Operation Guide 3134 3205

MO1002-EA

Getting Acquainted

Congratulations upon your selection of this CASIO watch. To get the most out

of your purchase, be sure to read this manual carefully.

•This watch does not have a time zone that corresponds to the UTC

offset of –3.5 hours. Because of this, the radio-controlled timekeeping

and World Time functions will not display the correct time for

Newfoundland, Canada.

Applications

The built-in sensors of this watch measure direction, barometric pressure,

temperature and altitude. Measured values are then shown on the display.

Such features make this watch useful when hiking, mountain climbing, or

when engaging in other such outdoor activities.

Keep the watch exposed to bright light

The electricity generated by the solar cell of the

watch is stored by a built-in battery. Leaving or

using the watch where it is not exposed to light

causes the battery to run down. Make sure the

watch is exposed to light as much as possible.

•When you are not wearing the watch on your

wrist, position the face so it is pointed at a

source of bright light.

•You should try to keep the watch outside of

your sleeve as much as possible. Charging is

reduced significantly if the face is covered only

partially.

Bright light

Solar cell

•The watch continues to operate, even when it is not exposed to light.

Leaving the watch in the dark can cause the battery to run down, which will

result in some watch functions being disabled. If the battery goes dead, you

will have to re-configure watch settings after recharging. To ensure normal

watch operation, be sure to keep it exposed to light as much as possible.

If the display of the watch is blank...

If the display of the watch is blank, it means that the watch’s Power Saving

function has turned off the display to conserve power.

•See “Power Saving” for more information.

About This Manual

•Depending on the model of your watch, display

text appears either as dark figures on a light

background (Module 3134), or light figures on

a dark background (Module 3205). All sample

displays in this manual are shown using dark

figures on a light background.

•Button operations are indicated using the

letters shown in the illustration.

•Each section of this manual provides you with

the information you need to perform operations

in each mode. Further details and technical

information can be found in the “Reference”

section.

(Light)

Module 3134

Module 3205

General Guide

•The illustration below shows which buttons you need to press to navigate

between modes.

•In any mode, press to illuminate the display.L

•You can use buttons , and to enter a sensor mode directly fromA, B C

the Timekeeping Mode or from another sensor mode. To enter a sensor

mode from the Tide/Moon Data, Countdown Timer, Stopwatch, World Time,

Alarm, Data Recall, or Receive Mode, first enter the Timekeeping Mode

and then press the applicable button.

Timekeeping Mode

Altimeter Mode

Stopwatch

Mode

Countdown

Timer Mode

Digital

Compass Mode

Press D.

Press .B

Alarm Mode

Press C.

Sensor Modes

World Time Mode

Barometer/

Thermometer Mode

Press .A

Data Recall

Mode

▲

Receive Mode

▲

Tide/Moon Data

Mode

▲

Press

Warning!

•The measurement functions built into this watch are not intended for

taking measurements that require professional or industrial precision.

Values produced by this watch should be considered as reasonable

representations only.

•The Moon phase indicator and tide graph data that appear on the

display of this watch are not intended for navigation purposes. Always

use proper instruments and resources to obtain data for navigation

purposes.

•This watch is not an instrument for calculating low tide and high tide

times. The tide graph of this watch is intended to provide a reasonable

approximation of tidal movements only.

•When engaging in mountain climbing or other activities in which losing

your way can create a dangerous or life-threatening situation, always be

sure to use a second compass to confirm direction readings.

•Note that CASIO COMPUTER CO., LTD. assumes no responsibility for

any damage or loss suffered by you or any third party arising through

the use of this product or its malfunction.

Bright light

Electrical

energy

All

functions

enabled

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Charge

Solar cell

(Converts light to

electrical power.)

Rechargeable battery

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Some

functions

disabled

Dis-

charge

Battery charges in the light. Battery discharges in the dark.

•The actual level at which some functions are disabled depends on the

watch model.

•Frequent display illumination can run down the battery quickly and require

charging. The following guidelines give an idea of the charging time

required to recover from a single illumination operation.

Approximately five minutes exposure to bright sunlight coming in through

a window

Approximately 50 minutes exposure to indoor fluorescent lighting

•Be sure to read “Power Supply” for important information you need to

know when exposing the watch to bright light.

Operation Guide 3134 3205

Radio-controlled Atomic Timekeeping

This watch receives a time calibration signal and updates its time setting

accordingly.

