Operating a MIDI Device (MIDI Mode)

In MIDI mode, you can control electronic musical gear

(such as amps and eect units) or MIDI-compatible

devices like your smartphone or computer.

Instead of using a wireless connection, you can also

connect via cable to the MIDI OUT connector or USB

port.

You can use the dedicated app, “FS-1-WL Editor” to

customize the settings.

For details on the dedicated app, see the BOSS

website.

https://www.boss.info/

Connecting to an Electronic Musical Instrument (Pairing)

1. Turn this unit on in MIDI mode.

2. Press the [Bluetooth] (INSTRUMENT) button.

The indicator blinks.

3. Connect your electronic musical instrument to the FS-1-WL via Bluetooth.

The indicator lights up when the connection has been established.

MEMO

For details on how to connect, refer to the owner’s manual of your electronic musical

instrument.

Connecting with a Smartphone/Computer (Pairing)

1. Turn this unit on in MIDI mode.

2. Press the [Bluetooth] (Smartphone/PC) button.

The indicator blinks.

3. Connect the smartphone/computer and FS-1-WL from the application you want

to control.

The indicator lights up when the connection has been established.

Replacing the Batteries

Insert the batteries in the correct direction as shown in the illustration.

*To prevent this product from operating incorrectly or malfunctioning,

insert or replace the batteries before connecting this product to

another device.

*Use alkaline batteries if you are running the unit on battery power.

*When turning the unit over, handle the unit carefully; do not drop it.

*If you handle batteries improperly, you risk explosion and uid

leakage. Make sure that you carefully observe all of the items related to

batteries that are listed in “USING THE UNIT SAFELY” and “IMPORTANT

NOTES” (leaet “USING THE UNIT SAFELY” and the Owner’s Manual).

Restoring the Factory Settings (Factory Reset)

1. Disconnect any cables that are plugged into the CTL1,2, EXP, USB or MIDI OUT

connectors and jacks.

2. Hold down the [Bluetooth] (Smartphone/PC) button to turn the power on and set

this unit to MIDI mode.

The POWER indicator blinks green, and the pedal indicator R blinks blue.

3. Press the pedal switch R.

This executes the factory reset.

The pedal indicator R blinks red while the factory reset is in progress.

*Do not turn o the power while the indicator is blinking red.

MIDI CC numbers

(default value)

Parameter MIDI CC#

PEDAL L 80

PEDAL C 81

PEDAL R 82

EXP 11

CTL1 85

CTL2 86

Before using this unit, carefully read “USING THE UNIT SAFELY” and “IMPORTANT NOTES” (the leaet “USING THE UNIT SAFELY” and the Owner’s Manual). After reading, keep the

document(s) where it will be available for immediate reference.

An Overview of the FS-1-WL

The FS-1-WL is a footswitch that can be used wirelessly.

• This unit lets you control apps on your smartphone or computer (such as apps for

turning pages, YouTube, DAWs and so on).

• You can also control electronic musical gear (such as amps and eect units) or

MIDI-compatible devices like your smartphone or computer.

Refer to the “FS-1-WL Connection Guide” for details on how to

connect this device to your smartphone/computer or to your

BOSS/Roland product.

https://roland.cm/fs-1-wl_om

Panel Descriptions

L C R

Name Explanation

Pedal switch /

indicator (L, C, R)

Depress a pedal switch to control the connected device.

The pedal indicator lights up when the pedal switch is on.

POWER indicator

This indicator lights when the [POWER] switch is turned on.

Lit green There is sucient battery power.

Lit red The battery will be depleted in an hour.

[POWER] switch

Turns the power on/o.

MIDI The unit uses MIDI mode.

HID The unit uses HID mode.

DC IN jack

Connect an AC Adaptor (PSA series; sold separately) to this

jack.

* Use only the specied AC adaptor (PSA series; sold

separately), and connect it to an AC outlet of the correct

voltage.

* If the AC adaptor is connected while power is on, the power

supply is drawn from the AC adaptor.

CTL1, 2 jacks

Connect a footswitch (FS-5U, FS-6 or FS-7, sold separately) to

these jacks.

You can use a footswitch to control dierent MIDI/HID data

than the data you can control with the pedal switches.

Mode and polarity switch settings for the footswitch

FS-7

FS-6

FS-5U

1/4” phone type Ð

1/4” phone type

Stereo 1/4” phone

type Ð 1/4” phone

type x 2

Stereo 1/4” phone type

Ð Stereo 1/4” phone

type

Name Explanation

EXP jack

Connect an expression pedal (such as a Roland EV-5; sold

separately).

This lets you control MIDI control change (CC) numbers from

this unit.

* Use only the specied expression pedal. Connecting

expression pedals made by third-party manufacturers may

cause this unit to malfunction.

MIDI OUT

connector

Connect this to the MIDI IN connector of an external MIDI

device with a TRS/MIDI connecting cable (BMIDI-5-35, sold

separately).

* Do not use this connector for connecting to audio devices.

Doing so may cause a malfunction.

USB port

Use a commercially available USB cable to connect this unit to

the USB port on your computer.

