TG I53 deutsch TG I53 english TG I53 français
Sie haben sich für das Kondensatormikrofon TG I53 von
beyerdynamic entschieden. Vielen Dank für Ihr Ver trauen.
Nehmen Sie sich bitte einige Minuten Zeit und lesen Sie diese
Produkt information vor Inbetriebnahme aufmerksam durch.
Sicherheitsinformationen
• Schützen Sie das Mikrofon vor Feuchtigkeit, Herunterfallen
und Stoß. Sie könnten das Mikrofon dabei beschädigen!
• Pusten Sie nicht in das Mikrofon und vermeiden Sie es, auf
den Mikrofonkorb zu klopfen. Zur Funktionskontrolle sollten
Sie in das Mikrofon sprechen oder leicht am Mikrofonkorb
kratzen.
Anwendungen
Das TG I53 eignet sich zur Abnahme von verschiedensten
Instrumenten. Es empfiehlt sich vor allem als Overheadmikrofon
im Schlagzeug- und Percussionbereich, für HiHat, Holz- und
Blechblasinstrumente, Gitarre und andere Saiteninstrumente.
Anschluss
Das TG I53 ist mit einem 3-poligen XLR-Stecker ausgestattet.
Sie können es an jeden symmetrischen Mikrofoneingang mit
einer Phantomspeisung von 12 - 52 V anschließen. Empfohlene
Phantomspeisung: 48 V
Aufstellung
• Aufgrund der frequenzunabhängigen Nierencharakteristik ist
der vordere Aufnahmebereich relativ groß und auch bei seit-
lichen Bewegungen des Instruments treten keine Klangver-
färbung auf.
• Um maximale Rückkopplungssicherheit zu erreichen, sollten
Sie das Mikrofon so positionieren, dass die Monitorbox von
hinten (Winkel ca. 180° zur Mikrofonachse) auf das Mikrofon
strahlt.
• Zum Lieferumfang des TG I53 gehört die Mikrofonklammer
MA-CL 21 für Stative mit 3/8" oder 5/8"-Gewinde.
Pflege
Bei Bedarf reinigen Sie das TG I53 mit einem angefeuchteten,
weichen Tuch. Wenn notwendig, können Sie ein mildes
Reinigungsmittel (z.B. Geschirrspülmittel) verwenden, auf keinen
Fall lösemittelhaltige Reiniger! Achten Sie darauf, dass keine
Flüssigkeit in den Mikrofonkopf gelangt.
Service
Im Servicefall wenden Sie sich bitte an autorisiertes Fachpersonal.
Öffnen Sie das Mikrofon auf keinen Fall selbst, Sie könnten sonst
alle Gewährleistungsansprüche verlieren.
Version
Bez. Beschreibung Best.-Nr.. . . . . . . . . . . . . . . . . . .
TG I53 Instrumentenmikrofon,
Elektret-Kondensator, Niere
mit Mikrofonklammer. . . . . . . . . . . . . . 707.155
Zubehör - optional
MAV 800 Mikrofon-Abhängevorrichtung . . . . . . . . 448.133
WS 53 Windschutz, schwarz . . . . . . . . . . . . . . 436.607
Entsorgung
Dieses Produkt darf am Ende seiner Lebensdauer
nicht über den normalen Haushaltsabfall entsorgt
werden, sondern muss an einem Sammelpunkt für
das Recycling von elektrischen und elektronischen
Geräten abgegeben werden. Das Symbol auf dem
Produkt, der Gebrauchsanweisung oder der
Verpackung weist darauf hin.
Thank you for selecting the TG I53 condenser microphone from
beyerdynamic.
Please take some time to read carefully through this information
before using the product.
Safety Information
• Protect the microphone from moisture and sudden impacts.
You could damage the microphone!
• Do not blow into the microphone and do not knock on the
microphone basket. Speak into the microphone or lightly
scratch the microphone head grill to check functionality.
Applications
The TG I53 is suitable for miking up a variety of instruments. It
is particularly suited as an overhead microphone for drums and
percussion, for the hi-hat, woodwind and brass instruments,
guitars and other stringed instruments.
Connection
The TG I53 is equipped with a 3-pin XLR plug. It can be plugged
into any balanced microphone input with a phantom power of
12 - 52 V. Recommended phantom power: 48 V
Setting up
• Due to the cardioid polar pattern, which is dependent on
frequency, the recording range is relatively large and even
when the instrument is moved sideways, there is no sound
distortion.
• To achieve maximum feedback suppression, the microphone
should be positioned in such a way that the monitor speaker
is aimed at the microphone from behind (angle approx. 180°
to the microphone axis).
• The MA-CL 21 microphone clip for stands with a 3/8" and
