Quick Setup Guide
Declaration of Conformity
We, Manufacturer/Importer
Declare that the product
SOHO Live Series Switch
Live-5E, Live-8E, Live-16E, Live-5GT, Live-8GT
is in conformity with
In accordance with 2014/30/EU and 2014/35/EU Directive
Clause
Manufacturer/Importer
AirLive Technology Corporation
4F, No.132, Lane 235, Baoqian Rd., Xindian Dist.,
New Taipei City 23145, Taiwan
CE marking
Name : A van Rossem Position/ Title : Product Manager
Date : October 2023Place : Taiwan
AirLive Technology Co ion drporat eclares tha hi evt t s d ice
is in compliance with the ntesse ial require tsmen and
oth l ter re evan provis sion of i / direct ve 2014 30/EU, 2014/35/EU
EN IEC 61000-3-2:2019+A1:2021
EN 55032:2015+A11:2020
EN 55035:2017+A11:2020
EN 61000-3-3:2013+A2:2021+AC:2022-01
(EMC)
EN IEC 62368-1:2020/A11:2020
(LVD)
Conformity with
In accordance with RoHS Directive 2011/65/EU Annex II amending
Annex (EU)2015/863 and amending Annex (EU)2017/2102
Live-5E, Live-8E, Live-16E
Live Ethernet Switch
10/100Mbps
Live-5E, Live-8E, Live-16E
Live Ethernet Switch
10/100Mbps
EN LED DEF INIT NSIO
Power
Link/Act
Green ON
Green OFF
Green ON
Power is on and normal.
The switch is not receiving power.
Link connected.
Green OFF Link disconnect
Installation Step:
1. Remove the switch and accessories from the package.
2. Connect power to the switch. Make sure that “Power” LED is on.
3. Check the Port LED indicator status. When a device is connected
the port will light up.
4. For more product information visit www.airlive.com.
Installation Steps
Figure A
8x 10/100Mbps RJ45
5x 10/100Mbps RJ45
16x 10/100Mbps RJ45
Power
Power
Live-5E
Live-8E
Live-16E
Quick Setup Guide
Declaration of Conformity
We, Manufacturer/Importer
Declare that the product
SOHO Live Series Switch
Live-5E, Live-8E, Live-16E, Live-5GT, Live-8GT
is in conformity with
In accordance with 2014/30/EU and 2014/35/EU Directive
Clause
Manufacturer/Importer
AirLive Technology Corporation
4F, No.132, Lane 235, Baoqian Rd., Xindian Dist.,
New Taipei City 23145, Taiwan
CE marking
Name : A van Rossem Position/ Title : Product Manager
Date : October 2023Place : Taiwan
AirLive Technology Co ion drporat eclares tha hi evt t s d ice
is in compliance with the ntesse ial require tsmen and
oth l ter re evan provis sion of i / direct ve 2014 30/EU, 2014/35/EU
EN IEC 61000-3-2:2019+A1:2021
EN 55032:2015+A11:2020
EN 55035:2017+A11:2020
EN 61000-3-3:2013+A2:2021+AC:2022-01
(EMC)
EN IEC 62368-1:2020/A11:2020
(LVD)
Conformity with
In accordance with RoHS Directive 2011/65/EU Annex II amending
Annex (EU)2015/863 and amending Annex (EU)2017/2102
Live-5GT, Live-8GT
Live Gigabit Switch
10/100/1000Mbps
Live-5GT, Live-8GT
LED DEF INIT NSIO
Power
Link/Act
Green ON
Green OFF
Green ON
Power is on and normal.
The switch is not receiving power.
Link connected.
Green OFF Link disconnect
Installation Step:
1. Remove the switch and accessories from the package.
2. Connect power to the switch. Make sure that “Power” LED is on.
3. Check the Port LED indicator status. When a device is connected
the port will light up.
4. For more product information visit www.airlive.com.
Installation Steps
Figure A
8x 10/100/1000Mbps RJ45
5x 10/100/1000Mbps RJ45
Power
Live-5GT
Live-8GT
EN
Live gigabit Switch
10/100/1000Mbps
