PK22 AND PKEX22 SERIES

INSTALLATION INSTRUCTIONS

HB0123

INTENDED FOR DOMESTIC COOKING ONLY

INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.

HOMEOWNER: USE AND CARE INFORMATION ON PAGES 11 TO 13.

READ AND SAVE THESE INSTRUCTIONS

BEST; Hartford, Wisconsin www.BestRangeHoods.com 800-558-1711

BEST; Drummondville, QC, Canada www.BestRangeHoods.com 866-737-7770

To register your product online or for additional information visit www.BestRangeHoods.com

SV20827 rev. 02

! !

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR

INJURY TO PERSONS, OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended by the manufacturer. If you

have questions, contact the manufacturer at the address or telephone

number listed in the warranty.

2. Before servicing or cleaning unit, switch power off at service panel

and lock service disconnecting means to prevent power from being

switched on accidentally. When the service disconnecting means

cannot be locked, securely fasten a prominent warning device, such

as a tag, to the service panel.

3. Installation work and electrical wiring must be done by qualified

personnel in accordance with all applicable codes and standards,

including fire-rated construction codes and standards.

4. Sufficient air is needed for proper combustion and exhausting of

gases through the flue (chimney) of fuel burning equipment to prevent

backdrafting. Follow the heating equipment manufacturer’s guidelines

and safety standards such as those published by the National Fire

Protection Association (NFPA) and the American Society for Heating,

Refrigeration and Air Conditioning Engineers (ASHRAE) and the local

code authorities.

5. When cutting or drilling into wall or ceiling, do not damage electrical

wiring and other hidden utilities.

6. Ducted fans must always be vented to the outdoors.

7. Do not use this unit with any solid-state speed control device.

8. To reduce the risk of fire, use only metal ductwork.

9. This unit must be grounded.

10. When applicable local regulations comprise more restrictive installation

and/or certification requirements, the aforementioned requirements

prevail on those of this document and the installer agrees to conform

to these at his own expenses.

TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:

a) Never leave surface units unattended at high settings. Boilovers cause

smoking and greasy spillovers that may ignite. Heat oils slowly on low

or medium settings.

b) Always turn power pack ON when cooking at high heat or when

flambeing food (i.e.: Crêpes Suzette, Cherries Jubilee, Peppercorn

Beef Flambé).

c) Clean ventilating fans frequently. Grease should not be allowed to

accumulate on fan, filters or in exhaust ducts.

d) Use proper pan size. Always use cookware appropriate for the size of

the surface element.

TO REDUCE THE RISK OF INJURY TO PERSONS IN THE

EVENT OF A RANGE TOP GREASE FIRE, OBSERVE

THE FOLLOWING*:

1. SMOTHER FLAMES with a close-fitting lid, cookie sheet or metal tray,

then turn off the burner. BE CAREFUL TO PREVENT BURNS. IF THE

FLAMES DO NOT GO OUT IMMEDIATELY, EVACUATE AND CALL

THE FIRE DEPARTMENT.

2. NEVER PICK UP A FLAMING PAN — You may be burned.

3. DO NOT USE WATER, including wet dishcloths or towels — This

could cause a violent steam explosion.

4. Use an extinguisher ONLY if:

A. You own a Class ABC extinguisher and you know how to operate it.

The fire is small and contained in the area where it started.B.

The fire department has been called.C.

You can fight the fire with your back to an exit.D.

* Based on “Kitchen Fire Safety Tips” published by NFPA.

1. For indoor use only.

2. For general ventilating use only. Do not use to exhaust hazardous or

explosive materials and vapors.

3. To avoid motor bearing damage and noisy and/or unbalanced

impellers, keep drywall spray, construction dust, etc. off power unit.

4. Your power pack motor has a thermal overload which will automatically

shut off the motor if it becomes overheated. The motor will restart

when it cools down. If the motor continues to shut off and restart, have

the power pack serviced.

5. The minimum power pack distance above cooktop must not be less

than 24”. A maximum of 30” above cooktop is recommended for best

capture of cooking impurities.

6. Two installers are recommended because of the large size and weight

of this unit.

7. To reduce the risk of fire and to properly exhaust air, be sure to duct air

outside — Do not exhaust air into spaces within walls or ceiling or into

attics, crawl space or garage.

8. This product is equipped with a thermostat which may start blower

automatically. To reduce the risk of injury and to prevent power from

being switched on accidentally, switch power off at service panel and

lock or tag service panel.

9. Because of the high exhausting capacity of this unit, you should make

sure enough air is entering the house to replace exhausted air by

opening a window close to or in the kitchen.

10. To reduce the risk of fire and electrical shock, the Best models PK22

series should only be installed with their own built-in blowers, and the

Best models PKEX22 Series must only be installed with Best external

blower models EB6, EB9, EB12 or EB15; or Best in-line blowers

models ILB3, ILB6, ILB9, ILB11. Other blowers cannot be substituted.

11. PKEX22 models used with ILB3, ILB6 or EB6 blower, must be installed

over ranges rated 60,000 Btu/hr. maximum.

12. Please read specification label on product for further information and

requirements.

13. This power pack is equipped with a RF receiver (optional remote

control sold separately). Changes or modifications not expressly

approved by the party responsible for compliance could void the

user’s authority to operate this product. The remote control has been

tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules and the Canadian ICES-003.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. The remote control

generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected

WARNING

CAUTION

HL0192

- PK22 POWER PACK SYSTEM -

M 437ODEL

(HIGH CAPACITY ROOF CAP)

MODEL 441

(10’’ ROUND WALL CAP)

M 418 ODEL

(10” R OUND

ADJUSTABLE ELBOW )

M 410 ODEL

(10” R OUND DUCT

— 2 )FT. SECTIONS

AL3036, AL3042, AL3948,

AL3954, AL4554 OR AL4560

CUSTOM HOOD LINER OPTIONAL ( )

M 421ODEL

(10” R OUND VERTICAL IN LINE DAMPER -

SUPPLIED WITH INTERNAL BLOWER POWER PAC K)

10” ROUND ADAPTER

( SUPPLIED WITH INTERNAL

BLOWER POWER PACK)

D (1200 )UAL BLOWER CFM

ALP36, ALP42, ALP48,

ALP54 OR ALP60

A MBIENT LIGHT PANEL OPTIONAL ( )

ACR1 REMOTE CONTROL

( )OPTIONAL

PK22 POWER PACK
