User Instructions

4/16

specications, diagrams, images, and instructions herein are

subject to change without notice. ADJ Products, LLC logo and

identifying product names and numbers herein are trademarks

of ADJ Products, LLC. Copyright protection claimed includes all

forms and matters of copyrightable materials and information

now allowed by statutory or judicial law or hereinafter granted.

Product names used in this document may be trademarks or

registered trademarks of their respective companies and are

hereby acknowledged. All non-ADJ Products, LLC brands and

product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis-

claim any and all liabilities for property, equipment, building, and

electrical damages, injuries to any persons, and direct or indi-

rect economic loss associated with the use or reliance of any

information contained within this document, and/or as a result

of the improper, unsafe, unsucient and negligent assembly,

installation, rigging, and operation of this product.

Europe Energy Saving Notice

Energy Saving Matters (EuP 2009/125/EC)

Saving electric energy is a key to help protecting the enviroment.

Please turn o all electrical products when they are not in use. To

avoid power consumption in idle mode, disconnect all electrical

equipment from power when not in use. Thank you!

PinPoint Gobo CoLoR

ADJ Products, LLC - www.adj.com - PinPoint Gobo COLOR User Manual Page 3

• DC Powered and Battery Powered

• Dimming 0-100%

• Fast Color Fade & Change and Slow Color Fade & Change,

• UC IR Remote Compatible (Not Included) & Airstream IR

Compatible

• ADJ LED RC2 Compatible (Not Included)

PinPoint Gobo COLOR Warranty Registration

PinPoint Gobo COLOR Features

To optimize the performance of this product, please read these operat-

ing instructions carefully to familiarize yourself with the basic operations

of this unit. These instructions contain important safety information

regarding the use and maintenance of this unit. Please keep this manual

with the unit, for future reference.

PinPoint Gobo COLOR General Instructions

The PinPoint Gobo COLOR two year limited warranty. carries a

Please fill out the enclosed warranty card to validate your purchase.

All returned service items whether under warranty or not, must be

freight pre-paid and accompany a return authorization (R.A.) number.

The R.A. number must be clearly written on the outside of the return

package. A brief description of the problem as well as the R.A. number

must also be written down on a piece of paper included in the ship-

ping carton. If the unit is under warranty, you must provide a copy of

your proof of purchase invoice. You may obtain a R.A. number by con-

tacting our customer support team on our customer support number.

All packages returned to the service department not displaying a R.A.

number on the outside of the package will be returned to the shipper.

PinPoint Gobo COLOR Introduction

ADJ Products, LLC - www.adj.com - PinPoint Gobo COLOR User Manual Page 2

Unpacking: Thank you for purchasing the PinPoint Gobo COLOR by

ADJ Products, LLC. Every PinPoint Gobo COLOR has been thoroughly

tested and has been shipped in perfect operating condition. Carefully

check the shipping carton for damage that may have occurred during

shipping. If the carton appears to be damaged, carefully inspect your

xture for any damage and be sure all accessories necessary to oper-

ate the unit has arrived intact. In the case damage has been found

or parts are missing, please contact our toll free customer support

number for further instructions. Do not return this unit to your dealer

without rst contacting customer support.

Introduction: The ADJ PinPoint Gobo Color is a battery powered

GOBO projector powered by a 10-Watt Quad (RGBA 4-in-1) LED. It

includes 4 standard removable GOBOs and a frost filter to defuse the

beam for wider washes of light. When the GOBO is remove it may be

used as a pinspot to spot tables, decor, architecture or used for spe-

cial effects.

The PinPoint Gobo Color has an easy replaceable GOBO holder so

that user may interchange the supplied GOBOs or to insert custom

GOBOs. Located on the side of the fixture are sliders to manually adjust

the focus and beam angle.

Customer Support: ADJ provides a customer support line, to pro-

vide set up help and to answer any question should you encounter

problems during your set up or initial operation. You may also visit us

on the web at www.adj.com for any comments or suggestions. Service

Hours are Monday through Friday 8:00 a.m. to 4:30 p.m. Pacic Stan-

dard Time.

Voice: (323) 582-3322

Fax: (323) 582-3108

E-mail: support@americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

ADJ Products, LLC.

PLEASE recycle the shipping carton when ever possible.

PinPoint Gobo COLOR Safety Precautions

ADJ Products, LLC - www.adj.com - PinPoint Gobo COLOR User Manual Page 4 ADJ Products, LLC - www.adj.com - PinPoint Gobo COLOR User Manual Page 5

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken. Do not attempt to remove or break o the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out`

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to the point they exit from the unit.

• Cleaning -The fixture should be cleaned only as recommended by

t he manufacturer. See page 3 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (inclu-

d ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

1. Handling of Batteries

1.1 Do Not Short Circuit the Battery

Try to never short circuit the battery. It generates a very high current

which could cause the battery to overheat which may result in elec-

trolyte gel leakage, harmful fumes, or explosion. The LIR tabs may

easily short-circuit by placing them on conductive surface. A short cir-

cuit may lead to heat build up and damage of the battery. An appro-

priate circuitry with PCM is employed to protect accidental short

circuit of the battery pack.

1.2 Mechanical shock

Droping the unit, impact hit, bending, etc. may cause failure or short-

end life of the LIR battery.

2. Other

2.1 Battery connection

1). Direct soldering of wire leads or devices to the battery is strictly

prohibited.

2). Lead tabs with pre-soldered wiring shall be spot welded to the

batteries. Direct soldering may cause damage of components, such

as separator and insulator, by heat build up.

2.2 Prevention of short circuit within a battery pack

There is enough insulation layers between wiring and the batteries to

provide extra safety protection. The battery pack is constructed in a

way that no short circuit will occur which may cause smoke or re.

2.3 Do No Disassemble the Batteries

1). Never disassemble the batteries.

Doing this may cause a internal short circuit in the battery, which may

lead to harmful fumes, re, explosion, or other problems.

2). Electrolyte Gel is harmful

Electrolyte Gel should not leak from the LIR battery. Should the

electrolyte gel come into contact with the skin or eyes, ush the area

of contact immediately with fresh water and seek medical attention

immediately.

2.4 Do Not Expose the Battery to Heat or Fire

Never incinerate or dispose of the batteries in re. This may cause an

explosion, which would be very dangerous.

PinPoint Gobo COLOR Battery Precautions
