024 x 768

resolutions

• VA panel technology ensures accurate colours and oers high contrast ratios

with wide viewing angles (15” only)

• Anti-Burn-in

TM technology prevents image ghosting

• NeoVTM Optical Glass and metal housing for excellent cleanability and

protection

• Crisp 20,000,000 dynamic contrast ratio

• PiP/PbP functions enable multi-source viewing simultaneously

• Image enhancer: Deinterlace / Noise Reduction

• Versatile connectivity: DisplayPort, HDMI, DVI, VGA

• Front-sided IP22 Compliant (IEC 60529 Standard) (17”, 19”, 22” and

24” only)

• EcoSmart Sensor automatically adjusts brightness level according to

ambient lighting conditions

• Flicker-free display technology reduces eye discomfort

• Built-in speakers

• Selectable gamma curves optimise dierent kinds of images

• Lockable control keys to prevent tampering in public environments

• Designed and developed for continous 24/7 operation

• Premium-grade panel for high reliability and long product lifetime

• Available also in white

Others AG Neovo X-Series

www.agneovo.com

Specifications X-15E X-17E X-19E

Panel Type LED-Backlit TFT LCD (VA Technology) LED-Backlit TFT LCD (TN Technology) LED-Backlit TFT LCD (TN Technology)

Panel Size 15.0" 17.0" 19.0"

Max. Resolution XGA 1024 x 768 SXGA 1280 x 1024 SXGA 1280 x 1024

Pixel Pitch 0.297 mm 0.264 mm 0.294 mm

Brightness 300 cd/m² 250 cd/m² 250 cd/m²

Contrast Ratio 20,000,000:1 (DCR) 20,000,000:1 (DCR) 20,000,000:1 (DCR)

Viewing Angle (H/V) 176°/176° 170°/160° 170°/160°

Display Colour 16.2M 16.7M 16.7M

Response Time 5 ms 3 ms 3 ms

Frequency (H) 24 kHz-83 kHz 24 kHz-83 kHz 24 kHz-83 kHz

Frequency (V) 50 Hz-75 Hz 50 Hz-75 Hz 50 Hz-75 Hz

DisplayPort x 1 x 1 x 1

HDMI 1.4 x 1 1.4 x 1 1.4 x 1

DVI 24-Pin DVI-D 24-Pin DVI-D 24-Pin DVI-D

VGA 15-Pin D-Sub x 1 15-Pin D-Sub x 1 15-Pin D-Sub x 1

Audio In Stereo Audio Jack (3.5 mm) Stereo Audio Jack (3.5 mm) Stereo Audio Jack (3.5 mm)

Internal Speakers 2W x 2 2W x 2 2W x 2

Power Requirements DC 12V, 1.49A DC 12V, 1.58A DC 12V, 1.72A

On Mode 11W (On) 13W (On) 14W (On)

Standby Mode < 0.5W < 0.5W < 0.5W

Off Mode < 0.3W < 0.3W < 0.3W

Power Supply External External External

Thickness 3.0 mm (0.12") 3.0 mm (0.12") 3.0 mm (0.12")

Reflection Rate < 1% < 1% < 1%

Transmission Rate

Hardness

> 97%

> 9H

> 97%

> 9H

> 97%

> 9H

Temperature 0°C-40°C (32°F-104°F) 0°C-40°C (32°F-104°F) 0°C-40°C (32°F-104°F)

Humidity 10%-90% (non-condensing) 10%-90% (non-condensing) 10%-90% (non-condensing)

Temperature -20°C-60°C (-4°F-140°F) -20°C-60°C (-4°F-140°F) -20°C-60°C (-4°F-140°F)

Humidity 5%-95% (non-condensing) 5%-95% (non-condensing) 5%-95% (non-condensing)

VESA FPMPMI Yes (100 x 100 mm & 75 x 75 mm) Yes (100 x 100 mm & 75 x 75 mm) Yes (100 x 100 mm & 75 x 75 mm)

Tilt 0° to 20° 0° to 22° 0° to 22°

Kensington Security Slot Yes Yes Yes

Product with Base (W x H x D) 380.0 x 359.0 x 155.0 mm (15.0" x 14.1" x 6.1") 409.4 x 398.2 x 175.0 mm (16.1" x 15.7" x 6.9") 445.4 x 420.2 x 175.0 mm (17.5" x 16.5" x 6.9")

Product w/o Base (W x H x D) 380.0 x 315.0 x 53.5 mm (15.0" x 14.1" x 2.1") 409.4 x 361.9 x 64.5 mm (16.1" x 15.7" x 2.5") 445.4 x 383.9 x 64.5 mm (17.5" x 15.1" x 2.5")

Packaging (W x H x D) 470.0 x 460.0 x 199.0 mm (18.5" x 18.1" x 7.8") 506.0 x 506.0 x 225.0 mm (19.9" x 19.9" x 8.9") 552.0 x 526.0 x 225.0 mm (21.7" x 20.7" x 8.9")

Product w/o Base 4.2 kg (9.3 lb) 5.2 kg (11.5 lb) 6.0 kg (13.2 lb)

Product with Base 4.6 kg (10.1 lb) 6.0 kg (13.2 lb) 6.8 kg (15.0 lb)

Packaging 5.8 kg (12.8 lb) 7.5 kg (16.5 lb)

Supplied Power Adaptor, Power Cord, VGA Cable, Audio Cable,

Quick Start Guide, Warranty Card

Power Adaptor, Power Cord, VGA Cable, Audio Cable,

Quick Start Guide, Warranty Card

Power Adaptor, Power Cord, VGA Cable, Audio Cable,

Quick Start Guide, Warranty Card

Ceiling Mount (Landscape only) CMP-01+WMK-03 CMP-01+WMK-03 CMP-01+WMK-03

Wall Mount (Landscape only) WMA-01, WMK-01, WMK-03, PMK-01 WMA-01, WMK-01, WMK-03, PMK-01 WMA-01, WMK-01

Desk mount (Landscape only) DMC-01, DMC-02D, DMS-01D, DMS-01Q, ES-02 DMC-01, DMC-02D, DMS-01D, DMS-01Q, ES-02 DMC-01, DMC-02D, DMS-01D, DMS-01Q, ES-02

Glass

Panel

Frequency

Signal Input

Audio

Power

Weight

Regulation Approval

Accessories

Optional Accessories

Operating Conditions

Storage Conditions
