MODELS 2830 & 2836 ECLIPSE

DOWNDRAFT BLOWER SYSTEM

READ AND SAVE THESE INSTRUCTIONS

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO

PERSONS, OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended by the manufacturer. If you have

questions, contact the manufacturer at the address or telephone number

in the warranty.

2. Before servicing or cleaning unit, switch power off at service panel and lock

the service disconnecting means prevent power from being switched to

on accidentally. When the service disconnecting means cannot be locked,

securely fasten a prominent warning device, such as a tag, to the service

panel.

3. Installation work and electrical wiring must be done by a qualified person(s)

in accordance with all applicable codes and standards, including fire-rated

construction codes and standards.

4. Sufficient air is needed proper combustion and exhausting of gases for

through the flue (chimney) of fuel burning equipment to prevent backdraft-

ing. Follow the heating equipment manufacturer’s guideline and safety

standards such as those published the National Protection by Fire Asso-

ciation (NFPA), and the American Society Heating, Refrigeration and for

Air Conditioning Engineers (ASHRAE), and the local code authorities.

5. When cutting or drilling into wall or ceiling, do not damage electrical wiring

and other hidden utilities.

6. Do not use this range hood with an additional speed control device.

7. Ducted fans must be vented the outdoors. always to

8. To reduce the risk of use only metal fire, ductwork.

9. Do not install this product with the activating switch directly behind a burner

or element. Minimum distance between the switch and the edge of the

burner should be 4 inches.

10. Loose-fitting or hanging clothing should never be when operating worn

this appliance. They be ignited may by burners/elements on cooktop.

11. Children should not be left alone or unattended in the area where this

appliance is in use.

12. This unit must be grounded.

TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:

1. Never leave surface units unattended at high settings. Boilovers cause

smoking and spillovers that ignite. greasy may Heat oils slowly on or low

medium settings.

2. Always turn hood ON when cooking at high heat or when cooking flaming

foods.

3. Clean ventilating fans frequently. Grease should not be allowed to

accumulate on or filter. fan

4. Use proper pan size. Always use cookware appropriate for the size of the

surface element.

TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A

RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWINGa:

1. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray,

then turn the burner. off BE CAREFUL TO PREVENT BURNS. If the

flames do not go out immediately, EVACUATE AND CALL THE FIRE

DEPARTMENT.

2. NEVER PICK UP A - FLAMING PAN You may be burned.

3. DO USE WATER, including dishcloths or towels violent NOT wet - a

steam explosion will result.

WARNING

4. Use an extinguisher ONLY if:

A. You know you have a Class ABC extinguisher, and you already

know operate how to it.

B. The is small fire and contained in the area where it

started.

C. The department is being fire called.

can fight the with your back an exit.D. You fire to

a Based on “Kitchen Firesafety Tips” published by NFPA.

CAUTION

1. For indoor use only.

2. For general ventilating use only. Do not use to exhaust hazardous or

explosive materials and vapors.

3. To avoid motor bearing damage and noisy and/or unbalanced impel-

lers, keep drywall spray, construction dust, etc. off power unit.

4. Clean filters and grease-laden surfaces frequently.

5. Do not repair or replace part of this appliance unless any specifically

recommended in this manual. All other servicing should be done by a

qualified technician.

6. Please read specification label on product further information and for

requirements.

7. To reduce the risk of and electric fire shock, install the downdraft only

with Broan Exterior Blower Models 331H or 332H or Broan In-Line

Blower Models HLB3, HLB6, HLB9, or HLB111. Other blowers cannot

be substituted. (Blowers sold separately.)

INSTALLER: Save this manual for Electrical Inspector and Homeowner to use.

HOMEOWNER: Use and Care Information on Pages 4 & 5.

INTENDED FOR DOMESTIC COOKING ONLY

GROUNDING INSTRUCTIONS

This appliance must be grounded. In the event of an electrical

short-circuit, grounding reduces the risk of the electric shock by

providing an escape wire the electric current.for This appliance

is equipped with a cord having a grounding wire with a grounding

plug. The plug must be plugged into an outlet that is properly

installed and grounded.

WARNING – Improper grounding can result in a risk of electric

shock.

