Sida 1/174
The Ultimate
Driving Machine
Owner's Manual
for Vehicle
Contents
A-Z
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
325Ci
330Ci
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
Congratulations, and thank you for choosing a BMW.
Thorough familiarity with your vehicle will provide you with enhanced control and
security when you drive it. Therefore, we have one request:
Please take the time to read this Owner's Manual and familiarize yourself with the
information that we have compiled for you before starting off in your new BMW. The
manual contains important data and instructions intended to assist you in obtaining
maximum satisfaction from your BMW's unique array of advanced technical fea-
tures. It also contains information on vehicle maintenance designed to enhance
operating safety while simultaneously helping you to maintain your BMW's value
throughout an extended service life. For additional information refer to the supple-
mental manuals.
This Owner's Manual should be considered a permanent part of this vehicle. It
should stay with the vehicle when sold to provide the next owner with important
operating, safety and maintenance information.
We wish you an enjoyable driving experience.
BMW AG
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
4
Notes
© 2004 Bayerische Motoren Werke
Aktiengesellschaft
Munich, Germany
Reprinting, including excerpts, only with the
written consent of BMW AG, Munich.
Order No. 01 41 0 158 112
US English II/04
Printed in Germany
Printed on environmentally friendly paper,
bleached without chlorine, suitable for recycling.
About this Owner's Manual
We have made every effort to ensure
that you are able to find what you need
in this Owner's Manual as quickly as
possible. The fastest way to find certain
topics is by using the detailed index at
the end. If you wish to gain an initial
overview of your vehicle, you will find
this in the first chapter.
Should you wish to sell your BMW at
some time in the future, please remem-
ber to hand over this Owner's Manual
to the new owner; it is an important part
of the vehicle.
Additional sources of information
If you have any additional questions,
your BMW center will be glad to advise
you.
You can find more information about
BMW, for example on its technology,
on the Internet at www.bmw.com.
Symbols used
Indicates precautions that must
be followed precisely in order to
avoid the possibility of personal injury
and serious damage to the vehicle.
Indicates information that will
assist you in gaining the optimum
benefit from your vehicle and enable
you to care more effectively for your
vehicle.
Refers to measures that can be
taken to help protect the environ-
ment.
Marks the end of a specific item of
information.
Indicates special equipment, coun-
try-specific equipment and optional
extras when available.
Vehicle Memory, Key Memory,
refer to page . Identifies func-
58
tions that can be specifically adapted
for a particular key or vehicle. These
adjustments can be performed by your
BMW center.
Indicates that you should consult
the relevant section of this
Owner's Manual for information on a
particular part or assembly.
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
5
Notes
Your individual vehicle
On purchasing your BMW, you have
decided in favor of a model with individ-
ualized equipment and features. This
Owner's Manual describes all models
and equipment that BMW offers within
the same group.
We hope you will understand that
equipment and features are included
that you might not have chosen for your
vehicle. You can easily identify any dif-
ferences with the aid of the asterisk
used to identify all optional equipment
and accessories.
If your BMW features equipment such
as a car radio or telephone, which is not
described in this Owner's Manual, Sup-
plementary Owner's Manuals are
enclosed. We ask you to read these
manuals as well.
Status at time of printing
BMW pursues a policy of continuous,
ongoing development that is conceived
to ensure that our vehicles continue to
embody the highest quality and safety
standards combined with advanced,
state-of-the-art technology. For this
reason, the features described in this
Owner's Manual could differ from those
in your vehicle. Nor can errors and
omissions be entirely ruled out. You are
therefore asked to appreciate that no
claims can be recognized on the basis
of the data, illustrations or descriptions
in this Owner's Manual.
For your own safety
Maintenance and repair
Advanced technology, e.g. the
use of modern materials and high-
performance electronics, requires spe-
cially adapted maintenance and repair
methods. Therefore, only have corre-
sponding work on your BMW carried
out by a BMW center or a workshop
that works according to BMW repair
procedures with correspondingly
trained personnel. If work is carried out
improperly there is a danger of conse-
quential damage and the related safety
risks.<
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
6
Notes
Parts and accessories
Important safety information!
For your own safety, use genuine
parts and accessories approved by
BMW.
When you purchase accessories tested
and approved by BMW and Original
BMW Parts, you simultaneously acquire
the assurance that they have been thor-
oughly tested by BMW to ensure opti-
mum performance when installed on
your vehicle.
BMW warrants these parts to be free
from defects in material and workman-
ship.
BMW will not accept any liability for
damage resulting from installation of
parts and accessories not approved by
BMW.
BMW cannot test every product made
by other manufacturers to ascertain
whether it can be used on a BMW
safely and without risk to either the
vehicle, its operation, or its occupants.
Original BMW Parts, BMW Accessories
and other products approved by BMW,
together with professional advice on
using these items, are available from all
BMW centers.
Installation and operation of non-BMW
approved accessories such as alarms,
radios, amplifiers, radar detectors,
wheels, suspension components, brake
dust shields, telephones – including
operation of any portable cellular phone
from within the vehicle without using an
externally mounted antenna – or trans-
ceiver equipment such as a CB, walkie-
talkie, ham radio or similar, may cause
extensive damage to the vehicle, com-
promise its safety, interfere with the
vehicle's electrical system or affect the
validity of the BMW Limited Warranty.
Contact your BMW center for additional
information.
