December update 29 , 2016

Additional Information for

Range Hoods meeting ADA Compliance

Broan and NuTone branded residential range hoods can be installed to comply

with Sections 308 and 309 of ADA Guidelines, when used with appropriately

mounted controls installed at 15” to 48” above the floor and control access

should not require reaching over a cooking appliance.

The following range hoods can work in an ADA Compliant situation when the

range hood is wired to operate from a dedicated, standard electrical wall

switch. facilitate this application, share the information on the following To

pages with your electrician when preparing for the installation.

2-SPEED RANGE HOODS:

Broan 40000, F40000, 41000, 42000, 43000, 52000,

PM250, QL1, QS1, QSE1, QDE, QML and CBD1 Series,

BKSA1, CLSC1, CRSF1

NuTone NS6500, NSPM250, RL6200, WS1 Series, AHSA1, AVSF1

INTERMEDIATE RANGE HOODS: (with variable speed)

Broan 46000 & QT20000 Series

NuTone ACS Series

INSTALLATION

1. WARNING

To avoid fire or electrical shock, turn off power at circuit

breaker or fuse. Test that the power is off before wiring.

2. MOUNT THE SWITCH BOX

For 2-Rocker Switch: Install a 3½" deep single-gang

switch box or a 2" deep double-gang switch box.

For 3-Rocker Switch: Install a 2½" deep double-gang

switch box with a single device adapter plate.

3. ATTACH POWER CABLE

Clamp wiring to switch box and unit using appropriate

clamp. Provide 6" leads inside box and fan for easier

wiring.

4. CONNECT WIRING

General instructions for all configurations:

Make sure both the switch box and the appliance are

properly grounded.

Make sure ground wire is securely fastened to control's

ground screw. Tighten ground screw 14 to 16-in. lbs.

torque.

Remove insulation per strip gauge on control (approx.

5/8"). Use proper wire nut sizes for number and size of

wires.

For push-in terminals: Use #14-AWG solid copper wire

only.

For screw terminals: Use #12 or #14-AWG solid copper

wire only. Tighten screw terminals 14 to 16-in. lbs. torque.

Choose 4A., 4B. or 4C

4A. When using 2-Rocker or 3-Rocker Switch to turn an

appliance ON & OFF:

Make electrical connections following appropriate

diagram.

(over)

WARNING

To prevent serious injury from electrical shock or damage

to electrical components - DO NOT WIRE HOT!

Each individual rocker switch on this control is rated at 15

AMPS, @ 120 VAC. The total load on this control must not

exceed 20 AMPS, @ 120 VAC.

Warranty is void if miswired.

WARNING

ALL ELECTRICAL WORK MUST BE DONE IN

ACCORDANCE WITH LOCAL CODES, ORDINANCES,

OR NATIONAL ELECTRICAL CODE AS APPLICABLE.

FOR SAFETY, THIS PRODUCT MUST BE INSTALLED IN

A GROUNDED SWITCH BOX. IF YOU ARE UNFAMILIAR

WITH METHODS OF INSTALLING ELECTRICAL

WIRING, SECURE THE SERVICES OF A QUALIFIED

ELECTRICIAN.

Turn off power and lock out service panel before installing

or wiring this product.

Use this control only with copper or copper-clad wire. Do

not use aluminum wire with this device.

2-ROCKER & 3-ROCKER SWITCHES

3 - ROCKER SWITCH

2 - ROCKER SWITCH

STEP 4A

NOTE: If the switch has not been wired properly and wires need

to be moved, proceed as follows:

WARNING: To avoid fire or electrical shock, turn off power at

circuit breaker or fuse. Test that the power is off

before wiring.

1. Each wire opening has a

release slot.

2. Push a small nail or screw-

driver into release slot

while gently removing wire.

3. DO NOT pull any wire out

of the switch without using

the release slot. The switch

may become damaged.

RELEASE SLOT

WIRE OPENING

C O M

B L A C K

W H I T E

G R O U N D

G R D

B L A C K

W H I T E

G R O U N D

1 2 0 V A C

L I N E I N

L O A D

S I N G L E - G A N G

S W I T C H B O X A P P L I A N C E

R E D

COM

GRD

BLACK

WHITE

DOUBLE-GANG SWITCH BOX

(with single device adapter plate) APPLIANCE

GROUND

120 VAC

LINE IN

BLACK

WHITE

BLACK

WHITE

GROUND

LOAD

RED

FROM

HOOD

2-ROCKER

SWITCH

WHITE

BL KAC

RED GROUND

‡

** INTERMEDIATE

HOODS

4B. When using a 2-Rocker Switch to turn a range hood

ON & OFF from another location with 120 VAC

POWER CABLE ENTERING SWITCH BOX:

Remove the range hood’s wiring cover. If the hood

has a BLACK JUMPER WIRE, it must be cut and

the end stripped as shown. (FIG. I)

Use UL approved clamps to secure all cables to

hood and box. Make wiring connections following

appropriate diagram. Use proper wire nut sizes for

number and size of wires. Replace range hood wir-

ing cover.

