Sida 1/16
www.aja.com
Installation and Operation
Guide
B e c a u s e i t m a t t e r s .
RD10MD2
Dual HD to SD
Down Converter
R-series Card Module
Published: 6/30/10
2
Trademarks
AJA
®
, KONA
®
, Ki Pro®, and XENA
®
are registered trademarks of AJA Video, Inc. FiDO™, Io HD
™
and Io
™
are trademarks of AJA Video, Inc. HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC. DVI is a registered trademark of DDWG.
All other trademarks are the property of their respective holders.
Notice
Copyright © 2010 AJA Video, Inc. All rights reserved. All information in this manual is subject to
change without notice. No part of the document may be reproduced or transmitted in any form, or by
any means, electronic or mechanical, including photocopying or recording, without the express
written permission of AJA Inc.
Contacting Support
To contact AJA Video for sales or support, use any of the following methods:
180 Litton Drive, Grass Valley, CA. 95945 USA
Telephone: 800.251.4224 or 530.274.2048
Fax: 530.274.9442
Web: http://www.aja.com
Support Email: support@aja.com
Sales Email: sales@aja.com
When calling for support, have all information at hand prior to calling.
Limited Warranty
AJA Video warrants that this product will be free from defects in materials and workmanship for a
period of five years from the date of purchase. If a product proves to be defective during this warranty
period, AJA Video, at its option, will either repair the defective product without charge for parts and
labor, or will provide a replacement in exchange for the defective product.
In order to obtain service under this warranty, you the Customer, must notify AJA Video of the defect
before the expiration of the warranty period and make suitable arrangements for the performance of
service. The Customer shall be responsible for packaging and shipping the defective product to a
designated service center nominated by AJA Video, with shipping charges prepaid. AJA Video shall
pay for the return of the product to the Customer if the shipment is to a location within the country in
which the AJA Video service center is located. Customer shall be responsible for paying all shipping
charges, insurance, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or
inadequate maintenance and care. AJA Video shall not be obligated to furnish service under this
warranty a) to repair damage resulting from attempts by personnel other than AJA Video
representatives to install, repair or service the product, b) to repair damage resulting from improper
use or connection to incompatible equipment, c) to repair any damage or malfunction caused by the
use of non-AJA Video parts or supplies, or d) to service a product that has been modified or integrated
with other products when the effect of such a modification or integration increases the time or
difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY AJA VIDEO IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED.
AJA VIDEO AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. AJA VIDEO’S RESPONSIBILITY TO REPAIR OR REPLACE
DEFECTIVE PRODUCTS IS THE WHOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR
ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER AJA
VIDEO OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
1
3
AJA RH10MD2 Dual HD Down Converter User Manual
Introduction
The RD10MD2 is a 10-bit broadcast-quality Dual channel HD down converter.
Channels 1 and 2 are fully independent. Channel 1 has 1 re-clocked HD/SD-SDI
outputs and channel 2 also has 1 re-clocked HD/SD-SDI output. Both Channel 1
and 2 have 2 down converted outputs, which can be independently configured
as SDI or composite analog. All HD formats are supported including 24p/psf
with 3:2 pulldown. The SD output can be formatted for either 4:3 or 16:9
monitors. For 4:3 monitors both Letterbox and Crop modes are supported. The
RD10MD2 is dual-rate (HD/SD) and supports SDI inputs.
The RD10MD2 is compatible with AJA’s FR1 or FR2 frames.
Features
RD10MD2 Card Module, Side View
•
Dual Independent Channel HD to SD Down Conversion
•
Re-clocking HD-SDI/SDI input loop outputs
•
Multi-Standard HD-SDI or SDI Input
•
SDI and Composite Analog Outputs
•
3/2 Pulldown for 23.98/24 Hz P/PSF inputs
•
Full 10-bit Data Path, Multi-point Interpolation
•
Configurable for 16:9 or 4:3 Monitors
•
Letterbox and Crop Modes
•
4:3 Safe-Zone Graticule
•
Pedestal on Composite Analog Outputs
