Split type air conditioner
User Manual
BBFDA 070/BBFDA 071
BBFDA 090/BBFDA 091
BBFDA 120/BBFDA 121
BBFDA 180/BBFDA 181
BBFDA 240/BBFDA 241
BBVHM 090/BBVHM 091
BBVHM 120/BBVHM 121
BBVHM 180/BBVHM 181
BBVHM 240/BBVHM 241
CONTENTS
ENGLISH 3-60
РУССКИЙ 61-134
O‘ZBEK 135-196
V2111003
AG UM
Please read this user manual first!
Dear Customer,
Thank you for preferring a Beko product. We hope that you get the best results from
your product which has been manufactured with high quality and state-of-the-art
technology. Therefore, please read this entire user manual and all other accompanying
documents carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well. Follow all
warnings and information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this manual:
This product has been manufactured at modern facilities respectful to the environment without harming nature.
Complies with the WEEE Regulation. Does not contain PCB.
C
Important information or useful
hints about usage.
A
Warning for hazardous
situations with regard to life
and property.
Warning to actions that must
never perform.
B
Warning for electric shock.
This symbol shows that
information is available such
as the operating manual or
installation manual.
Do not cover it.
This symbol shows that the
operation manual should be
read carefully.
This symbol shows that a
service personnel should be
handling this equipment with
reference to the installation
manual.
(For R32/ R290 gas type)
This symbol
shows that this
appliance used
a flammable
refrigerant. If
the refrigerant
is leaked and
exposed to an
external ignition
source, there is a
risk of fire.
CONTENTS
1 Safety precautions 6
2 Unit specifications and features 15
2.1 Indoor unit display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Operating temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3 Inverter split type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4 Fixed-speed type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.5 Other features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.6 Manual operation (without remote) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.7 Install the HomeWhiz kit (wireless module) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3 Care and maintenance 21
3.1 Cleaning your indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.2 Cleaning your air filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.3 Maintenance — long periods of non-use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.4 Maintenance – pre-season inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4 Troubleshooting 24
4.1 Common issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5 Accessories 28
6 Installation summary - indoor unit 30
7 Unit parts 31
8 Indoor unit installation 32
8.1 Installation instructions - Indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
9 Outdoor unit installation 41
9.1 Installation instructions — outdoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4 / 196 EN Split type air conditioner / User Manual
CONTENTS
10 Refrigerant piping connection 46
10.1 Connection instructions – refrigerant piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
10.2 Instructions for connecting piping to outdoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
11 Air evacuation 50
11.1 Preparations and precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
11.2 Evacuation instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
11.3 Note on adding refrigerant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
12 Electrical and gas leak checks 52
12.1 Before test run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
12.2 Electrical safety checks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
12.3 Gas leak checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
13 Test Run 54
13.1 Test run instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
14 European disposal guideline 55
15 Installation instructions 56
15.1 F-Gas instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
16 Specifications 57
16.1 BBFDA & BBVHM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Split type air conditioner / User Manual 5 / 196 EN
6 / 196 EN Split type air conditioner / User Manual
Warning
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the appliance.
Cleaning and user maintenance
shall not be made by children
without supervision (European
Union countries).
This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
Children should be supervised to
ensure that they do not play with
the appliance.
Warnings for product
use
•
If an abnormal situation
arises (like a burning smell),
immediately turn off the unit and
disconnect the power. Call your
dealer for instructions to avoid
electric shock, fire or injury.
•
Do not insert fingers, rods or
other objects into the air inlet
or outlet. This may cause injury,
since the fan may be rotating at
high speeds.
•
Do not use flammable sprays
such as hair spray, lacquer or
paint near the unit. This may
cause fire or combustion.
•
Do not operate the air
conditioner in places near or
around combustible gases.
Emitted gas may collect around
the unit and cause explosion.
1 Safety precautions
10 / 196 EN Split type air conditioner / User Manual
HygieneMax(UV-C lamp)
(Applicable to the unit
contains HygieneMax
feature only)
This appliance contains a
HygieneMax(UV-C lamp). Please
read the following instructions
before opening the appliance.
1. Do not operate
HygieneMax(UV-C lamp)
outside of the appliance.
2. Appliances that are obviously
damaged must not be
operated.
3. Unintended use of the appliance
or damage to the housing
may result in the escape of
dangerous UV-C radiation.
UV-C radiation may, even in
small doses, cause harm to the
eyes and skin.
4. The appliance must be
disconnected from the supply
mains before cleaning your unit
or any other maintenance.
5. UV-C barriers bearing the
ultraviolet radiation hazard
symbol should not be removed.
A
Warning: This
appliance contains an
UV emitter. Do not stare
at the light source.
Warnings for product
installation
1. Installation must be performed
by an authorized dealer or
specialist. Defective installation
can cause water leakage,
electrical shock, or fire.
2. Installation must be performed
according to the installation
instructions. Improper
installation can cause water
leakage, electrical shock, or fire.
1 Safety precautions
Split type air conditioner / User Manual 11 / 196 EN
3. Contact an authorized service
technician for repair or
maintenance of this unit. This
appliance shall be installed in
accordance with national wiring
regulations.
4. Only use the included
accessories, parts, and
specified parts for installation.
Using non-standard parts can
cause water leakage, electrical
shock, fire, and can cause the
unit to fail.
5. Install the unit in a firm location
that can support the unit’s
weight. If the chosen location
cannot support the unit’s
weight, or the installation is not
done properly, the unit may
drop and cause serious injury
and damage.
6. Install drainage piping according
to the instructions in this
manual. Improper drainage may
cause water damage to your
home and property.
7. For units that have an auxiliary
electric heater, install the do not
unit within 1 meter (3 feet) of
any combustible materials.
8. Do not install the unit in a
location that may be exposed
to combustible gas leaks. If
combustible gas accumulates
around the unit, it may cause
fire.
9. Do not turn on the power until
all work has been completed.
10. When moving or relocating
the air conditioner, consult
experienced service
technicians for disconnection
and reinstallation of the unit.
11. How to install the appliance
to its support, please read
the information for details in
“indoor unit installation” and
“outdoor unit installation”
sections.
1 Safety precautions
12 / 196 EN Split type air conditioner / User Manual
Note about fluorinated
gasses (Not applicable
to the unit using R290
Refrigerant)
1. This air-conditioning unit
contains fluorinated greenhouse
gasses. For specific information
on the type of gas and the
amount, please refer to the
relevant label on the unit itself
or the “User Manual - Product
Fiche“ in the packaging of the
outdoor unit. (European Union
products only).
2. Installation, service,
maintenance and repair of this
unit must be performed by a
certified technician.
3. Product uninstallation and
recycling must be performed by
a certified technician.
4. For equipment that contains
fluorinated greenhouse gases
in quantities of 5 tonnes of
CO2 equivalent or more, but
of less than 50 tonnes of CO2
equivalent, If the system has a
leak-detection system installed,
it must be checked for leaks at
least every 24 months.
5. When the unit is checked for
leaks, proper record-keeping
of all checks is strongly
recommended.
Warning for Using R32/
R290 Refrigerant
•
When flammable refrigerant
are employed, appliance shall
be stored in a well -ventilated
area where the room size
corresponds to the room area as
specifiec for operation.
For R32 frigerant models:
Appliance shall be installed,
operated and stored in a room
with a floor area larger than
4m2.
For R290 refrigerant models,
appliance shall be installed,
operated and stored in a room
with a floor area larger than:
<=9000Btu/h units: 13m2
1 Safety precautions
Split type air conditioner / User Manual 13 / 196 EN
>9000Btu/h and <=12000Btu/h
units: 17m2
>12000Btu/h and
<=18000Btu/h units: 26m2
>18000Btu/h and
<=24000Btu/h units: 35m2
•
Reusable mechanical
connectors and flared joints are
not allowed indoors.
(EN Standard Requirements).
•
Mechanical connectors used
indoors shall have a rate of not
more than 3g/year at 25% of the
maximum allowable pressure.
When mechanical connectors
are reused indoors, sealing parts
shall be renewed. When flared
joints are reused indoors, the
flare part shall be re-fabricated.
(UL Standard Requirements)
•
When mechanical connectors
are reused indoors, sealing parts
shall be renewed. When flared
joints are reused indoors, the
flare part shall be re-fabricated.
(IEC Standard Requirements)
•
Mechanical connectors used
indoors shall comply with
ISO 14903.
European disposal
guidelines
This marking shown on the
product or its literature, indicates
that waste electrical and eletrical
equipment should not be mixed
with general household waste.
Correct disposal
of this product
(Waste electrical
& Electronic
equipment)
This appliance contains
refrigerant and other potentially
hazardous materials. When