4C. When using a 2-Rocker Switch to turn a range hood

ON & OFF from another location with 120 VAC

POWER CABLE ENTERING HOOD:

Remove the range hood’s wiring cover. If the hood

has a BLACK JUMPER WIRE, it must be cut and

the end stripped as shown. (FIG. I)

Use UL approved clamps to secure all cables to

hood and box. Make wiring connections following

appropriate diagram. Use proper wire nut sizes for

number and size of wires. Replace range hood wir-

ing cover.

5. MOUNT CONTROL IN SWITCH BOX

Tuck wires into switch box and fasten the control to

box using attached screws.

6. ATTACH SWITCH PLATE

Fasten the switch plate to the control using the short

screws from the parts bag.

* 2-SPEED RANGE HOODS:

Broan 40000, F40000, 41000, 42000, 43000, 52000,

PM250, CBD1, QL1, QML, QS1 & QSE1 Series. NuTone

NS6500, NSPM250, RL6200 & WS1 Series.

** INTERMEDIATE RANGE HOODS:

Broan 46000 & QT20000 Series. NuTone ACS3 Series.

BROAN-NUTONE ONE YEAR LIMITED WARRANTY

Broan-NuTone warrants to the original consumer purchaser of its products that

such products will be free from defects in materials or workmanship for a period of

one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

During this one-year period, Broan-NuTone will, at its option, repair or replace, without

charge, any product or part which is found to be defective under normal use and service.

THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS, TUBES,

HALOGEN AND INCANDESCENT BULBS, FUSES, FILTERS, DUCTS, ROOF CAPS, WALL

CAPS AND OTHER ACCESSORIES FOR DUCTING. This warranty does not cover (a) normal

maintenance and service or (b) any products or parts which have been subject to misuse,

negligence, accident, improper maintenance or repair (other than by Broan-NuTone), faulty

installation or installation contrary to recommended installation instructions.

The duration of any implied warranty is limited to the one-year period as specified for the

express warranty. Some states do not allow limitation on how long an implied warranty

lasts, so the above limitation may not apply to you.

BROAN-NUTONE’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN-NUTONE’S

OPTION, SHALL BE THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS

WARRANTY. BROAN-NUTONE SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL

OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH PRODUCT USE OR

PERFORMANCE. Some states do not allow the exclusion or limitation of incidental or

consequential damages, so the above limitation or exclusion may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights, which

vary from state to state. This warranty supersedes all prior warranties.

To qualify for warranty service, you must (a) notify Broan-NuTone at the address or

telephone number below, (b) give the model number and part identification and (c)

describe the nature of any defect in the product or part. At the time of requesting warranty

service, you must present evidence of the original purchase date.

Broan-NuTone LLC, 926 W. State Street, Hartford, Wisconsin 53027

www.broan.com 800-558-1711

FIG. I * 2- SPEED

HOODS

** INTERMEDIATE

HOODS

CUT BLACK

JUMPER WIRE

HERE!

CUT BLACK

JUMPER

WIRE HERE!

STEP 4B

POWER INTO SWITCH

STEP 4C

POWER INTO HOOD

‡ CODE REQUIRES BOTH

ENDS OF THIS WIRE'S

INSULATION TO BE COL-

ORED. USE A PERMA-

NENT MARKER.

* 2- SPEED

HOODS

RED

BLACK

BLUE

RED

WHITE

BLUE

RED

99043739D

PK92824-10-00-0E

FROM SWITCH

BOX

REF. FIG 1

WHITE

BLUE BLACK

BLACK

GRN

** INTERMEDIATE

HOODS

REF. FIG 1

BLUE

BLACK

REF. FIG 1

* 2- SPEED

HOODS

BLACK

GROUND

120 VAC

LINE IN

TO SWITCH

BOX

BLACK

WHITE

‡GROUND

120 VAC

LINE IN

TO SWITCH

BOX

WHITE

BLACK

REF. FIG 1

GRN

RED

BLACK

WHITE

FROM SWITCH

BOX

WHITE‡

2-ROCKER

SWITCH

RED

BL KAC

GROUND

WHITE

120 CVA

LINE IN

HOOD