Do not use key or remote control to
lock doors or luggage compartment
with anyone inside the vehicle. Refer to
the Owner's Manual for more details.<
Maintenance, replacement, or
repair of the emission control
devices and systems may be performed
by any automotive repair establishment
or individual using any certified auto-
motive part.<
Service and warranty
This manual is supplemented by a Ser-
vice and Warranty Information Booklet
for US models or a Warranty and Ser-
vice Guide Booklet for Canadian mod-
els.
We recommend that you read this pub-
lication thoroughly.
Your BMW is covered by the following
warranties:
>New Vehicle Limited Warranty
>Rust Perforation Limited Warranty
>Federal Emissions System Defect
Warranty
>Federal Emissions Performance War-
ranty
>California Emission Control System
Limited Warranty.
Detailed information about these war-
ranties is listed in the Service and War-
ranty Information Booklet for US mod-
els or in the Warranty and Service
Guide Booklet for Canadian models.
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
7
Notes
Reporting safety defects
The following only applies to vehicles
owned and operated in the US.
If you believe that your vehicle has a
defect which could cause a crash or
could cause injury or death, you should
immediately inform the National High-
way Traffic Safety Administration
NHTSA in addition to notifying BMW of
North America, LLC, P.O. Box 1227,
Westwood, New Jersey 07675-1227,
telephone toll-free 1-800-831-1117.
If NHTSA receives similar complaints, it
may open an investigation, and if it
finds that a safety defect exists in a
group of vehicles, it may order a recall
and remedy campaign. However,
NHTSA cannot become involved in indi-
vidual problems between you, your
dealer, or BMW of North America, LLC.
To contact NHTSA, you may either call
the Auto Safety Hotline toll-free at
1-800-424-9393 or 366-0123 in the
Washington, D.C. area, or write to:
NHTSA, U.S. Department of Transpor-
tation, Washington, D.C. 20590. You
can also obtain other information about
motor vehicle safety from the Hotline.
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
Contents
Notes
About this Owner's Manual 4
Additional sources of
information 4
Symbols used 4
Your individual vehicle 5
Status at time of printing 5
For your own safety 5
Service and warranty 6
Reporting safety defects 7
Overview
Cockpit 14
Instrument cluster 16
Indicator and warning lamps 18
Buttons in steering wheel* 21
Hazard warning triangle* 22
First-aid kit* 22
Refueling 23
Fuel specifications 24
Controls and features
Opening and closing:
Keys 28
Central locking system 28
Opening and closing – via the
remote control 29
Opening and closing – via the
door lock 31
Opening and closing – from the
inside 32
Luggage compartment lid 33
Luggage compartment 35
Alarm system* 36
Electric power windows 38
Glass sunroof, electric* 39
Adjustments:
Safe seating position 41
Seats 42
Manual seat adjustment 42
Power seat adjustment* 44
Lumbar support* 44
Head restraints 45
Entering the rear 45
Safety belts 46
Seat and mirror memory* 47
Seat heating* 48
Mirrors 49
Steering wheel 50
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
Contents
9
Passenger safety systems:
Airbags 51
Transporting children safely 54
Vehicle Memory, Key
Memory 58
Driving:
Ignition lock 59
Starting the engine 59
Switching off the engine 61
Parking brake 61
Manual transmission 62
Sequential manual gearbox
SMG* 63
Automatic transmission with
Steptronic* 67
Turn signal indicator/Headlamp
flasher 70
Washer/wiper system/Rain
sensor* 71
Cruise control* 72
Everything under control:
Odometer 74
Tachometer 74
Energy control 74
Fuel gauge 75
Engine coolant temperature
gauge 75
Service interval display 76
Check Control 76
Clock 77
Computer 78
Technology for safety and
driving convenience:
Park Distance Control (PDC)* 80
Dynamic Stability Control
(DSC) 81
Flat Tire Monitor* 82
Brake force display 84
Lamps:
Parking lamps/Low beams 85
Adaptive headlights* 86
Instrument lighting 86
High beams/Standing lamps 87
Front fog lamps 87
Interior lamps 88
Controlling the climate for
pleasant driving:
Air conditioning 90
Automatic climate control* 94
Roller sun blind* 98
Interior conveniences:
Premium sound system* 99
Glove compartment 99
Storage compartments 100
Microphone* 101
Ashtray, front* 102
Ashtray, rear* 102
Clothes hooks 103
Loading and transporting:
Through-loading system 104
Ski bag* 105
Cargo loading 106
Roof-mounted luggage
rack* 109
Controls and features
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
Contents
Operation, maintenance
Special operating instructions:
Break-in procedures 112
General driving notes 113
Antilock Brake System
(ABS) 115
Wheels and tires:
Tire inflation pressure 116
Tire code 118
Tire condition 119
Run Flat tires* 120
New wheels and tires 121
Snow chains* 122
In the engine compartment:
Hood 123
Engine compartment
essentials 124
Washer fluids 126
Engine oil 126
Coolant 128
Brake fluid 128
Maintenance:
BMW Maintenance System 130
Laws and regulations:
California laws 132
OBD interface socket 132
Owner service procedures
Replacement procedures:
Onboard tool kit 136
Windshield wiper blades 136
Lamps and bulbs 137
Changing a wheel 141
Battery 145
Fuses 145
Giving and receiving
assistance:
Receiving assistance 146
Jump-starting 147
Towing and tow-starting the
vehicle 149
Technical data
Engine data 154
Dimensions 155
Weights 156
Capacities 157
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
Contents
11
Index
Everything from A to Z 160
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
12
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
13
Overview
Controls and features
Operation, maintenance
Owner service procedures
