THUNDER 450 RGBW
Please read the manual before using the product
USER´S
MANUAL
THUNDER 450
RGBW
THUNDER 450 RGBW USER´S
MANUAL
Table Of Contents
1. Safety instruction
2. Introduction
3. Fixture overview
4. How to set the unit
4.1 Control panel
4.2 Main function
5. Control by DMX
5.1 DMX512 connection
5.2 Addressing setting
5.3 DMX protocol
6. Maintenance
6.1 Cleaning
6.2 LED performance
7. Technical Specification
13
3. If you have intermittent DMX signal problems, check the pins on
connectors or on PCB of the unit or the previous one.
4. Try to use another DMX controller.
5. Check if the DMX cables run near or run alongside to high voltage
cables that may cause damage or interference to DMX interface
circuit.
C. One of the channels is not working well
1. The stepper motor might be damaged or the cable connected to
the PCB is broken.
TECHNICAL SPECIFICATION
• Voltage:AC100-240V/300W,50/60Hz
• Light source: Mainly output is 216pcs of 1W white SMD LED, and
aura light is used 768pcs RGB 3in1 SMD LED
• Power consumption(Flashing mode):500W
• Continuous lighting mode:300W
• Lifespan:50,000 hours
• Beam angle:80 degree for white color with optical reflecting patter,
• 120 degree for aura
• Dimming:0-100% linear electronic dimming
• Strobe:0-30 times/sec
• Control mode:DMX512,Master/slave,Auto run,manual
• Channel:6/16/42CH
• Cooling:silent fans keep fixtures cooling
• 18 blocks individual controlled,can make hundreds of special
effects
• Color temperature:5000-6500K
• Housing:Fire and explosion-proof Plastic
• Size:460*220*125mm(fixture)
• Weight:4.3kg
MAINTENANCE
Following are a few common problems that may occur during
operation. Here
are some suggestions for easy troubleshooting:
A. The unit does not work, no light and the fan does not work
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.
3. Check the power on LED.
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors and cables
to see if link properly.
2. If the DMX LED is on and no response to the channel, check the
address settings and DMX polarity.
THUNDER 450 RGBW USER´S
MANUAL
12 1
28
000-255
Red 0-100%
LED Group 10
29
000-255
Green 0-100%
30
000-255
Blue 0-100%
31
000-255
Red 0-100%
LED Group 11
32
000-255
Green 0-100%
33
000-255
Blue 0-100%
34
000-255
Red 0-100%
LED Group 12
35
000-255
Green 0-100%
36
000-255
Blue 0-100%
37
000-255
White group 1 dimming from 0-100%
38
000-255
White group 2 dimming from 0-100%
39
000-255
White group 3 dimming from 0-100%
40
000-255
White group 4 dimming from 0-100%
41
000-255
White group 5 dimming from 0-100%
42
000-255
White group 6 dimming from 0-100%
Safety instruction
Please read the instruction carefully which includes important information
about the installation, usage and maintenance.
Please keep this User Manual for future consultation. If you sell the unit to
another user, be sure that they also receive this instruction booklet.
1.Unpack and check carefully there is no transportation damage before
using the unit.
2.Before operating, ensure that the voltage and frequency of power supply
match the power requirements of the unit.
3.It’s important to ground the yellow/green conductor to earth in order to
avoid electric shock.
4.The unit is for indoor use only. Use only in a dry location.
5.The unit must be installed in a location with adequate ventilation, at least
50cm from adjacent surfaces. Be sure that no ventilation slots are blocked.
6.Disconnect main power before replacement or servicing.
7.Make sure there are no flammable materials close to the unit while
operating as it is fire hazard.
8.Use safety cables when fixing this unit. DO NOT handle the unit by its head
only, always carry by its base.
9.Maximum ambient temperature is Ta: 40 degrees C. DO NOT operate it
where the temperature is higher than this.
10.Unit surface temperature may reach up to 75 degrees C. DO NOT touch
the housing with bare hands during its operation. Turn off the power and ‐
allow about 15 minutes for the unit to cool down before replacing or serving.
11.In the event of a serious operating problem, stop using the unit immedia-
tely. Never try to repair the unit by yourself. Repairs carried out by unskilled
people can lead to damage or malfunction.
Warning! Warning! Warning!
