TECHNICAL SPECIFICTIONS
Transducer type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dynamic
Operating principle . . . . . . . . . . . . . . . . . . . Pressure gradient
Frequency response
Close miking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 - 18,.000 Hz
Distant miking (distance 1 m) . . . . . . . . . . . . . 40 - 18,000 Hz
Polar pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cardioid
Open circuit voltage
at1 kHz (0 dB = 1 V/Pa). . . . . . . . . . . . . . 1.8 mV/Pa (-55.0 dB) ±3 dB
Nominal impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 350 Ω
Load impedance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≥ 1.5 kΩ
Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR, 3-pin, male
Dimensions
Length. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185 mm
Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 320 g
APPLICATIONS
The M 70 PRO X dynamic microphone has an extended,
balanced frequency response and is used for high-
quality recordings of speech and vocals. The distinctive
cardioid polar pattern eliminates unwanted signals, and
the precisely tuned proximity effect ensures consistent
sound clarity. The extended frequency response ensures
a differentiated and high-resolution sound image.
The rugged design of the M 70 PRO X features a high
durability.
The integrated, elastic system suspension effectively
prevents mechanical vibration. The supplied pop filter
extensively suppresses plosive sounds, while the
gooseneck allows for optimal positioning.
The M 70 PRO X is particularly suitable for:
• Speech for broadcast applications
(radio, podcast, streaming)
• Vocals (rock, pop music)
FEATURES
• Extended and balanced frequency response
• Cardioid polar pattern
• Integrated elastic system suspension
• Rugged design
SUPPLIED ACCESSORIES
• Elastic microphone holder
• Studio pop filter with gooseneck
• Carrying bag
M 70 PRO X
Dynamic Microphone
Order # 718.351
beyerdynamic GmbH & Co. KG
Theresienr. 8 | 74072 Heilbronn – Germany
Tel. +49 (0) 71 31 / 617 - 300 | info@beyerdynamic.de | www.beyerdynamic.de
For fuher diributors worldwide, please go to www.beyerdynamic.com
Non-contractual illurations. Contents subject to change without notice. E1 / M 70 PRO X (04.21)
1 of 2
FREQUENCY RESPONSE & POLAR PATTERN
This polar pattern and frequency response curve (measuring tolerance ± 3 dB) correspond to a typical production sample
for this microphone.
M 70 PRO X
beyerdynamic GmbH & Co. KG
Theresienr. 8 | 74072 Heilbronn – Germany
Tel. +49 (0) 71 31 / 617 - 300 | info@beyerdynamic.de | www.beyerdynamic.de
For fuher diributors worldwide, please go to www.beyerdynamic.com
Non-contractual illurations. Contents subject to change without notice. E1 / M 70 PRO X (04.21)
2 of 2
Frequency response curve ± 3 dB M 70 PRO X 0 dB = 1.8 mV/Pa
Diance 2 cm
Diance 1 m