Technical data
Index
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
14
Cockpit
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
15
1 Parking lamps/Low beams 85
2>Turn signal indicators 70
>Standing lamps 87
>High beams 87
>Headlamp flasher 70
>Computer 78
3 Washer/wiper system/Rain
sensor 71
4 Hazard warning flashers
5 Central locking system 28
6>Initiating an emergency call 146
>Mobile Service 147
7 Rear window defroster , 92 97
8 Horn: the entire surface
9 Adjusting the steering wheel 50
10 Fog lamps 87
Cockpit
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
16
Instrument cluster
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
17
1 Fuel gauge 75
2 Indicator lamp for turn signals 20
3 Speedometer
4 Indicator and warning lamps 18
to 20
5 Tachometer and Energy Control 74
6 Engine coolant temperature
gauge 75
7 Indicator and warning lamps 18
to 20
8 Control button for the clock 77
9 Selector lever and program display
for automatic transmission/sequen-
tial manual gearbox SMG, transmis-
sion indicator lamp , ,
19 65 69
10 Display for
>Trip odometer/Odometer 74
>Clock 77
>Service interval 76
>Computer 78
11 Check Control 76
12 Trip odometer, reset to zero 74
13 Indicator and warning lamps 18
to 20
Instrument cluster
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
18
Indicator and warning lamps
Technology that monitors itself
Indicator and warning lamps that are
identified by ● are tested for proper
functioning whenever the ignition key is
turned. They each light up once for dif-
ferent periods of time.
If a fault should occur in one of these
systems, the corresponding lamp does
not go out after the engine is started, or
it lights up while the vehicle is moving.
You will see how to react to this below.
Red: stop immediately
Battery charge current ●
The battery is no longer being
charged. Indicates a defective
alternator drive belt or a problem with
the alternator's charge circuit. please
contact the nearest BMW center.
If the drive belt is defective, stop
and switch off the engine immedi-
ately to prevent overheating and seri-
ous engine damage. If the drive belt is
defective, increased steering effort is
also required.<
Engine oil pressure ●
The engine oil pressure is too
low. Stop the vehicle immedi-
ately and switch off the engine. It is not
possible to continue driving. Please
contact the nearest BMW center.
Do not continue driving, as the
engine could sustain serious dam-
age from inadequate lubrication.<
Brake warning lamp ●
If the lamp comes on when the
parking brake is not engaged:
check the brake fluid level. It is very
important that you follow the instruc-
tions on page before driving on.
128
Have the system checked immediately.
Brake warning lamp for Cana-
dian models.
Flat Tire Monitor ●
In addition, an acoustic signal is
sounded: there is a flat tire.
Reduce speed and carefully come to a
stop. Avoid sudden braking and steer-
ing maneuvers.
For additional information, refer to
page .
83
Red and yellow: continue driving
cautiously
The brake warning lamp comes
on together with the yellow indi-
cator lamps for ABS ● and
DSC:
The entire ABS, CBC and DSC
control system has failed. Con-
tinue driving cautiously and
defensively. Avoid hard brake
applications. Please have the system
checked by your BMW center as soon
as possible.
Additional information beginning on .
81
CBC, ABS and DSC and DBC
indicator and warning lamps for
Canadian models.
Red: an important reminder
Brake warning lamp
Comes on when the parking
brake is applied – an additional
acoustic signal sounds when starting
off.
For additional information, refer to
page .
61
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
19
Brake warning lamp for Cana-
dian models.
Please fasten safety belts ●
Comes on together with an
acoustic signal until the safety
belts are fastened.
For additional information on safety
belts, refer to page .
46
Airbags ●
Have the system checked as
soon as possible.
For additional information, refer to
page .
53
Orange: consult the nearest BMW
center
Automatic transmission/sequen-
tial manual gearbox
The respective transmission has
responded to a malfunction by reverting
to operation in its emergency default
program. Have the system checked
immediately.
For additional information, refer to
pages .
65, 69
Yellow: check as soon as possible
Engine oil level
If the lamp comes on during
normal vehicle operation: the
engine oil level has fallen to the abso-
lute minimum; refill as soon as possible.
Do not drive more than approx.
30 miles/50 km before refilling.
For additional information, refer to
page .126
Engine oil level
Comes on after the engine has
been shut off: add engine oil at
the earliest opportunity, such as the
next time you stop to refuel.
For additional information, refer to
page .
126
Brake pads ●
Have the brake pads checked
immediately.
For additional information, refer to
page .
114
Flat Tire Monitor ●
The Flat Tire Monitor is malfunc-
tioning or out of order. If there is
a malfunction, have the system
checked.
For additional information, refer to
page .84
Dynamic Stability Control
(DSC) ●
Indicator lamp flashes:
The system is actively regulating drive
torque and braking force.
The indicator lamp stays lit:
DSC has been switched off with the
button; DTC is operational.
If there is a malfunction, have the sys-
tem checked.
Additional information beginning on .
81
Dynamic Stability Control (DSC)
and brake warning lamp
The indicator lamps remain on:
DSC/DTC have been switched
off with the button or are faulty.
If there is a malfunction, have
the system checked as soon as possi-
ble.
Additional information beginning on .
81
DSC indicator and brake warn-
ing lamps for Canadian models.