disposing of this appliance, the
law requires special collection
and treatment. dispose of Do not
this product as household waste
or unsorted municipal waste.
When disposing of this appliance,
you have the following options:
1 Safety precautions
14 / 196 EN Split type air conditioner / User Manual
•
Dispose of the appliance at
designated municipal electronic
waste collection facility.
•
When buying a new appliance,
the retailer will take back the old
appliance free of charge.
•
The manufacturer will take back
the old appliance free of charge.
(for some countries)
•
Sell the appliance to certified
scrap metal dealers. (for some
countries)
C
Special notice:
Disposing of this
appliance in the
forest or other
natural surroundings
endangers your
health and is bad
for the environment.
Hazardous substances
may leak into the
ground water and
enter the food chain.
1 Safety precautions
Split type air conditioner / User Manual 15 / 196 EN
2.1 Indoor unit display
C
Note: Different models have different front panels and display windows. Not all the display
codes describing below are available for the air conditioner you purchased. Please check
the indoor display window of the unit you purchased.
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be
slightly different. The actual shape shall prevail.
(A) (B)
Front panel
Louver
Power cable (some units)
Remote control Remote control holder
(some units)
Display window
“fresh“ when Fresh or HygieneMax (if any) feature is activated (some units)
“defrost“ when defrost feature is activated.
“run“ when the unit is on.
“timer“ when TIMER is set.
“ “ when Wireless Control feature is activated (some units)
“ “ Displays temperature, operation feature and error codes:
•
“ “ for 3 seconds when:
•
TIMER ON is set (if the unit is OFF, “ “ remains on when TIMER
ON is set)
•
FRESH, HygieneMax, SWING, TURBO, ECO, or SILENCE feature is turned on
“ “ for 3 seconds when:
•
TIMER OFF is set
•
FRESH, HygieneMax, SWING, TURBO, ECO, or SILENCE feature is turned off
•
“ “ when defrosting
•
“ “ when 8°C heating feature is turned on (some units)
•
“ “ when GoClean feature is turned on (For Inverter split type)
when unit is SelfClean+ (For Fixed-speed type)
fresh defrost run timer
Functional filter
(On back of main filter - some units)
Display Code
Meanings
2 Unit specifications and features
16 / 196 EN Split type air conditioner / User Manual
2.2 Operating temperature
When your air conditioner is used outside of
the following temperature ranges, certain safety
protection features may activate and cause the
unit to disable.
2.3 Inverter split type
COOL mode HEAT mode DRY mode
Room
Temperature
16°C - 32°C
(60°F - 90°F)
0°C - 30°C
(32°F - 86°F)
10°C - 32°C
(50°F - 90°F)
Outdoor
Temperature
0°C - 50°C (32°F - 122°F) -15°C - 24°C
(5°F - 75°F)
for some model
-20°C - 24°C
(-4°F - 75°F)
0°C - 50°C
(32°F - 122°F)
-15°C - 50°C (5°F - 122°F)
(For models with low temp.
cooling systems.)
0°C - 52°C (32°F - 126°F)
(For special tropical models)
0°C - 52°C
(32°F - 126°F)
(For special tropical
models)
For outdoor units with auxiliary electric heater When outside temperature is below 0°C (32°F), we
strongly recommend keeping the unit plugged in
at all time to ensure smooth ongoing performance.
2.4 Fixed-speed type
COOL mode HEAT mode DRY mode
Room
Temperature 16°C-32°C (60°F-90°F) 0°C-30°C
(32°F-86°F) 10°C-32°C (50°F-90°F)
Outdoor
Temperature
18°C-43°C (64°F-109°F)
-7°C-24°C
(19°F-75°F)
11°C-43°C (52°F-109°F)
-7°C-43°C (19°F- 109°F)
(For models with low-temp cooling
systems)
18°C-43°C (64°F-109°F)
18°C-52°C (64°F -126°F)
(For special tropical models)
18°C-52°C (64°F- 126°F)
(For special tropical models)
2 Unit specifications and features
Split type air conditioner / User Manual 17 / 196 EN
C
Note: Room relative humidity less
than 80%. If the air conditioner
operates in excess of this figure,
the surface of the air conditioner
may attract condensation. Please
sets the vertical air flow louver to
its maximum angle (vertically to the
floor), and set HIGH fan mode.
To further optimize the performance of your
unit, do the following:
•
Keep doors and windows closed.
•
Limit energy usage by using TIMER ON and
TIMER OFF functions.
•
Do not block air inlets or outlets.
•
Regularly inspect and clean air filters.
A guide on using the infrared remote is not
included in this literature package. Not all the
functions are available for the air conditioner,
please check the indoor display and remote
control of the unit you purchased.
2.5 Other features
•
Auto-restart (some units)
If the unit loses power, it will automatically
restart with the prior settings once power has
been restored.
•
Wireless control (some units)
Wireless control allows you to control your air
conditioner using your mobile phone and a
wireless connection.
For the USB device access, replacement,
maintenance operations must be carried out by
professional staff.
•
Louver angle memory (some units)
When turning on your unit, the louver will
automatically resume its former angle.
•
GoClean function (some units)
-
The GoClean Technology washes away dust
when it adheres to the heat exchanger by
automatically freezing and then rapidly thawing
the frost. A “pi-pi” sound will be heard. The
operation is used to produce more condensed
water to improve the cleaning effect, and the
cold air will blow out. After cleaning, the internal
wind wheel then keeps operating with hot air to
blow-dry the evaporator, thus keeping the inside
clean.
-
When this function is turned on, the indoor unit
display window appears “CL“ , after finish whole
process, the unit will turn off automatically and
cancel GoClean function.
-
For some units, the system will start high-
temperature cleaning process, and the
temperature of air outlet is very high. Please
keep away from it. And this would lead to the
rising of the room temperature.
•
Breeze away (some units)
This feature avoids direct air flow blowing on
the body and make you feel indulging in silky
coolness.
•
Refrigerant leakage detection (some units)
The indoor unit will automatically display
“ELOC”or flash LEDS (model dependent) when
it detects refrigerant leakage. Please call service
for this defective.
2 Unit specifications and features
18 / 196 EN Split type air conditioner / User Manual
•
Sleep operation
•
The SLEEP function is used to decrease energy
use while you sleep (and don’t need the same
temperature settings to stay comfortable).
This function can only be activated via remote
control. And the Sleep function is not available
in FAN or DRY mode.
•
Press the button when you are ready SLEEP
to go to sleep. When in COOL mode, the unit
will increase the temperature by 1°C (2°F) after
1 hour, and will increase an additional 1°C (2°F)
after another hour. When in HEAT mode, the
unit will decrease the temperature by 1°C (2°F)
after 1 hour, and will decrease an additional 1°C
(2°F) after another hour.
The sleep feature will stop after 8 hours and the
system will keep running with final situation.
1hr 1hr
SLEEP Operation
Saving energy during sleep
Cool mode (+1°C/2°F) per hour
for the first two hours
Heat mode (-1°C/2°F) per hour
for the first two hours
Set
temperature
Keep
running
C
Note: For multi-split air
condtioners, the following
functions are not available:
SelfClean+, GoClean function,
Silence feature, Breeze away
function, Refrigerant leakage
detection function and Eco
feature.
•
Setting Angle of Air Flow
2.5.1 Setting vertical angle of air
flow (See Fig.A)
While the unit is on, use the button on SWING
remote control to set the direction (vertical angle)
of airflow. Please refer to the Remote Control
Manual for details.
Range
C
Note: Do not move louver by
hand. This will cause the louver to
become out of sync. If this occurs,
turn off the unit and unplug it for a
few seconds, then restart the unit.
This will reset the louver.
Fig. A
2 Unit specifications and features
Split type air conditioner / User Manual 19 / 196 EN
C
Note on louver angles:
When using COOL or DRY mode,
do not set louver at too vertical an
angle for long periods of time. This
can cause water to condense on
the louver blade, which will drop
on your floor or furnishings.
When using COOL or HEAT mode,
setting the louver at too vertical an
angle can reduce the performance
of the unit due to restricted air
flow.
2.5.2 Setting horizontal angle of
air flow
The horizontal angle of the airflow must be set
manually. Grip the deflector rod (See ) and Fig.B
manually adjust it to your preferred direction. For
some units, the horizontal angle of the airflow
can be set by remote control. please refer to the
Remote Control Manual.
A
Warning:
Do not put your fingers in or
near the blower and suction
side of the unit. The high-
speed fan inside the unit may
cause injury.
Deflector
rod
Fig. B
2 Unit specifications and features
20 / 196 EN Split type air conditioner / User Manual
2.6 Manual operation
(without remote)
A
Warning:
The manual button is
intended for testing
purposes and emergency
operation only. Please do not
use this function unless the
remote control is lost and it
is absolutely necessary. To
restore regular operation,
use the remote control to
activate the unit. Unit must
be turned off before manual
operation.
To operate your unit manually:
1. Open the front panel of the indoor unit.
2. Locate the on the right-Manual control button
hand side of the unit.
3. Press the Manual control button one time to
activate FORCED AUTO mode.
4. Press the Manual control button again to
activate FORCED COOLING mode.
5. Press the Manual control button a third time to
turn the unit off.
6. Close the front panel.
Manual control button
2.7 Install the HomeWhiz kit
(wireless module)
1. Remove the protective cap of the HomeWhiz kit
(wireless module)
2. Open the front panel and insert the HomeWhiz
kit (wireless module) into the reserved interface.
Insert
A
Warning:
This interface is only
compatible with HomeWhiz
kit (wireless module) provided
by the manufacturer.
2 Unit specifications and features
Split type air conditioner / User Manual 21 / 196 EN
3.1 Cleaning your indoor unit
A
Before cleaning or
maintenance:
Always turn off your air
conditioner system and
disconnect its power
supply before cleaning or
maintenance.
A
Warning:
Only use a soft, dry cloth to
wipe the unit clean. If the unit
is especially dirty, you can
use a cloth soaked in warm
water to wipe it clean.
•
Do not use chemicals or
chemically treated cloths
to clean the unit.
•
Do not use benzene, paint
thinner, polishing powder
