10TW1-2 / 10TW1-4 Subwoofer Drive r
Congratulations on your purchase of a JL Audio subwoofer component. Your JL Audio subwoofer
is a precision loudspeaker which has been engineered to produce the highest quality sub-bass
performance in your vehicle. Authorized JL Audio dealers have extensive technical information
for many different applications of your new speaker. They also have the knowledge, skills and tools
to build a high-quality enclosure that will maximize the performance of your speaker. We highly
recommend that you have your enclosure built by an authorized JL Audio dealer.
Inside you will find specifications and two recommended enclosures for your speaker; one is a
sealed enclosure, the other is a ported design. Both types of enclosures will give you excellent sound
quality and low-frequency extension. The sealed enclosure is a better choice if space is extremely
tight, but the ported enclosure will produce 3dB more output at the same power if you have the
extra space to work with.
OWNER’S MANUAL
2 JL AUDIO 10TW1-2 / 10TW1-4
SUBWOOFER 10TW1-2 10TW1-4
Free Air Resonance (Fs): 41.45 Hz 38.09 Hz
Electrical “Q” (Qes): 0.696 0.639
Mechanical “Q” (Qms): 9.702 10.070
Total Speaker “Q” 0.649 0.601(Qts):
Equivalent Compliance (Vas): 0.364 ft3
10.31 litres
0.429 ft3
12.15 litres
One-way, Linear Excursion (Xmax)*: 0.40 in
10 mm
0.40 in
10 mm
Efficiency (1W/1m)**: 82.5 dB SPL 82.2 dB SPL
Effective Piston Area (Sd): 41.602 in2
0.0268 m2
41.602 in2
0.0268 m2
DC Resistance (Re): 2.428 ohm 3.516 ohm
Nominal Impedance: 2 ohm 4 ohm
Power Handling (continuous): 300 W 300 W
* Xmax specifications are derived via one-way voice coil overhang method with no correction factors applied.
** Efficiency (1W/1m) is not an accurate indicator of a subwoofer’s output capability and
should not be used as a comparison to other subwoofers to determine which one is “louder”!
A
C
D
B
E
F
10TW1 SUBWOOFER PHYSICAL
SPECIFICATIONS
Nominal Diameter: 10.0 in
250 mm
Overall Diameter (A): 10.375 in
264 mm
Mounting Hole Diameter (B): 9.0625 in
230 mm
Bolt Hole Circle (C): 9.7 in
246 mm
Magnet Diameter (D): 4.54 in
115 mm
Mounting Depth (E): 4.36 in
111 mm
Frontal Grille Protrusion (F): 0.87 in
22 mm
Net Weight: 10.5 lbs
4.8 kg
Driver Displacement: 0.047 ft3
1.33 litres
JL AUDIO 10TW1-2 / 10TW1-4
U.S. PATENTS: #6,095,280 #8,374,379 #5,734,132 | Other U.S. & Foreign patents pending.
All specifications are subject to change without notice.
D
H
W
W
H
D
SW
SH
PL
P Lort Wall ength:
20.8125 in (529 mm)
(End correction accounted for)
JL AUDIO 10TW1-2 / 10TW1-4 3
SUBWOOFER RECOMMENDED SEALED ENCLOSURES
Volume
(net int.)
External Dimensions
( epth)Width x Height x D
F3
(Hz)
Fc
(Hz) Qtc
10TW1-2 0.35 ft3
9.91 litres
16.125 in x 14.00 in x 5.25 in
410 mm x 356 mm x 133 mm 48.31 59.21 0.927
10TW1-4 0.35 ft3
9.91 litres
16.125 in x 14.00 in x 5.25 in
410 mm x 356 mm x 133 mm 47.24 56.83 0.897
All specifications are subject to change without notice.
SUBWOOFER RECOMMENDED PORTED ENCLOSURES
Volume
(net int.)
Enclosure External Dimensions
( epth)Width x Height x D
Slot Port Internal Dimensions
( lot lot S Width x S Height x Effective Port Length)
Tune to:
(Hz)
F3
(Hz)
10TW1-2 0.625 ft3
17.7 litres
26.625 in x 16.00 in x 5.25 in
676 mm x 406 mm x 133 mm
3.75 in x 1.875 in x 22.50 in
95 mm x 48 mm x 572 mm 35 30.56
10TW1-4 0.625 ft3
17.7 litres
26.625 in x 16.00 in x 5.25 in
676 mm x 406 mm x 133 mm
3.75 in x 1.875 in x 22.50 in
95 mm x 48 mm x 572 mm 35 30.77
! ! CAUTION ! !
Prolonged exposure to sound pressure levels in excess of 100dB can cause permanent hearing loss. This high-performance
speaker can exceed this level. Please exercise restraint in its operation in order to preserve your ability to enjoy its fidelity.
When installing a subwoofer in your vehicle, it is extremely important to secure the enclosure firmly. We recommend
bolting the enclosure through the metal of the floorpan or the frame of the vehicle with large diameter washers
for reinforcement. If an enclosure is not firmly attached, it can become a projectile in a collision. This is particularly
important in a hatchback, station wagon, sports utility vehicle, or van.
• The enclosure recommendations listed are external
dimensions which assume the use of 3/4" (19mm)
thick material. If you are using thick 5/8" (16mm)
material, subtract from each dimension. 1/4" (6.5mm)
Do not use any material with a thickness of less than
5/8" (16mm) as this may compromise the rigidity of
the enclosure.
• All enclosure volumes listed are net internal volumes!
Box volume displacement, port displacement and
brace displacement must be added to obtain the final
gross internal volume. All enclosure dimensions listed
have already taken this into account.
• When using two subwoofers in a common
enclosure simply the required volume and, double
in the case of a ported enclosure, use the two times
recommended port(s).
• We recommend the use of this speaker in a
bi-amplified system using high-quality satellite
speakers and amplifiers. We do not recommend
the use of this subwoofer with a passive crossover
(coil), as this type of device will adversely affect
performance.
All specifications are subject to change without notice.