Indicator and warning lamps
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
20
Dynamic Brake Control (DBC) ●
Malfunction in the DBC system.
Conventional braking efficiency
is available and unrestricted.
Have the system checked as soon as
possible.
For additional information, refer to
page .
115
Dynamic Brake Control (DBC)
warning lamp for Canadian
models.
Add washer fluid
The washer fluid level is too low,
top it up at the earliest opportu-
nity.
For additional information, refer to
page .
126
CHECK GAS CAP* ●
This indicator lamp comes on
when the gas cap is loose or
missing.
Close the gas cap tightly: refer to
page .
24
SERVICE ENGINE SOON ●
If the indicator lamp comes on
either continuously or intermit-
tently, this indicates a fault in the emis-
sions-related electronic systems.
Although the vehicle remains opera-
tional, you should have the systems
checked by your BMW center at the
earliest possible opportunity.
For additional information, refer to
page .
132
Service Engine Soon indicator
lamp for Canadian models.
Engine electronics ●
There is a fault in the electronic
engine-management system.
You can continue to drive with reduced
engine output or engine speed. Please
have the system inspected at your
BMW center.
Add coolant
The coolant level is too low. Add
coolant at the earliest opportu-
nity.
For additional information, refer to
page .
128
Green: for your information
Turn signal indicator
Flashes when the turn signal is
operated.
Rapid flashing indicates a system mal-
function.
For additional information, refer to
page .
70
Cruise control
Lights up when the cruise con-
trol is activated. Ready for oper-
ation via the buttons in the steering
wheel.
For additional information, refer to
page .
72
Front fog lamps
Lights up whenever you switch
on the front fog lamps.
For additional information, refer to
page .
87
Blue: for your information
High beams
Comes on when the high beams
are on or the headlamp flasher
is actuated.
For additional information, refer to
pages , .
70 87
Indicator and warning lamps
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
21
Buttons in steering wheel*
These buttons let you operate the fol-
lowing functions quickly and without
being distracted from traffic conditions:
>Selected radio functions
>The cruise control
>Selected telephone functions
>The voice recognition system.
The controls are active only when
the corresponding systems and
accessories are switched on.<
Press briefly:
Receive a phone call, initiate dialing,
terminate a call.
Extended pressure:
Switch voice recognition on and off.
Display/hide telephone book. Display
the entries one after another with the
forward/backward buttons.
Forward:
>Radio
Press briefly: next station in station
memory
Extended pressure: station search
>CD
Press briefly: jump to next track
Extended pressure: search function
in track
>Cassette
Press briefly: jump to next track or
stop fast forward
Extended pressure: fast forward
>Phone
Scan personal phone book.
Rewind: same functions as forward.
Volume.
Cruise control: select a stored setting.
Cruise control: store and accelerate +
or decelerate and store –.
Cruise control: activate/interrupt/deac-
tivate.
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
22
Hazard warning triangle*
The hazard warning triangle is stored in
a storage case on the left side of the
luggage compartment.
Always observe all legal regula-
tions requiring a warning triangle
to be carried in the vehicle. <
First-aid kit*
The first-aid kit is located under the
passenger seat.
To release: pull the handle and fold the
cover down.
To close: fold the cover up and press it
until the tab engages.
Several of the items contained in
the first-aid pouch have a limited
service life. For this reason, check the
expiration dates of each of the items
regularly, and replace any with passed
dates. These items can be purchased in
any drugstore or pharmacy.
Always observe all legal regulations
requiring a first-aid kit to be carried in
the vehicle.<
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
23
Refueling
Fuel filler door
Always switch off the engine
before refueling, as it is not possi-
ble to add fuel with the engine running,
and attempts may also trigger the
SERVICE ENGINE SOON lamp.<
Press on the rear edge of the fuel filler
door to open and close it.
If an electrical malfunction occurs, you
can unlock the fuel filler door manually:
Pull the knob with the fuel pump sym-
bol, located on the right side wall of the
luggage compartment.
Always observe all safety precau-
tions posted at the service station
when handling fuel.
Never carry spare fuel containers in
your vehicle. Whether empty or full,
these containers can leak, cause an
explosion, or lead to fire in the event of
a collision.<
Please observe while refuelling
Open the gas cap carefully to pre-
vent fuel from spraying out. Fuel
spray may cause injury.<
Place the gas cap in the bracket
attached to the fuel filler door.
When refueling, insert the filler nozzle in
the filler pipe. Lifting the nozzle during
refueling
> results in premature pump shutoff
> and will reduce the effect of the vapor
recovery system on the pump.
The fuel tank is full when the filler noz-
zle shuts off the first time.
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
24
Closing the gas cap
Place the cap in position and turn it
until a clearly audible click is heard.
Close the gas cap carefully after
refueling until a click is heard.
While closing, be sure not to squeeze
the strap which is fastened to the cap.
A loose or missing cap will activate the
CHECK GAS CAP lamp.* <
Warning lamp lights up. The *
gas cap is not properly closed
or is missing. Check if the gas
cap is properly closed.
Fuel tank capacity
> Approx. 16.6 gal./63 liters, of which
> approx. 2.1 gal./8 liters are reserve
capacity.
Do not drive to the last drop of
fuel. This can prevent the engine
from operating properly and result in
damage.<
Fuel specifications
The engine uses lead-free gasoline
only.
Required fuel
Premium Unleaded Gasoline,
Minimum Octane Rating: AKI 91.
