Sida 1/12
HOBS 60 cm
USER INSTRUCTIONS
GB
TECHNICAL CHARACTERISTICS
Cooking hobs 60x50 Gas Electric
Burners 4 gas –
– 4 elec.
Reference type P4 01 PE 03
Supply Voltage/Frequency (V/Hz) 240/50 240/50
Installed electric power (W) – 6000
Gas burner power:
Medium burner kW 1,45 (x 3) –
Large burner kW 2,9 –
Power of gas installed:
- G20/20 mbar (kW)* 7,45
- G30/28-30 mbar (g/h) 542
Electric ignition yes –
Product size mm. 585x500 585x500
Degree protection – Type Y
Class 3
Fig. 1
Fig. 4 Fig. 4 bis
* Manufacturer setting GB cat. II2H3+
TECHNICAL CHARACTERISTICS
FOR AUSTRALIA
Cooking hobs 60x50
Burners 4 gas 4 gas 3 gas 3 gas
– – 1electric 1 electric
Reference type P401 P402 P301 P302
Supply Voltage/Frequency (V/Hz) 230/50 230/50 230/50 230/50
Installed electric power (W) – – 1400 1400
Semi rapid burner 3 3 2 2
Rapid burner 1 1 1 1
Power of gas installed: (MJ/H)
- Natural gas 1,13 kPa* 28 28 22,1 22,1
- LPG gas 2,75 kPa 25,2 25,2 19,7 19,7
Electric ignition yes yes yes yes
Gas safety device – yes – yes
Product size mm. 585x500 585x500 585x500 585x500
Degree protection – – Type Y Type Y
Class 3 3 3 3
Fig. 1
* Manufacturer setting
2
VERY IMPORTANT - APPLYING THE SEALANT
Important - The diagram below shows how the sealant should be applied.
INSTALLATION
The Purchaser is responsible for the installation of the hob. The Manufacturer does not
accept any responsibility for any damage or loss resulting from incorrect installation,
and as such this will not covered by the Manufacturer’s Guarantee.
The hob may be installed in any worktop which is heat resistant to a temperature of
100° C, and has a thickness of 25 - 40 mm. The dimensions of the insert to be cut
out of the worktop are in shown in Fig. 1.
If the Hob is fitted next to a cabinet on either side,
the distance between the Hob and the cabinet
must be at least 30 mm (see Fig. 2); while the
distance between the hob and the rear wall must
be at least 40 mm.
If below the hob there is an accessible space,
there must be a partition panel in insulating mate-
rial (wood or similar) providing a space of at least
10 mm below the Hob (see Fig. 2).
The Hob unit is fitted by attaching the Fixing
Clamps supplied, using the holes at the base of
the unit.
Fig. 2
Partition panel
30 mm
min.
30 mm
10 mm
This appliance has been designed for non-professional, i.e. domestic, use.
Appropriate checks and tests have ensured that, even in the most extreme conditions,
the temperatures reached are within acceptable limits
. The Hob is thermally insula-
ted (in line with Regulation EN) and may be installed: next to panels higher than
the
worktop, for type «Y», or next to panels not higher than the worktop for type
«X.».
See technical characteristics table «Degree of protection».
