E60000 SERIES
INTENDED FOR DOMESTIC COOKING ONLY
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 13 & 14.
Broan-NuTone LLC; Hartford, Wisconsin www.broan.com 800-558-1711
Broan-NuTone Canada Inc.; Mississauga, Ontario www.broan.ca 877-896-1119
REGISTER YOUR PRODUCT ON LINE AT: www.broan.com/register
SV08340 rev. E
HB0073
INSTALLATION INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
!
!
- 2 -
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY TO PERSONS, OBSERVE
THE FOLLOWING:
1. Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer at the address or telephone number
listed in the warranty.
2. Before servicing or cleaning unit, switch power off at
service panel and lock service disconnecting
means to prevent power from being switched on
accidentally. When the service disconnecting
means cannot be locked, securely fasten a prominent
warning device, such as a tag, to the service panel.
3. Installation work and electrical wiring must be
done by qualified personnel in accordance with all
applicable codes and standards, including fire-rated
construction codes and standards.
4. Sufficient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of
fuel burning equipment to prevent backdrafting.
Follow the heating equipment manufacturer’s
guidelines and safety standards such as those
published by the National Fire Protection
Association (NFPA), and the American Society for
Heating, Refrigeration and Air Conditioning
Engineers (ASHRAE), and the local code authorities.
5. When cutting or drilling into wall or ceiling, do not
damage electrical wiring and other hidden utilities.
6. Ducted fans must always be vented to the outdoors.
7. Do not use this unit with any additional solid-state
speed control device.
8. To reduce the risk of fire, use only metal ductwork.
9. This unit must be grounded.
10.
When applicable local regulations comprise more
restrictive installation and/or certification
requirements, the aforementioned requirements
prevail on those of this document and the installer
agrees to conform to these at his own expenses
TO REDUCE THE RISK OF A RANGE TOP
GREASE FIRE:
a) Never leave surface units unattended at high
settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on low or
medium settings.
b) Always turn hood ON when cooking at high heat or
when flambeing food (i.e.: Crêpes Suzette,
Cherries Jubilee, Peppercorn Beef Flambé).
c) Clean ventilating fans frequently. Grease should
not be allowed to accumulate on fan, filters or
exhaust ducts.
d) Use proper pan size. Always use cookware
appropriate for the size of the surface element.
TO REDUCE THE RISK OF INJURY TO PERSONS
IN THE EVENT OF A RANGE TOP GREASE
FIRE, OBSERVE THE FOLLOWING*:
1. SMOTHER FLAMES with a close-fitting lid, cookie
sheet or metal tray, then turn off the burner.
BE CAREFUL TO PREVENT BURNS. IF THE
FLAMES DO NOT GO OUT IMMEDIATELY, EVACUATE
AND CALL THE FIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN—You may be
burned.
3. DO NOT USE WATER, including wet dishcloths or
towels—This could cause a violent steam explosion.
4. Use an extinguisher ONLY if:
A. You own a Class ABC extinguisher and you know
how to operate it.
B. The fire is small and contained in the area
where it started.
C. The fire department has been called.
D. You can fight the fire with your back to an exit.
*Based on “Kitchen Fire Safety Tips” published by NFPA.
CAUTION
1. For indoor use only.
2. For general ventilating use only. Do not use to
exhaust hazardous or explosive materials and vapors.
3. To avoid motor bearing damage and noisy and/or
unbalanced impellers, keep drywall spray, construction
dust, etc. off power unit.
4. Your hood motor has a thermal overload which will
automatically shut off the motor if it becomes
overheated. The motor will restart when it will be
cooled down. If the motor continues to shut off and
restart, have the hood serviced.
5. For best capture of cooking impurities, the bottom of
the hood should be at a minimum of 24” and at
a maximum of 30” above the cooking surface.
6. Two installers are recommended because of the
large size and weight of this hood.
7. To reduce the risk of fire and to properly exhaust air,
be sure to duct air outside—Do not exhaust air into
spaces within walls or ceiling or into attics, crawl
space or garage.
8. This product is equipped with a thermostat which
may start blower automatically. To reduce the risk of
injury and to prevent power from being switched on
accidentally, switch power off at service panel and
lock or tag service panel.
9. Because of the high exhausting capacity of this
hood, you should make sure enough air is entering
the house to replace exhausted air. Use an appropriate
make-up air device or open a window close to or in
the kitchen.
10. To reduce the risk of fire and electric shock, the
Broan Elite E60E Series hood must be installed with
one Broan exterior blower model 331H, 332H, 335
or 336; or one Broan in-line blower model HLB3,
HLB6, HLB9, HLB11. Other blowers cannot be
substituted. (Exterior or in-line blowers sold separately.)
11. Please read specification label on product for further
information and requirements.
WARNING WARNING
!
!
- 3 -
HL0099
RMP SERIES
BACKSPLASH
(STAINLESS STEEL WALL
COVERING WITH WARMING
SHELVES. OPTIONAL)
MODEL 427
(4½” 18½” X
TO 10” ROUND,
6” HIGH - LATERAL)
MODEL 423
(4½” 18½” X
TO 10” ROUND -
VERTICAL)
MODEL 424
(4½” 18½” X
TO 10” ROUND -
H )ORIZ. FRONT/REAR
MODEL 454
(4½” 18½” X
TO 10” ROUND -
H )ORIZ. /RIGHT
MODEL 453
(4½” 18½” X
TO 10” ROUND -
H )ORIZ. /LEFT
E60000 SERIES HOOD
OPTIONAL
NON-DUCTED RECIRCULATION KIT
ANKE60 SERIES
- E60000 SERIES RANGE HOOD SYSTEM -
INTERNAL BLOWERS
MODEL 437
(HIGH CAPACITY ROOF C )AP
MODEL 441
(10’’ ROUND WALL C )AP
MODEL 410
(10”
ROUND DUCT
—2 FT. SECTIONS)
MODEL 418
(10” ROUND
ADJUSTABLE ELBOW)
OPTIONAL DECORATIVE
FLUE AEE SERIES
MODEL 421
(10” ROUND ERTICALV
I - )N LINE DAMPER
8” ROUND
ADJUSTABLE
ELBOW
MODEL 412
TRANSITION
(3¼” 10” X TO 7”)
STANDARD
DUCT
(3¼” 10”)X
MODEL 647
(7” ROUND WALL C )AP
MODEL 634 644OR
(ROOF C )AP
MODEL 643
(8” ROUND WALL C )AP
8” ROUND
STANDARD
DUCT
MODEL 407
(7” ROUND
—2 FT. SECTIONS)
MODEL 413
TRANSITION
(3¼” 10” X TO 8”)
MODEL 639
(3¼” 10”X
WALL C )AP
MODEL 415
(7” ROUND
ADJUSTABLE ELBOW )
ADAPTER/DAMPER 3¼’’ 10’’X
(SUPPLIED WITH
SINGLE BLOWER HOOD)
ADAPTER 4½” 18½”X
(SUPPLIED WITH
DOUBLE BLOWER HOOD)
D B )UAL LOWER (1200 CFM
