MODELS:
NC27-1-W, NC33-1-W, NC41-1-W, NC49-1-W
Product Registration
READ AND SAVE THIS INSTRUCTIONS
The information contained in this will instruct you on how toOwner's Guide
properly operate and care for your product. Please read through the information
contained in your literature pack to learn more about your new appliance.
Record Your Model and Serial Numbers
Record the Model No. and Serial No. of this freezer in the space provided
below. The nameplate is located at the back of the equipment.
Model No.: _____________________________________
Serial No.: _____________________________________
Energy Saving Ideas
1. The freezer should be located in the coolest area of the room, away from
heat producing appliances or heating ducts, and out of direct sunlight.
2. Overloading the freezer forces the compressor to run longer. Do not
exceed the load limit according to labels fixed on the inner cabinet (which
corresponds to the baskets height) since the product will start warming up
instead a cooling down and the compressor will run longer.
3. Product to be loaded should be at -4° F (-20° C) since the equipment is
intended for maintaining a cool product at 0° F (-18° C) at load level rather
than cooling or freezing up a warm product
4. Grids at the side and backside of the freezer should not be interfered
allowing a clear space of 4” (10 cm.)
5. Assure keeping the lids closed to avoid warm air and moisture get into the
freezer.
Important Safety Instructions
R .EAD ALL INSTRUCTIONS BEFORE USING THIS FREEZER
WARNING For Your Safety
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
WARNING Child Safety
Destroy carton, plastic bags, and any exterior wrapping material
immediately after the freezer is unpacked. Children should never use
these items for play. Cartons covered with rugs, bedspreads, plastic
sheets or stretch wrap may become airtight chambers and can quickly
cause suffocation.
A child might suffocate if he crawls into a freezer to hide or play.
Remove the door of a freezer when not in use, even if you plan to
discard the freezer. Many communities have laws requiring you to take
this safety precaution.
Remove and discard any spacers used to secure the shelves during
shipping. Small objects are a choke hazard to children.
WARNING Electrical Information
These guidelines must be followed to ensure that safety mechanisms in
the design of this freezer will operate properly.
Refer to the serial plate for correct electrical rating. The power cord of
the appliance is equipped with a three-prong grounding plug for protection
against shock hazards. It must be plugged directly into its own properly
grounded three prong receptacle, protected with a 15 amp time delay fuse
or circuit breaker. The receptacle must be installed in accordance with the
local codes and ordinances.
Consult a qualified electrician. Receptacles protected by Ground Fault
Circuit Interrupters (GFCI) are NOT RECOMMENDED. DO NOT use an
extension cord or adapter plug.
If voltage varies by 10 percent or more, freezer performance may be
affected. Operating the freezer with insufficient power can damage the
motor. Such damage is not covered under the warranty. If you suspect
voltage is high or low, consult your power company for testing.
To prevent the freezer from being turned off accidentally, do not plug unit
into an outlet controlled by a wall switch or pull cord.
Do not pinch, knot, or bend power cord in any manner.
WARNING Other Precautions
1. Never unplug the freezer by pulling on the power cord. Always grip the
plug firmly and pull straight out from the receptacle.
2. Turning the control to OFF turns off the compressor, but does not
disconnect power to other electrical components.
3. If the power cord is damaged, it should be replaced through your service
agency or qualified personal only.
First Steps
This user’s manual contains general working instructions for your freezer.
Before starting the freezer, follow these important first steps:
Installation
Verify that your energy source is 1ph/120V~
Choose a place that is near a grounded electrical outlet.
The freezer should be located where surrounding temperatures will not
exceed 110°F (43°C). Temperatures of 32°F (0°C) and below will NOT
affect freezer operation. Additional compressor heaters are not
recommended.
Allow space around the unit for good air circulation. Leave a 4” (100 mm)
space on all sides of the freezer for adequate circulation. Do not block the
side and backside grids.
Cleaning
Wash any removable parts, the freezer interior, and exterior with mild
detergent and warm water. Wipe dry. DO NOT USE HARSH CLEANERS
ON THESE SURFACES.
Do not use razor blades or other sharp instruments, which can scratch the
appliance surface.
SCRAPPING OF FROST
It is recommended to remove the frost accumulated before reloading the
freezer or anytime when one quarter inch of frost has accumulated.
Keeping the freezer plugged-in, with product, place a clean dry soft cloth
over the product to catch the frost that will be removed in the following
step.
Remove the frost using a plastic scrapper trying to go through the basket
handles to eliminate as much frost as possible.
The soft cloth, already wet with the frost removed, could be used for light
cleaning the inner cabinet prior to reloading.
Total inside cleaning
To perform a deep cleaning, remove the product and relocate it in another
freezer. Unplug the freezer and allow the equipment to defrost.
Do the cleaning with a wet cloth. Do not pour water or any other liquid.
Dry up completely and plug the freezer in again allowing 4 hours to run
empty before reloading it again.
Warning THE LOWER SIDE OF THE GLASS LIDS IS PROVIDED WITH A SPECIAL
FILM O NOT USE RACER BLADES OR OTHER SHARP INSTRUMENTS WHICH CAN. D
SCRATCH THIS SURFACE AND DAMAGE THE FILM. For cleaning use only a damp soft
cloth.
Freezer Lids Removal
The lids are provided with aluminum angle retainers to keep them in place.
These retainers are installed at the front and at the rear of the aluminum frame
where the lids run
The aluminum angle retainer at the rear is shorter than the front ones to allow
the lids removal.
If lids must be removed:
1. Stand- in front of the freezer.
2. Assure that the lower lid is totally closed to the right side of the freezer.
3. To remove the top lid, run it open to its maximum and then pull it up from
the rear (see figure). Handle the lid carefully and place it in a straight
safety place.
4. To remove the lower lid, slide it open to the opposite side and then pull it
up from the rear. Handle the lid carefully and put it in a safety place.
5. To install the lids again, reverse the previous steps starting with the lower
lid, assuring that the grooves in the plastic profiles at the rear and the front
of the lids get inserted correctly into the aluminum retainers, first to the
front side and then at the rear.
Dice:
Aluminum
angle retainer
Debe decir:
Aluminum
angle retainer
