ECONOMY RANGE HOOD

INSTALLATION INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO

PERSONS, OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended by the manufacturer. If you have

questions, contact the manufacturer at the address or telephone number

listed in the warranty.

2. Before servicing or cleaning unit, switch power off at service panel and

lock service panel to prevent power from being switched on accidentally.

When the service disconnecting means cannot be locked, securely fasten

a prominent warning device, such as a tag, to the service panel.

3. Installation work and electrical wiring must be done by a qualified

person(s) in accordance with all applicable codes and standards.

4. Sufficient air is needed for proper combustion and exhausting of

gases through the flue (chimney) of fuel burning equipment to prevent

backdrafting. Follow the heating equipment manufacturer’s guideline and

safety standards such as those published by the National Fire Protection

Association (NFPA), and the American Society for Heating, Refrigeration

and Air Conditioning Engineers (ASHRAE), and the local code authorities.

5. When cutting or drilling into wall or ceiling, do not damage electrical wiring

and other hidden utilities.

6. Ducted fans must always be vented to the outdoors.

7. Do not use this unit with any solid-state speed control device.

8. To reduce the risk of fire, use only metal ductwork.

9. Use with approved cord-connection kit only.

10.This unit must be grounded.

TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:

1. Never leave surface units unattended at high settings. Boilovers cause

smoking and greasy spillovers that may ignite. Heat oils slowly on low

or medium settings.

2. Always turn hood ON when cooking at high heat or when cooking flaming

foods.

3. Clean ventilating fans frequently. Grease should not be allowed to

accumulate on fan or filter.

4. Use proper pan size. Always use cookware appropriate for the size of

the surface element.

TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A

RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING:*

1. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray,

then turn off the burner. BE CAREFUL TO PREVENT BURNS. If the

flames do not go out immediately, EVACUATE AND CALL THE FIRE

DEPARTMENT.

2. NEVER PICK UP A FLAMING PAN - You may be burned.

3. DO NOT USE WATER, including wet dishcloths or towels - a violent

steam explosion will result.

4. Use an extinguisher ONLY if:

A. You know you have a Class ABC extinguisher and you already know how

to operate it.

B. The fire is small and contained in the area where it started.

C. The fire department is being called.

D. You can fight the fire with your back to an exit.

*Based on “Kitchen Firesafety Tips” published by NFPA.

CAUTION

1. For indoor use only.

2. For general ventilating use only. Do not use to exhaust hazardous or

explosive materials and vapors.

3. To avoid motor bearing damage and noisy and/or unbalanced impellers,

keep drywall spray, construction dust, etc. off power unit.

4. For best capture of cooking impurities, your range hood should be

mounted 20-25” above the cooking surface.

5. Please read specification label on product for further information and

requirements.

IMPORTANT: OBSERVE ALL GOVERNING CODES AND

ORDINANCES

Your range hood has been designed to filter out smoke, odors, and grease

which rise from the cooking surface. Before you begin the installation be

sure that all parts and accessories are removed from carton. For best results

and ease in the installation of this range hood, read the instructions sheet

to become familiar with the step-by-step installation.

TOOLS AND MATERIALS REQUIRED

Drill, electric or ratchet drive

 1/8" drill bit for drilling pilot holes

 7/64" drill bit to drill holes for EZ1 brackets mounting screws

 1-1/4" wood bit for drilling electrical wiring access hole

 One common head sc securing hood mounting screws to rewdriver for

the cabinet and hood sheet metal parts

 Pliers for opening knockouts

 Pencil, rule and level for marking cabinet locations

 Saber saw or keyhole saw for cutting the wall or cabinet openings

 Metal snips, duct tape, duct (with elbows and transition, if necessary),

roof cement or caulk, and roof or wall cap, as required

 Electrical wiring and supplies of type to comply with local codes

The following materials are required only for installation on recessed bottom

kitchen cabinets:

 Two 1" x 2" x 12" (approximate length) wood strips (purchase locally)

 Four 1-1/4" long flat head wood screws (purchase locally)

INSTALLER:

LEAVE THIS MANUAL WITH THE HOMEOWNER.

HOMEOWNER:

USE AND CARE INSTRUCTIONS ON PAGE 4.

INTENDED FOR DOMESTIC COOKING ONLY

www.broan.com/register.