5/8" thread adapter is included in delivery of the TG I53.
Maintenance
The TG I53 may be cleaned with a soft, damp cloth as required.
If necessary, a gentle cleaning agent (e.g. washing-up liquid) may
be used – but on no account use a cleaner containing solvents.
Make sure that no liquid penetrates the microphone head.
Service
Servicing must be carried out by qualified service personnel only.
Dismantling the microphone yourself will invalidate the guarantee.
Version
Model Description Order #. . . . . . . . . . . . . . . . . . . . .
TG I53 Instrument microphone,
electret condenser,
cardioid, with microphone clamp . . . . . 707.155
Optional Accessories
MAV 800 Clip for hanging mounting
of microphones . . . . . . . . . . . . . . . . . . 448.133
WS 53 Wind shield, black. . . . . . . . . . . . . . . . 436.607
Disposal
This symbol on the product, in the instructions or
on the packaging means that your electrical and
electronic equipment should be disposed at the
end of its life separately from your household
waste. There are separate collection systems for
recycling in the EU. For more information, please
contact the local authority or your retailer where
you purchased the product.
Nous vous félicitons pour l’achat du microphone à condensateur
T G I53 de beyerdynamic et vous remercions de votre confiance.
Veuillez lire attentivement ces informations produit avant de la
mise en marche du microphone.
Sécurité
• Veillez à ce que le microphone soit protégé de l’humidité et
de tous dommages résultant de chutes ou de chocs
mécaniques.
• Ne soufflez pas dans le microphone. Pour tester le bon
fonctionnement, nous vous recommandons de parler dans le
microphone ou de gratter très légèrement la tête du micro-
phone.
Applications
Le TG I53 se prête à la prise de son des instruments les plus
divers. Il est particulièrement recommandé en tant que micro-
phone suspendu de type « overhead » pour la prise de batterie et
de percussions, de hi-hat, d’instruments à vent en bois et en
cuivre, de guitare et d’autres instruments à cordes.
Branchement
Le TG I53 est doté d’une fiche XLR 3 broches. Vous pouvez
brancher le microphone sur toutes les entrées de microphone
symétriques avec une alimentation fantôme de 12 - 52 V.
Alimentation fantôme recommandée: 48 V
Montage
• Grâce à la directivité cardioïde indépendante de la fréquence,
la zone d’enregistrement avant est relativement étendue et il
n’y a pas de risque de coloration sonore, même lors de
déplacements hors axe de l’instrument.
• Pour une protection maximum contre l’effet Larsen, nous
recommandons de positionner le microphone de façon à ce
que le son du moniteur parvienne de l’arrière au microphone
(angle d’environ 180° par rapport à l’axe du microphone).
• Le TG I53 est livré avec la pince de microphone MA-CL 21
pour les pieds de sol avec filetage 3/8" et 5/8".
Entretien
Le cas échéant, nettoyez le TG I53 à l’aide d’un chiffon doux
humidifié. Si nécessaire, vous pouvez utiliser un produit
nettoyant doux (p. ex. produit vaisselle), n’utilisez en aucun cas
de solvants. Veillez à ce qu’aucun liquide ne pénètre dans la tête
de microphone.
Service après-vente
En cas de nécessité veuillez vous adresser à un technicien
beyerdynamic autorisé. N’ouvrez jamais le microphone, vous
risquerez sinon de perdre vous droits de garantie.
Modèle
Mod. Description Art. N°. . . . . . . . . . . . . . . . . . . . .
TG I53 Microphone pour instruments,
condensateur électret,
cardioïde, avec pince de microphone . . 707.155
Accessoires en option
MAV 800 Dispositif de suspension
pour microphone . . . . . . . . . . . . . . . . . 448.133
WS 53 Bonnette anti-vent, noire . . . . . . . . . . . 436.607
Evacuation
Ce symbole sur le produit, l’emballage ou dans le
manuel signifie que votre équipement électrique et
électronique doit être, en fin de vie, jeté
séparement de vos déchets ménages. Il existe en
France des systèmes de collecte différents pour les
déchets recyclables. Pour plus d’information,
veuillez contacter les autorités locales ou le
revendeur chez qui vous avez acheté le produit.