Consult a qualified electrician if the grounding instructions are

not completely understood, or if doubt exists as whether the to

appliance is properly grounded.

Do not use an extension cord. If the power supply cord is too short,

have a qualified electrician install an outlet near the appliance.

SPECIFICATIONS

VOLTS AMPS Hz. DISCHARGE

120 6.0 MAX. 60 3-1/4 X 10

TAKE MEASUREMENTS

1. Refer to the cooktop installation instructions for dimensions of

cooktop, countertop cut-out, and cabinet requirements. The

Model 2830 will in most 30" wide cabinets and the Model fit

2836 will in most 36" wide cabinets. However, it is recom-fit

mended that oversized cabinets be used for easier installation.

2. Cooktop depth can vary greatly from one to another. This may

cause the of these appliances be rather tight.fit two to

Pay special attention the areas of potential interference high-to

lighted above. A countertop with (A) a raised lip and/or (B) a

backsplash not allow enough flat countertop a proper may for

installation. Note that 2" of flat countertop is required behind

cooktop and that 1-3/4" is necessary between the back edge of

the cooktop and the inside of cabinet back. 2

PLAN THE DUCTWORK

Install downdraft with an exterior blower that draws 6.0 AMPS

or less.

1. This downdraft blower is most efficient when used system

with round ductwork. Use a combination of elbows and 10"

transitions (shown below), closest the downdraft, in order to

to to get from 3¼" x 10" round as soon as possible. 10"

2. For best performance: Choose the ducting option which al-

lows the shortest length of ductwork and a minimum number

of elbows and transitions. Check location of floor joists, wall

studs, electrical wiring or plumbing possible interference. for

EQUALS 6 FT. OF

STRAIGHT DUCT

8" ROUND

ELBOW

3-1/4" X 10"

TO 8" RD.

TRANSITION

3-1/4" X 10"

90O ELBOW

EQUALS 8

FT. OF

STRAIGHT DUCT

EQUALS 2

FT. OF

STRAIGHT DUCT

8" - 10"

INCREASER

3-1/4" x 10"

DISCHARGE

3. The will operate most efficiently when the ductwork system

does not exceed 40 feet of equivalent duct. The illustrations,

above, shows equivalent feet of elbows and transitions. The

number of feet of straight duct plus the equivalent feet of

transitions and/or elbows be used should equal 40 feet or to

less.

NOTE: The equivalent feet of various roof and wall caps has

been taken into consideration. Do not include them in this

calculation.

4. Refer instructions packed with exterior blower or in-line to

blower additional information.for

PLAN THE WIRING

1. The downdraft and exterior blower normally draws 6 system

AMPS and requires a 120 VAC, 60 Hz circuit.

2. The unit has a 2 long power cord with a 3-pronged plug. ft.

Plan to provide a grounded outlet in a location which will allow

the unit’s power cord to reach. (Note: If the Model 2830 is be-

ing installed in a 30" wide cabinet or the Model 2836 is being

installed in a 36" wide cabinet, the outlet cannot be located

on the back wall of cabinet.) Outlet may also be wall-mounted,

with access hole in cabinet.

Note: The high level of air of this appliance affect the flow may

gas flame on some types of gas cooktops. This is NORMAL and

will cause no harm, can be corrected lowering the speed but by

of the blower.

COUNTER

TOP COOKTOP

AIR

VENT

CHIMNEYTOP

3-1/4" x DUCT 10"

CONNECTOR

120 VAC

GROUND-

ED OUTLET

PLANNING

This downdraft blower is system

designed be used exhaust to to

airborne contaminants when cook-

ing with a variety of gas or electric

cooktops. It can be mounted in

island, peninsula, or conventional

wall locations.

This system can be easily installed

following these basic steps:

• Cut out the countertop opening.

• Mount the unit in the cabinet.

• Install exterior or in-line blower

• Connect the ductwork and

electrical.

• Install the cooktop.

TYPICAL INSTALLATION

CUT COUNTERTOP OPENING

1. Lay out and cut the cooktop cut-out enough FORWARD far

so downdraft will behind it.fit

2. Set cooktop in place and slide it as forward as possible. far

Center and square it with edges of countertop.

