Cover A
Enclosed Accessories
After opening the box, check that the following accessories are enclosed. If any item is missing or damaged,
contact your retailer.
Accessories
The following items should also be enclosed in the box.
1. 2. 3. 4. 5. 6. 7. 8. 9.
10. 11. 12. 13. 14. 15. 16.* 17. 18. 19.
20. 21. 22. 23. 24. 25. 26. 27.
28. 29.
* 75/11 2 needles
90/14 2 needles
90/14 2 needles: Ball point needle (gold colored)
30. 31. 32.
No. Part Name Part Code No. Part Name Part Code
U.S.A. Others U.S.A. Others
1 Buttonhole foot “A” XC2691-051 17 Twin needle X59296-051
2 Overcasting foot “G” XC3098-051 18 Cleaning brush X59476-051
3 Monogramming foot “N” X53840-351 19 Eyelet punch 135793-001
4 Zipper foot “I” X59370-051 20 Screwdriver (large) X55467-051
5 Zigzag foot “J” (on machine) XC3021-051 21 Screwdriver (small) X55468-051
6 Blind stitch foot “R” X56409-051 22 Spool cap (large) 130012-054
7 Button fitting foot “M” 130489-001 23 Spool cap (medium)(2) X55260-153
8 Walking foot SA140 XC2214-002 24 Spool cap (small) 130013-154
9 Quilting foot SA129 XC1948-002 25 Extra spool pin XC4654-051
10 Stitch guide foot “P” SA160 XA8839-002 26 Spool net XA5523-050
11 Adjustable zipper/piping foot SA161 XC1970-002 27 Foot controller XC1154-051
12 Non stick foot SA114 XC1949-002 28 Grid sheet set SA527 XC4549-051
13 Open toe foot SA147 XC1964-002 29 Knee lifter XA6941-052
14 Seam ripper X54243-001 30 Operation manual XE1139-001
15 Bobbin (4) SA156 XA5539-151 31 Quick reference guide
XC4546-151,XC4589-051
16 Needle set X58358-051 32 Hard case XC2360-152
Note
(For U.S.A. only)
●Foot controller: Model N5V
This foot controller can be used on this
machine model NX-400/PC-420.
●The screw of the presser foot holder is
available through your authorized dealer
(Part code: XA4813-051).
●The organized accessory tray is
available,through your authorized
dealer.(Part code: XC4489-051)
Cover B
GETTING READYCONTENTS SEWING BASICS UTILITY STITCHES APPENDIX INDEX
Names of Machine Parts and Their Functions
The names of the various parts of the sewing machine and their functions are described below. Before using the
sewing machine, carefully read these descriptions to learn the names of the machine parts.
Front view
1 2Thread guide plate / Thread guide cover
Pass the thread around the thread guide plate when
threading the upper thread.
3Spool pin
Place the spool on the spool pin.
4Thread guide for bobbin winding
Pass the thread around this thread guide when winding
the bobbin thread.
5Upper cover
Open the upper cover to place the spool of thread on
the spool pin.
6Bobbin winder
Use the bobbin winder when winding the bobbin.
7Operation panel
Select a stitch from those that appear in the operation
panel. (page Cover E)
8Sewing speed controller
Use the sewing speed controller to adjust the sewing
speed.
9Knee lifter mounting slot
Plug the knee lifter into the knee lifter mounting slot.
0Operation buttons
Use the operation buttons to start the sewing machine
and automatically cut the thread. (page Cover D)
AFlat bed attachment with accessory compartment
Store presser feet and bobbins in the accessory
compartment of the flat bed attachment. When sewing
cylindrical pieces, remove the flat bed attachment.
BThread cutter
Pass the threads through the thread cutter to cut them.
CNeedle threader lever
Use the needle threader to thread the needle.
DThread tension dial
Use the thread tension dial to adjust the tension of the
upper thread.
5
3
4
6
2
1
7
0
8
C
D
B
A
9
———————————————————————————————————————— Names of Machine Parts and Their Functions
Cover C
GETTING READYCONTENTS SEWING BASICS UTILITY STITCHES APPENDIX INDEX
Needle and presser foot
section
1Buttonhole lever
Lower the buttonhole lever when sewing buttonholes
and bar tacks.
2Thread guide discs
Pass the thread through the thread guide discs when
using the needle threader to thread the needle.
3Needle bar thread hook
Pass the upper thread through the needle bar thread
hook.
4Needle plate
The needle plate is marked with guides for sewing
straight seams.
5Bobbin cover/shuttle
Remove the bobbin cover, and then insert the bobbin
into the shuttle.
6Feed dogs
The feed dogs feed the fabric in the sewing direction.