or other solvents to clean
the unit. They can cause
the plastic surface to crack
or deform.
•
Do not use water hotter
than 40°C (104°F) to clean
the front panel. This can
cause the panel to deform
or become discolored.
3.2 Cleaning your air filter
A clogged air conditioner can reduce the cooling
efficiency of your unit, and can also be bad for
your health. Make sure to clean the filter once
every two weeks.
1. Lift the front panel of the indoor unit.
2. First press the tab on the end of filter to loosen
the buckle, lift it up, then pull it towards yourself.
3. Now pull the filter out
4. If your filter has a small air freshening filter,
unclip it from the larger filter. Clean this air
freshening filter with a hand-held vacuum.
5. Clean the large air filter with warm, soapy water.
Be sure to use a mild detergent.
6. Rinse the filter with fresh water, then shake off
excess water.
7. Dry it in a cool, dry place, and refrain from
exposing it to direct sunlight.
8. When dry, re-clip the air freshening filter to the
larger filter, then slide it back into the indoor
unit.
9. Close the front panel of the indoor unit.
3 Care and maintenance
Split type air conditioner / User Manual 23 / 196 EN
3 Care and maintenance
3.3 Maintenance — long
periods of non-use
If you plan not to use your air conditioner for an
extended period of time, do the following:
Clean all filters
Turn off the unit and
disconnect the power
Turn on FAN function until
unit dries out completely
Remove batteries from
remote control
3.4 Maintenance – pre-
season inspection
After long periods of non-use, or before periods of
frequent use, do the following:
Check for damaged wires
Check for leaks
Clean all filters
Replace batteries
Make sure nothing is blocking all air inlets and outlets
24 / 196 EN Split type air conditioner / User Manual
A
Safety precautions:
If ANY of the following conditions occurs, turn off your unit immediately!
•
The power cord is damaged or abnormally warm
•
You smell a burning odor
•
The unit emits loud or abnormal sounds
•
A power fuse blows or the circuit breaker frequently trips
•
Water or other objects fall into or out of the unit
Do not attempt to fix these yourself! Contact an authorızed service
provider immedıately!
4.1 Common issues
The following problems are not a malfunction and in most situations will not require repairs.
Issue Possible causes
Unit does not turn on
when pressing ON/OFF
button
The Unit has a 3-minute protection feature that prevents the unit from
overloading. The unit cannot be restarted within three minutes of being
turned off.
The unit changes from
COOL/HEAT mode to
FAN mode
The unit may change its setting to prevent frost from forming on the
unit. Once the temperature increases, the unit will start operating in the
previously selected mode again.
The set temperature has been reached, at which point the unit turns off
the compressor. The unit will continue operating when the temperature
fluctuates again.
The indoor unit emits
white mist
In humid regions, a large temperature difference between the room’s air
and the conditioned air can cause white mist.
Both the indoor and
outdoor units emit white
mist
When the unit restarts in HEAT mode after defrosting, white mist may be
emitted due to moisture generated from the defrosting process.
The indoor unit makes
noises
A rushing air sound may occur when the louver resets its position.
A squeaking sound may occur after running the unit in HEAT mode due to
expansion and contraction of the unit’s plastic parts.
4 Troubleshooting
Split type air conditioner / User Manual 25 / 196 EN
Issue Possible causes
Both the indoor unit
and outdoor unit make
noises
Low hissing sound during operation: This is normal and is caused by
refrigerant gas flowing through both indoor and outdoor units.
Low hissing sound when the system starts, has just stopped running, or
is defrosting: This noise is normal and is caused by the refrigerant gas
stopping or changing direction.
Squeaking sound: Normal expansion and contraction of plastic and
metal parts caused by temperature changes during operation can cause
squeaking noises.
The outdoor unit makes
noises The unit will make different sounds based on its current operating mode.
Dust is emitted from
either the indoor or
outdoor unit
The unit may accumulate dust during extended periods of non-use,
which will be emitted when the unit is turned on. This can be mitigated by
covering the unit during long periods of inactivity.
The unit emits a bad
odor
The unit may absorb odors from the environment (such as furniture,
cooking, cigarettes, etc.) which will be emitted during operations.
The unit’s filters have become moldy and should be cleaned.
The fan of the outdoor
unit does not operate
During operation, the fan speed is controlled to optimize product
operation.
Operation is erratic,
unpredictable, or unit is
unresponsive
Interference from cell phone towers and remote boosters may cause the
unit to malfunction.
In this case, try the following:
•
Disconnect the power, then reconnect.
•
Press ON/OFF button on remote control to restart operation.
C
Note: If problem persists, contact a local dealer or your nearest customer service center.
Provide them with a detailed description of the unit malfunction as well as your model
number.
4 Troubleshooting
26 / 196 EN Split type air conditioner / User Manual
When troubles occur, please check the following points before contacting a repair company.
Problem Possible causes Solution
Poor cooling
performance
Temperature setting may be higher
than ambient room temperature Lower the temperature setting
The heat exchanger on the indoor
or outdoor unit is dirty Clean the affected heat exchanger
The air filter is dirty Remove the filter and clean it
according to instructions
The air inlet or outlet of either unit
is blocked
Turn the unit off, remove the
obstruction and turn it back on
Doors and windows are open
Make sure that all doors and
windows are closed while operating
the unit
Excessive heat is generated by
sunlight
Close windows and curtains during
periods of high heat or bright
sunshine
Too many sources of heat in
the room (people, computers,
electronics, etc.)
Reduce amount of heat sources
Low refrigerant due to leak or long-
term use
Check for leaks, re-seal if
necessary and top off refrigerant
SILENCE function is activated
(optional function)
SILENCE function can lower
product performance by reducing
operating frequency. Turn off
SILENCE function.
The unit is not working
Power failure Wait for the power to be restored
The power is turned off Turn on the power
The fuse is burned out Replace the fuse
Remote control batteries are dead Replace batteries
The Unit’s 3-minute protection has
been activated
Wait three minutes after restarting
the unit
Timer is activated Turn timer off
4 Troubleshooting
Split type air conditioner / User Manual 27 / 196 EN
Problem Possible causes Solution
The unit starts and
stops frequently
There’s too much or too little
refrigerant in the system
Check for leaks and recharge the
system with refrigerant.
Incompressible gas or moisture has
entered the system
Evacuate and recharge the system
with refrigerant
The compressor is broken Replace the compressor
The voltage is too high or too low Install a manostat to regulate the
voltage
Poor heating
performance
The outdoor temperature is
extremely low Use auxiliary heating device
Cold air is entering through doors
and windows
Make sure that all doors and
windows are closed during use
Low refrigerant due to leak or long-
term use
Check for leaks, re-seal if
necessary and top off refrigerant
Indicator lamps
continue flashing The unit may stop operation or continue to run safely. If the indicator
lamps continue to flash or error codes appear, wait for about 10 minutes.
The problem may resolve itself.
If not, disconnect the power, then connect it again. Turn the unit on. If
the problem persists, disconnect the power and contact your nearest
customer service center.
Error code appears and
begins with the letters as
the following in the window
display of indoor unit:
•
E(x), P(x), F(x)
•
EH(xx), EL(xx), EC(xx)
•
PH(xx), PL(xx), PC(xx)
C
Note: If your problem persists after performing the checks and diagnostics above, turn off
your unit immediately and contact an authorized service center.
4 Troubleshooting
28 / 196 EN Split type air conditioner / User Manual
The air conditioning system comes with the following accessories. Use all of the installation parts and
accessories to install the air conditioner. Improper installation may result in water leakage, electrical
shock and fire, or cause the equipment to fail. The items are not included with the air conditioner must be
purchased separately.
Name of
accessories Qty (pc) Shape Name of accessories Qty (pc) Shape
Manual 2~3 Remote controller 1
Drain joint (for
cooling & heating
models)
1 Battery 2
Seal (for cooling &
heating models) 1Remote controller
holder(optional) 1
Mounting plate 1
Fixing screw for
remote controller
holder(optional)
2
Anchor
5~8
(depending
on models)
Small Filter
(Need to be installed
on the back of main air
filter by the authorized
technician while installing
the machine)
1~2
(depending
on models)
Mounting plate
fixing screw
5~8
(depending
on models)
Wireless USB kit
1 (For Wifi
models
only)
5 Accessories
Split type air conditioner / User Manual 29 / 196 EN
Name Shape Quantity (PC)
Connecting pipe
assembly
Liquid side Ø6.35 (1/4 in)
Parts you must purchase
separately. Consult the dealer
about the proper pipe size of
the unit you purchased.
Ø9.52 (3/8in)
Gas side
Ø9.52 (3/8in)
Ø12.7 (1/2in)
Ø16 (5/8in)
Ø19 (3/4in)
Magnetic ring and belt
(if supplied ,please refer
to the wiring diagram to
install it on the connective
cable.)
1 2 3
Pass the belt through the
hole of the Magnetic ring
to fix it on the cable
Varies by model
5 Accessories
30 / 196 EN Split type air conditioner / User Manual
123
4
15cm (5.9in)
4 5 6
78
9
Select installation location
Drill wall hole
Prepare drain hose
Determine wall hole position
Connect piping
Wrap piping and cable
(not applicable for some locations in North America)
Attach mounting plate
Connect wiring
(not applicable for some
locations in North America)
Mount indoor unit
15cm (5.9in)
2.3m (90.55in)
12cm
(4.75in)
12cm
(4.75in)
6 Installation summary - indoor unit
Split type air conditioner / User Manual 31 / 196 EN
C
Note: The installation must be performed in accordance with the requirement of local and
