Unpacking: Thank you for purchasing the Mister Kool by American

DJ . Every unit has been thoroughly tested and has been shipped in ®

perfect operating condition. Carefully check the shipping carton for

damage that may have occurred during shipping. If the carton appears

to be damaged, carefully inspect your xture for any damage and be

sure all equipment necessary to operate the unit has arrived intact. In

the event damage has been found or parts are missing, please contact

our toll free customer support number for further instructions. Do not

return this unit to your dealer without rst contacting customer sup-

port.

Introduction: This unit is designed to produce a ground fog effect to

enhance dance floors, entry ways, and for halloween effects. Included

with this unit is a timer remote control. Please read the following

instructions and safety precautions before attempting any installation

or using your new Mister Kool.™

Customer Support: American DJ provides a toll free customer sup-®

port line, to provide set up help and to answer any question should

you encounter problems during your set up or initial operation. You

may also visit us on the web at www.americandj.com for any com-

ments or suggestions. For service related issue please contact Ameri-

can DJ . Service Hours are Monday through Friday 9:00 a.m. to 5:00 ®

p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ.

Please recycle the shipping cartoon whenever possible.

Mister Kool™ Introduction

User Instructions

4295 Charter Street

Los Angeles Ca. 90058

www.americandj.com

Revised 5/07

Caution: Fog Machines may set off Smoke Alarms!

Mister Kool™ Safety Precautions

Mister Kool™ Set-Up

1. Open the shipping carton and carefully remove the unit from the

shipping carton.

2. Be sure to remove all the packing material especially around the

nozzle.

3. Set the machine on a flat dry surface and unscrew the knob on

the top of the unit. Open the top of the unit, and fill the inside of

the Mister Kool with ice.

4. Remove the reservoir cap located on the top of the machine.

5. Fill the Mister Kool reservoir with American DJ brand fog juice

only and replace the cap.

6. Insert the water tube into the water bag. When the ice melts, the

water will empty into the bag.

7. Remove the remote control from the carton. Firmly attach the

remote control to the remote control socket located on the rear

unit.

8. Plug the unit in to a matching power supply and flip the power

switch to the on position.

9. Follow the operating instructions on the next page for proper

operation.

The Mister Kool™ carries a one year (365 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase.

All returned service items whether under warranty or not, must be

freight pre-paid and accompany a return authorization (R.A.) num-

ber. The R.A. number must be clearly written on the outside of the

return package. A brief description of the problem as well as the R.A.

number must also be written down on a piece of paper included in

the shipping carton. If the unit is under warranty, you must provide a

copy of your proof of purchase invoice. You may obtain a R.A. num-

ber by contacting our customer support team on our toll free custom-

er support number. All packages returned to the service department

not displaying a R.A. number on the outside of the package will be

returned to the shipper.

Mister Kool™ Warranty Registration

• Be sure to save the packing carton in the unlikely event the unit

may have to be returned for service

• Do not spill water or other liquids into or on to your fogger. Be

sure that all the fog uid is kept inside the uid reservoir

• Be sure that the local power outlet match that or the required

voltage for your fog machine

• Do not remove the top cover under any conditions. There are no

user serviceable parts inside

• Disconnect the unit’s main power when left unused for long peri-

ods of time

• Never connect this unit to a dimmer pack

• Do not attempt to operate this unit, if it becomes damaged in anyway

• Never operate this unit when it’s cover is removed

• To reduce the risk of electrical shock or re, do not expose this

unit rain or moisture

• Do not attempt to operate this unit if the power cord has been fray-

ed or broken. Do not attempt to remove or break off the ground

prong from the electrical cord. This prong is used to reduce the

risk of electrical shock and re in case of an internal short

• Disconnect from main power before making any type of connection

• Never block the ventilation holes. Always be sure to mount this

unit in an area that will allow proper ventilation. Allow about 6”

(15cm) between this device and a wall

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties

• Always mount this unit in a safe and stable matter

• Please route your power cord out of the way of foot trafc. Power

cords should be routed so they are not likely to be walked on,

pinched by items placed upon or against them

• The unit should only be serviced by qualified service personnel

when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.

D. The appliance does not appear to operate normally or

exhibits a marked change in performance.

Always be sure to maintain an adequate supply of American DJ ®

Brand Fog juice™ in the fluid reservoir. Running the fog machine

dry will cause pump failure and or clogging. This is the largest

cause of failure in fog and fog machines.

Mister Kool™ Trouble Shooting

If you experience low fog output, pump noise, or no fog output at all,

disconnect and discontinue use immediately. Do not continue push-

ing the remote control’s activation button as this may damage the

Mister Kool. Check fluid level, the external fuse or breaker, remote

connection, and be sure the wall outlet is sending power. If all of the

above appear to be okay, and the unit fails to operate correctly, the

unit may require service. Please contact customer support for further

instructions. Please do not return the unit to your dealer without con-

tacting customer support first.

This unit has a 5 minute warm up time. After the unit is warmed

up follow the directions below for ground fogger operation.

Remote Operation: The remote allows the unit to run automatically

or by timer. The remote has a “on/off” button, that must be turned on

to operate the unit. A red LED above the on/off button will glow when

the remote is activated.