7Presser foot
The presser foot applies pressure consistently on the
fabric as the sewing takes place. Attach the appropriate
presser foot for the selected stitching.
8Presser foot holder
The presser foot is installed onto the presser foot holder.
Right-side/rear view
1Presser foot dial
Use the presser foot dial to adjust the amount of
pressure that the presser foot applies to the fabric.
2Handle
Carry the sewing machine by its handle when
transporting the machine.
3Balance wheel
Turn the balance wheel toward you to raise and lower
the needle to sew one stitch.
4Air vent
The air vent allows the air surrounding the motor to be
exchanged. Do not cover the air vent while the sewing
machine is being used.
5Main power switch
Use the main power switch to turn the sewing machine
on and off.
6Foot controller jack
Insert the plug on the end of the foot controller cable
into the foot controller jack.
7Power supply jack
Insert the plug on the power supply cord into the power
supply jack.
8Feed dog position switch
Use the feed dog position switch to lower the feed dogs.
Memo
●Refer to Cover B, D or E pages while you
are learning to use your machine.
1
23
4
5
6
7
8
2
3
5
6
4
7
8
1
Cover D
GETTING READYCONTENTS SEWING BASICS UTILITY STITCHES APPENDIX INDEX
Operation buttons
The operation buttons help you to easily perform various basic sewing machine operations.
1Start/stop button
Press the start/stop button to start or stop sewing. The
machine sews at a slow speed at the beginning of
sewing while the button is depressed. When sewing is
stopped, the needle is lowered in the fabric. For details,
refer to “Starting to sew” (page 49).
The button lights up in green, red or orange, depending
on how the sewing machine is being operated.
Green: When the machine is ready to start
sewing or while it is sewing
Red: When the machine is not ready to start
sewing
Orange: When the bobbin winder shaft is moved
to the right for winding the bobbin
thread onto the bobbin
2Reverse/reinforcement stitch button
Press the reverse/reinforcement stitch button to sew
reverse stitches or reinforcement stitches. Reverse
stitches are sewn by keeping the button pressed down to
sew in the opposite direction. Reinforcement stitches
are sewn by sewing 3 to 5 stitches on top of each other.
For details, refer to “Securing the stitching” (page 51).
3Needle position button
Press the needle position button to raise or lower the
needle. Pressing the button twice sews one stitch.
4Thread cutter button
Press the thread cutter button after stopping sewing to
cut both the upper and the bobbin threads. For details,
refer to “Cutting the thread” (page 53).
5Sewing speed controller
Slide the sewing speed controller to adjust the sewing
speed.
6Presser foot lever
Raise and lower the presser foot lever to raise and lower
the presser foot.
Note
●Do not press the thread cutter button if there
is no fabric under the presser foot or while
the machine is sewing, otherwise damage to
the machine may occur.
●When cutting thread thicker than #30,
nylon thread or other special threads, use
the thread cutter on the side of the machine.
For details, refer to “Cutting the thread”
(page 53).
2
3
1
5
6
4
●Do not press the thread cutter button after
the threads have already been cut, otherwise
the needle may break, the threads may
become tangled or damage to the machine
may occur.
CAUTION
1
GETTING READYCONTENTS SEWING BASICS UTILITY STITCHES APPENDIX INDEX
Optional Accessories
The following are available as optional accessories.
1. Side cutter
Part code: SA177,XC3879-002
2. Quilting guide
Part code: SA132, XC2215-002
3. Wide table
Part code: SA537,XC4541-051
Memo
●To obtain optional accessories or parts, contact your sales representative or the nearest authorized
service center.
1. 2. 3.
———————————————————————————————————————————————————Enclosed Accessories
2
GETTING READYCONTENTS SEWING BASICS UTILITY STITCHES APPENDIX INDEX
Introduction
Thank you for purchasing this sewing machine.
Before using this sewing machine, carefully read the “Important Safety Instructions” (page 6), and then study this
manual for the correct operation of the various functions.
In addition, after you have finished reading this manual, store it where it can quickly be accessed for future
reference.
Sewing Machine Features
1Easy upper threading
Since the spool can be installed at the front of the sewing machine, the upper thread can easily be threaded. In addition,
the needle can be threaded with a simple operation. (page 24)
2Automatic thread-cutting
The sewing machine can be set to automatically cut the thread at the end of the stitching. (page 58)
3One-touch lower threading
You can start sewing without pulling up the bobbin thread. (page 22)
4Simple bobbin-winding
The bobbin can quickly and easily be wound with thread. (page 18)
5Built-in stitches
You can select from the built-in stitches available, including utility stitches, character stitches and decorative stitches.