TG I53 english TG I53 françaisTG I53 deutsch
Technical Specifications
Transducer type . . . . . . . . . . . . . . . Condenser (back electret)
Operating principle . . . . . . . . . . . . . Pressure gradient
Polar pattern . . . . . . . . . . . . . . . . . Cardioid
Frequency response:
Close miking . . . . . . . . . . . . . . . . 20 - 20,000 Hz
Distant miking (measured at 1 m). . . 35 - 20,000 Hz
Open circuit voltage . . . . . . . . . . . . 6.8 mV/Pa
(-43.4 dBV) ±2.5 dB
Nominal impedance . . . . . . . . . . . . 200 Ω
Load impedance . . . . . . . . . . . . . . . ≥ 1 kΩ
Max. SPL
at 24 V and 48 V phantom power . . . . 140 dB
S/N ratio . . . . . . . . . . . . . . . . . . . . 61 dB [CCIR; Q-Peak]
71 dB [A; RMS]
Equivalent SPL. . . . . . . . . . . . . . . . 23 dB [A; RMS]
33 dB [CCIR; Q-Peak]
Power supply . . . . . . . . . . . . . . . . . Phantom power:
P12; P24; P48
(recommended: 48 V)
Power consumption. . . . . . . . . . . . . 4.7 mA
Connection. . . . . . . . . . . . . . . . . . . XLR, 3-pin, male
Dimensions . . . . . . . . . . . . . . . . . . 100 x 19.5 mm
Weight (without clamp) . . . . . . . . . . 36 g
Spécifications techniques
Type de transducteur . . . . . . . . . . . Condensateur
(back-électret)
Principe de travail . . . . . . . . . . . . . Gradient de pression
Directivité . . . . . . . . . . . . . . . . . . . Cardioïde
Bande passante:
à proximité . . . . . . . . . . . . . . . . . 20 à 20 000 Hz
à distance (distance 1 m) . . . . . . 35 à 20 000 Hz
Efficacité en champs libre. . . . . . . . 6,8 mV/Pa
(-43,4 dBV) ±2,5 dB
Impédance nominale. . . . . . . . . . . . 200 Ω
Impédance de charge min. . . . . . . . ≥ 1 kΩ
Pression sonore max.
avec 24 V et 48 V
alimentation fantôme. . . . . . . . . . . . . 140 dB
Rapport signal-bruit . . . . . . . . . . . . 61 dB [CCIR; Q-Peak]
71 dB [A; RMS]
Niveau de pression sonore équivalent. . . 23 dB [A; RMS]
33 dB [CCIR; Q-Peak]
Alimentation . . . . . . . . . . . . . . . . . Fantôme: P12; P24; P48
(recommandée: 48 V)
Consommation . . . . . . . . . . . . . . . . 4,7 mA
Connecteur. . . . . . . . . . . . . . . . . . . XLR, 3 broches, mâle
Dimensions . . . . . . . . . . . . . . . . . . 100 x 19,5 mm
Poids (sans pince) . . . . . . . . . . . . . 36 g
Technische Daten
