User s Manual

’

’’

SRP-Q300/302

THERMAL RECEIPT PRINTER

Rev. 1.01

http://www.bixolon.com

Rev. 1.01

- 2 -

SRP-Q300/302

Introduction

SRP-Q300/302 series printers have been designed to be connected to various types of

electronic devices such as POS (Point Of Sales), and computer peripheral devices.

※

※※ The main features of the printer are as follows:

1. Thermal Printer and B-gate

2. Low-noise thermal transfer method printing

3. Maximum 220mm/s printing speed

4. External dimensions

- SRP-Q300/302: 128 x 125 x 125 (W x L x H)

- SRP-Q300H/302H: 128 x 125 x 160.2 (W x L x H)

5. Charging function for USB, Ethernet, Wireless LAN, Bluetooth, mobile devices; supports

NFC, DK, CDP

6. Equipped with data buffer (receives print data even while printing)

7. Can print a range of barcodes

8. Range of printing density and selectable speed

(controlled with virtual memory switch management)

It is advisable to read the contents of this manual carefully before using the printer for the rst

time.

※

※※ Use only authorized supplies that can be trusted!

- We are not responsible for quality and service for damage caused by the use of

unauthorized products (or recycled ones).

Rev. 1.01

- 3 -

SRP-Q300/302

Battery Safety Warning

Please sure to read this guide prior to use. be

Warning

1. If the battery is not charged after the charging time, stop charging and contact the seller.

2. Store and use the battery where it will not come into contact with liquid (water, salt water,

etc.). There may be a risk of overheating rupturing or igniting. ,

3. Avoid exposing the battery to high temperatures over 50 and do not store or use it in a ℃

place with high temperature and humidity. There may be a risk of overheating rupturing or ,

igniting In addition, it may reduce the performance and life of the battery. There is a risk of .

explosion, especially when the battery is placed a fire or stored near a heating device by

(e.g., heater, etc.).

4. Do not put the battery in a microwave oven or high-pressure cooker (pressure cooker, etc.).

There may be a risk of overheating rupturing or igniting. ,

5. Do not use or leave the battery exposed to direct sunlight or high temperatures such as in

a car. It may reduce battery performance and life, or there may be a risk of overheating,

rupturing or igniting.

6. The usage temperature range of the battery is as follows. If used outside of this range,

battery performance and life may be reduced, or there may be a risk of overheating,

rupturing or igniting.

- Charging: 0 to 40 C (32 to 104 ° ° F)

- Using: -15 to 50 C (5 to 122 ° ° F)

- g-term storage (over 30 days): -15 to 40 C (5 to 104 Lon ° ° F)

7. Be sure to only use adapter or charger approved by us to charge the battery. Use of an

any other adapter or charger may reduce battery performance and life, or cause a risk of

overheating pturing or igniting. , ru

8. Do not use the (+) and (-) terminals of the battery reversely. Failure to use the equipment

may result in an abnormal chemical reaction inside the battery, which may cause

overheating, rupturing or igniting.

9. Do not touch the (+) and (-) terminals of the battery with metal. Also, do not carry or store it

with metal goods (necklaces, hair pins, coins, etc.). There may be a risk of overheatinglic ,

rupturing or igniting.

10. Do not use the battery in a place where static electricity can be generated. It may damage

the protective device, resulting in reduction of battery performance and life, or there may

be a risk of overheating rupturing or igniting. ,

11. Avoid causing any strong impact to the battery or throwing it. The protective device inside

the battery may be damaged, which may reduce the battery performance and life, or there

may be a risk of overheating rupturing or igniting. ,