•This watch is designed to pick up the time calibration signals transmitted in

Germany (Mainflingen), England (Anthorn), the United States (Fort Collins)

and Japan.

•See the information under Signal Reception Troubleshooting if you“ ”

experience problems with time calibration signal reception.

Current Time Setting

This watch adjusts its time setting automatically in accordance with a time

calibration signal. You also can perform a manual procedure to set the time

and date, when necessary.

•The first thing you should do after purchasing this watch is to specify

your Home City (the city where you normally will use the watch). For

more information, see “To specify your Home City”.

•When using the watch outside the areas covered by the time signal

transmitters, you will have to adjust the current time setting manually as

required. See “Timekeeping” for more information about manual time

settings.

•The U.S. time calibration signal can be picked up by the watch while in

North America. The term North America“ ” in this manual refers to the area

that consists of Canada, the continental United States, and Mexico.

•Using this watch in a country covered by a time calibration that is different

from the countries it supports may result in incorrect time indication due to

local application of summer time, etc.

To specify your Home City

1. In the Timekeeping Mode, hold down untilE

the city code starts to flash, which indicates

the setting screen.

2. Press A C (east) and (west) to select the

city code you want to use as your Home City.

LON : London

PAR, BER : Paris, Berlin, Milan, Rome,

Amsterdam, Hamburg, Frankfurt,

Vienna, Barcelona, Madrid

ATH : Athens

HKG, TYO, SEL : Hong Kong, Tokyo, Seoul

HNL : Honolulu

ANC : Anchorage, Nome

LAX : Los Angeles, San Francisco, Las Vegas, Seattle/Tacoma,

Vancouver, Tijuana

DEN : Denver, El Paso, Edmonton, Culiacan

City code

Hour :

Minute

PM indicator

Second

Month – Day

CHI : Chicago, Houston, Dallas/Fort Worth, New Orleans, Winnipeg,

Mexico City

NYC: New York, Detroit, Miami, Boston, Montreal

•For full information on city codes, see the “City Code Table”.

•Note that this watch does not have a city code that corresponds to

Newfoundland.

3. Press E to exit the setting screen.

•Normally, your watch should show the correct time as soon as you select

your Home City code. If it does not, it should adjust automatically after the

next auto receive operation (in the middle of the night). You also can

perform manual receive or you can set the time manually.

•The watch will receive the time calibration signal automatically from the

applicable transmitter (in the middle of the night) and update its settings

accordingly. For information about the relationship between city codes and

transmitters, see “ ”Time Calibration Signal Reception and “Transmitters”.

•See the maps under “ ”Approximate Reception Ranges for information about

the reception ranges of the watch.

•Under factory default settings, auto receive is turned off for all of the

following city codes: (Hong Kong), (Honolulu), and HKG HNL ANC

(Anchorage). For details about turning on auto receive for these city codes,

see “To turn auto receive on and off”.

•You can disable time signal reception, if you want. See “To turn auto receive

on and off for more information.”

Time Calibration Signal Reception

There are two different methods you can use to receive the time calibration

signal: auto receive and manual receive.

•Auto Receive

With auto receive, the watch receives the time calibration signal automatically

up to six times a day. When any auto receive is successful, the remaining

auto receive operations are not performed. For more information, see “About

Auto Receive”.

•Manual Receive

Manual receive lets you start a time calibration receive operation with the

press of a button. For more information, see “To perform manual receive”.

•Proper signal reception can be difficult or even impossible under the

conditions listed below.

•Signal reception normally is better at night than during the day.

•Time calibration signal reception takes from two to seven minutes, but in

some cases it can take as long as 14 minutes. Take care that you do not

perform any button operations or move the watch during this time.

Inside or

among

buildings

Inside a

vehicle

Near a

construction

site, airport,

or other

sources of

electrical

noise

Near high-

tension

power lines

Among or

behind

mountains

Near

household

appliances,

office

equipment,

or a mobile

phone

•The time calibration signal the watch will attempt to pick up depends on its

current Home City code setting as shown below.

Home City Code

LON,

PAR , BER, ATH

HKG*, TYO, SEL

HNL ANC LAX*, *, ,

DEN, CHI, NYC

Frequency

60.0 kHz

77.5 kHz

40.0 kHz

60.0 kHz

Transmitter

Anthorn (England)

Mainflingen (Germany)

Fukushima (Japan)

Fukuoka/Saga (Japan)

Fort Collins, Colorado

(United States)

* The areas covered by the HKG HNL ANC, , and city codes are quite far

from the time calibration signal transmitters, and so certain conditions

may cause problems with signal reception.