Wandlerprinzip Kondensator (Back-Elektret). . . . . . . . . . . . . . . .
Arbeitsprinzip. . . . . . . . . . . . . . . . . Druckgradientenempfänger
Richtcharakteristik . . . . . . . . . . . . . Niere
Übertragungsbereich:
Nahfeld . . . . . . . . . . . . . . . . . . . 20 - 20.000 Hz
Fernfeld (Entfernung 1 m) . . . . . . 35 - 20.000 Hz
Feldleerlaufübertragungsfaktor. . . . . 6,8 mV/Pa
(-43,4 dBV) ±2,5 dB
Nennimpedanz . . . . . . . . . . . . . . . . 200 Ω
Nennabschlussimpedanz . . . . . . . . . ≥ 1 kΩ
Max. Grenzschalldruckpegel
bei 24 V u. 48 V Phantomspeisung. . . 140 dB
Geräuschspannungsabstand. . . . . . . 61 dB [CCIR; Q-Peak]
71 dB [A; RMS]
Äquivalentschalldruckpegel . . . . . . . 23 dB [A; RMS]
33 dB [CCIR; Q-Peak]
Spannungsversorgung . . . . . . . . . . . Phantomspeisung:
P12; P24; P48
(empfohlen: 48 V)
Stromaufnahme . . . . . . . . . . . . . . . 4,7 mA
Anschluss . . . . . . . . . . . . . . . . . . . XLR, 3-pol., male
Abmessungen . . . . . . . . . . . . . . . . . 100 x 19,5 mm
Gewicht (ohne Klammer). . . . . . . . . 36 g
+20
+10
0 dB
-10
-20
-30
20 200 2k 20k100 1k 10k50 500 5k Hz
--
125 Hz
250 Hz
500 Hz
1000 Hz
4000 Hz
8000 Hz
16000 Hz
300°
270°
210°
240°
180°
150°
120°
90°
60°
30°
0°
330°
-5dB
-10dB
-15dB
-20dB
2000 Hz
Richtdiagramm • Polar Pattern • Directivité
Frequenzkurve • Frequency Response Curve • Courbe de fréquence
Schaltbild • Wiring Diagram • Diagramme de câblage
± 2.5 dB TG I53 0 dB = 6.8 mV/Pa
www.beyerdynamic.com
beyerdynamic GmbH & Co. KG . Theresienstraße 8 . 74072 Heilbronn . Germany .
Tel. +49 7131 617-0 . Fax +49 7131 617-204 . info@beyerdynamic.de
Weitere Vertriebspartner weltweit finden Sie im Internet unter www.beyerdynamic.com
Abbildungen nicht vertragsbindend. Änderungen vorbehalten.
For further distributors worldwide, please go to www.beyerdynamic.com
Non-contractual illustrations. Subject to change without notice.
DE-EN-FR 5 / TG I53 / 624.926 (08.19)
TG I53
KONDENSATORMIKROFON
CONDENSER MICROPHONE
MICROPHONE À CONDENSATEUR
PRODUKTINFORMATION
PRODUCT INFORMATION
INFORMATIONS DE PRODUIT
Produktspecifikationer
Varumärke: | Beyerdynamic |
Kategori: | mikrofon |
Modell: | I53c |
Behöver du hjälp?
Om du behöver hjälp med Beyerdynamic I53c ställ en fråga nedan och andra användare kommer att svara dig
mikrofon Beyerdynamic Manualer

