Café™ 20.1 Cu. Ft. Fully Integrated Installation
French-Door Bottom Freezer
CIP36NP2VS1
FEATURES
Exterior Style Built-In Standard Installation 4-Door Bottom Freezer
Total Capacity 20.1 Cu. Ft.
FF Capacity 13.69 Cu. Ft.
FZ Capacity 3.45 Cu. Ft.
Convertible Drawer 2.91 Cu. Ft.
ADA Compliant No
ENERGY STAR No
Depth Built-In
Ice & Water Dispenser No
Icemaker Yes
Water Filtration Yes
Control Type Upfront Electronic Digital Temperature Display
Internal Lighting LED
Colors Available Stainless Steel
Case Color Unfinished Sides or Panel Required
Claims & Certifications MADE IN AMERICA, California Prop 65
Configuration Full Door
Temperature Management Features Integrated Air Management System
Cabinet Shelves (total & fz) 4 Half Width; 1 Full Width
Fresh Food Cabinet Shelf Features 4 Adjustable Glass; 1 Fixed
Glass Shelves Yes
Fresh Food Cabinet Pans/Drawers 2
Clear Bins and Pans Yes
Fresh Food Drawer Features Climate Zone
Fresh Food Door Bins 6
Fresh Food Door Bins Type 6 Half Width
Freezer Drawer Equipped with Ice Maker and Divider Slide
Filter Change Indicator Yes – On Upfront Control
GE Water Filtration System XWFE Leak Detect in Top Above Case
Leveling System
4 Point (2 adjustable back rollers, 2 adjustable
front legs)
Convertible Drawer
4 Temperature Settings: cold drinks, meat,
snacks or frozen items
Refrigerant Type r600a
Sealed System Design TwinChill Evaporators
Defrost Type Automatic Defrost
Connected
Embedded WiFi; App details; Display/change
temperature; Alert if fresh food temperature is too
high; Alert if freezer temperature is too high; Alert if
water filter needs to be replaced; Alert for software
OTA updates
CIP36NP2VS1
Stainless Steel with Brushed
Stainless handles
WARRANTY
Labor Warranty
Limited 1-year entire appliance
Limited 5-year sealed refrigerating system
Parts Warranty
Limited 1-year entire appliance
Limited 5-year sealed refrigerating system
ADDITIONAL ACCESSORIES
CXSB3H3PVBZ
Brushed Bronze
Optional Kits
CXSB3H3PVBT
Brushed Black
Optional Kits
CXSB3H3PVCU
Brushed Copper
Optional Kits
CXSB3H3PVCG
Brushed Brass
Optional Kits
CXSB3H3PVFB
Flat Black
Optional Kits
WEIGHTS & DIMENSIONS
Overall depth 24-3/4 in.
Overall width 35-3/4 in.
Overall height 83-7/8 in.
Case depth without door 22-1/8 in
Depth without handle 24-3/4 in.
Height to top of case 83-11/16 in.
Approximate shipping weight 590 lbs.
Net weight 550 lbs.
Café™ 20.1 Cu. Ft. Fully Integrated Installation
French-Door Bottom Freezer
CIP36NP2VS1
A
D
C
B
E
A - Overall Height
B - Height to Top of Case (in)
C - Unit Depth with Door Closed with Handle (in)
D - Case Width (in)
E - Overall Width (in)
Approximate Shipping Weight (lb)
Net Weight (lb)
Overall
Weights & Dimensions
83 7/8
83 11/16
27 5/16
35 5/16
35 3/4
590
550
Power / Ratings
Volts/Hertz/Amps 115V 60Hz 20A
35 5/16" (89.7)
Case width
21 5/8"
(54.9)
TOP VIEW
**Dim A
Door
Angle
90°
115°
**Dim A
6 3/4" (17.1)
14" (35.6)
SIDE VIEW
43 3/4" (111.1)
43 3/4" (111.1)
46 3/8" (117.8)
43 1/16" (109.4)
40 1/2" (102.9)
DIMENSIONS AND INSTALLATION
**PRODUCT CLEARANCES
The factory-set 115° door swing can be adjusted to 90°
if clearance to adjacent cabinets or walls is restricted.
GROUNDING THE REFRIGERATOR
IMPORTANT—PLEASE READ CAREFULLY
FOR PERSONAL SAFETY, THIS APPLIANCE
MUST BE PROPERLY GROUNDED
The power supply cord of this appliance is equipped with a
three-prong (grounding) plug which mates with a standard
three-prong (grounding) wall receptacle to minimize the
possibility of electric shock hazard from this appliance.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Where a standard 2-prong wall outlet is encountered, it
is your personal responsibility and obligation to have it
replaced with a properly-grounded 3-prong wall outlet.
DO NOT, UNDER ANY CIRCUMSTANCES,
CUT OR REMOVE THE THIRD (GROUND)
PRONG FROM THE POWER CORD.
DO NOT USE AN ADAPTER PLUG TO
CONNECT THE REFRIGERATOR TO A
2-PRONG OUTLET.
DO NOT USE AN EXTENSION CORD
WITH THIS APPLIANCE.
Café™ 20.1 Cu. Ft. Fully Integrated Installation
French-Door Bottom Freezer
CIP36NP2VS1
DIMENSIONS AND INSTALLATION
(FULLY INTEGRATED INSTALLATION)
FLOORING
For proper installation, this refrigerator must be placed on a level surface
of hard material that is at the same height as the rest of the flooring. This
surface should be strong enough to support a fully loaded refrigerator, or
approximately 1500 lbs.
NOTE: Protect the finish of the flooring. Cut a large section of the cardboard carton
and place under the refrigerator where you are working.
WATER AND ELECTRICAL LOCATIONS
The opening must be prepared with the electrical and water supply
located as shown.
FINISHED RETURN OF 6" REQUIRED
A minimum 6" (15.2) finished return matching cabinet exterior
recommended on interior on all sides and top at front of opening
ADDITIONAL SPECIFICATIONS
A 120 volt, 60Hz, 15- or 20-amp power supply is required. An individual
properly-grounded branch circuit or circuit breaker is recommended.
Install a properly-grounded 3-prong electrical receptacle recessed into
the back wall. Electrical must be located on rear wall as shown.
NOTE: GFI (ground fault interrupter) is not recommended. Water line can enter
the opening through the floor or rear wall. The water line installed should be
1/4" O.D. copper tubing or GE SmartConnect™ tubing between the cold water
line and water connection location. The line should be long enough to extend
to the front of the refrigerator. Installation of an easily-accessible shuto valve
in the water line is required.
SIDE VIEW
25" (63.5)
FRONT VIEW
ELEC W
36" (91.4)
84"
(213.4)
18"
(45.7) 9"
(22.9)
6"
(15.2)
2 1/2"
(6.4)
9"
(22.9)
8"
(20.3)
6"
(15.2)
Finished
Return
Back
