Best Trovare WCP3I36SB Bruksanvisning

Best Fläktkåpa Trovare WCP3I36SB

Läs nedan 📖 manual på svenska för Best Trovare WCP3I36SB (1 sidor) i kategorin Fläktkåpa. Denna guide var användbar för 4 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/1
B E S T R A N G E H O O D S . C O M | 5 Y E A R P A R T S / 2 Y E A R L A B O R W A R R A N T Y
23
Install hood so that the bottom of the
unit is 24" to 30" above the cooking
surface. Mounting height may be
affected by ceiling height.
Ducted telescopic flue accommodates
celling heights from 8' to 9'. Flue
extension for higher ceilings is also
available.
*299 CFM max with ARP6 or ARP10
reducer plate option
For more details see the product
specifications sheet found at
www.BESTRangeHoods.com
Model Numbers:
WCP3I30SB WCP3I36SB
T R O V A R E ™WCP3
Tap-touch control features
easy-to-clean surface.
Hybrid baffle filters provide
ultra-efficient grease removal
with superior air flow.
Hood Sizes
Width 30", 36"
Depth 20"
Finish
Stocked Brushed Stainless Steel
Special Order NA
Features
Lighting Type LED Modules (450 Lumens each,
4.5 watts per module,
color temp 3000K)
Number of Modules 2
Lighting Levels 2
Lighting Modules Included Yes
Control Type 3-speed Tap Touch
Control Features Heat Sentry™, Filter Clean Reminder
Remote Control NA
Filter Type Hybrid Baffle Filter
Non-ducted Capability Yes
Hood Blower Included
Internal
Blower CFM Low/High 200/600
Sones Low/High 1.5/11.0
Accessories
10' Flue Extension (Ducted) AEWCP3SB
Recirculation Kit HRKBSS
Non-Duct Filter FILTERECB
CFM Reducer Kit ARP6, ARP310
Installation Requirements
Amps @ 120V: Internal Blower 3.9
Electrical Connection Plug In
Duct Size: Internal Blower 6" round, 3-1/4" x 10"
Duct Direction 6" V, 3-1/4" x 14" V and H
Backdraft Damper Included
C H I M N E Y
3-speed high performance blower
featuring 600 CFM, HVI certified*,
offering 1.5 sones level at
minimum speed.
Two ultra efficient hybrid baffle
filters, easy to clean, for optimal
grease removal.
Two built-in LED modules
provide an even lighting over the
cooktop.
Telescopic chimney for 8' to 9'
ceiling.
Optional flue extension available
for 10' ceiling.
Two-level LED modules evenly
illuminate cooktop.

Produktspecifikationer

Varumärke: Best
Kategori: Fläktkåpa
Modell: Trovare WCP3I36SB