This allows the FS-1-WL to operate as a USB MIDI device.

There is no need to install a driver.

* HID signals are not outputted.

[Bluetooth]

(INSTRUMENT)

button/indicator

Pairs this unit with an electronic musical instrument.

Lit Connected

Blink Now pairing

Unlit Not connected

[Bluetooth]

(Smartphone/PC)

button/indicator

Pairs this unit with your smartphone or computer.

Lit Connected

Blink Now pairing

Unlit Not connected

*To prevent malfunction and equipment failure, always turn down the volume, and

turn o all the units before making any connections.

Wirelessly Operating an App on Your Smartphone/Computer (HID Mode)

In HID mode, you can use this unit instead of a keyboard to control apps on your

smartphone or computer, such as apps for turning pages, YouTube, DAWs and so on.

You can select from three types of settings (memories) to operate the target device,

depending on the app you’re using.

Memory Recommended

app

PEDAL

RCTL1 CTL2

(default value) Sheet music app Ù Ø Home × Ö

2YouTube ÙSpace Ø< >

3DAW Enter/

Return Space R × Ö

You can use the dedicated app, “FS-1-WL Editor” to customize the settings.

For details on the dedicated app, see the BOSS website.

https://www.boss.info/

Selecting a Memory

1. Press and hold down a pedal switch to turn the power on and set the unit to HID

mode.

Memory 1 Pedal switch L

Memory 2 Pedal switch C

Memory 3 Pedal switch R

The selected memory is saved even if you turn o the power.

Connecting with a Smartphone/Computer (Pairing)

1. Select a memory that’s appropriate for the app you’re using.

2. Turn this unit on in HID mode.

3. Press the [Bluetooth] (Smartphone/PC) button.

The indicator blinks.

4. Connect the FS-1-WL to your smartphone or computer from that device’s settings

screen.

The indicator lights up when the connection has been established.

Power Supply: Use of Batteries

• If operating this unit on batteries, please

use alkaline batteries.

• Even if batteries are installed, the unit

will turn o if you connect or disconnect

the power cord from the AC outlet while

the unit is turned on, or if you connect or

disconnect the AC adaptor from the unit.

You must turn o the power before you

connect or disconnect the power cord or

AC adaptor.

Repairs and Data

• Before sending the unit away for repairs,

be sure to write down the needed

information. Although we will do our

utmost to preserve the data stored in

your unit when we carry out repairs, in

some cases, such as when the memory

section is physically damaged, restoration

of the stored content may be impossible.

Roland assumes no liability concerning

the restoration of any stored content that

has been lost.

Additional Precautions

• Any data stored within the unit can be

lost as the result of equipment failure,

incorrect operation, etc. To protect

yourself against the irretrievable loss of

data, be sure to write down the needed

information.

• Roland assumes no liability concerning

the restoration of any stored content that

has been lost.

Caution Regarding Radio Frequency

Emissions

• The following actions may subject you to

penalty of law.

• Disassembling or modifying this

device.

• Removing the certication label

axed to the back of this device.

• Using this device in a country other

than where it was purchased

Intellectual Property Right

• The word mark and logos Bluetooth®

are registered trademarks owned by

Bluetooth SIG, Inc. and any use of such

marks by Roland is under license.

• Roland, BOSS are either registered

trademarks or trademarks of Roland

Corporation in the United States and/or

other countries.

• Company names and product names

appearing in this document are

registered trademarks or trademarks of

their respective owners.

IMPORTANT NOTES

English Main Specications

Power supply Alkaline battery (AAA, LR03) x 2, AC adaptor (sold separately)

Current draw 65 mA

Expected battery life under

continuous use

Alkaline battery: 14 hours

* These gures will vary depending on the actual conditions of use.

Dimensions 207 (W) x 77 (D) x 32 (H) mm, 8-3/16 (W) x 3-1/16 (D) x 1-5/16 (H) inches

Weight (including batteries) 258 g, 10 oz

Accessories Owner’s Manual, Leaet “USING THE UNIT SAFELY”,

Alkaline battery (AA, LR03) x 2

Options (sold separately)

AC adaptor: PSA series

Footswitch: FS-5U

Dual footswitch: FS-6, FS-7

Expression pedal: EV-30, FV-500L, FV-500H, Roland EV-5

TRS/MIDI connecting cable: BMIDI-5-35, BMIDI-1-35, BMIDI-2-35,

BCC-1-3535, BCC-2-3535

*This document explains the specications of the product at the time that the

document was issued. For the latest information, refer to the Roland website.

For the USA

SUPPLIER’S DECLARATION OF CONFORMITY

Compliance Information Statement

Model Name :

Type of Equipment :

Responsible Party :

Address :

Telephone :

FS-1-WL

Wireless foot switch

Roland Corporation U.S.

5100 S. Eastern Avenue Los Angeles, CA 90040-2938

(323) 890-3700

Redistribution and use in source and binary forms, with or without modication, are permitted provided that the following conditions are met:

* Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

* Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL

DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY,

WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Patent: roland.cm/patents