national standards. The installation may be slightly different in different areas.
（ ） （ ）1 2
Air-break switch
1. Wall mounting plate
2. Front panel
3. Power cable (some units)
4. Louver
5. Functional filter (On back of main filter - some
units)
6. Drainage pipe
7. Signal cable
8. Refrigerant piping
9. Remote controller
10. Remote controller holder (some units)
11. Outdoor unit power cable (some units)
C
Note on illustrations:
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor
unit may be slightly different. The actual shape shall prevail.
7 Unit parts
32 / 196 EN Split type air conditioner / User Manual
8.1 Installation instructions -
Indoor unit
8.1.1 Prior to installation
Before installing the indoor unit, refer to the label
on the product box to make sure that the model
number of the indoor unit matches the model
number of the outdoor unit.
Step 1: Select installation location
Before installing the indoor unit, you must
choose an appropriate location. The following are
standards that will help you choose an appropriate
location for the unit.
Proper installation locations meet the following
standards:
•
Good air circulation
•
Convenient drainage
•
Noise from the unit will not disturb other people
•
Firm and solid—the location will not vibrate
•
Strong enough to support the weight of the unit
•
A location at least one meter from all other
electrical devices (e.g., TV, radio, computer)
Do not install unit in the following locations:
•
Near any source of heat, steam, or combustible
gas
•
Near flammable items such as curtains or
clothing
•
Near any obstacle that might block air
circulation
•
Near the doorway
•
In a location subject to direct sunlight
C
Note about wall hole:
If there is no fixed refrigerant
piping:
While choosing a location, be
aware that you should leave ample
room for a wall hole (see Drill wall
hole for connective piping step)
for the signal cable and refrigerant
piping that connect the indoor
and outdoor units. The default
position for all piping is the right
side of the indoor unit (while facing
the unit). However, the unit can
accommodate piping to both the
left and right.
Refer to the following diagram to ensure
proper distance from walls and ceiling:
15cm (5.9in) or more
2.3m (90.55in) or more
12cm (4.75in)
or more
12cm (4.75in)
or more
Step 2: Attach mounting plate to wall
The mounting plate is the device on which you will
mount the indoor unit.
•
Remove the screw that attaches the mounting
plate to the back of the indoor unit.
8 Indoor unit installation
Split type air conditioner / User Manual 33 / 196 EN
•
Secure the mounting plate to the wall with the
screws provided. Make sure that mounting plate
is flat against the wall.
C
Note for concrete or brick walls:
If the wall is made of brick,
concrete, or similar material, drill
5mm-diameter (0.2in-diameter)
holes in the wall and insert the
sleeve anchors provided. Then
secure the mounting plate to the
wall by tightening the screws
directly into the clip anchors.
Step 3: Drill wall hole for connective piping
1. Determine the location of the wall hole based
on the position of the mounting plate. Refer to
Mounting plate dimensions.
2. Using a 65mm (2.5in) or 90mm (3.54in)
(depending on models) core drill, drill a hole in
the wall. Make sure that the hole is drilled at
a slight downward angle, so that the outdoor
end of the hole is lower than the indoor end
by about 5mm to 7mm (0.2-0.275in). This will
ensure proper water drainage.
3. Place the protective wall cuff in the hole. This
protects the edges of the hole and will help seal
it when you finish the installation process.
A
Warning:
When drilling the wall
hole, make sure to avoid
wires, plumbing, and other
sensitive components.
Wall
Indoor Outdoor
5-7mm
(0.2-0.275in)
8.1.2 Mounting plate dimensions
Different models have different mounting plates.
For the different customization requirements,
the shape of the mounting plate may be slightly
different. But the installation dimensions are the
same for the same size of indoor unit.
See type A and type B for example:
Correct orientation of mounting plate
Type A Type B
8 Indoor unit installation
34 / 196 EN Split type air conditioner / User Manual
348.4mm (13.7in)
403mm (15.9in)
418mm (16.5in)
527mm (20.7in)
722mm (28.5in)
805mm (31.7in)
835mm (32.9in)
973mm(38.3in)
179mm (7.1in)
231mm (9.1in)
246mm (9.7in)
247mm (9.7in)
101mm(4.0in)
190mm (7.5in)
230mm (9.1in)
190mm(7.5in)
244mm(9.6in)
106mm(4.2in)
165mm (6.5in)
136mm (5.4in)
121mm (4.8in)
121mm (4.8in)
Model A
Model B
Model C
Model D
Indoor unit outline
Right rear wall hole
65mm (2.5in)
Right rear wall hole
65mm (2.5in)
Right rear wall hole
65mm (2.5in)
Right rear wall hole
65mm (2.5in)
Left rear wall hole
65mm (2.5in)
Left rear wall hole
65mm (2.5in)
Left rear wall hole
65mm (2.5in)
Left rear wall hole
65mm (2.5in)
290mm (11.4in)
297mm (11.7in)
297mm(11.7in)
318mm (12.5in)
49mm (1.95in)
47mm (1.8in)
47mm(1.8in)
48mm (1.9in)
29mm (1.1in)
37mm
(1.45in)
36mm
(1.4in)
36mm
(1.4in)
37mm (2.1in)
49mm
(1.95in)
53mm
(2.1in)
53mm
(2.1in)
48mm
(1.9in)
603mm (23.7in)
643.6mm (25.3in)
1082mm (42.6in)
1259mm (49.55in)
257mm (10.1in)
52mm (2.05in)
52mm (2.05in)
199mm (7.8in)
129mm (5.1in) 322mm (12.7in)
332mm (13.05in)
172mm (6.8in)
389mm (15.3in)
Model E
Model F
Indoor unit outline
Right rear wall hole
90mm (3.54in)
Right rear wall hole
90mm (3.54in)
Left rear wall hole
90mm (3.54in)
Left rear wall hole
90mm (3.54in)
338mm (13.3in)
362mm (14.25in) 54mm (2.1in)
55mm
(2.2in)
54mm
(2.1in)
173mm
(6.8in)
C
Note: When the gas side
connective pipe is Ø16mm (5/8in)
or more, the wall hole should be
90mm (3.54in).
Step 4: Prepare refrigerant piping
The refrigerant piping is inside an insulating sleeve
attached to the back of the unit. You must prepare
the piping before passing it through the hole in the
wall.
1. Based on the position of the wall hole relative to
the mounting plate, choose the side from which
the piping will exit the unit.
2. If the wall hole is behind the unit, keep the
knock-out panel in place. If the wall hole is to
the side of the indoor unit, remove the plastic
knock-out panel from that side of the unit. This
will create a slot through which your piping can
exit the unit. Use needle nose pliers if the plastic
panel is too difficult to remove by hand.
8 Indoor unit installation
Split type air conditioner / User Manual 35 / 196 EN
Knock-out Panel
3. If existing connective piping is already
embedded in the wall, proceed directly to
the step. If there is no Connect drain hose
embedded piping, connect the indoor unit’s
refrigerant piping to the connective piping that
will join the indoor and outdoor units. Refer to
the Refrigerant Piping Connection section of this
manual for detailed instructions.
C
Note on piping angle:
Refrigerant piping can exit the
indoor unit from four different
angles:Left-hand side, Right-hand
side, Left rear, Right rear.
A
Warning:
Be extremely careful not to
dent or damage the piping
while bending them away
from the unit. Any dents in
the piping will affect the unit’s
performance.
Step 5: Connect drain hose
By default, the drain hose is attached to the left-
hand side of unit (when you’re facing the back
of the unit). However, it can also be attached to
the right-hand side. To ensure proper drainage,
attach the drain hose on the same side that your
refrigerant piping exits the unit. Attach drain hose
extension (purchased separately) to the end of
drain hose.
•
Wrap the connection point firmly with Teflon
tape to ensure a good seal and to prevent
leaks.
•
For the portion of the drain hose that will remain
indoors, wrap it with foam pipe insulation to
prevent condensation.
•
Remove the air filter and pour a small amount of
water into the drain pan to make sure that water
flows from the unit smoothly.
C
A note on drain hose placement:
Make sure to arrange the drain
hose according to the following
figures.
8 Indoor unit installation
36 / 196 EN Split type air conditioner / User Manual
Correct
Make sure there are no kinks
or dent in drain hose to ensure
proper drainage.
Not correct
Kinks in the drain hose will
create water traps.
Not correct
Kinks in the drain hose will
create water traps.
Not correct
Do not place the end of the
drain hose in water or in
containers that collect water.
This will prevent proper
drainage.
Plug the unused drain hole
To prevent unwanted leaks you must plug the
unused drain hole with the rubber plug provided.
Before performing any electrical work, read
these regulations
1. All wiring must comply with local and national
electrical codes, regulations and must be
installed by a licensed electrician.
2. All electrical connections must be made
according to the Electrical Connection Diagram
located on the panels of the indoor and outdoor
units.
3. If there is a serious safety issue with the power
supply, stop work immediately. Explain your
reasoning to the client, and refuse to install the
unit until the safety issue is properly resolved.
4. Power voltage should be within 90-110% of
rated voltage. Insufficient power supply can
cause malfunction, electrical shock, or fire.
5. If connecting power to fixed wiring, a surge
protector and main power switch should be
installed.
6. If connecting power to fixed wiring, a switch
or circuit breaker that disconnects all poles
and has a contact separation of at least 1/8in
(3mm) must be incorporated in the fixed wiring.
The qualified technician must use an approved
circuit breaker or switch.
7. Only connect the unit to an individual branch
circuit outlet. Do not connect another appliance
to that outlet.
8. Make sure to properly ground the air
conditioner.
9. Every wire must be firmly connected. Loose
wiring can cause the terminal to overheat,
resulting in product malfunction and possible
fire.
10. Do not let wires touch or rest against refrigerant
tubing, the compressor, or any moving parts
within the unit.
11. If the unit has an auxiliary electric heater, it
must be installed at least 1 meter (40in) away
from any combustible materials.
12. To avoid getting an electric shock, never touch
the electrical components soon after the power
supply has been turned off. After turning off the
power, always wait 10 minutes or more before
you touch the electrical components.
8 Indoor unit installation
Split type air conditioner / User Manual 37 / 196 EN
A
Warning:
Before performing any
electrical or wiring work,
turn off the main power to
the system.
Step 6: Connect signal and power cables
The signal cable enables communication between
the indoor and outdoor units. You must first
