MODELS EW5630SS • EW5636SS

Page 1

Chimney

Range Hood

READ AND SAVE THESE INSTRUCTIONS

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY

TO PERSON(S) OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended by the manufacturer. If

you have questions, contact the manufacturer at the address or

telephone the number listed in warranty.

2. servicing Before or cleaning unit, switch power off at service panel

and lock service disconnecting means to prevent power from being

switch on accidentally. When the service disconnecting means

cannot be a locked, securely fasten prominent warning device,

such a as tag, to the service panel.

3. Installation work and electrical be wiring must done by qualified

personnel in accordance codes standards, applicable with all and

including construction fire-rated codes and standards.

4. is combustion Sufficient air needed for proper and exhausting

of gases through the flue (chimney) burning of fuel equipment to

prevent back drafting. Follow the heating equipment manufacturer’s

guideline published and safety standards such as those by the

National Protection Association American Fire (NFPA), and the

Society Refrigeration for Heating, and Air Conditioning Engineers

(ASHRAE), and the local code authorities.

5. This product may have sharp edges. Be careful to avoid cuts and

abrasions during installation and cleaning.

6. When cutting or drilling into wall or ceiling, do not damage electrical

wiring and other hidden utilities.

7. Ducted fans must be always vented to the outdoors.

8. only Use metal ductwork.

9. Do not use this unit with any other solid-state speed control device.

10. Do operate not any fan with a damaged cord or plug. Discard fan or

return to an authorized service facility for examination and/or repair.

11. GROUNDING be INSTRUCTION: The appliance must grounded.

In the event of an electrical short circuit, grounding reduces the risk

of electric shock by providing an escape wire for the electric current.

The appliance is equipped with a cord having a grounding wire with

a be is grounding plug. The plug must plugged into an outlet that

properly installed grounded. grounding and WARNING: Improper

can a a result in risk of electric shock. Consult qualified electrician

if the if grounding instructions are not completely understood, or

doubt exists is Do as to whether the appliance properly grounded.

not is use an extension cord. If the power supply cord too short,

have a qualified electrician install an outlet near the appliance.

TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:

a) Never leave surface units unattended at high settings. Boilovers

cause smoking and greasy spillovers oils that may ignite. Heat

slowly low on or medium settings.

b) Always turn hood ON when cooking at high heat or when flambéing

food Peppercorn (i.e. Crêpes Suzette, Cherries Jubilee, Beef

Flambé).

c) Clean ventilating frequently. fans be Grease should not allowed to

accumulate on fan or filters.

d) Use proper pan size. Always use cookware appropriate for the size

of surface the element.

1. For indoor use only.

2. For general ventilating use only. Do not use to exhaust hazardous

or explosive materials and vapors.

3. To avoid motor bearing damage and noisy and/or unbalanced

impeller, keep drywall spray, construction dust, etc. off power unit.

4. Your hood motor has a thermal overload which will automatically

shut off the motor if it becomes overheated. The motor will restart

when it will cool down. If the motor continues to shut off and

restart, the hood serviced. have

5. The bottom of the hood MUST BE LESS than 24” NOT and

recommended at maximum of 36” a above cooktop best for

capture of cooking impurities.

6. Two installers are recommended because of the size of this

hood.

7. To reduce risk of fire and to properly exhaust air, be sure duct to

air outside. Do not exhaust air into spaces within walls or ceilings

or into attics, crawl spaces, or garages.

8. Be careful when installing the decorative flue and hood, they may

have sharp edges.

9. This hood is not intended to a be used as shelf.

10. Please read specification label on product further information for

and requirements.

Installer: Leave this manual

with the homeowner.

Homeowner: Operation and Maintenance

instructions on pages 7 & 8.

WARNING

CAUTION

FOR DOMESTIC COOKING ONLY

WARNING

TO REDUCE THE RISK OF INJURY TO PERSON(S) IN THE EVENT

OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING*:

1. SMOTHER a FLAMES with close-fitting lid, cookie sheet, or metal

tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS.

IF DO THE FLAMES NOT GO OUT IMMEDIATELY, EVACUATE

AND CALL THE FIRE DEPARTMENT.

2. NEVER PICK A – be UP FLAMING PAN You may burned.

3. DO NOT USE WATER, including wet dishcloths or towels – a violent

steam explosion will result.

4. Use extinguisher an ONLY if:

A. You a extinguisher, know you have Class ABC and you

know how operate to it.

B. The is small fire and contained in the it area where started.

C. The department is fire being called.

D. You can fight the fire with your back to an exit.

* Based on published “Kitchen Fire Safety Tips” by NFPA

MODELS EW5630SS • EW5636SS

Page 2

INSTALL THE DUCTWORK

(Ducted Hoods Only)

1. Decide where the ductwork will run between the hood and

the outside.

2. A straight, short duct run will allow the hood perform most to

efficiently.