Minimum Octane Rating corresponds to
the Anti Knock Index AKI and is deter-
mined according to the so-called
(R+M)/2 method.
Do not use leaded gasoline, as
otherwise the lambda probe and
catalytic converter will be permanently
damaged.<
Use high-quality brands
Field experience has indicated signifi-
cant differences in fuel quality: volatility,
composition, additives, etc., among
gasolines offered for sale in the United
States and Canada. Fuels containing up
to and including 10% ethanol or other
oxygenates with up to 2.8 % oxygen by
weight, that is, 15% MTBE or 3% meth-
anol plus an equivalent amount of co-
solvent, will not void the applicable
warranties with respect to defects in
materials or workmanship.
The use of poor-quality fuels may
result in drivability, starting and
stalling problems especially under cer-
tain environmental conditions such as
high ambient temperature and high alti-
tude.
Should you encounter drivability prob-
lems which you suspect could be
related to the fuel you are using, we
recommend that you respond by
switching to a recognized high-quality
brand.
Failure to comply with these recom-
mendations may also result in unsched-
uled maintenance.<
Refueling
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
25
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
26
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
28
Opening and closing
Keys
The key set
1 Master keys with remote control.
They govern the functions of the Key
Memory. Certain functions in your
vehicle may operate differently
depending on the key, refer to
page .
58
To distinguish between keys, you can
mark each key with remote control by
applying one of the colored decals
that you received when accepting
delivery of your vehicle
In every master key with the
remote control feature there is an
extended-life battery that is charged
automatically in the ignition lock as you
drive.
Therefore, use otherwise unused mas-
ter keys for a longer journey every six
months so that the battery can be
charged.<
2 Spare key – for storage in a safe
place, such as in your wallet. This key
is not intended for constant use. The
luggage compartment lid and the
glove compartment cannot be locked
and unlocked with this key. This is
useful for valet parking, for example
Central locking system
The concept
The central locking system is ready for
operation whenever the driver's door is
closed. The system simultaneously
engages and releases the locks on the
>doors
>luggage compartment lid
>fuel filler door.
The central locking system can be
operated
>from outside via the remote control
as well as via the driver's door lock
>from inside by pressing a button.
The fuel filler door is not locked when
the central locking system is activated
from the inside, refer to page . When
32
the system is actuated from the out-
side, the anti-theft system is also acti-
vated. This prevents the doors from
being unlocked via the lock buttons or
the release handle. The alarm system is
also activated or deactivated.
If locked from the inside, the central
locking system unlocks automatically in
the event of an accident, except on
doors that have been locked individu-
ally using the lock buttons, refer to
page . In addition, the hazard warn-
32
ing flashers and interior lamps come on.
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
29
Opening and closing – via the remote control
The concept
The remote control also provides two
additional functions beyond the central
locking feature:
>To switch on interior lamps, refer to
page .
30
With this function you can also
search for your vehicle when parked
in an underground garage, for
instance
>To open the luggage compartment
lid, refer to page .
30
The luggage compartment lid will
open slightly, regardless of whether it
was previously locked or unlocked.
Whenever you unlock or lock the vehi-
cle, you simultaneously deactivate/acti-
vate the anti-theft system, disarm/arm
the alarm system and switch the interior
lamps on/off.
You can have a signal set to con-
firm that the vehicle's locks have
engaged securely.<
Master keys with remote control
Persons or animals inside the
vehicle may be able to lock the
doors from the inside. For this reason,
always take the vehicle keys with you
so that the vehicle can be opened again
from the outside at any time.<
If it is no longer possible to lock
the vehicle via the remote control,
the battery is discharged. Use this key
while driving for an extended period in
order to recharge the battery.
To prevent unauthorized use of the
remote control, surrender only the
spare key when leaving the vehicle for
valet parking, for example.
In the event of a system malfunction,
please contact your BMW center. You
can also obtain replacement keys
there.<
1 Unlock, convenience opening mode,
and disarm alarm system
2 Lock and secure, arm alarm system,
activate interior lamps, disarm tilt
alarm sensor and interior motion sen-
sor
3 Open the luggage compartment lid,
Panic mode – trigger alarm
To release
Press the button once to unlock the
driver's door.
Press the button a second time to dis-
engage all vehicle locks.
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
30
Convenience opening mode
Press the button briefly and then keep it
pressed. The electric power windows
and the glass sunroof open.
To lock and secure
Press button.
To switch on the interior lamps
With the vehicle locked, press button.
With this function, you can also search
for your vehicle when parked in an
underground garage, for instance.
To open the luggage
compartment lid
Press button briefly.
The luggage compartment lid will open
slightly, regardless of whether it was
previously locked or unlocked.
If the vehicle was previously
locked, the luggage compartment
is also locked again after it is closed.
Before and after a trip, be sure that the
luggage compartment lid has not been
opened unintentionally.<
Panic mode* – trigger alarm
By pressing the button for more than
2 seconds, the alarm system* can be
triggered in the event of danger, if the
system is armed.
To switch off the alarm:
Press button.
External systems
Malfunctions:
Local radio waves can impede the func-
tioning of the remote control.
If this occurs, open and close the vehi-
cle using a master key in the door lock.
For US owners only
The transmitter and receiver units com-
ply with part 15 of the FCC Federal
Communications Commission regula-
tions. Operation is governed by the fol-
lowing:
FCC ID:
>LX8EWS
>LX8FZVS
>LX8FZVE.
