Operation Guide 3189/3252
E-2
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To set the time and date ......................................................................................... E-7
To input a new Data Bank record ........................................................................ E-12
To recall Data Bank records ................................................................................ E-15
To edit a Data Bank record .................................................................................. E-16
To delete a Data Bank record .............................................................................. E-16
To view the time in another city code ................................................................. E-17
To toggle a city code time between Standard Time and
Daylight Saving Time ........................................................................................ E-18
MA1012-EA
E
About This Manual
•Depending on the model of your watch, display text
appears either as dark figures on a light background or
light figures on a dark background. All sample displays
in this manual are shown using dark figures on a light
background.
•Button operations are indicated using the letters shown
in the illustration.
•Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
E-1
Contents
General Guide ......................................................................................................... E-4
Timekeeping ............................................................................................................ E-6
Data Bank .............................................................................................................. E-11
World Time ............................................................................................................ E-17
Day Counter .......................................................................................................... E-19
Alarms .................................................................................................................... E-23
Stopwatch .............................................................................................................. E-28
Countdown Timer ................................................................................................. E-30
Reference .............................................................................................................. E-32
Specifications ....................................................................................................... E-35
E-3
To set the target date ............................................................................................ E-20
To set an alarm time ............................................................................................. E-24
To test the alarm ................................................................................................... E-25
To turn an alarm on and off ................................................................................. E-26
To turn the Hourly Time Signal on and off ......................................................... E-27
To use the countdown timer ................................................................................ E-30
To set the countdown start time .......................................................................... E-31
To turn the button operation tone on and off ..................................................... E-32
E-4
General Guide
•Press C to change from mode to mode.
•Pressing L in any mode illuminates the display.
Timekeeping Mode World Time ModeData Bank Mode
Press .
E-5
•If you do not perform any operation for a few minutes while a setting screen (with
flashing digits) is on the display, the watch exits the setting screen automatically.
•If you do not perform any operation for a few minutes in the Alarm Mode, Day
Counter Mode, or Data Bank Mode, the watch reverts to the normal timekeeping
screen automatically.
Countdown
Timer Mode
Alarm Mode Stopwatch ModeDay Counter Mode
E-6
Timekeeping
Use the Timekeeping Mode to set and view the current
time and date.
•Pressing A in the Timekeeping Mode will display the
currently selected Home City.
•Press D to toggle between 12-hour and 24-hour
formats.
•With 12-hour format, times between midnight and noon
are indicated by A (am), while times between noon and
midnight are indicated by P (pm).
•The A and P indicators do not appear when you are
using 24-hour format.
Year
Day of week
Seconds
Month – Day
Hour
PM indicator
Minutes
E-7
To set the time and date
1. While in the Timekeeping Mode, hold down A until the second’s digits flash on the
display, which indicates the setting screen.
2. Press C to move the flashing in the sequence shown below.
DST
Seconds
Month
Day
City code
Minutes
Year
Hour
E-8
3. While the seconds setting is selected (flashing), press D to reset it to 00. If you
press D while the seconds setting is in the range of 30 to 59, the seconds are
reset to 00 and 1 is added to the minutes. If the seconds setting is in the range of
00 to 29, the minutes count is unchanged.
•While the DST* setting is selected (DST on indicator is flashing), press D to
toggle it on (On) and off (OF).
•The DST on/off setting you select for the Timekeeping Mode affects the World
Time Mode.
•While the city code setting is selected, use D and B to scroll through the
available codes until the one you want to use as your home time city is displayed.
•For full information on city codes, see the “City Code Table” at the back of this
manual.
4. While any other setting is selected (flashing), press D to increase it or press B to
decrease it. Holding down D or B scrolls at high speed.
5. Press A to exit the setting screen.
•The day of the week is set in accordance with the date automatically.
•The date can be set within the range of January 1, 2000 to December 31, 2099.
E-9
•The watch’s built-in full automatic calendar makes allowances for different month
lengths and leap years automatically. Once you set the date, there should be no
reason to change it except after replacement of the watch’s battery.
* See “Daylight Saving Time (DST) Setting” (page E-18) for details about the DST
setting.
Operation Guide 3189/3252
E-10
Backlight Precautions
The backlight uses an EL (electro-luminescent) panel that causes the entire display to
glow for easy reading in the dark.
In any mode, press L to illuminate the display for about two seconds.
•The electro-luminescent panel that provides illumination loses power after very long
use.
•The illumination provided by the backlight may be hard to see when viewed under
direct sunlight.
•The watch may emit an audible sound whenever the display is illuminated. This is
due to vibration of the EL panel used for illumination, and does not indicate
malfunction.
•The backlight turns off automatically whenever an alarm sounds.
•Frequent use of the backlight shortens the battery life.
E-11
Data Bank
Mode indicator Name area
Remainin
g
free records Number area
Alternate at
the 1-second
interval.