choose the right cable size before preparing it for
connection.
Cable types
•
Indoor power cable (if applicable): HO5W-F or
H05V2V2-F
•
Outdoor power cable: H07RN-F or H05RN-F
•
Signal cable: HO7RN-F
C
Note: In North America, choose
the cable type according to
the local electrical codes and
regulations.
Minimum cross-sectional area of power and
signal cables (for reference) (not applicable for
North America)
Rated current of
appliance (A)
Nominal cross-sectional
area (mm²)
> 3 and ≤ 6 0.75
> 6 and ≤ 10 1
> 10 and ≤ 16 1.5
> 16 and ≤ 25 2.5
> 25 and ≤ 32 4
> 32 and ≤ 40 6
Choose the right cable size
The size of the power supply cable, signal cable,
fuse, and switch needed is determined by the
maximum current of the unit. The maximum
current is indicated on the nameplate located on
the side panel of the unit.
C
Note: In North America, please
choose the right cable size
according to the minimum
circuit ampacity indicated on the
nameplate of the unit.
A
Warning:
All wiring must be
performed strictly in
accordance with the wiring
diagram located on the
back of the indoor unit’s
front panel.
1. Open front panel of the indoor unit.
2. Using a screwdriver, open the wire box cover
on the right side of the unit. This will reveal the
terminal block.
Front view
Terminal block
Wire cover
Screw
Cable clamp
8 Indoor unit installation
Split type air conditioner / User Manual 39 / 196 EN
Drain hose must be on bottom
Make sure that the drain hose is at the bottom of
the bundle. Putting the drain hose at the top of the
bundle can cause the drain pan to overflow, which
can lead to fire or water damage.
Do not intertwine signal cable with other wires
While bundling these items together, do not
intertwine or cross the signal cable with any other
wiring.
2. Using adhesive vinyl tape, attach the drain hose
to the underside of the refrigerant pipes.
3. Using insulation tape, wrap the signal wire,
refrigerant pipes, and drain hose tightly together.
Double-check that all items are bundled.
Do not wrap ends of piping
When wrapping the bundle, keep the ends of the
piping unwrapped. You need to access them to
test for leaks at the end of the installation process
(refer to Electrical checks and leak checks
section of this manual).
Step 8: Mount indoor unit
If you installed new connective piping to the
outdoor unit,do the following:
1. If you have already passed the refrigerant piping
through the hole in the wall, proceed to Step 4.
2. Otherwise, double-check that the ends of the
refrigerant pipes are sealed to prevent dirt or
foreign materials from entering the pipes.
3. Slowly pass the wrapped bundle of refrigerant
pipes, drain hose, and signal wire through the
hole in the wall.
4. Hook the top of the indoor unit on the upper
hook of the mounting plate.
5. Check that unit is hooked firmly on mounting
by applying slight pressure to the left and right-
hand sides of the unit. The unit should not jiggle
or shift.
6. Using even pressure, push down on the bottom
half of the unit. Keep pushing down until the unit
snaps onto the hooks along the bottom of the
mounting plate.
7. Again, check that the unit is firmly mounted by
applying slight pressure to the left and the
right-hand sides of the unit.
8 Indoor unit installation
40 / 196 EN Split type air conditioner / User Manual
If refrigerant piping is already embedded in the
wall, do the following:
1. Hook the top of the indoor unit on the upper
hook of the mounting plate.
2. Use a bracket or wedge to prop up the unit,
giving you enough room to connect the
refrigerant piping, signal cable, and drain hose.
Wedge
3. Connect drain hose and refrigerant piping
(refer to section Refrigerant piping connection
of this manual for instructions).
4. Keep pipe connection point exposed to perform
the leak test (refer to Electrical checks and
leak checks section of this manual).
5. After the leak test, wrap the connection point
with insulation tape.
6. Remove the bracket or wedge that is propping
up the unit.
7. Using even pressure, push down on the bottom
half of the unit. Keep pushing down until the unit
snaps onto the hooks along the bottom of the
mounting plate.
Unit is adjustable
Keep in mind that the hooks on the mounting
plate are smaller than the holes on the back of the
unit. If you find that you don’t have ample room
to connect embedded pipes to the indoor unit,
the unit can be adjusted left or right by about 30-
50mm (1.18-1.96in), depending on the model.
Move to left or right
30-50mm
(1.18-1.96in)
30-50mm
(1.18-1.96in)
8 Indoor unit installation
42 / 196 EN Split type air conditioner / User Manual
Step 2: Install drain joint (heat pump unit only)
Before bolting the outdoor unit in place, you must
install the drain joint at the bottom of the unit. Note
that there are two different types of drain joints
depending on the type of outdoor unit.
If the drain joint comes with a rubber seal (see
Fig. A), do the following:
1. Fit the rubber seal on the end of the drain joint
that will connect to the outdoor unit.
2. Insert the drain joint into the hole in the base
pan of the unit.
3. Rotate the drain joint 90° until it clicks in place
facing the front of the unit.
4. Connect a drain hose extension (not included)
to the drain joint to redirect water from the unit
during heating mode.
If the drain joint doesn’t come with a rubber
seal Fig. B (see ), do the following:
1. Insert the drain joint into the hole in the base
pan of the unit. The drain joint will click in place.
2. Connect a drain hose extension (not included)
to the drain joint to redirect water from the unit
during heating mode.
(A) (B)
Base pan hole of
outdoor unit
Seal
Seal
Drain joint
C
In cold climates:
In cold climates, make sure that
the drain hose is as vertical as
possible to ensure swift water
drainage. If water drains too
slowly, it can freeze in the hose
and flood the unit.
Step 3: Anchor outdoor unit
The outdoor unit can be anchored to the ground
or to a wall-mounted bracket with bolt(M10).
Prepare the installation base of the unit according
to the dimensions below.
Unit mounting dimensions
The following is a list of different outdoor unit sizes
and the distance between their mounting feet.
Prepare the installation base of the unit according
to the dimensions below.
D
W
H
Air inlet
Air inlet
Air outlet
A
B
D
9 Outdoor unit installation
44 / 196 EN Split type air conditioner / User Manual
position, and hammer expansion bolts into the
wall.
5. Check that the mounting brackets are level.
6. Carefully lift unit and place its mounting feet on
brackets.
7. Bolt the unit firmly to the brackets.
8. If allowed, install the unit with rubber gaskets to
reduce vibrations and noise.
Step 4: Connect signal and power cables
The outside unit’s terminal block is protected by
an electrical wiring cover on the side of the unit.
A comprehensive wiring diagram is printed on the
inside of the wiring cover.
A
Warning:
Before performing any
electrical or wiring work,
turn off the main power to
the system.
1. Prepare the cable for connection:
Use the right cable
Please choose the right cable refer to “Cable
types” in page 37.
Choose the right cable size
The size of the power supply cable, signal cable,
fuse, and switch needed is determined by the
maximum current of the unit. The maximum
current is indicated on the nameplate located on
the side panel of the unit.
C
Note: In North America, please
choose the right cable size
according to the Minimum
Circuit Ampacity indicated on the
nameplate of the unit.
a. Using wire strippers, strip the rubber jacket
from both ends of cable to reveal about 40mm
(1.57in) of the wires inside.
b. Strip the insulation from the ends of the wires.
c. Using a wire crimper, crimp u-lugs on the ends
of the wires.
Pay attention to live wire
While crimping wires, make sure you clearly
distinguish the Live (“L”) Wire from other wires.
A
Warning:
All wiring work must
be performed strictly in
accordance with the wiring
diagram located inside of
wire cover of the outdoor
unit.
2. Unscrew the electrical wiring cover and remove
it.
3. Unscrew the cable clamp below the terminal
block and place it to the side.
4. Connect the wire according to the wiring
diagram, and firmly screw the u-lug of each wire
to its corresponding terminal.
5. After checking to make sure every connection
is secure, loop the wires around to prevent rain
water from flowing into the terminal.
6. Using the cable clamp, fasten the cable to the
unit. Screw the cable clamp down tightly.
9 Outdoor unit installation
Split type air conditioner / User Manual 45 / 196 EN
7. Insulate unused wires with PVC electrical tape.
Arrange them so that they do not touch any
electrical or metal parts.
8. Replace the wire cover on the side of the unit,
and screw it in place.
Cover
Screw
C
Note: If the cable clamp looks
like the following, please select
the appropriate through-hole
according to the diameter of the
wire.
Buckle
Three size hole: small, large, medium
When the calbe is not fasten enough, use the
buckle to prop it up , so it can be clamped tightly.
In North America
1. Remove the wire cover from the unit by
loosening the 3 screws.
2. Dismount caps on the conduit panel.
3. Temperarily mount the conduit tubes(not
included) on the conduit panel.
4. Properly connect both the power supply and
low voltage lines to the corresponding terminals
on the terminal block.
5. Ground the unit in accordance with local codes.
6. Be sure to size each wire allowing several
inches longer than the required length for wiring.
7. Use lock nuts to secure the conduit tubes.
Connecting cable
Over 1.57in.(40mm)
Conduit panel
Wire Cover
Terminal block
Please select the appropriate through-hole
according to the diameter of the wire.
9 Outdoor unit installation
46 / 196 EN Split type air conditioner / User Manual
When connecting refrigerant piping, let do not
substances or gases other than the specified
refrigerant enter the unit. The presence of other
gases or substances will lower the unit’s capacity,
and can cause abnormally high pressure in the
refrigeration cycle. This can cause explosion and
injury.
C
Note on pipe length:
The length of refrigerant piping will
affect the performance and energy
efficiency of the unit. Nominal
efficiency is tested on units with a
pipe length of 5 meters (16.5ft)( In
North America, the standard pipe
length is 7.5m (25’)). A minimum
pipe run of 3 metres is required
to minimise vibration & excessive
noise. In special tropical area, for
the R290 refrigerant models, no