Twelve of the most often used utility stitches can quickly be selected with the stitch keys. (page 68)
6Knee lifter
Use the knee lifter to raise and lower the presser foot with your knee, leaving both hands free to handle the fabric.
(page 61)
14
2
3
6
5
7
GETTING READYCONTENTS SEWING BASICS UTILITY STITCHES APPENDIX INDEX
FOR USERS IN THE UK, EIRE, MALTA AND CYPRUS ONLY
If this machine is fitted with a three-pin non-rewireable BS plug then please read the following.
IMPORTANT
If the available socket outlet is not suitable for the plug supplied with this equipment, it should be cut
off and an appropriate three-pin plug fitted. With alternative plugs an approved fuse must be fitted in
the plug.
NOTE
The plug served from the main lead must be destroyed as a plug with bared flexible cords is
hazardous if engaged in a live socket outlet. In the event of replacing the plug fuse, use a fuse
approved by ASTA to BS 1362, i.e. carrying the mark, rating as marked on plug.
Always replace the fuse cover, never use plugs with the fuse cover omitted.
WARNING
DO NOT CONNECT EITHER WIRE TO THE EARTH TERMINAL WHICH IS MARKED WITH THE
LETTER ‘E’, BY THE EARTH SYMBOL OR COLOURED GREEN OR GREEN AND YELLOW.
The wires in this main lead are colored in accordance with the following code:
Blue Neutral
Brown Live
As the colors of the wiring in the main lead of this appliance may not correspond with the colored
markings identifying the terminals in your plug, proceed as follows.
The wire which is colored blue must be connected to the terminal which is marked with the letter
‘N’ or colored black or blue.
The wire which is colored brown must be connected to the terminal which is marked with the letter
‘L’ or colored red or brown.
Produktspecifikationer
| Varumärke: | Brother |
| Kategori: | Symaskin |
| Modell: | PC-420PRW |
Behöver du hjälp?
Om du behöver hjälp med Brother PC-420PRW ställ en fråga nedan och andra användare kommer att svara dig
Symaskin Brother Manualer
1 Mars 2025
11 Februari 2025
6 Februari 2025
26 Januari 2025
26 Januari 2025
25 Januari 2025
14 Januari 2025
14 Januari 2025
8 Januari 2025
3 Januari 2025
Symaskin Manualer
- Symaskin AEG
- Symaskin IKEA
- Symaskin Medion
- Symaskin Siemens
- Symaskin Ambiano
- Symaskin Alfa
- Symaskin Silvercrest
- Symaskin Tristar
- Symaskin Livoo
- Symaskin Bestron
- Symaskin Sinbo
- Symaskin Jata
- Symaskin Emerio
- Symaskin Singer
- Symaskin Bernina
- Symaskin Pfaff
- Symaskin Blaupunkt
- Symaskin Juki
- Symaskin Solac
- Symaskin Elna
- Symaskin Termozeta
- Symaskin Jocca
- Symaskin Kenmore
- Symaskin Guzzanti
- Symaskin Easymaxx
- Symaskin Toyota
- Symaskin Husqvarna
- Symaskin Bernette
- Symaskin Janome
- Symaskin Necchi
- Symaskin Yamato
- Symaskin Durkopp Adler
- Symaskin Kayser
- Symaskin RCE
- Symaskin Privileg
- Symaskin Lifetec
- Symaskin Kunft
- Symaskin Veritas
- Symaskin Union Special
- Symaskin Easy Home
- Symaskin Carina
- Symaskin Lervia
- Symaskin Vendomatic
- Symaskin Home Electric
- Symaskin Baby Lock
- Symaskin Empisal
- Symaskin Crofton
- Symaskin Lewenstein
- Symaskin Durabase
- Symaskin Meister Craft
- Symaskin Micromaxx
- Symaskin Yamata
- Symaskin Weasy
- Symaskin Łucznik
- Symaskin Silver
- Symaskin Victoria
- Symaskin Prince
- Symaskin Hofmann
- Symaskin Kohler
- Symaskin Muller
- Symaskin Sinojo
- Symaskin Huskystar
- Symaskin Gritzner
- Symaskin LERAN
- Symaskin W6
- Symaskin Prixton
- Symaskin Primera
- Symaskin Zippy
- Symaskin Feiyue
- Symaskin Mediashop
- Symaskin ER
- Symaskin Novamatic
- Symaskin Siemssen
- Symaskin Mio Star
- Symaskin Husqvarna-Viking
- Symaskin SteamMax
Nyaste Symaskin Manualer
8 April 2025
5 Mars 2025
4 Mars 2025
25 Februari 2025
25 Februari 2025
25 Februari 2025
25 Februari 2025
18 Februari 2025
17 Februari 2025
12 Februari 2025