The Data Bank Mode lets you store up to 25 records, each with a name (up to eight
characters) and a phone number (up to 12 digits). Entering the Data Bank Mode displays
a screen that shows the mode name (DB) and remaining memory capacity (number of
records) for a few moments. After that, the record you were viewing the last time you
exited the Data Bank Mode will appear. Anytime you input a new record, all records will
be sorted automatically into alphabetic sequence on the name.*
* A to Z, 0 to 9, symbols (, or -)
E-12
To input a new Data Bank record
1. In the Data Bank Mode, use D (+) and B (–) to scroll through the Data Bank
records and display the one you want to input data.
2. Hold down A until a cursor appears on the name area.
3. Use D and B to scroll through characters at the current cursor position.
Characters scroll in the sequence shown below.
(Space) A to Z 0 to 9 . (Period) - (Hyphen)
Press .
Press .
• Holding down D or B scrolls at high speed.
E-13
4. When the character you want is at the current cursor position, press C to move the
cursor to the right.
1st digit 8th digit
12th digit 1st digit
Name area
Number area
Press .
5. Repeat the steps 3 and 4 to input the rest of the characters.
•You can input up to eight characters for the name, though only three characters
are visible at a time.
•If the name you input has fewer than eight characters, use C to move the cursor
to the eighth space (which means you would press C three times after inputting
a five-character name).
6. After you input the name, use C to move the cursor to the number area.
•Pressing C while the cursor is located at the eighth character of the name area
advances to the number area. Pressing C while the cursor is located at the 12th
digit of the number area returns to the name area.
E-14
7. Use D and B to scroll through characters (hyphen, numbers, space) at the
current cursor position on the number area. Characters scroll in the sequence
shown below.
(Space)
0 to 9 - (Hyphen)
Press .
Press .
•Holding down D or B scrolls characters at high speed.
8. When the character you want is at the cursor position, press C to move the cursor
to the right.
9. Repeat steps 7 and 8 to input the rest of the numbers you want.
•You can input up to 12 digits for the number.
E-15
10. After inputting the name and number of the record, press A to store it and exit
the setting screen.
•The display can show only three name characters at a time. Longer names scrolls
continuously from right to left. The symbol “ ” indicates that the character to the
left is the last, and the character to the right is the first.
To recall Data Bank records
In the Data Bank Mode, use D (+) and B (–) to scroll through Data Bank records on
the display.
•Holding down B or D scrolls at high speed.
E-16
To edit a Data Bank record
1.
In the
Data Bank
Mode, scroll through the records and display the one you want to edit.
2. Hold down A until the cursor appears in the display.
3. Use C to move the cursor to the character you want to change.
4. Use D and B to change the character.
•See step 3 of “To input a new Data Bank record” for information on inputting name
characters, and step 7 for inputting number characters.
5. After making the changes that you want, press A to store them and exit the setting
screen.
To delete a Data Bank record
1. In the Data Bank Mode, scroll through the records and display the one you want to
delete.
2. Hold down A until the cursor appears in the display.
3. Press B and D at the same time. The message “CLR” appears in the display,
indicating that the record was deleted.
•After the record is deleted, the cursor appears in the name area, ready for input.
4. Input a new record or press A to exit the setting screen.
E-17
World Time
World Time shows the current time in 30 cities (29 time
zones) around the world.
•All of the operations in this section are performed in the
World Time Mode, which you enter by pressing C
(page E-4).
To view the time in another city code
In the World Time Mode, press D to scroll through city
codes (time zones) to the east or B to scroll to the west.
•For full information about city codes, see the “City Code
Table” at the back of this manual.
•If the current time shown for a city is wrong, check your
Timekeeping Mode time and Home City code settings
and make the necessary changes.
Current time in the zone
of the selected city code
City code
Mode indicator
E-18
Daylight Saving Time (DST) Setting
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
To toggle a city code time between Standard Time and Daylight Saving Time
1. In the World Time Mode, use B and D to display the
city code (time zone) whose Standard Time/Daylight
Saving Time setting you want to change.
2. Hold down A for about one second to toggle between
Daylight Saving Time (DST indicator displayed) and
Standard Time (DST indicator not displayed).
DST indicator
•The DST indicator will appear on the display whenever you display a city code for
which Daylight Saving Time is turned on.
•Note that the DST/Standard Time setting affects only the currently displayed city
code. Other city codes are not affected.
E-19
Day Counter
The Day Counter Mode lets you count the number of days
from the Timekeeping Mode’s current date to a specific
target date.
This watch has five day counters. You can assign text
titles up to eight characters long to each of the five Day
Counters. Whenever the date specified by any one of the
day counters matches the date of the Timekeeping Mode
(regardless of the day counter’s year setting), the DAYS
indicator flashes on the Timekeeping Mode screen. In the
Day Counter Mode, the DAYS indicator flashes on the
screen of the particular day counter whose date matches
the date of the Timekeeping Mode.
•The day counter on the display when you exit the Day
Counter Mode appears first the next time you enter the
Day Counter Mode.