refrigerant can be added and the
maximum length of refrigerant
pipe should not exceed 10 meters
(32.8ft).
Refer to the table below for specifications on the
maximum length and drop height of piping.
Maximum length and drop height of refrigerant piping per unit model
Model Capacity (BTU/h) Max. length (m) Max. drop height (m)
R410A, R32 Inverter
split air conditioner
< 15,000 25 (82ft) 10 (33ft)
≥15,000 and < 24,000 30 (98.5ft) 20 (66ft)
≥24,000 and < 36,000 50 (164ft) 25 (82ft)
R22 Fixed-speed split air
conditioner
< 18,000 10 (33ft) 5 (16ft)
≥18,000 and < 21,000 15 (49ft) 8 (26ft)
≥21,000 and < 35,000 20 (66ft) 10 (33ft)
R410A, R32 Fixed-
speed split Air
conditioner
< 18,000 20 (66ft) 8 (26ft)
≥18,000 and < 36,000 25 (82ft) 10 (33ft)
10 Refrigerant piping connection
Split type air conditioner / User Manual 47 / 196 EN
10.1 Connection instructions –
refrigerant piping
Step 1: Cut pipes
When preparing refrigerant pipes, take extra care
to cut and flare them properly. This will ensure
efficient operation and minimize the need for future
maintenance.
1. Measure the distance between the indoor and
outdoor units.
2. Using a pipe cutter, cut the pipe a little longer
than the measured distance.
3. Make sure that the pipe is cut at a perfect 90°
angle.
90°
Oblique Rough Warped
C
Do not deform pipe while
cutting:
Be extra careful not to damage,
dent, or deform the pipe while
cutting. This will drastically reduce
the heating efficiency of the unit.
Step 2: Remove burrs
Burrs can affect the air-tight seal of refrigerant
piping connection. They must be completely
removed.
1. Hold the pipe at a downward angle to prevent
burrs from falling into the pipe.
2. Using a reamer or deburring tool, remove all
burrs from the cut section of the pipe.
Pipe
Reamer
Point down
Step 3: Flare pipe ends
Proper flaring is essential to achieve an airtight
seal.
1. After removing burrs from cut pipe, seal the
ends with PVC tape to prevent foreign materials
from entering the pipe.
2. Sheath the pipe with insulating material.
3. Place flare nuts on both ends of pipe. Make
sure they are facing in the right direction,
because you can’t put them on or change their
direction after flaring.
Flare nut
Copper pipe
4. Remove PVC tape from ends of pipe when
ready to perform flaring work.
5. Clamp flare form on the end of the pipe. The
end of the pipe must extend beyond the
edge of the flare form in accordance with the
dimensions shown in the table below.
10 Refrigerant piping connection
48 / 196 EN Split type air conditioner / User Manual
Piping extension beyond flare form
Outer diameter
of pipe (mm)
A (mm)
Min. Max.
Ø 6.35 (Ø 0.25”) 0.7 (0.0275”) 1.3 (0.05”)
Ø 9.52 (Ø 0.375”) 1.0 (0.04”) 1.6 (0.063”)
Ø12.7 ( Ø 0.5”) 1.0 (0.04”) 1.8 (0.07”)
Ø 16 ( Ø 0.63”) 2.0 (0.078”) 2.2 (0.086”)
Ø 19 (Ø 0.75”) 2.0 (0.078”) 2.4 (0.094”)
A
Flare form
Pipe
6. Place flaring tool onto the form.
7. Turn the handle of the flaring tool clockwise until
the pipe is fully flared.
8. Remove the flaring tool and flare form, then
inspect the end of the pipe for cracks and even
flaring.
Step 4: Connect pipes
When connecting refrigerant pipes, be careful not
to use excessive torque or to deform the piping in
any way. You should first connect the low-pressure
pipe, then the high-pressure pipe.
Minimum bend radius
When bending connective refrigerant piping, the
minimum bending radius is 10 cm.
≥10cm (4in)Radius
Instructions for connecting piping to indoor
unit
1. Align the center of the two pipes that you will
connect.
Indoor unit tubing Flare nut Pipe
2. Tighten the flare nut as tightly as possible by
hand.
3. Using a spanner, grip the nut on the unit tubing.
4. While firmly gripping the nut on the unit tubing,
use a torque wrench to tighten the flare nut
according to the torque values in the Torque
requirements table below. Loosen the flaring
nut slightly, then tighten again.
10 Refrigerant piping connection
Split type air conditioner / User Manual 49 / 196 EN
Torque requirements
Outer diameter of
pipe (mm)
Tightening torque (N•cm) Flare dimension(B)
(mm)
Flare shape
Ø 6.35 (Ø 0.25”) 18~20 (180~200kgf.cm) 8.4~8.7 (0.33~0.34”)
R0.4~0.8
45°±2
90 °
±4
B
Ø 9.52 (Ø 0.375”) 32~39 (320~390kgf.cm) 13.2~13.5 (0.52~0.53”)
Ø 12.7 (Ø 0.5”) 49~59 (490~590kgf.cm) 16.2~16.5 (0.64~0.65”)
Ø 16 (Ø 0.63”) 57~71 (570~710kgf.cm) 19.2~19.7 (0.76~0.78”)
Ø 19 (Ø 0.75”) 67~101 (670~1010kgf.cm) 23.2~23.7 (0.91~0.93”)
C
Do not use excessive torque:
Excessive force can break the nut
or damage the refrigerant piping.
You must not exceed torque
requirements shown in the table
above.
10.2 Instructions for
connecting piping to
outdoor unit
1. Unscrew the cover from the packed valve on
the side of the outdoor unit.
2. Remove protective caps from ends of valves.
3. Align flared pipe end with each valve, and
tighten the flare nut as tightly as possible by
hand.
4. Using a spanner, grip the body of the valve. Do
not grip the nut that seals the service valve.
Valve cover
5. While firmly gripping the body of the valve, use a
torque wrench to tighten the flare nut according
to the correct torque values.
6. Loosen the flaring nut slightly, then tighten
again.
7. Repeat Steps 3 to 6 for the remaining pipe.
C
Use spanner to grip main body
of valve:
Torque from tightening the flare nut
can snap off other parts of valve.
10 Refrigerant piping connection
50 / 196 EN Split type air conditioner / User Manual
11.1 Preparations and
precautions
Air and foreign matter in the refrigerant circuit
can cause abnormal rises in pressure, which can
damage the air conditioner, reduce its efficiency,
and cause injury. Use a vacuum pump and
manifold gauge to evacuate the refrigerant circuit,
removing any non-condensable gas and moisture
from the system.
Evacuation should be performed upon initial
installation and when unit is relocated.
Before performing evacuation
•
Check to make sure the connective pipes
between the indoor and outdoor units are
connected properly.
•
Check to make sure all wiring is connected
properly.
11.2 Evacuation instructions
1. Connect the charge hose of the manifold
gauge to service port on the outdoor unit’s low
pressure valve.
2. Connect another charge hose from the manifold
gauge to the vacuum pump.
3. Open the Low Pressure side of the manifold
gauge. Keep the High Pressure side closed.
4. Turn on the vacuum pump to evacuate the
system.
5. Run the vacuum for at least 15 minutes, or until
the Compound Meter reads -76cmHG (-10 5Pa).
Manifold gauge
Compound gauge
-76cmHg
Low pressure valve
Pressure hose/
Charge hose
High pressure valve
Charge hose
Vacuum
pump
Low pressure valve
Pressure gauge
6. Close the Low Pressure side of the manifold
gauge, and turn off the vacuum pump.
7. Wait for 5 minutes, then check that there has
been no change in system pressure.
8. If there is a change in system pressure, refer
to Gas Leak Check section for information on
how to check for leaks. If there is no change
in system pressure, unscrew the cap from
the packed valve (high pressure valve). Insert
hexagonal wrench into the packed valve (high
pressure valve) and open the valve by turning
the wrench in a 1/4 counterclockwise turn.
Listen for gas to exit the system, then close the
valve after 5 seconds.
9. Watch the Pressure Gauge for one minute to
make sure that there is no change in pressure.
The Pressure Gauge should read slightly higher
than atmospheric pressure.
10. Remove the charge hose from the service port.
Flare nut
Cap
Valve stem
Valve body
11 Air evacuation
Split type air conditioner / User Manual 51 / 196 EN
11. Using hexagonal wrench, fully open both the
high pressure and low pressure valves.
12. Tighten valve caps on all three valves (service
port, high pressure, low pressure) by hand. You
may tighten it further using a torque wrench if
needed.
C
Open valve stems gently:
When opening valve stems, turn
the hexagonal wrench until it hits
against the stopper. Do not try to
force the valve to open further.
11.3 Note on adding
refrigerant
Some systems require additional charging
depending on pipe lengths. The standard pipe
length varies according to local regulations. For
example, in North America, the standard pipe
length is 7.5m (25’). In other areas, the standard
pipe length is 5m (16’). The refrigerant should
be charged from the service port on the outdoor
unit’s low pressure valve. The additional refrigerant
to be charged can be calculated using the
following formula:
Additional refrigerant per pipe length
Connective pipe
length (m)
Air purging
method Additional refrigerant
≤ Standard pipe length Vacuum pump N/A
> Standard pipe length Vacuum pump
Liquid side: Ø 6.35 (ø 0.25”)
R32:
(Pipe length – standard length) x 12g/m
(Pipe length – standard length) x 0.13oZ/ft
R290:
(Pipe length – standard length) x 10g/m
(Pipe length – standard length) x 0.10oZ/ft
R410A:
(Pipe length – standard length) x 15g/m
(Pipe length – standard length) x 0.16oZ/ft
R22:
(Pipe length – standard length) x 20g/m
(Pipe length – standard length) x 0.21oZ/ft
Liquid side: Ø 9.52 (ø 0.375”)
R32:
(Pipe length – standard length) x 24g/m
(Pipe length – standard length) x 0.26oZ/ft
R290:
(Pipe length – standard length) x 18g/m
(Pipe length – standard length) x 0.19oZ/ft
R410A:
(Pipe length – standard length) x 30g/m
(Pipe length – standard length) x 0.32oZ/ft
R22:
(Pipe length – standard length) x 40g/m
(Pipe length – standard length) x 0.42oZ/ft
For R290 refrigerant unit, the total amount
of refrigerant to be charged is no more than:
387g(<=9000Btu/h), 447g(>9000Btu/h and
<=12000Btu/h), 547g(>12000Btu/h and
<=18000Btu/h), 632g(>18000Btu/h and
<=24000Btu/h).
A
Warning:
Do not mix refrigerant types.
11 Air evacuation
Split type air conditioner / User Manual 53 / 196 EN
12.3 Gas leak checks
There are two different methods to check for gas
leaks.
Soap and water method
Using a soft brush, apply soapy water or liquid
detergent to all pipe connection points on the
indoor unit and outdoor unit. The presence of
bubbles indicates a leak.
Leak detector method
If using leak detector, refer to the device’s
operation manual for proper usage instructions.
After performing gas leak checks
After confirming that the all pipe connection points
Do not leak, replace the valve cover on the outside
unit.
A
BC
D
Check-point of indoor unit
A: Low pressure stop valve
B: High pressure stop valve
C& D: Indoor unit flare nuts
Check-point of outdoor unit
12 Electrical and gas leak checks
54 / 196 EN Split type air conditioner / User Manual
13.1 Test run instructions