To order Service Parts: go to www.broan.com

BUEZ0

HOOD

BUEZ1

HOOD

BUEZ2

HOOD

ALUMINUM

FILTER (BUEZ0

& BUEZ2 HOODS

ONLY) WIRING BOX COVER

PREPARING THE HOOD

1. Unpack hood and check contents. You should receive:

1 – Aluminum filter (BUEZ0 and BUEZ2 hoods only)

1 – 3-1/4" x 10" damper/duct connector, mounted inside of hood for

shipping only (BUEZ0 hood only)

1 – Ductfree filter (BUEZ1 hood only)

1 – Installation parts bag (under wiring box cover)

1 – Set of EZ1 brackets (under wiring box cover)

2. Remove wiring box cover. Remove EZ1 brackets and parts bag from

behind wiring box.

3. Remove top or rear electrical knockout. Install an appropriate strain relief.

4. BUEZ0 hood only: Remove rear or top duct knockout. Install damper/

duct connecter over opening made. Use 2 no. 8B sheet metal screws

provided.

PLANNING DUCTWORK INSTALLATION

This section is for BUEZ0 and BUEZ2 hoods only. For BUEZ1hoods,

skip this section and go to "Preparing the Installation Location".

Begin planning ductwork by deciding where duct will run between hood

and outside. For best performance, use shortest possible duct run and a

minimum number of elbows. There are several choices.

Ducting directly through the wall (for range hoods mounted on an exterior

wall). Shown are two ways to duct through an outside wall. If a wall cap

is used directly off the back of the hood, special care must be taken to

make sure that the damper in the damper/duct connector on the hood

and damper in the wall cap do not interfere with each other when the

hood is operating. This could result in either inadequate air delivery or

back drafts. If this condition does exist, remove the hood damper flap.

Sometimes when using a wall cap, it is easier to duct vertically and then

use an elbow.

Start at the exterior and run ductwork back to the range hood. For best

performance, use the shortest possible duct run and a minimum number

of elbow. Tape all duct connections using metal foil duct tape.

ROOF CAP

REMOVE THE

HOOD DAMPER

FLAP IF IT

INTERFERES

WITH THE WALL

CAP DAMPER

DAMPER

(INCLUDED)

BP87Q DAMPER (NOT

INCLUDED) LOCATED

AT L E AS T 6 " F ROM

HOOD IN VE R T ICAL

SECTION OF DUCT

PREPARING THE INSTALLATION

LOCATION

NOTE: MOUNT HOOD SO THAT BOTTOM OF HOOD IS 18" TO 24" ABOVE

COOKING SURFACE. TOP FRONT OF HOOD SHOULD BE FLUSH WITH

FRONT OF CABINET FRAME.

IF DISTANCE BETWEEN WALL AND FRONT OF CABINET FRAME IS

MORE THAN 12", THERE WILL BE A SPACE BETWEEN BACK OF HOOD

AND WALL. THIS IS NORMAL.

OMIT STEP 1 IF HOOD WILL BE INSTALLED UNDER CABINETS WITH

FLUSH BOTTOM OR INSTALLED USING THE EZ1 BRACKETS.

1. For cabinets with recessed bottoms only, if not using EZ1 brackets: Install

wood filler strips on each side of recessed area under cabinet. Use two

1" x 2" strips cut to length (use thicker strips if necessary). Fasten strips

with wood screws about 3" in from each end.

2. Measure and mark the following:

a.) Electrical wiring opening in wall or cabinet.

b.) Duct opening in wall or cabinet (BUEZ0 and BUEZ2 hoods ).only

FILLER STRIP

DAMPER/DUCT CONNECTOR

(BUEZ0 HOOD ONLY)

DUCTFREE

FILTER (BUEZ1

HOOD ONLY)

HINGE PINS

DUCT KNOCKOUTS

BUEZ2 BUEZ0

9 7/ 8 ”

7 1/ 2 ”

7 1

/ 2 ”

1/ 4 ”5 1

/ 4 ”

7/ 8 ”

6 7

/ 8 ”

10 5/ 8 ”

10 1

/ 2 ”

1 1/ 2 ”

12”

CENTER LINE

HOOD WIDTH

FILLER

STRIP

3/4 ”

1/8 ”

A = 7-15/16” FOR 21” RANGE HOODS

B = 10-15/16” FOR 21” RANGE HOODS

A & B = 13-15/16” FOR 30” RANGE HOOD

A & B = 16-15/16” FOR 36” RANGE HOOD

A & B = 10-15/16” FOR 24” RANGE HOODS A & B = 19-15/16” FOR 42” RANGE HOOD

* Duct cutouts not centered

on 21” hood width.

