INSTALLATION,

USE & CARE INSTRUCTIONS

WWW.BROAN-NUTONE.COM WWW.BROAN-NUTONE.CA

Serial number: 1105024C

Powerpack Inserts

Model numbers: PM400SS,

BBN2243SS, BBN2303SS

PM400SS

BBN2243SS

BBN2303SS

INSTALLATION, USE & CARE INSTRUCTIONS

TABLE OF CONTENTS

Safety 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation 5-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Recommended Tools and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Contents ...........................................................5

Install Ductwork (Ducted Installations Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Optional Liners (PM400SS Unit Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Remove the Adapter/Damper ............................................7

Remove the Cabinet Brackets ...........................................7

Prepare the Cabinet ...............................................8-10

Prepare the Unit 11-12 .................................................

Install the Unit 13-15 ...................................................

Connect Ductwork ...................................................15

Wiring ............................................................16

Install the Filter(s) ...................................................16

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Maintenance and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Grease Filter(s)

Non-Ducted Recirculation Filter(s)

Stainless Steel Cleaning

Wiring Diagrams 19-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Service Parts 21-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

INSTALLATION, USE & CARE INSTRUCTIONS

SAFETY

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE

FOLLOWING:

• Use this unit only in the manner intended by the manufacturer. If you have questions, contact the

manufacturer at the address or telephone number listed in the warranty.

• Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting

means to prevent power from being switched on accidentally. When the service disconnecting means

cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel.

• Installation work and electrical wiring must be done by a qualified person(s) in accordance with all

applicable codes and standards, including fire-rated construction codes and standards.

• Sufficient air is needed for proper combustion and exhausting of gases through the flue (chimney) of

fuel burning equipment to prevent backdrafting. Follow the heating equipment manufacturer’s guideline

and safety standards such as those published by the National Fire Protection Association (NFPA), and

the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the

local code authorities.

• When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.

• Ducted fans must always be vented to the outdoors.

• Do not use this unit with any separate solid-state speed control device.

• To reduce the risk of fire, use only metal ductwork.

• This unit must be grounded.

• When installing, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves.

• When applicable local regulations comprise more restrictive installation and/or certification

requirements, the aforementioned requirements prevail on those of this document and the installer

agrees to conform to these at his own expense.

To register your product, please visit our website:

In the United States - broan-nutone.com

In Canada - broan-nutone.ca

For Technical Support, call:

In the United States - 800-637-1453

In Canada - 800-567-3855

Installer: Leave this manual with the homeowner.

READ AND SAVE THESE INSTRUCTIONS

Intended for domestic cooking only