3. Long duct runs, elbows and transitions will reduce the

performance of the hood. Use as of them as possible. few

Larger ducting be required best performance with may for

longer duct runs.

4. Install wall cap or roof cap. Connect round metal ductwork

to towards cap and back work the hood location. Use duct

tape seal the joints between ductwork sections.to

MEASURE THE INSTALLATION

The minimum hood distance above cooktop MUST BE NOT

LESS than 24”.

A maximum of 36” above cooktop is recommended best for

capture of cooking impurities.

Distances 36” at the installer and users discretion; over are

providing that the ceiling height permits.

PREPARE THE HOOD

HOOD

15 7/8” TO CENTER

OF UPPER BRACKET

HOLES

ROUND ELBOW

HOOD MOUNTING

BRACKET

24” 36” TO AB EOV

COOKING SURFACE

3½”

DECORATIVE FLUE

6” ROUND DUCT

ROOF CAP

WALL P CA

2” TO CENTER

OF LOWER HOOD

CHASIS HOLES

3¾” FROM WALL

TO CENTER LINE

OF DUCT

DECORATIVE FLUE

Unpack hood and check contents. You should receive:

1 - Hood Assembly

1 - Glass Canopy

1 - Decorative Flue Assembly (consisting of upper and lower flue)

1 - Upper Flue Mounting Bracket

1 - Aluminum Grease Filter (installed on hood)

2 - 35W MR16 GU10 Halogen Lamps (installed on hood)

1 - Parts Bag containing:

6 - Mounting Screws (4mm x 38mm Cross Recessed Pan Head)

2 - Mounting Screws (4mm x 12mm Cross Recessed Pan Head)

4 - Mounting Screws (.188” x .250” Cross Recessed Flat Head)

1 - Suction Cup Tool

1 - Installation Manual

6 MOUNTING

SCREWS

(4mm x 38mm

Cross Recessed

Pan Head)

2 MOUNTING

SCREWS

(4mm x 12mm

C dross Recesse

Pan Head)

DECORATIVE

FLUE

ASSEMBLY

UPPER

FLUE MOUNTING

BRACKET

4 MOUNTING

SCREWS

(.188” x .250”

Cross Recessed

Flat Head)

BULB

SUCTION

CUP TOOL

GLASS

CANOPY

HOOD

ASSEMBLY

MODELS EW5630SS • EW5636SS

Page 3

INSTALL THE WIRING INSTALL THE HOOD MOUNTING

SUPPORT

1. Construct wood wall framing that is flush with interior

surface of wall studs. Make sure the framing is centered over

installation location.

NOTE

Hood distance above cooktop is: Minimum 24”, Maximum 36”.

9-ft. and 10-ft. ceilings require Flue Extension, Model may

FXNE56SS depending on installation height (purchase

separately). See chart below additional installation height for

information.

2. After wall surface is finished, fasten (2) 4mm x 38mm screws

at the locations shown above. DO TIGHTEN screws all NOT

the way.

12”

MAX.

HOOD

CENTERLINE

5”

MAX.

15¼”

24” TO 36”

ABOVE COOKTOP

GROUNDING INSTRUCTIONS

This appliance must be grounded. In the event of an electrical

short circuit, grounding reduces the risk of electric shock by

providing an escape wire the electric current. This appliance for

is equipped with a cord having a grounding wire with a grounding

plug. The plug must be plugged into an outlet that is properly

installed and grounded.

Position the electrical outlet within the space covered the by

decorative flue and where it will not interfere with the round

duct. Make sure the outlet is no further than from the 12” top

of the hood chassis and that the outlet does not interfere with

a mounting bracket fastening area or where the decorative flue

touches the wall.

36” HIGH COOKTOP

13 7/ ”8

3 ”

4 7/ ”16

4mm x 38mm

SCREWS

HERE

SEE

CHART

BELOW

24" 25" 26" 27" 28" 29" 30" 31" 32" 33" 34" 35" 36"

Ceiling

Height

8 Feet 39-7/8" 40-7/8" 41-7/8" 42-7/8" 43-7/8" 44-7/8" 45-7/8" 46-7/8" 47-7/8" 48-7/8" *49-7/8" *50-7/8" *51-7/8"

9 Feet **46-7/8" **47-7/8" **48-7/8" 49-7/8" 50-7/8" 51-7/8"

9 Feet

with

FXNE56SS 39-7/8" 40-7/8" 41-7/8" 42-7/8" 43-7/8" 44-7/8" 45-7/8"

10 Feet

with

FXNE56SS 39-7/8" 40-7/8" 41-7/8" 42-7/8" 43-7/8" 44-7/8" 45-7/8" 46-7/8" 47-7/8" 48-7/8" 49-7/8" 50-7/8" 51-7/8"

* Not recommended for non-ducted conﬁguration

** Non-duct recirculation louvers will be exposed in ducted conﬁguration

Desired Hood Distance (Above 36" High Cooktop)

Upper Mounting Screws Location (Distance above 36" High Cooktop - (Dimension “A”)
