INSTALLATION, MAINTENANCE AND USE
INSTRUCTIONS FOR
FREE-STANDING COOKERS
91,5x64 cm (type M91/M91V)
READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING
THE APPLIANCE.
The manufacturer will not be responsible for any damage to property or to persons
caused by incorrect installation or improper use of the appliance.
The manufacturer is not responsible for any inaccuracies, due to printing or transcription
errors, contained in this booklet. In addition, the appearance of the figures reported is also
purely indicative.
The manufacturer reserves the right to make changes to its products when considered
necessary and useful, without affecting the essential safety and operating characteristics.
2
CONTENTS:
INSTALLER TECHNICAL MANUAL ...............................................................................................................pg. 2
Installing the cooker - Installation information .................................................................................................pg. 2
Ventilation and aeration of rooms....................................................................................................................pg. 3
Height adjustable legs ....................................................................................................................................pg. 3
Backguard installation instruct ........................................................................................................................pg. 3
Gas connection ...............................................................................................................................................pg. 3
Adaptation to different types of Gas and burner adjustments..........................................................................pg. 3-4
Electric connection ..........................................................................................................................................pg. 4-5
APPLIANCE MAINTENANCE - Replac
ing parts .............................................................................................pg. 5
USE AND MAINTENANCE MANUAL .............................................................................................................pg. 6
Description of control panel and control types.................................................................................................pg. 6
Using burners..................................................................................................................................................pg. 6
Using the gas oven ........................................................................................................................................pg. 6-7-8
Using the electric thermostat...........................................................................................................................pg. 8
Using the 2+0 switch........................................................................................................................................pg. 8
Using the 9+0 switch .......................................................................................................................................pg. 8
Using the natural conventional electric oven ..................................................................................................pg. 9
Using the ventilated electric oven....................................................................................................................pg. 9-10
Using the electric grill - ventilated electric grill.................................................................................................pg. 10
Using the self cleaning oven ..........................................................................................................................pg. 10
Cleaning the appliance....................................................................................................................................pg. 11
After-sales technical service and spare parts..................................................................................................pg. 11
THIS APPLIANCE HAS BEEN DESIGNED FOR NON-PROFESSIONAL DOMESTIC USE.
INSTALLER TECHNICAL MANUAL
This appliance is marked according to the European directive 2002/95/EC
This appliance is marked according to the European directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
This guideline is the frame of a European-wide validity of return and recycling on
Waste Electrical and Electronic Equipment.
INSTALLER INFORMATION
The installation, all adjustments, transformations and maintenance listed in this part of the manual must be
carried out only by skilled personnel.
Improper installation may cause damage to persons, animals or property, for which the manufacture will not be
held responsible.
The appliance safety or automatic adjustment devices may be changed during the service life of the system only
by the manufacturer or by the duly authorised supplier.
INSTALLING THE COOKER
After having removed the various loose parts from the internal and external packing, make sure that the cooker is not
damaged. In case of doubt, do not use the appliance and contact skilled personnel.
Keep all the dangerous packing parts (polystyrene foam, bags, cardboard, staples, etc.) away from children.
The appliance can be installed as a freestanding unit, next to a wall at a distance of no less than 20mm (Fig.2,
Class 1
Installation) or inserted between two walls (Fig.1, Class 2 Subclass 1 Installation). A single sidewall that exceeds the
height of the work surface is possible. This must be at a minimum distance of 70 mm from the edge of the cooker (Fig.2,
Class 1 Installation)
Any walls of the adjacent furniture pieces and the wall behind the cooker must be made with heat-resistant material that
can withstand a minimum overtemperature of 65 K.
The appliance can be installed as class 1 and as class 2 subclass 1.
WARNING: when the appliance is installed as class 2 subclass 1, the connection to the gas network must only
use metal flexible pipes that conform with the national standards in force.
IMPORTANT INFORMATION FOR INSTALLING THE APPLIANCE
The cooker can be installed separately, as a freestanding unit, or between kitchen units or between a kitchen
unit and the wall. The device must be installed in accordance with the regulations stated in UNI 7129 and UNI
7131 standards.
