Sida 1/8

APX1000

QUICKSTART GUIDE

ENGLISH

Do NOT make any connections

when any device is powered on.

Note: Please see the SPEAKER

CONNECTION section for important

setu

information.

QUICKSTART GUIDE (ENGLISH)

BOX CONTENTS

APX1000

Power cable

Quickstart Guide

Safety & Warranty Information Booklet

QUICK SETUP

1. Make sure all items listed in the BOX CONTENTS section are included in the box.

2. READ SAFETY & WARRANTY INFORMATION BOOKLET BEFORE USING THE PRODUCT.

3. Study the connection diagram in this guide.

4. Place all devices in an appropriate position for operation.

5. Make sure all devices are turned off and all faders and gain knobs are set to "zero."

6. Connect all sound sources' outputs to amplifier inputs as indicated in the diagram.

7. Connect the amplifier outputs to speakers.

8. Plug all devices into an appropriate power source.

9. Switch everything on in the following order:

• Sound sources (i.e. microphones, turntables, CD players, etc.)

• Mixer

• Ampliﬁer

• Speakers

10. When turning powering down, turn everything off in the following order:

• Speakers

• Ampliﬁer

• Mixer

• Sound sources

CONNECTION DIAGRAM

PUS H PUSH

How do I know if my 1/4" cables

are balanced?

BALANCED

UNBALANCED

REAR PANEL DIAGRAM

PUSH P USH

45 5

1. COOLING FAN- This fan secures cooling for the amplifier. The airflow is from front to rear. The fan speed is

electronically regulated depending on the temperature of the power devices. Do not block these fan grills or

mount the amplifier in an enclosed rack, which could cause the amplifier to overheat.

2. LOW PASS FILTER – This switch activates the built-in low cut filter. All audio below 30 Hz will be removed

from the output signal.

3. BALANCED COMBO INPUTS – Connect your mixer to the balanced

XLR or balanced 1/4" input for that channel.

4. OUTPUT MODE SWITCH – The APX 1000 presents three operating

modes:

Stereo Mode

In this mode, CH 1 and CH 2 operate independently (as a normal

stereo amplifier) The CH 1 input signal will be output from the CH 1 output connector, and CH 2 input

signal will be output from the CH 2 output

connector.

Parallel Mono Mode

In this mode, CH 1 input signal will be output from

the output connectors of both

channels.

Bridged Mode

In this mode, CH 1 input signal will be output from

the bridge-mono output connector.

5. CHANNEL OUTPUTS – Connect your speakers' input

jacks to these outputs.

• For the binding posts, red is the positive signal

and black is the negative signal. Please make

sure to respect the speaker polarity when using binding post. Turn off the unit before connecting an

audio signal to the binding post to avoid any electric shock!

• The SPEAKON outputs are specifically designed to connect to high power speakers. The correct polarity

is secured automatically. They prevent shock hazard and they lock-in securely. Please see the

SPEAKER CONNECTION section to properly and safely connect your speakers.

6. POWER IN – Connect the cable to a standard wall outlet. Be sure the supplied voltage matches the required

voltage of the amplifier. Do not connect the amplifier to an outlet that does not match the required voltage;

doing so could damage the amplifier.

WARNING!: Do not adjust the

STEREO/MONO BRIDGE SWITCH when the

amplifier is on.

WARNING!: Do not allow any wires of

adjacent terminals to come in contact with

each other. Also, do not connect either

positive (red) output to chassis ground.