Compliance statement:
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
>This device may not cause harmful
interference, and
>this device must accept any interfer-
ence received, including interference
that may cause undesired operation.
Any unauthorized modifications to
these devices could void the
user's authority to operate the equip-
ment.<
Opening and closing – via the remote control
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
31
Opening and closing – via the door lock
One turn of the key in the driver's door
lock unlocks the driver's door only.
Turning the key a second time unlocks
the passenger-side door, the luggage
compartment lid and the fuel filler door.
You can have a signal set to con-
firm that the vehicle's locks have
engaged securely.<
Convenience operation
You can also operate the power win-
dows and the glass sunroof via the door
lock.
>To open: with the door closed, hold
the key in the Unlock position
>To close: with the door closed, hold
the key in the Lock position.
Whenever closing the windows or
sliding/tilt sunroof you should
always monitor their path and progress
to ensure that no one is injured.
Release the key to stop the windows or
sliding/tilt sunroof.<
Manual operation
If there is an electrical malfunction, you
can unlock or lock the driver's door by
turning the key in the lock all the way to
the left or right.
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
32
Opening and closing – from the inside
You can use this button to control the
central locking system whenever the
doors are closed. The doors and lug-
gage compartment lid are unlocked or
locked only. The anti-theft system is not
activated.
If only the driver's door was
unlocked from the outside and
you press the button, then, with the
driver's door still open, the passenger-
side door, the luggage compartment lid
and the fuel filler door will unlock, too.
If the driver's door is closed, it will be
locked.<
If you desire, the central locking
system can be activated automati-
cally as soon as you begin to drive. This
can be adjusted to be key-specific.<
To unlock and open the doors
1. Press the button for the central lock-
ing system
2. Pull the release handle above the
armrest on the door you wish to open
or
pull the release handle for any door
twice: to unlock and open the door.
To lock
>Either use the central locking button
to lock both doors at once or
>press the individual door lock buttons
down. In this case, the fuel filler door
will stay unlocked. To prevent the
driver from being inadvertently
locked out of the vehicle, the driver's
door lock button will not engage as
long as the door is open.
Persons or animals inside the
vehicle may be able to lock the
doors from the inside. For this reason,
always take the vehicle keys with you
so that the vehicle can be opened again
from the outside at any time.<
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
33
Luggage compartment lid
The lock
Only the master keys fit in the lock for
the luggage compartment lid, refer to
page .
28
To secure separately
Turn the master key to the right past the
resistance point and then pull it out in
the horizontal position.
This locks the luggage compartment lid
and disconnects it from the central
locking system. This feature can be
used to prevent unauthorized access to
the luggage compartment when you
surrender the spare key only, refer to
page . This can be advantageous for
28
valet parking, for example.
To open from the outside
Press the button in the handle recess:
the luggage compartment lid opens
slightly.
The luggage compartment is lit when it
is opened.
Manual operation
In the event of electrical malfunction
Turn the master key all the way to the
left – the luggage compartment lid will
open slightly.
The luggage compartment lid is locked
again as soon as you close it.
To open from the inside, refer to the fol-
lowing section.
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
34
To open from the inside*
If the luggage compartment lid has not
been locked separately, you can open it
with this button in the footwell on the
driver's side when the vehicle is sta-
tionary.
To close
The handle recesses in the interior trim
panel of the luggage compartment lid
make it easier to pull the lid down.
To avoid injuries, be sure that the
travel path of the luggage com-
partment lid is clear when it is closed,
following the same precautions as with
all closing procedures.<
Operate the vehicle only when the
luggage compartment lid is com-
pletely closed. Otherwise, exhaust
fumes could penetrate the interior of
the vehicle.<
If at any time it does become necessary
to operate the vehicle with the luggage
compartment lid open:
1. Close all windows and the glass sun-
roof
2. Greatly increase the quantity of air
coming from the air conditioning or
automatic climate control system,
refer to page .
90 or 94
Luggage compartment lid
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
36
Floor mat
You can turn the floor mat over to trans-
port soiled objects, etc. The rubber-
coated side is suitable for washing and
is also designed to inhibit sliding.
The fittings at the corners of the lug-
gage compartment provide you with a
convenient means of attaching luggage
compartment nets and flexible straps *
for securing luggage.
Refer also to Cargo loading on
page .
106
Alarm system*
The concept
The vehicle alarm system responds:
>When a door, the hood or the lug-
gage compartment lid is opened
>To movement inside the vehicle –
interior motion sensor
>To variations in the vehicle's tilt angle
such as those occurring during
attempts to steal the wheels or tow
the vehicle – tilt alarm sensor.
>To interruption of battery voltage.
The system responds to unauthorized
vehicle entry and attempted theft by
simultaneously activating the following:
>The acoustic alarm sounds for
30 seconds
>The hazard warning flashers are acti-
vated for approx. five minutes
>The high beams flash on and off in
rhythm with the hazard warning flash-
ers.
To arm and disarm the alarm
system
When the vehicle is locked or unlocked
via the remote control or the driver's
door lock, the alarm system is also
simultaneously armed or disarmed.
You can have different acknowl-
edgment signals set to confirm
arming and disarming.<
You can also open the luggage com-
partment lid when the system is armed
by pressing the remote control button,
refer to page . The lid is once again
30
secured when it is closed.
Extended pressure on the button sets
off the alarm – Panic mode, refer to
page .
