CLASSICAL COOKER HOOD USER'S MANUAL (EN)



Dear Custo

Dear CustoDear Customer,

mer,

mer, mer,

Thank you for preferring our product. It is very important that you install the cooker hood correctly so as to use ,

it for a long time, efficiently and reliability. Please read this User's Manual carefully before installation and using.

1)1)

WHAT

WHAT WHAT TO DO BEFORE US

TO DO BEFORE US

TO DO BEFORE USTO DO BEFORE USING

ING

ING ING

1. Please feed your cooker hood with 220 V through a grounded line.

"WE SHALL ASSUME NO RESPONSIBILITY FOR THE LOSSES CAUSED BY UNGROUNDED

LINES"

2. Please connect your cooker hood to chimney outlet where warm gases are discharged and equipment such as

heaters or boilers are connected.

3. Please plug your cooker hood to an earthed socket, while the buttons on the control panel are in off position.

4. Please install the bulb by opening the aluminum cassette filters below your cooker hood.

5. Please install your cooker hood using the instructions within the packing.

6. The distance between the aluminum cassette filter and oven or hob upper surface must be minimum 75cm for

gas ovens, 65 cm for electric ovens.

7. Your cooker hood has been manufactured to offer operation with or without smoke hole connection.

2) CONNECTIO

2) CONNECTIO2) CONNECTION TO DUCTIN

N TO DUCTIN

N TO DUCTINN TO DUCTING FUNCTION

G FUNCTION

G FUNCTION G FUNCTION

There is an air discharge outlet on your cooker hood. Please connect the outlet to the chimney outlet, air discharge

or atmosphere, by cutting the glass, using aluminum pipe of 12cm diameter. For the vertical outlets, entry of rain

water into cooker hood should be prevented. Chimney outlet connection will be provided through this hole. For

this purpose, we recommend you to use 120mm diameter pipe with cooker hood. The pipe should be as short as

possible and if possible number of bends. This is important for an efficient operation.

3) RECIRCULA

3) RECIRCULA3) RECIRCULATION FU

TION FU

TION FUTION FUNCTION

NCTION

NCTIONNCTION

Note: If it is necessary to use with recirculation function, you can obtain carbon filter from our authorized dealers.

Please remove the cassette aluminum filter on the cooker hood, by pressing the latches inward, and install the

ACTIVE CARBON FILTER that you have obtained from the service. Your cooker hood is ready to operate with

recirculation mode.

4) INSTALL

4) INSTALL4) INSTALLATION OF THE CO

ATION OF THE CO

ATION OF THE COATION OF THE COOKER HOOD

OKER HOOD

OKER HOODOKER HOOD

Use the cooker hood frame to mark upper or back connection holes as well as chimney outlet connection.

(Figure1- Page13)You can see last page of this manuel). Cut chimney outlet hole. Use 4 screws of 3.5x16 YHB to

install the cooker hood onto the kitchen shelf. For the back connection, use an impact drill to open two 7.8mm

diameter, 45mm deep holes and place two dowels of 8mm diameter into these two holes. Screw the L brackets so

as there is 10mm space between them and holes. (Figure2-Page ). Mount your cooker hood to those brackets 13

through the 2 slots in the back and fix the cooker hood by tightening L brackets. The wall must be intact and

drilled without any damage; otherwise it cannot bear the cooker hood. Connect the aluminum spiral pipe to

complete installation. After installation of inox model hood, please pull up aluminum folio from surface of hood.

5) ELECTRICA

5) ELECTRICA5) ELECTRICAL CONNECTI

L CONNECTI

L CONNECTIL CONNECTION

ON ON

Connect the cooker hood to a grounded wall outlet which is close enough for the length of the cooker hood cable.

PUSH BUT

PUSH BUTPUSH BUTTON SWITCH USI

TON SWITCH USI

TON SWITCH USITON SWITCH USING INFORMATIO

NG INFORMATIO

NG INFORMATIONG INFORMATION

N N

The functions of the buttons are as follows:

0 : Stop the engine

1 : Powering the first lev el

2 : Powering the second level

3 : Powering the third level

: On and off button of lamp

Note: While cooking food, push the buttons 1 or 2. For frying or similar meals, use 3.

6) ALUMINIU

6) ALUMINIU6) ALUMINIUM FILTER

M FILTER

M FILTERM FILTER

The purpose of the cassette aluminum filter is to hold oil particles. Depending on the usage, this filter is clogged

by oil. In such a case, remove the filter and wash it with warm water and detergent, either in the sink, or dish

washer, dry and re-install.

WARNING: ACTIVE CARBON FILTER can not be -used after washing. re

7) CARBO

7) CARBO7) CARBON FILTER (RECIRC

N FILTER (RECIRC

N FILTER (RECIRCN FILTER (RECIRCULATION

ULATION

ULATIONULATION FUNCTION

FUNCTION

FUNCTION FUNCTION)

)

) )

Carbon filter has been developed to remove odors, and must be replaced once in 4 months.

NOTE: Spare filters should be bought from authorized services.

8) RECOMME

8) RECOMME8) RECOMMENDATIO

NDATIO

NDATIONDATION

N N

 Do not replace filters while cooker hood is operating.

 Operate the cooker hood only after placing the pan on the oven.

 Transport the cooker hood considering the marks on it, using original packing. Protect from any humidity,

water, impact etc. that would damage the equipment.

 Keep the packing waste far from children, and discard the wastes in suitable waste places.

 If you have a trouble with your cooker hood, do not allow interruption of unauthorized persons, only

apply to authorized services.

9) IMPORTA

9) IMPORTA9) IMPORTANT INSTALLA

NT INSTALLA

NT INSTALLANT INSTALLATIO

TIO

TIOTION AND USAGE

N AND USAGE

N AND USAGEN AND USAGE NOTES

NOTES

NOTES NOTES

1. Prevent any foreign objects falling into the cooker hood and causing an obstruction within the motor.

2. Use aluminum pipe instead of a plastic one for air discharge, apply a screen on the discharge outlet so as to

prevent ingress of any foreign objects.

3. Prevent any hot oil and carelessly thrown foods on the oven.

4. Do not forget any cooking or frying pan on the burning oven.

5. You must clean or replace oily cooker hood filter periodically .

6. If there is no user signature on the warranty certificate, or the consumer makes misleading or incorrect

statements, we reserve our legal remedies. In such a case, warranty period will end immediately.

7. The products for which no warranty certificate is presented are outside of warranty cover.

8. Aluminum filter must be washed once in 2 months.

10) DISCLA

10) DISCLA10) DISCLAIMER

IMER

IMER IMER

We shall have no responsibility for fires or failures occurring due to user’s fault to comply with instructions. This

also will make warranty void.