You should perform the Test run for at least
30 minutes.
1. Connect power to the unit.
2. Press the button on the remote ON/OFF
controller to turn it on.
3. Press the button to scroll through the MODE
following functions, one at a time:
•
COOL — Select lowest possible temperature
•
HEAT — Select highest possible temperature
4. Let each function run for 5 minutes, and
perform the following checks:
List of checks to
perform
Pass/Fail
No electrical leakage
Unit is properly grounded
All electrical terminals properly
covered
Indoor and outdoor units are
solidly installed
All pipe connection points do
not leak
Outdoor
(2):
Indoor
(2):
Water drains properly from
drain hose
All piping is properly insulated
Unit performs COOL function
properly
Unit performs HEAT function
properly
Indoor unit louvers rotate
properly
Indoor unit responds to remote
controller
Double-check pipe connections
During operation, the pressure of the refrigerant
circuit will increase. This may reveal leaks that
were not present during your initial leak check.
Take time during the Test Run to double-check
that all refrigerant pipe connection points do not
have leaks. Refer to section for Gas leak check
instructions.
5. After the Test run is successfully completed,
and you confirm that all checks points in List
of Checks to Perform have PASSED, do the
following:
a. Using remote control, return unit to normal
operating temperature.
b. Using insulation tape, wrap the indoor
refrigerant pipe connections that you left
uncovered during the indoor unit installation
process.
If ambient temperature is below 16°C (60°F)
You can’t use the remote controller to turn on the
COOL function when the ambient temperature
is below 16°C. In this instance, you can use the
Manual control button to test the COOL function.
1. Lift the front panel of the indoor unit, and raise it
until it clicks in place.
2. The button is located on the Manual control
right-hand side of the unit. Press it 2 times to
select the COOL function.
3. Perform Test Run as normal.
Manual control button
13 Test Run
Split type air conditioner / User Manual 55 / 196 EN
This appliance contains refrigerant and other
potentially hazardous materials. When disposing of
this appliance, the law requires special collection
and treatment, dispose of this product as Do not
household waste or unsorted municipal waste.
When disposing of this appliance, you have the
following options:
-
Dispose of the appliance at designated
municipal electronic waste collection facility.
-
When buying a new appliance, the retailer
will take back the old appliance free of
charge.
-
The manufacturer will take back the old
appliance free of charge.
-
Sell the appliance to certified scrap metal
dealers.
C
Special notice: Disposing
of this appliance in the forest
or other natural surroundings
endangers your health and is bad
for the environment. Hazardous
substances may leak into the
ground water and enter the food
chain.
This symbol indicates that this product shall not be
disposed with other household wastes at the end
of its service life. Used device must be returned
to official collection point for recycling of electrical
and electronic devices. To find these collection
systems please contact to your local authorities or
retailer where the product was purchased. Each
household performs important role in recovering
and recycling of old appliance. Appropriate
disposal of used appliance helps prevent potential
negative consequences for the environment and
human health.
14 European disposal guideline
56 / 196 EN Split type air conditioner / User Manual
15 Installation instructions
15.1 F-Gas instruction
This product contains fluorinated greenhouse
gases.
The fluorinated greehouse gases are contained in
hermetically sealed equipment.
Installs, services, maintains, repairs, checks for
leaks or decommissions equipment and product
recycling should be carried out by natural persons
that hold relevant certificates.
If the system has a leakage detection system
installed, leakage checks should be performed at
least every 12 months, make sure system operate
properly.
If product must be performed leakage checks,
it should specify Inspection cycle, establish and
save records of leakage checks.
C
Note: For hermetically sealed
equipment, local air conditioner,
window air conditioner and
dehumidifier, if CO2 equivalent of
fluorinated greenhouse gases is
less than 10 tonnes, it should not
perform leakage checks.
58 / 196 EN Split type air conditioner / User Manual
16 Specifications
Model name Indoor unit BBFDA 070 BBFDA 090 BBFDA 120 BBFDA 180 BBFDA 240
Outdoor unit BBFDA 071 BBFDA 091 BBFDA 121 BBFDA 181 BBFDA 241
Rated Current Input-EN 60335(A) 6.7 9.0 15.5 16
Indoor unit Resistance Class IPX0 IPX0 IPX0 IPX0 IPX0
Outdoor unit Resistance Class
High Pressure Pipe Diameter (mm) 6.35mm (1/4in) 6.35mm (1/4in) 6.35mm (1/4in) 6.35mm (1/4in) 9.52mm (3/8in)
Low Pressuer Pipe Diameter (mm) 9.52mm (3/8in) 9.52mm (3/8in) 12.7mm (1/2in) 12.7mm (1/2in) 15.9mm (5/8in)
Max. elevation (m) 8 8 8 8 10
Max. pipe length (m) 10 20 20 20 25
Additional Gas Quantity (g/m) 15 15 15 15 30
Power Supply Cord specification (mm2) 3G1.5 mm23G1.5 mm23G1.5 mm23G1.5 mm23G2.5 mm2
Indoor & Outdoor Connection Cord (mm2) 5G1.0 mm25G1.0 mm23*1.5 mm2
2*0.75 mm
2
3*1.5 mm2
2*0.75 mm
24*1.0 mm2
Indoor Unit (WxHxD) mm 729x292x200 729x292x200 802x295x200 971x321x228 1082x337x234
Outdoor Unit (WxHxD) mm 720x495x270 720x495x270 720x495x270 765x555x303 890x673x342
Indoor Unit Net Weight (kg) 8.5 8.5 9.5 13 15
Outdoor Unit Net Weight (kg) 24.5 25 27.5 34.5 53
Note:
1. Specifications are standard values calculated based on rated operating conditions, They will vary in
difference work condition.
2. Our company has quick technical imporvments. There will be prior notice for any change of technical
data. Please read nameplate on the air-conditioner.
7.0
IP24 IP24 IP24 IP24 IP24
Split ty air cope nd neritio / Use Mr anual 59 / 196 EN
16 Specications
Model name Indoor unit BBVHM 090 BBVHM 120 BBVHM 180 BBVHM 240
Outdoor unit BBVHM 091 BBVHM 121 BBVHM 181 BBVHM 241
Refrigerant R410A R410A R410A R410A
Total Refrigerant Amount (g) 670 740 1400 1480
Anti-Electric Class I Class I Class I Class I
Climate Class T1 T1 T1 T1
Heating Type Heat Pump Heat Pump Heat Pump Heat Pump
Power Supply Connection Indoor Indoor Indoor Outdoor
Cooling Capacity (Btu/h) [T1] 9000 12000 18000 24000
Cooling Capacity (Btu/h) [T3] — — — —
Cooling Capacity (W) [T1] 2638 3517 5275 7034
Cooling Capacity (W) [T3] — — — —
Heating Capacity (Btu/h) 9000 12000 18000 24000
Heating Capacity (W) 2638 3517 5275 7034
Energy Efficiency Cooling [T1] 3.21 3.21 3.21 3.21
Energy Efficiency Cooling [T3] — — — —
Energy Efficiency Heating (W/W) 3.61 3.61 3.61 3.61
Energy Level-Cooling
Energy Level-Heating
411 548 822 1096
Power of Electric Heater (W) — — — —
Cooling Power Input (W) [T1] 822 1096 1643 2191
Cooling Power Input (W) [T3] — — — —
Heating Power Input (W) 731 974 1461 1948
Voltage/Frequency (V/Hz) 50Hz, 1Ph
Cooling Running Current (A) [T1] 3.7 5 7.1 9.5
Cooling Running Current (A) [T3] — — — —
Heating Running Current (A) 3.3 4.4 6.3 8.5
Noise Pressure Level - Indoor Unit (dBA) 40/33.5/30.5 40.5/34.5/31.0 44/36.5/32.5 48.5/41/34
Noise Pressure Level - Outdoor Unit (dBA) 54.5 55 57 60
Air flow volume (m3/h) 515/371/304 552/471/436 830/590/520 1150/820/670
Rated Power Input-EN 60335(W) 2200 2200 2800 3800
Rated Current Input-EN 60335(A) 10.5 10.5 13.5 18
Indoor unit Resistance Class IPX0 IPX0 IPX0 IPX0
Annual Energy Consumption (kWh)
— — — —
— — — —
220-240V~
50Hz, 1Ph
220-240V~
50Hz, 1Ph
220-240V~
50Hz, 1Ph
220-240V~
60 / 196 EN Split type air conditioner / User Manual
16 Specifications
Model name Indoor unit BBVHM 090 BBVHM 120 BBVHM 180 BBVHM 240
Outdoor unit BBVHM 091 BBVHM 121 BBVHM 181 BBVHM 241
Outdoor unit Resistance Class IP24 IP24 IP24 IP24
High Pressure Pipe Diameter (mm) 6.35mm (1/4in) 6.35mm (1/4in) 6.35mm (1/4in) 9.52mm (3/8in)
Low Pressuer Pipe Diameter (mm) 9.52mm (3/8in) 12.7mm (1/2in) 12.7mm (1/2in) 15.9mm (5/8in)
Max. elevation (m) 10 10 20 20
Max. pipe length (m) 25 25 30 30
Additional Gas Quantity (g/m) 15 15 15 30
Power Supply Cord specification (mm2) 1.5x3 1.5x3 1.5x3 2.5x3
Indoor & Outdoor Connection Cord (mm2) 1.5x4 1.5x4 1.5x4 1.5x4
Indoor Unit (WxHxD) mm 729x292x200 802x295x200 971x321x228 1082x337x234
Outdoor Unit (WxHxD) mm 720x495x270 720x495x270 805x554x330 890x673x342
Indoor Unit Net Weight (kg) 8.0 9.0 12.0 14.0
Outdoor Unit Net Weight (kg) 23.0 22.5 33.0 41.5
Note:
1. Specifications are standard values calculated based on rated operating conditions, They will vary in
difference work condition.
2. Our company has quick technical imporvments. There will be prior notice for any change of technical
data. Please read nameplate on the air-conditioner.
СОДЕРЖАНИЕ
1 Правила техники безопасности 64
2 Технические характеристики и особенности изделия 77
2.1 Дисплей внутреннего блока . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
2.2 Рабочая температура . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
2.3 Сплит-система инверторного типа . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
2.4 Изделия с фиксированной мощностью . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
2.5 Дополнительные функции. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
2.6 Ручное управление (без пульта дистанционного управления) . . . . . . . . . . . . . . . . . . . . . . . 82
2.7 Установка комплекта HomeWhiz (беспроводной модуль) . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
3 Уход и техническое обслуживание 85
3.1 Очистка внутреннего блока. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
3.2 Очистка воздушного фильтра . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
3.3 Техническое обслуживанию при длительных периодах простоя. . . . . . . . . . . . . . . . . . . . . . 88
3.4 Техническое обслуживание для подготовки к началу сезона. . . . . . . . . . . . . . . . . . . . . . . . . 88
4 Поиск и устранение неисправностей 89
4.1 Общие проблемы. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
5 Принадлежности 95
6 Сводный обзор установки внутреннего блока 97
7 Компоненты изделия 98
8 Монтаж внутреннего блока 99
8.1 Инструкции по установке внутреннего блока . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
9 Монтаж наружного блока 109
9.1 Инструкции по установке наружного блока . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
62 / 196 RU Cплит-система кондиционирования воздуха/
руководство пользователя

