USER’S
MANUAL
rev. 2.0 f
AP4.9
USER’S MANUAL
2
AP4.9 bit /
Index
1. PRODUCT DESCRIPTION / PRECAUTIONS ..........................................................................................................................3
2. PACKAGE CONTENTS ...............................................................................................................................................................3
3. and DRC INSTALLATIONAP4.9 bit ........................................................................................................................................4
4. CONNECTION PANEL DESCRIPTION .....................................................................................................................................5
1 POWER ..............................................................................................................................................................................5
2INPUTS / REM IN-OUT...................................................................................................................................................6
3 ASP AUTOMATIC SPEAKER PRESENCE 7 ....................................................................................................................
4 SPEAKER OUT 7 ..................................................................................................................................................................
5 SUB OUT 8 ...........................................................................................................................................................................
6 OPTICAL IN 8 .......................................................................................................................................................................
7 DSP OUT 8 ...........................................................................................................................................................................
8 DRC 9 ................................................................................................................................................................................
9 USB 10 ..............................................................................................................................................................................
10 UPGRADE OFF-ON 10 ........................................................................................................................................................
11 PRESET 10 ...........................................................................................................................................................................
12 FUSE ..............................................................................................................................................................................10
13 LOGO STATUS 10 ...............................................................................................................................................................
5. CONNECTIONS .........................................................................................................................................................................11
5.1 POWER SUPPLY AND REMOTE TURN ON. 11 .............................................................................................................
5.2 INPUT SIGNALS 12 ............................................................................................................................................................
5.3 DIGITAL OPTICAL IN INPUT SIGNALS 13 .....................................................................................................................
5.4 OUTPUT SIGNALS 14 ........................................................................................................................................................
5.4.1 PRESET 0: DEFAULT: 2 WAY ACTIVE FRONT + EXTERNAL SUBWOOFER. 15 ..............................................
5.4.2 PRESET 1: FRONT + REAR + EXTERNAL SUBWOOFER 16 ..............................................................................
5.4.3 PRESET 2: FRONT + BRIDGE SUBWOOFER 17 ...................................................................................................
5.4.4 PRESET 3: HI POWER FRONT + EXTERNAL SUBWOOFER 18 ........................................................................
5.4.5 PRESET 4: 3 WAY ACTIVE FRONT + SUB 19 .......................................................................................................
5.4.6 PRESET 5: 3 WAY ACTIVE FRONT + REAR + SUBWOOFER 20 ........................................................................
5.4.7 PRESET 6: 2 WAY ACTIVE FRONT + REAR + SUBWOOFER 21 ........................................................................
5.4.8 PRESET 7: 2 WAY ACTIVE FRONT + REAR + 2 WAY ACTIVE CENTER + SUBWOOFER .................................... 22
PERSONAL COMPUTER E CONTROLLO REMOTO DIGITALE (DRC). 235.5 ...................................................................
6. GUIDE FOR INSTALLING/UNINSTALLING PRIMA SOFTWARE AND DRIVERS ..........................................................24
6.1 GUIDED PROCEDURE FOR PC SOFTWARE INSTALLATION 24 ................................................................................
6.2 GUIDED PROCEDURE FOR DRIVER INSTALLATION 26 .............................................................................................
6.3 UNINSTALLING AP4.9 bit SOFTWARE 27 ....................................................................................................................
7. HOW TO SET UP AP 8.9 BIT WITH A PC WITH A PCAP4.9 bit ....................................................................................28
7.1 OFFLINE MODE ..............................................................................................................................................................28
7.2 TARGET MODE ..............................................................................................................................................................29
7.3 ADJUSTING ACOUSTIC REPRODUCTION 35 ...............................................................................................................
7.3.1 DEVICE INFO ......................................................................................................................................................35
7.3.2 FILE MAIN MENU 36 ..............................................................................................................................................
7.3.3 MEMORIES MAIN MENU 36 .................................................................................................................................
7.3.4 SETTINGS MAIN MENU 37 ...................................................................................................................................
7.3.5 DEVICE MAIN MENU 40 ........................................................................................................................................
7.3.6 HELP MAIN MENU 41 ............................................................................................................................................
7.3.7 SELECTED INPUT .............................................................................................................................................41
7.3.8 CHANNEL MAP 41 ..................................................................................................................................................
