Sida 1/8
Memphis 30USB
Please read the manual before using the product
USER´S
MANUAL
7
Memphis 30USB
NOTES
Memphis 30USB USER´S
MANUAL
1 6
Thank you for choosing AUDIBAX brand
This amplifier has been designed for "P.A. system" purposes. It is used for
example in offices, schools, churches, shops shopping centers, restaurants,
convention, centers, auditoriums etc.
Its advanced protection systems prevent damages caused by short circuits,
overheating and overloads and make it safe and reliable.
It comes with 2 microphone inputs, 1 line input, and speaker terminals both for
4/8 Ohm.
It is provided with Mp3 module for music track playback tuner and bluetooth
receiver to connect smartphones or tablets.
The current manual is referred to 2 models differing only for their power.
Cautions and warnings
• Read carefully the instructions given in this manual and follow them strictly
• Keep this manual for future reference and include it if you give the product
to another user.
• This device works with dangerous 230V mains power. Do not open. do not
disassemble and don't try to operate inside. In case of wrong use an electric
shock may occur.
• Contact a specialized technician for the installation
• Always make sure to connect the device to a power outlet with the correct
voltage
• Avoid using the unit: in places with temperatures above 35C, or in places
exposed to rain, humidity, impacts and vibrations.
• Do not allow flammable liquid, water or objects to enter the product.
• Install the product in a ventilated position, far from heat sources and don't
obstruct the air vents.
• In the event of a serious operating problem, stop using the product immedia-
tely. Never try to repair it by yourself, but contact the authorized technical
service center. Repairs carried out by unskilled persons could lead to serious
damages both to the fixture and to people.
• Disconnect the unit from power when it is not used.
• Wait for the product to cool before cleaning or maintenance
• If the product doesn't turn on check the fuse and if necessarily replace it with
one of the same types and rating, after disconnecting the fixture from power.
• Do not turn the product on and off at short intervals, it may reduce the life of
the device.
TECHNICAL SPECIFICATIONS
Power (Max/RMS)
2x15W
Power supply
110-230V~AC-50/60Hz;12V-16V
Tone controls
None
Output Impedance
4-8 Ohms
RCA input &output
1
Mic inputs
2
MP3 player
USB/TF/BT
Bluetooth
Yes Freq.2.4Ghz
Other functions
FM radio /Priority/mute
Fuse
2A
Frequency response
Mic 100Hz-20 KHz; Line30Hz-20KHz
Total THD (at 1 KHz)
Less than 1%
Signal/noise ratio
Mic>70dB Line>80dB
Remote control battery
CR 2032 3VLithium(included)
Dimensions
150*52x190mm
Weight
1.0 Kg
Memphis 30USB USER´S
MANUAL
5 2
The manufacturer, in order to improve its
products, reserves the right to modify their
characteristics whether technical or
aesthetic, at any time and without notice.
This symbol alerts you of the presence of important operating and maintenan-
ce instructions, in the manual or in the documentation accompanying the
product
This symbol alerts you to the presence of uninsulated dangerous voltage within
the product's enclosure that might be of sufficient magnitude to constitute a
risk of electric shock. Do not open the product's case
To prevent possible hearing damage, do not listen at high volume levels for
long periods.
The CE mark indicates that this product complies with the applicable
European directives and their related standards Compliance documentation
in complete form is available at the company Karma Italiana Srl.
Directive 2012/19/UE regarding electric and electronic equipment waste
(WEEE). The symbol of the crossed-out dustbin indicates that the product at
the end of its life must be collected separately from other waste. The user must
therefore. confer the fixture complete with all the essential components to an
authorized disposal center for collection of electronic and electrical waste, or
return it to the dealer when buying new equipment of equivalent type, at a
rate of one to one, or one to zero if external dimension is less than
25cm.Appropriate separate collection to send the decommissioned
equipment to recycling, treatment and environmentally compatible disposal
helps to prevent negative impact on the environment and human health and
promotes recycling of the materials making up the product.
The product's remote control contains a battery which according to the
European Directive 2013/56/EU cannot be disposed of with normal household
waste. Please inquire about the local regulations regarding the separate
collection of batteries: a correct disposal allows to avoid negative consequen-
ces for the environment and health.
• Never disconnect the product from the power source by pulling on the cord.
• Periodically check the condition of the power cord.
Shipments and complaints
When purchasing or receiving the product open the box and carefully check
the content to make sure that all parts are present and in good condition.
Immediately notify the seller of any transport damage suffered by the device. If
you send the product for repair, it must be shipped with complete original
packaging: we therefore recommend keeping it along with invoice or the
purchase receipt.
Impedance speaker connection
This type of connection does not allow to limit individually the power of each
single speaker, but it gives the possibility to obtain higher performances. The
main rule to be respected is that the total impedance of the speakers must be
compatible with the impedances supported by the amplifier where the
speakers will be connected (4-8 Ω). If you use more than one speaker, the
value of impedance will be added up (in case of series wiring) or divided (in
case of series wiring).
If you connect only one speaker you have to consider the impedance of the
speaker itself. Mixing connections are also possible. Below are two examples:
Before making any connection, be sure that the unit is unplugged
from the power outlet.
All connections must be made with the appliance turned off.