Produktspecifikationer

Varumärke: BEKO
Kategori: Luftkonditionering
Modell: BBFDA 070 / BBFDA 071

Behöver du hjälp?

Om du behöver hjälp med BEKO BBFDA 070 / BBFDA 071 ställ en fråga nedan och andra användare kommer att svara dig


Luftkonditionering BEKO Manualer

BEKO

BEKO BEPB12H Bruksanvisning

8 Januari 2025
BEKO

BEKO EFE6030W Bruksanvisning

31 December 2025
BEKO

BEKO BIHPR 120 Bruksanvisning

27 Oktober 2024
BEKO

BEKO BK 6300 Bruksanvisning

21 September 2024
BEKO

BEKO BFYTI 360 / BFYTI 361 Bruksanvisning

17 September 2024
BEKO

BEKO BRH 246 Bruksanvisning

16 September 2024
BEKO

BEKO BPVOW 120 Bruksanvisning

16 September 2024
BEKO

BEKO BPVOW 090 Bruksanvisning

16 September 2024
BEKO

BEKO BRH 076 Bruksanvisning

16 September 2024
BEKO

BEKO BRH 245 Bruksanvisning

16 September 2024

Luftkonditionering Manualer

Nyaste Luftkonditionering Manualer

Midea

Midea MUB-60HRN1 Bruksanvisning

9 April 2025
Fakir

Fakir 1020 Bruksanvisning

9 April 2025
Daikin

Daikin FWP17CATN6V3 Bruksanvisning

9 April 2025
Daikin

Daikin FWP06CAFN6V3 Bruksanvisning

9 April 2025
Panasonic

Panasonic CS-45KA1E5 Bruksanvisning

9 April 2025
Daikin

Daikin FXNQ63A2VEB Bruksanvisning

9 April 2025
Daikin

Daikin FXNQ20A2VEB Bruksanvisning

9 April 2025
Frigidaire

Frigidaire GHWW125TE1 Bruksanvisning

9 April 2025
Frigidaire

Frigidaire GHWW105TE1 Bruksanvisning

9 April 2025
Frigidaire

Frigidaire FHPH142AA1 Bruksanvisning

9 April 2025