Beyerdynamic Fox - Professional USB studio microphone Bruksanvisning
12 September 2024
10 September 2024

10 September 2024

10 September 2024

10 September 2024

10 September 2024

10 September 2024

10 September 2024

10 September 2024

9 September 2024
mikrofon Manualer
- mikrofon Sony
- mikrofon Philips
- mikrofon Panasonic
- mikrofon JBL
- mikrofon Olympus
- mikrofon Yamaha
- mikrofon Yealink
- mikrofon Canon
- mikrofon Akg
- mikrofon Aluratek
- mikrofon Alto
- mikrofon OneConcept
- mikrofon Telefunken
- mikrofon Nedis
- mikrofon Thomson
- mikrofon Lenco
- mikrofon GoPro
- mikrofon Pyle
- mikrofon Manta
- mikrofon Renkforce
- mikrofon Sharkoon
- mikrofon Niceboy
- mikrofon Logitech
- mikrofon Manhattan
- mikrofon Audio-Technica
- mikrofon Trust
- mikrofon Gemini
- mikrofon Easypix
- mikrofon Toa
- mikrofon Roland
- mikrofon Axis
- mikrofon ART
- mikrofon Hama
- mikrofon Brigmton
- mikrofon Vonyx
- mikrofon Sennheiser
- mikrofon Techly
- mikrofon LD Systems
- mikrofon Bogen
- mikrofon Fenton
- mikrofon AVerMedia
- mikrofon American DJ
- mikrofon Connect IT
- mikrofon Steren
- mikrofon Plantronics
- mikrofon Steelseries
- mikrofon Mackie
- mikrofon Marantz
- mikrofon Sandberg
- mikrofon Galaxy Audio
- mikrofon Razer
- mikrofon Neumann
- mikrofon DJI
- mikrofon RCF
- mikrofon Insignia
- mikrofon Nacon
- mikrofon Rollei
- mikrofon Peerless-AV
- mikrofon Artsound
- mikrofon Genesis
- mikrofon Pyle Pro
- mikrofon Peavey
- mikrofon MXL
- mikrofon Boss
- mikrofon Behringer
- mikrofon PreSonus
- mikrofon NGS
- mikrofon Godox
- mikrofon Electro-Voice
- mikrofon Valcom
- mikrofon Tascam
- mikrofon Midas
- mikrofon Auna
- mikrofon IK Multimedia
- mikrofon Blue Microphones
- mikrofon Jabra
- mikrofon IDance
- mikrofon Samson
- mikrofon Simplecom
- mikrofon Speed-Link
- mikrofon Sven
- mikrofon Shure
- mikrofon QTX
- mikrofon Konig
- mikrofon Reloop
- mikrofon Chandler
- mikrofon Austrian Audio
- mikrofon Wharfedale
- mikrofon Chord
- mikrofon Technaxx
- mikrofon Pure Acoustics
- mikrofon T'nB
- mikrofon Phonak
- mikrofon Tracer
- mikrofon Audac
- mikrofon Azden
- mikrofon Countryman
- mikrofon GVM
- mikrofon Zoom
- mikrofon Marshall Electronics
- mikrofon Creative
- mikrofon Omnitronic
- mikrofon Vaddio
- mikrofon Golden Age Project
- mikrofon Blue
- mikrofon Apart
- mikrofon Saramonic
- mikrofon Rode
- mikrofon Line 6
- mikrofon Primus
- mikrofon JLab
- mikrofon Radial Engineering
- mikrofon Max
- mikrofon BOYA
- mikrofon Celly
- mikrofon Comica
- mikrofon Audient
- mikrofon Xtreme
- mikrofon Skytec
- mikrofon M-Audio
- mikrofon Senal
- mikrofon NZXT
- mikrofon Kopul
- mikrofon Krom
- mikrofon Monoprice
- mikrofon Aston
- mikrofon DPA
- mikrofon Ambient Recording
- mikrofon Proel
- mikrofon HQ Power
- mikrofon Solid State Logic
- mikrofon HyperX
- mikrofon Crestron
- mikrofon Adastra
- mikrofon Konig & Meyer
- mikrofon TeachLogic
- mikrofon Power Dynamics
- mikrofon Citronic
- mikrofon Atlas