7.3.9 SELECT CHANNEL ............................................................................................................................................42
7.3.10 FILTER SETTINGS .............................................................................................................................................42
7.3.11 SET DISTANCE AND DELAY ............................................................................................................................44
7.3.12 PARAMETRIC EQUALIZER ...............................................................................................................................47
7.3.13 OUTPUT LEVEL .................................................................................................................................................48
7.3.14 MEMORY .............................................................................................................................................................48
7.3.15 STATUS BAR 48 ......................................................................................................................................................
8. TROUBLESHOOTING ...............................................................................................................................................................49
8.1 SYNCHRONIZATION WITH A PC 49 ................................................................................................................................
8.2 BACKGROUND NOISE ..................................................................................................................................................49
8.3 FIRMWARE UPGRADE ..................................................................................................................................................49
9. DRC - DIGITAL REMOTE CONTROL (OPTIONAL) .............................................................................................................52
9.1 SEL BUTTON FUNCTIONS 53 ..........................................................................................................................................
9.2 OPERATIONAL ERROR MESSAGES 53 ...........................................................................................................................
10. ACCESSORIES ...........................................................................................................................................................................54
10.1 ASP - AUTOMATIC SPEAKER PRESENCE 54 ..................................................................................................................
ACP2 - 2 RCA ADAPTER CABLE 5410.2 ..................................................................................................................................
ACP6 - 6 RCA ADAPTER CABLE 5410.3 ..................................................................................................................................
APL 2 - AP4 D / AP1 D LINK CABLE 5410.4 ............................................................................................................................
APK 3 - AUDISON PRIMA TOWER KIT 3 5510.5 .....................................................................................................................
DRC DIGITAL REMOTE CONTROL 5510.6 ...............................................................................................................................
ECK DRC - CABLE EXTENSION KIT 5510.7 .............................................................................................................................
OP 1.5 TOSLINK OPTICAL CABLE 1,5 m / 59.05 in. 5510.8 .................................................................................................
OP 4.5 TOSLINK OPTICAL CABLE 4,5 m / 177.16 in................................................................................................5610.9
STA - F/F SOCKET TOSLINK ADAPTER.. 5610.10 ..................................................................................................................
SFC SAMPLING FREQUENCY CONVERTER.. 5610.11 ..........................................................................................................
11. TECHNICAL SPECIFICATIONS ..............................................................................................................................................57
USER’S MANUAL
3
AP4.9 bit /
1. PRODUCT DESCRIPTION / PRECAUTIONS
2. PACKAGE CONTENTS
AP4.9 bit is an amplifier featuring 4 channels settable into bridge mode, with a 32-bit, 147-MHz digital signal processor
(DSP) and 24-bit Analog-Digital and Digital-Analog converters, essential to optimize the acoustic performance of your
Car Audio entertainment system. It connects to any OEM system, even in vehicles with built-in audio processor, since
the AP4.9 bit sends back a linear signal thanks to the De-Equalization function.
It features 7 signal inputs, 6 Hi-Level and 1 S/PDIF optical digital, and provides 4 amplified outputs and 5 booster
outputs for an analog amplifier, to offer a 9-channel amplified system.
Each output channel features: a graphically adjustable parametric equalizer group, a 68-step frequency electronic
crossover as well as BUTTERWORTH or LINKWITZ filters with 6-24 dB slopes and a digital time delay line.
The user can adjust the settings through the DRC remote control device.AP4.9 bit
WARNING: 1. a PC provided with Windows XP, Windows Vista, Windows 7 or Windows 8 operating system, 1.5 GHz minimum
processor speed, 1 GB RAM minimum memory and a 1024 x 600 pixels minimum resolution graphics card as
well as at least 512 MB of available hard-disk space are required to install the software and setup the product.
2. Before connecting the product, carefully read this manual. Improper connections may cause damage
to
AP4.9 bit
or to the speakers in your car audio system.
1/2
- Multipolar cable, Inputs/Rem:
- Multipolar cable, Speakers out:
- NR. 1 - 30A replacement fuse:
- 1.8 m USB cable:
- 2.5 mm hex key:
- NR. 4 - 4.2 x 50 mm self-tapping, cross head mounting screws:
- AP4.9 bit amplifier
- Warranty
- Quick start guide
- CD ROM containing:
AP4.9 bit Software
This owner’s manual (.pdf)
Audio Test Tracks
30 A
- Multipolar cable, DSP out:
QUICK
START
GUIDE
AP4.9