30
Luggage compartment
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
37
Indicator lamp displays
>The indicator lamp below the interior
rearview mirror flashes continuously:
the system is armed
>The indicator lamp flashes immedi-
ately after the vehicle is locked: doors
or luggage compartment lid are not
completely closed. Even if you do not
close the alerted area(s), the remain-
ing areas are secured, and the indi-
cator lamp will flash continuously
after 10 seconds. However, the inte-
rior motion sensor is not activated
>The indicator lamp goes out immedi-
ately after the vehicle is unlocked: no
manipulation or attempted intrusions
have been detected in the period
since the system was armed
>The indicator lamp flashes for
10 seconds immediately after the
system is armed: an attempted entry
has been detected in the period since
the system was armed.
Following triggering of an alarm, the
indicator lamp will flash continuously.
Tilt alarm sensor and interior
motion sensor
Tilt alarm sensor:
The tilt of the vehicle is monitored. The
alarm system reacts, for example, to
attempts to steal the wheels or tow the
vehicle
Interior motion sensor:
In order for the interior motion sensor to
function properly, the windows and the
glass sunroof must be completely
closed.
Avoiding unintentional alarms
The tilt alarm sensor and interior motion
sensor may be switched off at the same
time. You can do this to prevent a false
alarm, e.g. in the following situations:
>In garages with elevator ramps
>When the vehicle is being trans-
ported by train
>When animals are to remain in the
vehicle.
To deactivate the tilt alarm and
interior motion sensors
>Press the button on the remote con-
trol twice.
The indicator lamp lights up briefly and
then flashes continuously. The tilt alarm
sensor and the interior motion sensor
are deactivated until the vehicle is
unlocked and locked again.
You can have the tilt alarm sensor
and the interior motion sensor
permanently deactivated.<
The system inadvertently deacti-
vates the tilt alarm sensor and the
interior motion sensor if the conve-
nience closing of windows and glass
sunroof is interrupted within the first
10 seconds and then restarted. The
vehicle must then be unlocked and
relocked before the sensors will resume
operation.<
Alarm system*
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
38
Electric power windows
To open and close windows
With the ignition key in position 1 or
higher:
>Press the switch to the resistance
point: the window retracts, or respec-
tively the tilt-out window moves out-
ward; it remains in motion for as long
as you maintain pressure on the
switch
>Press the switch briefly past the pres-
sure point: the window moves auto-
matically. Pressing the switch again
stops the opening cycle.
You can close the window in the same
manner by pulling the switch. The tilt-
out window does not close automati-
cally.
After the ignition has been switched off:
You can still operate the electric power
windows for up to 15 minutes, as long
as no one opens either of the doors.
When leaving the vehicle, always
remove the ignition key from the
lock and remember to close the doors
to prevent children from operating the
power windows and injuring them-
selves, etc.<
For convenience operation via the
remote control or the door lock, refer to
page .
30 or 31
Trap protection
The front windows are each equipped
with a contact strip located on the
upper inside of the window frame. If
pressure is exerted against this contact
strip while the window is being raised,
the system will respond by stopping the
window and then retracting it a small
distance.
Despite trap protection, always be
careful to ensure that the closing
path of the window is not obstructed.
Some types of objects, for instance
very thin objects, might fail to trigger
the contact strip in some situations.
If the switch is pulled and held beyond
the resistance point, this trap protection
is overridden.<
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
39
Glass sunroof, electric*
To prevent injuries, exercise care
when closing the glass sunroof
and keep it in your field of vision until it
is shut.
When leaving the vehicle, always
remove the ignition key from the lock
and remember to close the doors to
prevent children from operating the
glass sunroof and injuring themselves,
etc.<
Opening and closing
With the ignition key in position 1 or
higher.
>Slide the switch until you feel resis-
tance: the glass sunroof opens and
closes as long as you hold the switch
>Slide the switch past the pressure
point: the glass sunroof moves auto-
matically.
Tapping the switch again stops the
motion immediately.
The headliner insert retracts with the
glass sunroof while it is opening.
After the ignition has been switched off:
you can still operate the glass sunroof
for up to 15 minutes, as long as no one
opens either of the doors.
For the convenience mode via the
remote control or the door lock, refer to
page .
30 or 31
Raising the glass sunroof
With the ignition key in position 1 or
higher: tap the switch.
Tapping the switch again stops the
motion immediately.
If you briefly press the switch in the
raise direction while the glass sunroof is
open, the sunroof will rise to its upper-
most position.
After the ignition has been switched off:
you can still operate the glass sunroof
for up to 15 minutes, as long as no one
opens either of the doors.
The headliner insert slides back some-
what when you raise the glass sunroof.
Do not use force to close the
headliner insert with the sunroof in
its raised position, otherwise the mech-
anism will be damaged. When leaving
the vehicle, always remove the ignition
key from the lock and remember to
close the doors, otherwise children
could operate the sunroof and injure
themselves, etc.<
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
40
Trap protection
If the glass sunroof encounters resis-
tance when closing from approximately
the half-closed position or when closing
from the raised position, the closing
operation is interrupted and the glass
sunroof reopens slightly.
Despite trap protection, always
make sure that the sunroof can
close without obstruction, otherwise in
some cases, e.g. with thin objects, it is
not guaranteed that the closing opera-
tion will be interrupted.
