MOVABLE AIR CONDITIONER ●
CLIMATIZZATORE PORTATILE
CLIMATISEUR MOBILE ● MOBILES KLIMAGERÄT
ACONDICIONADOR PORTATIL ● AR CONDICIONADO PORT TILÁ
OPERATING INSTRUCTIONS
●
ISTRUZIONI D'USO
NOTICE D UTILISATION’
●
BEDIENUNGSANLEITUNG
INSTRUCCIONES DE USO ● INSTRUC ES DE FUNCIONAMENTOÇÕ
37.4252.008.2 06/2005
Save these instructions / Conservate queste istruzioni / Conserver cette notice d’utilisation
Bewahren Sie bitte diese Bedienungsanleitungen auf / Guardeis estas instrucciones / Guarde estas instruções
EG
I
F
D
E
P
PRODUCT IDENTIFICATION...................................................................................... 2
SIGNALING LAMPS .................................................................................................. 3
BEFORE USING THE APPLIANCE............................................................................. 3
OPERATION ............................................................................................................... 4
USING THE REMOTE CONTROL UNIT..................................................................... 4
•How to install batteries .............................................................................................. 4
•Temperature sensor selector..................................................................................... 4
•Operation with the remote control unit....................................................................... 4
REMOTE CONTROL UNIT ......................................................................................... 5
HOW TO SET THE PRESENT TIME .......................................................................... 6
COOLING .................................................................................................................. 6
DEHUMIDIFYING (DRY)............................................................................................. 6
FAN ONLY................................................................................................................... 6
ADJUSTING THE FAN SPEED................................................................................... 6
SLEEP MODE.............................................................................................................. 6
SETTING THE TIMER................................................................................................. 7
SETTING THE AIR FLOW DIRECTION..................................................................... 8
HOW TO DISCHARGE THE WATER TANKS............................................................. 8
OPERATION WITHOUT THE REMOTE CONTROL UNIT.......................................... 9
TIPS FOR ENERGY SAVING..................................................................................... 9
TROUBLESHOOTING............................................................................................... . 9
PORTHOLE KIT........................................................................................................... 10
CARE AND CLEANING .............................................................................................. 10
ELECTRIC WIRING DIAGRAMS’ SYMBOLS ............................................................ 11
NOTE: This symbol mark and
recycle system are applied only
to EU countries and not applied
to the countries in the other
area of the world.
Your product is designed and manu-
factured with high quality materials
and components which can be recy-
cled and reused.
This symbol means that electrical and
electronic equipment, at their end-of-
life, should be disposed separately
from your household waste.
Please dispose of this equipment at
your local community waste collec-
tion/recycling centre.
In the European Union there are sepa-
rate collection systems for used elec-
trical and electronic products.
Please help us to conserve the envi-
ronment we live in!
CONTENTS
PRODUCT IDENTIFICATION
1. Wireless remote control unit
2. Signaling lamps
3. Supply air deflector
4. Return air grille (both sides)
5. Air filter (both sides)
6. Air filter cover
7.
Tube for condensate discharge (Main tank)
8.
Tube for condensate discharge
(
Secondary
tank)
9. Electric cable with plug
10. Space for cable winding
11. Cable cover
12. Transportation wheels
13. Transportation handle
(both sides)
14. Retractile flexible pipe
15. Terminal pipe fitting
152
14
13
4
2
10 12
4
6
5
3
7
8
11
9
1
DECLARATION OF CONFORMITY
This product is marked as it
satisfies Directives:
–Low voltage no. 73/23 EEC and
93/68 EEC.
–Electromagnetic compatibility no.
89/336 EEC, 92/31 EEC and 93/68
EEC.
This declaration will become void in
case of of misusage and/or non
observance though partial of
manufacturer's installation and/or
operating instructions.
Operating limits:
Room Temperature:
Cooling: MIN: 16° °C D.B. / 14 C W.B.
MAX: 35 C D.B. / 24° °C W.B.
Dehumidification: MIN: 16 C D.B / 80% R.H.°
MAX: 35 C D.B. / 80% R.H.°
EG
3
SIGNALING LAMPS
1. Receiver : receives signals transmitted from the remote control.
2. TIMER lamp: This lamp lights up when the system is being
controlled by the timer or sleep mode.
3. OPERATION lamp: This lamp lights up during operation.
It blinks once to announce that the remote control signal
has been received and stored. It blinks continuously during
the protection modes (defrosting, etc.).
4. STANDBY lamp: This lamp lights up when the air conditioner
is connected to the power and ready to receive the remote
control command.
5. Water-level alarm: When the main tank is full, the air condition-
er stops automatically and this lamp begins blinking.
6. Operation button (without remote control): Push the button
to walk through the OFF and COOL operation modes.
The OFF position does not disconnect the power. Use the
main power switch to turn off power completely.
WARNING
BEFORE USING THE APPLIANCE
●Check that the power supply at the location where the air conditioner is going to be
used is 220-240V ~ 50Hz .
●Make sure that the electrical installation is suitable to supply continuously current
necessary for the air conditioner in addition to that already used by other electric
appliances (white goods, lighting). See the max electric input indicated on the
name plate positioned on the air conditioner.
●The installation of a double-pole switch, protected by 10 A fuses of the delayed
type, upstream the electricity wall socket, is recommended.
●The unit has to be connected according to the local electrical rules.
●Make sure that circuit breakers, fuses, etc, are of sufficient capacity to handle a
start-up current of 20 A (generally less then 1 second).
●Do not install the air conditioner where it could be wetted by drops of water (i.e. in
laundries).
●Before connecting the air conditioner to a power socket, make sure that the socket
is provided with an earth connection in compliance with local codes.
●Never use the power plug as a mean to start or stop the air conditioner: always
use the ON/OFF push-button switch on the air conditioner control panel.
●Do not move the air conditioner during operation, turn it off and disconnect the
plug from the power supply. Verify and eventually discharge the condensate water,
through the discharge tube located on the rear of the unit.
●WARNING! Do not stick anything into the air outlet of the air conditioner. This is
very dangerous because the fan is rotating at high speed.
●WARNING!
The air conditioner is provided with a time-guard system, which does not allow
re-starting of compressor until after 3 minutes from a previous stop.
●Make sure that there are no obstacles around the unit affecting the free circulation
of air. Do not block the air intakes and outlet of the unit with curtains or other.
Never put objects on the top of the unit.
●The air conditioner reaches the maximum efficiency at the following conditions:
1-The flexible tube is retracted, without bends and without the outlet nozzle.
2-When you switch on the air conditioner for the first time, set the fan at the LOW
speed for at least one hour, then set the HIGH speed.
●The manufacturer assumes no responsibilities if the safety regulations or local
codes are not observed.
Always unplug the unit from the power socket before moving or cleaning it.
WARNING
1
2
3
4
5
6
CAUTION
EG