BUEZ2 BUEZ0

EZ1 ONE-PERSON INSTALLATION SYSTEM

Use the appropriate brackets according to the kitchen cabinet type. Refer

to the marking on the brackets to determine the correct installation side

and orientation.

Mate the corresponding bracket to the cabinet side frame, while placing

rear end of bracket against the wall. Use a pencil to mark 3 holes (there

are 6 holes but only 3 are necessary).

Remove the bracket. Using a 7/64” drill bit, drill 3 holes where marked.

Assemble the bracket to the side frame using a Phillips screwdriver and

3 provided round head no. 8 x 5/8” wood screws. Repeat for the other

side frame.

FRAMED CABINET

7/64”

X Y

INSTALLING THE RANGE HOOD

This manual covers 2 kinds of installation: the standard (without EZ1

brackets) and the EZ1 one-person installation system. If the cabinet is

wider than the range hood width, please use the standard installation

method. For the standard installation, go to page 4.

WARNING: WHEN CUTTING OR DRILLING INTO WALL OR CABINET,

BE CAREFUL NOT TO CUT EXISTING ELECTRICAL WIRING.

3. Drill 1-1/4" electrical wiring opening in wall or cabinet bottom.

4. Drill four pilot holes in corners of marked duct opening and cut opening

with saber or keyhole saw (BUEZ0 and BUEZ2 hoods only).

FRAMELESS

CABINET

[ \

7/64”

3 X

Y Z

Align the corresponding bracket to the cabinet side, while placing rear

end of bracket against the wall. Draw a line on the outer edge of the

bracket (as shown).

Slide the bracket towards the center of cabinet and align the outside

edge of the bracket with the marked line, keeping the rear end edge

leaning on the wall.

 Use a pencil to mark 3 holes.

Remove the bracket. Using a 7/64” drill bit, drill 3 holes where marked.

Assemble the bracket to the cabinet bottom using a Phillips screwdriver

and 3 provided countersunk wood screws. Repeat for the other cabinet

side.

The following procedure applies to both framed or frameless

cabinet installations.

HORIZONTAL EXHAUST INSTALLATION ONLY

1. Pull house power cable out.

2. Temporarily hang the hood on the brackets using its 2 recessed REAR

HOLES ( and A B). While holding the hood, run the house power cable

into the hood through the strain relief previously installed.

3. Unhook the rear holes from the brackets and hang the hood using its

2 recessed FRONT HOLES. , attach the power While holding the hood

cable to the hood using the strain relief.

VERTICAL EXHAUST INSTALLATION ONLY

1. Pull house power cable out.

2. Hang the hood on the brackets using the 2 recessed FRONT HOLES.

While holding the hood, run the house power cable into the hood

through the strain relief previously installed. Attach power cable to the

hood.

Produktspecifikationer

Varumärke:	Broan
Kategori:	Fläktkåpa
Modell:	BUEZ130SS

Behöver du hjälp?

Om du behöver hjälp med Broan BUEZ130SS ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Fläktkåpa Broan Manualer

Broan BKDB136WW Bruksanvisning

27 Oktober 2024

Broan Elite RMIP45 Bruksanvisning

21 September 2024

Broan Elite 619004 Bruksanvisning

21 September 2024

Broan BWS1304SS Bruksanvisning

21 September 2024

Broan EWS1306BLS Bruksanvisning

21 September 2024

Broan BWP1304SS Bruksanvisning

21 September 2024

Broan PM250 Bruksanvisning

21 September 2024

Broan Elite 614804EX Bruksanvisning

21 September 2024

Broan BWP1364SS Bruksanvisning

21 September 2024

Broan Elite EW5830SS Bruksanvisning

21 September 2024

Fläktkåpa Manualer

Nyaste Fläktkåpa Manualer

Neff D61MAC1X0B Bruksanvisning

27 Oktober 2024

Klarstein 10033709 Bruksanvisning

27 Oktober 2024

Halifax FTHI740K Bruksanvisning

27 Oktober 2024

Hoover HDTI6500/1X Bruksanvisning

27 Oktober 2024

Heinner HTCH-440FS Bruksanvisning

27 Oktober 2024

ATAG WG411V Bruksanvisning

27 Oktober 2024

XO R30SC Bruksanvisning

26 Oktober 2024

IKEA DATID HW570 Bruksanvisning

24 Oktober 2024

Candy CDG6MB Bruksanvisning

24 Oktober 2024

Miele da 219 1 Bruksanvisning

24 Oktober 2024
