Sida 1/8
Dayton / Dayton 60BT 120BT
Please read the manual before using the product
USER´S
MANUAL
7
Dayton / Dayton 60BT 120BT
Mini Mixer Amplifier......................................................................................................1
User Manual..................................................................................................................1
Remote Controller........................................................................................................1
Packing list
List Quantity
Performance
Model
Dayton 60BT
Dayton 120BT
Power Supply
~110-240V 50/60Hz
MIC1 input sensitivity
5.5mV±1mV
7mV±1mV
MIC2 input sensitivity
5.5mV±1mV
7mV±1mV
AUX1 input sensitivity
350mV±10%
300mV±10%
AUX2 input sensitivity
350mV±10%
300mV±10%
EMC input sensitivity
350mV±10%
MIC frequency response
200Hz
～
10kHz
（
±3dB
）
100Hz
～
8kHz
（
±3dB
）
AUX frequency response
100Hz 15kHz ±3dB～ （ ）
80Hz 15kHz ±3dB～ （ ）
Noise
<5mV (4 load out)Ω
6mV(4 load out)Ω
Distortion
<1% 1KHz
Treble adjustment
10dB ±2（ ）
Bass adjustment
10dB ±2（ ）
Speaker Outputs
60W
120W
Interface output voltage
70V,100V(Constant voltage output)
，
4-16Ω
Machine size(D×W×H)
198×247×66mm
Packing size
302×343×121mm (1PC)
Maximum packing size
355×630×283mm (4PCS)
Net Weight
2.6KG
3KG
Gross Weight
3.25Kg (1PC)
3.7Kg (1PC)
Dayton / Dayton 60BT 120BT
1 6
USER´S
MANUAL
Safety Precautions
Please note the following symbols:
Lightning triangular symbols are used to alert the user to the risk of
electric shock.
The exclamation point triangle symbol is used to alert the user to
important operational or maintenance instructions.
Instructions for action
Remote control instructions
1. MIC mode
When the Microphone is broadcasting in any mode, the system will detect the
MIC and mute the others sources. It will return to the original play status when
the MIC has no signal.
2. Bluetooth mode
Press MODE to display “BLUE” on the digital screen, the “BLUE” will always flash
until device and mobile phone pairing success, take the name is “Dayton 60 BT
/ Dayton 120BT”. After finishing the pairing, the user can play music on the
mobile
phone. With excellent wireless transmission function, and the wireless
transmission distance is ≈10m.
3. USB mode
When the USB access, it will be USB mode automatically (plug and play)
4. Line mode
In line mode, press MODE, digital screen will display “AUX”
5. FM mode
Warning! To reduce the risk of electric shock or equipment damage, please
follow the following requirements:
● Please do NOT connect this device to the power source, before the system is
correctly wired.
● It is important to ensure that input voltage to the device is the same as
required voltage of the device; otherwise the device may be damaged.
● There is dangerous voltage in the device, which may cause personal electric
shock. Please do NOT open the case without permission, to avoid potential risks
of electric shock.
● The device is not completely disconnected from power source when it is
switched "OFF". For sake of safety, please disconnect the device from the
socket if it is not in use.
● Please do NOT place the device where it is extremely cold or hot.
● Good ventilation must be provided in the working environment of the device,
to avoid excessive temperature during its operation, which may cause
damages to the device.
● Please unplug the device from power socket in raining and wet days or if the
device is not in use for a long time.
● Please disconnect the power plug from sockets, to ensure the device has
been completely disconnected from power source, before any component is
removed from or re-installed in the device or before any electric connector of
the device is disconnected or reconnected.
● In case of any failure of the device, please do NOT open the case and repair
without permission from a professional personnel, to avoid accident or
additional damages to the device.
● Please do NOT place any corrosive chemicals near or on the device
Function key description
1. Power switch (MP3/FM/BT)
2. Mode: AUX,FM, BT and MP3 mode switch
3. Mute: MP3, FM and BT Mute key. Pressing this key, the
currently playing program is muted, and the LED display
screen will flash.
4. Play/ Pause key (MP3/BT), Radio channel selection:
repeatedly to recall the stored station
5. Previous song (MP3/BT), Previous channel (FM)
6. Next (MP3/BT), Next channel (FM)
7. EQ: Press this key you could choose different sound
effects when in MP3 mode. You could choose Classical,
Jazz, Rock, DBB, and Pop mode.
8. Vol-: MP3/FM/BT volume decrease
9. Vol+:MP3/FM/BT volume increase
10. 0-9 number key: select MP3 player's song by serial
number or stored the searched radio program by serial
number
11. USB / SD: When in MP3 mode, switch USB disk or SD
card to play
12. RPT: When in MP3 mode, repeat one or repeat all
1
2
4
7
8
10
3
5
6
9
11
12
Dayton / Dayton 60BT 120BT
5 2
USER´S
MANUAL
Rear panel (Take Dayton 120BT as an example)
1. Power input
Connect the power plug from this interface. Insert the plug into the machine,
and then connect the power grid.
2. FM antenna interface
Connect the FM antenna to this interface.
3. DC power input
DC24V backup power input interface. (DC24V IN, only half power output for
MP120UB)
4. Audio power output
Note: Any terminal of the power output cannot be connected to “Ground
wire” directly or through other devices.
5. AUX output
6. AUX1 input port
7. AUX2 input port
8. Audio source selection switch (AUX2-MIC2 Note:When you operate this
switch, you need to turn the volume down or turn off the device)
AUX2, MIC2/24V(Dayton 60BT is 48V) phantom power switch, toggle the switch
left and right to choose.
9. Indicator of phantom power (Dayton 60BT is 48V, MP120UB is 24V)
10. MIC2 balanced input interface
11. AUX2/MIC2 volume control
12. 100V emergency signal input (When using external 100V emergency signal
input, the ground wires of the two devices can not be connected together.)
13. Emergency input volume control
14. General emergency signal input port
1 2
3 4 5 6 7 8 9 10 11 12 13 14
Introduction...................................................................................................................3
Profile of Product...........................................................................................................3
Product feature.............................................................................................................3
Front panel....................................................................................................................3
Rear panel.....................................................................................................................5
Instructions for action ...................................................................................................6
Remote control instructions.........................................................................................6
Performance..................................................................................................................7
Packing list.....................................................................................................................7
Contents