Year – Month – Day
Target date
Text
DAYS indicator
Numbers of days
Mode indicator
Operation Guide 3189/3252
E-20
Recalling Day Counter Data
In the Day Counter Mode, use D (+) and B (–) to scroll through the day counters.
To set the target date
1. In the Day Counter Mode, use D (+) and B (–) to
display the day counter you want to set.
2. Hold down A until the flashing cursor appears in the
text area. This indicates the input screen.
3. Press C to move the flashing in the sequence shown
below.
1st digit
Day
8th digit
Year
Month
Press .
E-21
4. While the cursor is in the text area, use D and B to scroll through characters at
the current cursor position. Characters scroll in the sequence shown below. Holding
down D or B scrolls at high speed.
(Space) A to Z 0 to 9 . (Period) - (Hyphen)
Press .
Press .
5. While the cursor is in the date area, press D and B to scroll through digits at the
current cursor position. Holding down D or B scrolls at high speed.
•Press B and D at the same time, and the message “CLR” will appear in the
display. The characters in the text area are cleared and today’s date is set as the
target date. You then can make any changes in the date you want.
E-22
6. After you make the settings you want, press A to exit the input screen.
•The date can be set within the range of January 1, 1950 to December 31, 2049.
•The text area display can show only three characters at a time. Longer text scrolls
continuously from right to left. The symbol “ ” indicates that the character to the
left is the last, and the character to the right is first.
E-23
Alarms
You can set five independent Daily Alarms. When an
alarm is turned on, the alarm tone sounds when the alarm
time is reached.
You can turn on an Hourly Time Signal that causes the
watch to beep twice every hour on the hour.
•There are six screens in the Alarm Mode. Five are for
daily alarms (indicated by numbers from x1 through
x5), and one is for the Hourly Time Signal (indicated by
).
•All of the operations in this section are performed in the
Alarm Mode, which you enter by pressing C (page
E-5).
Alarm time
(Hour : Minutes)
Alarm number
Mode indicator
Alarm on
indicator
E-24
To set an alarm time
1. In the Alarm Mode, use D to scroll through the alarm screens until the one whose
time you want to set is displayed.
Alarm 2
Alarm 1
:00 (Hourly Time Signal)
Alarm 3
Alarm 5
Alarm 4
•To set a one-time alarm, display one of the screens indicated by an alarm number
from x1 through x5.
2. After you select an alarm, hold down A until the hour setting of the alarm time
starts to flash, which indicates the setting screen.
•This operation turns on the alarm automatically.
3. Press C to move the flashing between the hour and minute settings.
E-25
4. While a setting is flashing, use D (+) and B (–) to change it.
•When setting the alarm time using the 12-hour format, take care to set the time
correctly as a.m. (A indicator) or p.m. (P indicator).
5. Press A to exit the setting screen.
Alarm Operation
The alarm sounds at the preset time for about 10 seconds, regardless of the mode the
watch is in.
•To stop the alarm tone after it starts to sound, press any button.
To test the alarm
In the Alarm Mode, hold down D to sound the alarm.
E-26
To turn an alarm on and off
1. In the Alarm Mode, use D to select an alarm.
2. Press B to toggle it on (the alarm on indicator
displayed) and off (the alarm on indicator not
displayed).
•Turning on a daily alarm (x1 through x5) displays the
alarm on indicator on its Alarm Mode screen.
•In all modes, the alarm on indicator is shown for any
alarm that is currently turned on.
Alarm on indicator
E-27
To turn the Hourly Time Signal on and off
1. In the Alarm Mode, use D to select the Hourly Time
Signal ( ).
2. Press B to toggle it on (the hourly time signal on
indicator displayed) and off (the hourly time signal on
indicator not displayed).
•The Hourly Time Signal on indicator is shown on the
display in all modes while the Hourly Time Signal is
turned on.
Hourly time
signal on indicator
E-28
Stopwatch
The stopwatch lets you measure elapsed time, split times,
and two finishes.
•The display range of the stopwatch is 23 hours,
59 minutes, 59.99 seconds.
•The stopwatch continues to run, restarting from zero
after it reaches its limit, until you stop it.
•The stopwatch measurement operation continues even
if you exit the Stopwatch Mode.
•Exiting the Stopwatch Mode while a split time is frozen
on the display clears the split time and returns to
elapsed time measurement.
•All of the operations in this section are performed in the
Stopwatch Mode, which you enter by pressing C (page
E-5).
Mode indicator
Hours : Minutes
Seconds
1/100 second
E-29
Elapsed time measurement
Stop Re-start Stop Clear
Start
Start
Split
(SPL displayed)
Split release Stop Clear
Start Split Stop Split release Clear
Split time measurement
Split time and 1st-2nd place times
First runner
finishes.
Display time of
first runner.
Second runner
finishes.
Display time of
second runner.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | 3252 |
Behöver du hjälp?
Om du behöver hjälp med Casio 3252 ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