3. Place the plastic template against the back flange of the cook-

top and center it. Trace around template to mark the downdraft

opening.

4. Remove cooktop from countertop.

5. Cut downdraft opening. Be careful not chip edges of coun-to

tertop.

MOUNTING SCREWS

MOUNT THE UNIT

1. Set downdraft into opening. Extend leveling brackets floor to

of cabinet so downdraft sits straight. (Note: Leveling brackets

can be removed and re-attached in other positions. Bottom

flange face in tight cabinet installations.)may have to inward

2. Secure the downdraft the countertop as follows: Hold the to

downdraft against the back of countertop cut-out and tightening

the 2 mounting screws (one on each end of unit) on underside

of countertop. Use a wood shim between screw and underside

of granite countertops.

3. Screw leveling brackets bottom of cabinet. Tighten screws to

holding leveling bracket unit on each side.to

OUTLET AS-

SEMBLY

COLLAR

ELBOW

TRANSITION

INSTALL DUCTWORK & BLOWER

CAUTION - BEFORE CUTTING HOLE IN CABINET FOR DUCT-

WORK: Check for interference with floor joists, wall studs, electrical

wiring or plumbing.

1. Cut hole in cabinet as well as holes in wall or floor as neces-

sary.

2. Mount the exterior blower or in-line blower and back work

towards the cabinet, attaching all ductwork, elbows and transi-

tions as previously planned. Tape all ductwork connections to

make them secure and air tight. Refer instructions packed to

with exterior blower or in-line blower for additional information.

3. Connect ductwork (and transition, if required) downdraft. If to

necessary, LOOSEN nuts and screws that hold the blower in

place, and slide outlet assembly left or right to meet ductwork.

Re-tighten screws and nuts.

INSTALL ELECTRICAL WIRING

1. Mount a standard wiring box, with 3-pronged grounded recep-

tacle, inside the kitchen cabinet. Make sure the unit's power

cord can easily reach it.

2. Run appropriate power cable into cabinet and connect it to

electrical and receptacle.box

3. Exterior blower not exceed 6.0 Amp rating.may

4. Run 2-wire plus ground power cable from the remote blower

to wiring on downdraft. Remove wire cover and at-box box

tach cable using proper certified or recognized connector.

Use recognized wire connectors to connect wires. Make sure

wires cannot come loose from connectors after assembly.

5. Connect downdraft wiring power cable from exterior or in-to

line blower. black, white white and green Wire black to to to

green or bare wire.

6. Replace wiring cover.box

Produktspecifikationer

Varumärke:	Broan
Kategori:	Fläktkåpa
Modell:	283003

Behöver du hjälp?

Om du behöver hjälp med Broan 283003 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Fläktkåpa Broan Manualer

Broan BCSEK136WW Bruksanvisning

8 Januari 2025

Broan Elite E6030SSM Bruksanvisning

6 Januari 2025

Broan Elite E6430SSM Bruksanvisning

6 Januari 2025

Broan BKDB136WW Bruksanvisning

27 Oktober 2024

Broan Elite RMIP45 Bruksanvisning

21 September 2024

Broan Elite 619004 Bruksanvisning

21 September 2024

Broan BWS1304SS Bruksanvisning

21 September 2024

Broan EWS1306BLS Bruksanvisning

21 September 2024

Broan BWP1304SS Bruksanvisning

21 September 2024

Broan PM250 Bruksanvisning

21 September 2024

Fläktkåpa Manualer

Nyaste Fläktkåpa Manualer

Bosch DLN87AC60B Bruksanvisning

22 Mars 2025

Neff D86NAC1S0B Bruksanvisning

22 Mars 2025

Bosch DLN56AC60A Bruksanvisning

21 Mars 2025

Cata ISLA FENIX 1000 X Bruksanvisning

17 Mars 2025

Bosch DLN56AC60B Bruksanvisning

14 Mars 2025

Siemens LB77NAC50 Bruksanvisning

14 Mars 2025

Berbel BIH 120 BL Bruksanvisning

14 Mars 2025

Cata TF-5060 Bruksanvisning

14 Mars 2025

Novy 7245 Bruksanvisning

12 Mars 2025

AEG DECT6151S Bruksanvisning

11 Mars 2025