Anthorn

Mainflingen

1,500 kilometers

500 kilometers

Fort

Collins

2,000 miles

(3,000 kilometers)

600 miles

(1,000 kilometers)

1,000

kilometers

1,000

kilometers

Fukuoka/Saga

500

kilometers

Fukushima

500

kilometers

Approximate Reception Ranges

U.K. and German Signals U.S. Signal

Japan Signals

•Signal reception may not be possible at the distances noted below during

certain times of the year or day. Radio interference also may cause

problems with reception.

Mainflingen (Germany) or Anthorn (England) transmitters: 500

kilometers (310 miles)

Fort Collins (United States) transmitter: 600 miles (1,000 kilometers)

Fukushima or Fukuoka/Saga (Japan) transmitters: 500 kilometers (310

miles)

•Even when the watch is within the reception range of the transmitter, signal

reception will be impossible if the signal is blocked by mountains or other

geological formations between the watch and signal source.

•Signal reception is affected by weather, atmospheric conditions, and

seasonal changes.

Important!

•When getting ready to receive the time calibration signal, position the watch

as shown in the nearby illustration, with its 12 o’clock side facing towards a

window. This watch is designed to receive a time calibration signal late at

night. Because of this, you should place the watch near a window as shown

in the illustration when you take it off at night. Make sure there are no metal

objects nearby.

12 o’clock

•Make sure the watch is facing the right way.

Operation Guide 3134 3205

Note

•When a calibration time is reached, the watch will receive the calibration

signal only if it is in either the Timekeeping Mode or World Time Mode.

Reception is not performed if a calibration time is reached while you are

configuring settings.

•Auto receive of the calibration signal is designed to be performed early in

the morning, while you sleep (provided that the Timekeeping Mode time is

set correctly). Before going to bed for the night, remove the watch from your

wrist, and put it in a location where it can receive the signal easily.

•The watch takes from two to 14 minutes to receive the time calibration

signal whenever a calibration time is reached. Do not perform any button

operation within 14 minutes before or after any one of the calibration times.

Doing so can interfere with correct calibration.

•Remember that reception of the calibration signal depends on the current

time in the Timekeeping Mode. The receive operation will be performed

whenever the display shows any one of the calibration times, regardless of

whether or not the displayed time actually is the correct time.

About the Receiving Indicator

The receiving indicator shows the strength of the calibration signal being

received. For best reception, be sure to keep the watch in a location where

signal strength is strongest. The receiving indicator is displayed while an auto

or manual receive operation is in progress.

Receiving

indicator

Weak

(Level 0)

Strong

(Level 3)

•Even in an area where signal strength is strong, it takes about 10 seconds

for signal reception to stabilize enough for the receiving indicator to indicate

signal strength.

•Use the receiving indicator as a guide for checking signal strength and for

finding the best location for the watch during signal receive operations.

•Following reception of the time calibration signal and calibration of the

watch’s time setting, a settings updated“ ” indicator ( ) will remain on the

display in all modes. The settings updated indicator ( ) will not be

displayed if signal reception was unsuccessful or after you adjust the

current time setting manually.

•The settings updated indicator ( ) appears only when the watch is able to

receive both time and date data successfully. It does not appear when only

time data is received.

•The settings updated indicator ( ) indicates that at least one of the auto

calibration signal receive operations was successful. Note, however, that

the indicator disappears from the display each day at the start of the first

auto receive operation of the day.

To perform manual receive

1. Enter the Receive Mode.

2. Place the watch on a stable surface so its 12

o’clock side is facing towards a window.

3. Hold down A for about two seconds until RC!

appears on the display.

•Time calibration signal reception takes from

two to seven minutes, but in some cases it can

take as long as 14 minutes. Take care that you

do not perform any button operations or move

the watch during this time.

•If the receive operation is successful, the

reception date and time appear on the display,

along with the GET indicator.

The watch will enter the Receive Mode if you

press or if you do not perform any buttonA

operation for about one or two minutes.

Receiving

Receive successful

•If the current reception fails but a previous

reception was successful, the display shows

the previous reception’s date and time, and the

ERR indicator. indicates that none of

the reception operations have been successful

during the current date.

The watch will enter the Receive Mode without

changing the time setting if you press A or if

you do not perform any button operation for

about one or two minutes.

Note

•To interrupt a receive operation and return to

the Receive Mode, press A.