Manual: The remote has a green button, this button allows opera-

tion to be controlled manually. Fog will emit as long as this button is

pushed, a green LED above this button will glow when the manual

function is activate.

Timer: The timer function allows fog to be emitted at designated

intervals. To activate the timer function press the yellow timer but-

ton. A yellow LED will glow when the timer function is activated. The

“duration” knob will control the length of fog burst. The “interval”

knob will control the time between burst. Turning these knobs in a

clockwise direction will increase there values, turning them in a coun-

ter-clockwise direction will decrease their values.

Mister Kool™ Operating Instructions

1 YEAR LIMITED WARRANTY

A. American DJ hereby warrants, to the original purchaser, American DJ products to be ® ®

free of manufacturing defects in material and workmanship for a period of one year (365

days) from the date of purchase. This warranty shall be valid only if the product is pur-

chased within the United States of America, including possessions and territories. It is the

owner’s responsibility to establish the date and place of purchase by acceptable evidence,

at the time service is sought.

B. For warranty service, send the product only to the American DJ factory. All shipping ®

charges must be pre-paid. If the requested repairs or service (including parts replacement)

are within the terms of this warranty, American DJ will pay return shipping charges only ®

to a designated point within the United States. If the entire instrument is sent, it must be

shipped in its original package. No accessories should be shipped with the product. If any

accessories are shipped with the product, American DJ shall have no liability whatsoever ®

for loss of or damage to any such accessories, nor for the safe return thereof.

C. This warranty is void if the serial number has been altered or removed; if the product is

modied in any manner which American DJ® concludes, after inspection, affects the reli-

ability of the product; if the product has been repaired or serviced by anyone other than

the American DJ factory unless prior written authorization was issued to purchaser by ®

American DJ ; if the product is damaged because not properly maintained as set forth in ®

the instruction manual.

D. This is not a service contract, and this warranty does not include maintenance, cleaning

or periodic check-up. During the period specied above, American DJ® will replace defec-

tive parts at its expense, and will absorb all expenses for warranty service and repair labor

by reason of defects in material or workmanship. The sole responsibility of American DJ ®

under this warranty shall be limited to the repair of the product, or replacement thereof,

including parts, at the sole discretion of American DJ . All products covered by this war-®

ranty were manufactured after January 1, 1990, and bear identifying marks to that effect.

E. American DJ reserves the right to make changes in design and/or improvements upon ®

its products without any obligation to include these changes in any products theretofore

manufactured.

F. No warranty, whether expressed or implied, is given or made with respect to any acces-

sory supplied with products described above. Except to the extent prohibited by applicable

law, all implied warranties made by American DJ in connection with this product, includ-®

ing warranties of merchantability or tness, are limited in duration to the warranty period

set forth above. And no warranties, whether expressed or implied, including warranties of

merchantability or tness, shall apply to this product after said period has expired. The

consumer’s and or Dealer’s sole remedy shall be such repair or replacement as is expressly

provided above; and under no circumstances shall American DJ be liable for any loss or ®

damage, direct or consequential, arising out of the use of, or inability to use, this product.

G. This warranty is the only written warranty applicable to American DJ Products and ®

supersedes all prior warranties and written descriptions of warranty terms and conditions

heretofore published.

H. Lamps are not covered under this warranty.

Mister Kool™ Warranty

Produktspecifikationer

Varumärke:	American DJ
Kategori:	Effektmaskin
Modell:	Mister Kool

Behöver du hjälp?

Om du behöver hjälp med American DJ Mister Kool ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Effektmaskin American DJ Manualer

American DJ Entour Venue Bruksanvisning

24 September 2024

American DJ H2O DMX IR Bruksanvisning

24 Augusti 2024

American DJ Mega QA Go Bruksanvisning

21 Augusti 2024

American DJ Entour Cyclone Bruksanvisning

19 Augusti 2024

American DJ Mega Bar 50 RGB RC Bruksanvisning

16 Augusti 2024

American DJ PinPoint Gobo Bruksanvisning

11 Augusti 2024

American DJ Mister Kool Bruksanvisning

8 Augusti 2024

American DJ Mini Dekker Bruksanvisning

3 Augusti 2024

American DJ Fog Storm 1200 Bruksanvisning

30 Juli 2024

American DJ Focus Spot 2X Bruksanvisning

28 Juli 2024

Effektmaskin Manualer

Nyaste Effektmaskin Manualer

BeamZ PS6W 151.262 Bruksanvisning

18 Oktober 2024

Velleman vdl660rl Bruksanvisning

10 Oktober 2024

BeamZ SparkleWall 151.201 Bruksanvisning

8 Oktober 2024

Elation Sixbar 1000 IP Bruksanvisning

6 Oktober 2024

Laserworld GS-100RGB Bruksanvisning

3 Oktober 2024

Valueline VLLINKLED10 Bruksanvisning

2 Oktober 2024

BeamZ LUCID 1.2 150.462 Bruksanvisning

2 Oktober 2024

Behringer V-verb Pro REV2496 Bruksanvisning

2 Oktober 2024

BeamZ Mini 153.325 Bruksanvisning

30 September 2024

BeamZ BPP200 151.231 Bruksanvisning

29 September 2024