Trap protection is restricted when the
switch is pressed and held beyond the
pressure point. The sunroof opens only
slightly. If the switch is pressed and
held beyond the pressure point again
within approx. 2 seconds, trap protec-
tion is overridden.<
Manual operation
The glass sunroof can also be operated
manually in the event of an electrical
malfunction.
1. Pull out the switch, then reach into
the exposed opening and press out
the cover
2. Use the Allen key from the onboard
tool kit, refer to page , to turn the
136
glass sunroof in the desired direc-
tion.
Initializing the glass sunroof
If the glass sunroof can no longer
be automatically opened or closed
after manual operation, it must be ini-
tialized.<
With the key in ignition position 1 or
higher, press and hold the switch
beyond the pressure point until the
glass sunroof moves slightly.
Glass sunroof, electric*
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
42
Seats
When adjusting your seat, always
observe the following precautions
Never try to adjust your seat while
operating the vehicle. The seat
could respond with an unexpected
movement, and the ensuing loss of
vehicle control could lead to an acci-
dent. Never ride with the backrest
reclined to an extreme angle. This is
especially important for the front pas-
senger to remember. If you do, there is
a risk that you will slide under the safety
belt in an accident, thus reducing the
protection provided by the safety belt.<
Seat adjustment
>Manual seat adjustment, refer to
page 42
>Power seat adjustment, refer to
page 44
>Head restraint, refer to page 45
>Entering the rear, refer to page .45
Manual seat adjustment
Seat adjustment
1 Forward/backward adjustment
Pull the lever and slide the seat to the
desired position.
After you release the lever, move the
seat forward or backward slightly so
that it engages fully
2 Cushion height
Pull the lever and apply weight to or
remove weight from the seat as
required
3 Backrest angle
Pull the lever and apply weight to or
remove weight from the backrest to
reach the desired position
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
43
BMW sports seat* adjustment
You can also adjust the tilt angle and
the thigh support:
1 To tilt up:
Pull the lever up repeatedly, continu-
ing until the seat reaches the desired
tilt angle
2 To tilt down:
Push the lever down repeatedly, con-
tinuing until the seat reaches the
desired tilt angle
3 Thigh support:
Pull the lever and adjust the position
of the cushion for thigh support as
desired
Manual seat adjustment
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
45
Head restraints
Adjustments
Height: adjust by pulling up or pressing
down.
Press button to retract to the
lowest position – see arrow 1.<
Adjust the angle of the front head
restraints by tilting them manually.
You can reduce the risk of spinal
injury and whiplash by adjusting
the head restraint to a height at which it
is centered roughly at ear level.<
Removal – front
1. Pull up the head restraint, continuing
until it is at maximum extension
2. Press button – see arrow 1 – and
remove the head restraint.
Installation – front
Slide the head restraint into the sock-
ets.
Entering the rear
To release the backrest
Pull the lever upward and fold the back-
rest forward.
Lock both backrests while driving,
otherwise there is a danger of an
unexpected movement causing an
accident.<
OverviewControlsMaintenanceRepairsDataIndex
Online Edition for Part-No. 01 41 0 158 112 - © 03/04 BMW AG
Produktspecifikationer
| Varumärke: | BMW |
| Kategori: | Bil |
| Modell: | 3 Series Coupe (2006) |
Behöver du hjälp?
Om du behöver hjälp med BMW 3 Series Coupe (2006) ställ en fråga nedan och andra användare kommer att svara dig
Bil BMW Manualer
19 Oktober 2024
18 Oktober 2024
16 Oktober 2024
13 Oktober 2024
9 Oktober 2024
8 Oktober 2024
3 Oktober 2024
2 Oktober 2024
28 September 2024
20 September 2024
Bil Manualer
- Bil Ford
- Bil Fiat
- Bil Opel
- Bil Pioneer
- Bil Renault
- Bil Volvo
- Bil Alfa Romeo
- Bil ACME
- Bil Infiniti
- Bil Subaru
- Bil Saturn
- Bil Audi
- Bil Hyundai
- Bil GMC
- Bil Audio-Technica
- Bil Skoda
- Bil Chevrolet
- Bil Kia
- Bil Suzuki
- Bil Nissan
- Bil Mitsubishi
- Bil Peugeot
- Bil Toyota
- Bil Land Rover
- Bil Volkswagen
- Bil Chrysler
- Bil Lexus
- Bil Jaguar
- Bil Citroën
- Bil Seat
- Bil Genesis
- Bil Buick
- Bil Honda
- Bil Cadillac
- Bil Jeep
- Bil Tesla
- Bil Rover
- Bil Pontiac
- Bil Mazda
- Bil Mercedes-Benz
- Bil MG
- Bil Mini
- Bil DS
- Bil Vauxhall
- Bil Dodge
- Bil Smart
- Bil Porsche
- Bil Maserati
- Bil Saab
- Bil Lancia
- Bil RAM
- Bil Acura
- Bil Mercury
- Bil Marklin
- Bil Dacia
- Bil POLARIS
- Bil Scion
- Bil Tata
- Bil GEM
- Bil VDL
- Bil Sharper Image
- Bil Aguilar
- Bil Abarth
- Bil Lincoln
- Bil Mahindra
- Bil Chery
- Bil Lada
- Bil Aston Martin
- Bil McLaren
Nyaste Bil Manualer
7 April 2025
3 April 2025
1 April 2025
1 April 2025
26 Mars 2025
13 Mars 2025
10 Mars 2025
10 Mars 2025
10 Mars 2025
10 Mars 2025