Receive failed

If there was a previously

successful reception

If no reception has been

successful

To turn auto receive on and off

1. Enter the Receive Mode.

2. In the Receive Mode, hold down until theE

current auto receive setting (ON OFF or )

starts to flash. This is the setting screen.

•Note that the setting screen will not appear

if the currently selected Home City is one

that does not support time calibration

reception.

3. Press A to toggle auto receive on (ON) and

off (OFF).

4. Press E to exit the setting screen.

•For information about city codes that support

signal receive, see “To specify your Home

City”.

On/Off status

To check the latest signal reception results

Enter the Receive Mode.

•When receive is successful, the display shows

the time and date that receive was successful.

indicates that none of the reception

operations were successful.

•To return to the Timekeeping Mode, press D.

What you should do

•Enter the Receive Mode

and try again.

•Select one of the cities

to the left as your Home

City.

•Perform manual signal

receive or wait until the

next auto signal receive

operation is performed.

Problem

Cannot perform

manual receive.

Auto receive is

turned on, but

the settings

updated

indicator ( )

does not appear

on the display.

Probable Cause

•The watch is not in the Receive

Mode.

•Your current Home City is not

one of the following: LON, PAR,

BER, ATH, HKG, SEL, TYO,

HNL ANC LAX DEN CHI, , , , , or

NYC

•You changed the time setting

manually.

•You changed the DST setting of

your Home City in the World

Time Mode.

•

You pressed a button while signal

receive was in progress.

Signal Reception Troubleshooting

Check the following points whenever you experience problems with signal

reception.

*Next day

5:00 am

About Auto Receive

The watch receives the time calibration signal automatically up to six times a

day. When any auto receive is successful, the remaining auto receive

operations are not performed. The reception schedule (calibration times)

depends on your currently selected Home City, and whether standard time or

Daylight Saving Time is selected for your Home City.

Your Home City Auto Receive Start Times

1 2 3 4 5 6

LON Standard Time

1:00 am 2:00 am 3:00 am 4:00 am 5:00 am

Midnight

Daylight Saving Time

2:00 am 3:00 am 4:00 am 5:00 am

Midnight

1:00 am

PAR Standard Time

2:00 am 3:00 am 4:00 am 5:00 am

Midnight

1:00 am

BER

Daylight Saving Time

3:00 am 4:00 am 5:00 am

Midnight

1:00 am

2:00 am

ATH Standard Time

3:00 am 4:00 am 5:00 am

Midnight

1:00 am

2:00 am

Daylight Saving Time

4:00 am 5:00 am

Midnight

1:00 am

2:00 am

3:00 am

HKG,

SEL,

TYO

HNL,

ANC,

LAX,

DEN,

CHI,

NYC

Standard Time

Standard Time and

Daylight Saving

Time

Midnight

1:00 am

2:00 am

3:00 am

4:00 am

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	3205

Behöver du hjälp?

Om du behöver hjälp med Casio 3205 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Titta Casio Manualer

Casio Edifice EQB-1000TR-2AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1259PD-7BEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GA-810B-1A9ER Bruksanvisning

24 Oktober 2024

Casio Collection SGW-450HD-1BER Bruksanvisning

24 Oktober 2024

Casio Edifice EQB-1000XD-1AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1222A-2AVEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GMW-B5000G-2ER Bruksanvisning

24 Oktober 2024

Casio Radio Controlled WV-200E-1AVEF Bruksanvisning

24 Oktober 2024

Casio Collection LWS-2000H-2AVEF Bruksanvisning

24 Oktober 2024

Casio Pro Trek PRW-60YBM-1AER Bruksanvisning

24 Oktober 2024

Titta Manualer

Nyaste Titta Manualer

Lorus W207 Bruksanvisning

27 Oktober 2024

Invicta Specialty 31308 Bruksanvisning

27 Oktober 2024

Timex Ironman TW5M244009J Bruksanvisning

26 Oktober 2024

Timex MK1 TW2R68800VQ Bruksanvisning

26 Oktober 2024

Braun BN0021 Bruksanvisning

24 Oktober 2024

Braun AW60 Bruksanvisning

24 Oktober 2024

Braun BN0042 Bruksanvisning

24 Oktober 2024

Skmei 0984A Bruksanvisning

22 Oktober 2024

Suunto SPARTAN ULTRA 1.2 Bruksanvisning

21 Oktober 2024

Skmei 0955 Bruksanvisning

21 Oktober 2024