This appliance is not connected to devices which exhaust combustion products.
Special attention must be focused on the prescriptions described below regarding room aeration and
ventilation. Any hanging cabinets installed above the work surface must be located at a distance of no less than
700 mm.
3
ROOM VENTILATION
To ensure that the appliance operate correctly, the room where it is installed must be continuously ventilated. The room
volume should not be less than 25 m³ and the quantity of air needed shall be based on the regular combustion of gas
and on the ventilation of the room. Natural air will flow through permanent openings in the walls of the room to be
ventilated: these openings will be connected with the outside environment and shall have a minimum cross-section
defined by the current national standards regarding room ventilation (see Fig. 3).
These openings shall be built so that they cannot be clogged.
Indirect ventilation is also permitted by taking air from the rooms adjacent to the one to be ventilated.
LOCATION AND AERATION
The gas cooking appliances must always evacuate the combustion products by means of hoods connected to chimneys,
flues or directly outside (see Fig. 4). If a hood cannot be installed, it is possible to use a fan installed on a window or
directly facing outdoors, to be operated t ovided that there is strict compliance ogether with the appliance (see Fig. 5), pr
with the ventilation regulations.
HEIGHT ADJUSTABLE LEGS (Fig.6)
Legs are packed in the top box.
Legs should be installed with the appliance being near the location of final installation, they are not secure for long
transport. After unpacking the range, raise it about a foot to insert the legs in their bases assembled on the lower part of
the cooker and lower the range gently to keep any undue strain from legs and mounting hardware. It is recommended to
use a pallet or lift jack instead of tilting the unit.
BACKGUARD INSTALLATION INSTRUCTION
1) Remove n°2 screws fixing worktop as shown in fig.7
2) Place front part of the backguard and attach it from bottom side with the two removed screws (point 2) as shown in
fig .8
3) Fix the front part of the backguard with the screws supplied with the backguard kit (fig.9)
4) Assemble back part with front part of the backguard and fix them with a screws supplied with the backguard kit
(fig.10)
APPLIANCE GAS CONNECTION
Before connecting the appliance to the gas network, make sure that the data on the label attached to the food
warmer drawer or on the back of the cooker are compatible with what is indicated for the gas distribution
network.
A label attached to the last page of this handbook and in the food warmer drawer (or on the back) of the
appliance indicates the appliance adjustment conditions: type of gas and operating pressure.
IMPORTANT: This appliance must be installed in compliance with current national standards in force and used
only in a well-ventilated room.
WARNING: It should be recalled that the appliance utilises a threaded 1/2" gas cylindrical male fitting according
to UNI-ISO 228-1.
To connect the appliance to the gas network with a flexible rubber hose, a supplemental hose nipple fitting is
needed (see Fig. 11) which is supplied with the appliance.
ADAPTATION TO DIFFERENT TYPES OF GAS FOR COOKER TYPE M6V
Before performing any maintenance operation, disconnect the appliance from the gas supply and electricity
network.
REPLACING THE NOZZLES TO OPERATE WITH ANOTHER TYPE OF GAS FOR COOKER TYPE M6V:
Follow the instructions below to change the burner nozzles on the work surface:
1) Pull out the plug from the electric outlet to avoid any type of electric contact.
2) Remove the grids from the work surface.
3) Remove the burners.
4) Unscrew the nozzles using a 7 mm spanner, and replace them (Fig.12) with those needed for the new type of gas
according to what is indicated in Table 1.
Follow the instructions below to change the oven burner nozzle:
1) Remove the oven level (Fig. 13).
2) Loosen the screw V and pull out the burner from the support being careful not to damage the ignition plug and the
thermocouple (Fig. 14).
3) Unscrew the nozzle R using a 10 mm spanner and replace it with the nozzle needed for the new type of gas according
to what is indicated in Table 1
WARNING: After completing the above-mentioned replacements, the technician must adjust the burners, as
described in the paragraph below, seal any adjustment and pre-adjustment devices and apply the label on the
appliance, to replace the existing one, corresponding to the new gas adjustment. This label is contained in the
spare nozzle bag.