- mikrofon SPL
- mikrofon Monacor
- mikrofon Warm Audio
- mikrofon Ultimate Support
- mikrofon NOX
- mikrofon PSSO
- mikrofon Harley Benton
- mikrofon Kali Audio
- mikrofon Manley
- mikrofon JOBY
- mikrofon Audix
- mikrofon DAP Audio
- mikrofon Hohner
- mikrofon Thronmax
- mikrofon ClearOne
- mikrofon Dorr
- mikrofon Vocopro
- mikrofon Mojave
- mikrofon Singing Machine
- mikrofon Universal Audio
- mikrofon Auray
- mikrofon Bontempi
- mikrofon Triton
- mikrofon ITek
- mikrofon Schertler
- mikrofon Vimar
- mikrofon Speco Technologies
- mikrofon Pixel
- mikrofon Antelope Audio
- mikrofon Elgato
- mikrofon ONYX
- mikrofon MOZA
- mikrofon Gravity
- mikrofon DB Technologies
- mikrofon Hollyland
- mikrofon Epcom
- mikrofon TC Helicon
- mikrofon SE Electronics
- mikrofon Palmer
- mikrofon Fun Generation
- mikrofon Xvive
- mikrofon Karma
- mikrofon Nady
- mikrofon Oktava
- mikrofon Sontronics
- mikrofon Aston Microphones
- mikrofon Neewer
- mikrofon ANT
- mikrofon IMG Stage Line
- mikrofon Eikon
- mikrofon Kurzweil
- mikrofon JZ Microphones
- mikrofon Atlas Sound
- mikrofon Perfect Choice
- mikrofon Anywhere Cart
- mikrofon Owl Labs
- mikrofon Catchbox
- mikrofon White Shark
- mikrofon ViolaWave
- mikrofon Shadow
- mikrofon Fishman
- mikrofon Klover
- mikrofon Synco
- mikrofon Soundsation
- mikrofon Nuance
- mikrofon Joy-it
- mikrofon TIE Audio
- mikrofon Fluid
- mikrofon Relacart
- mikrofon Phonic
- mikrofon Lewitt
- mikrofon AVMATRIX
- mikrofon JTS
- mikrofon Klark Teknik
- mikrofon Lectrosonics
- mikrofon Intricon
- mikrofon The T.bone
- mikrofon Royer Labs
- mikrofon Miktek
- mikrofon Stageclix
- mikrofon Townsend Labs
- mikrofon Sabian
- mikrofon Sound Devices
- mikrofon Tula
- mikrofon DAP
- mikrofon United
- mikrofon ENDORFY
- mikrofon Alfatron
- mikrofon CAD Audio
- mikrofon Schoeps
- mikrofon Polsen
- mikrofon Sonuus
- mikrofon Mars Gaming
- mikrofon Majestic
- mikrofon AMT
- mikrofon Point Source Audio
- mikrofon AmpliVox
- mikrofon Eurosound
- mikrofon Rolls
- mikrofon Williams Sound
- mikrofon Mad Dog
- mikrofon SmallRig
- mikrofon Lorgar
- mikrofon KeepOut
- mikrofon Earthworks
- mikrofon Neat
- mikrofon Audibax
- mikrofon IMG Stageline
- mikrofon Scope Labs
- mikrofon AEA
- mikrofon Lauten Audio
- mikrofon Mirfak Audio
- mikrofon CKMOVA
- mikrofon Majority
- mikrofon DOCKIN
- mikrofon Nowsonic
- mikrofon Tonor
- mikrofon Prodipe
- mikrofon Deity
- mikrofon Antelope
- mikrofon MILAB
- mikrofon Vicoustic
- mikrofon Sanken
- mikrofon Switchcraft
- mikrofon Easyrig
- mikrofon Tonsil
- mikrofon Sescom
- mikrofon Sonic Presence
- mikrofon Movo
- mikrofon PureLink
- mikrofon Isovox
- mikrofon Glemm
- mikrofon Røde
- mikrofon Voice Technologies
- mikrofon PSC
- mikrofon Microtech Gefell
Nyaste mikrofon Manualer

16 Januari 2025

16 Januari 2025

15 Januari 2025

14 Januari 2025

8 Januari 2025

8 Januari 2025

7 Januari 2025

7 Januari 2025

6 Januari 2025

6 Januari 2025
