Operation Guide 3408

E-1

About This Manual

•Depending on the model of your watch, display text

appears either as dark figures on a light background or

light figures on a dark background. All sample displays

in this manual are shown using dark figures on a light

background.

•Button operations are indicated using the letters shown

in the illustration.

•Note that the product illustrations in this manual are

intended for reference only, and so the actual product

may appear somewhat different than depicted by an

illustration.

E-2

•Each section of this manual provides you with the information you need to perform

operations in each mode. Further details and technical information can be found in

the “Reference” section.

E-3

Contents

General Guide ......................................................................................................... E-6

Timekeeping ............................................................................................................ E-8

Stopwatch ..............................................................................................................E-12

Recall Mode ...........................................................................................................E-21

Countdown Timer .................................................................................................. E-25

Alarms ....................................................................................................................E-29

Dual Time ............................................................................................................... E-36

Illumination ............................................................................................................E-38

Reference .............................................................................................................. E-42

Specifications ....................................................................................................... E-47

E-4

Procedure Lookup

The following is a handy reference list of all the operational procedures contained in

this manual.

To set the time and date ......................................................................................... E-8

To toggle between 12-hour and 24-hour timekeeping ....................................... E-10

To toggle the Timekeeping Mode between DST and Standard Time ................ E-11

To measure elapsed time ..................................................................................... E-15

To measure elapsed time with lap times ............................................................ E-15

To measure elapsed time with split times .......................................................... E-17

To time first and second place finishes .............................................................. E-18

To recall stopwatch time records ........................................................................ E-22

To delete a log ....................................................................................................... E-24

E-5

To use the countdown timer ................................................................................ E-26

To configure countdown start time and auto-repeat settings .......................... E-27

To set an alarm time ............................................................................................. E-31

To test the alarm ................................................................................................... E-33

To select the operation of Alarm

...................................................................... E-34

To turn Alarms

and

on and off ..................................................................... E-35

To turn the hourly time signal on and off ........................................................... E-35

To set the Dual Time ............................................................................................. E-36

To illuminate the display manually ...................................................................... E-38

To specify the illumination duration ................................................................... E-39

To turn the auto light switch on and off .............................................................. E-41

To turn the button operation tone on and off ..................................................... E-43

E-6

General Guide

•Press C to change from mode to mode.

•In any mode (except when a setting screen is on the display), press L to illuminate

the face of the watch.

Timekeeping Mode

Press .C

Stopwatch Mode

▲

E-7

Dual Time Mode

Countdown Timer Mode

Alarm Mode

Recall Mode

▲

E-8

Timekeeping

Use the Timekeeping Mode to set and view the current

time and date.

To set the time and date

1. In the Timekeeping Mode, hold down A until the

seconds start to flash, which indicates the setting

screen.

2. Press C to move the flashing in the sequence shown

below to select other settings.

Hour Minutes

Year

DST

Day Month

Seconds

PM indicator

Minutes

Seconds

Month – DayDay of week

Hours

Seconds E-9

3. When the setting you want to change is flashing, use D B and to change it as

described below.

Screen: To do this:

Reset the seconds to 00

Toggle between Daylight Saving

Time ( ON) and Standard Time (OF)

Change the hour or minutes

Change the year

Change the month or day

Do this:

Press D.

Use D (+) and B (–).

4. Press A to exit the setting screen.

•The day of the week is displayed automatically in accordance with the date (year,

month, and day) settings.

•See “Daylight Saving Time (DST) Setting” below for details about the DST setting.

Operation Guide 3408

E-10

To toggle between 12-hour and 24-hour timekeeping

In the Timekeeping Mode, press D to toggle between 12-hour timekeeping and 24-

hour timekeeping.

•With the 12-hour format, the P (PM) indicator appears to the left of the hour digits for

times in the range of noon to 11:59 p.m. and the A (AM) indicator appears to the left

of the hour digits for times in the range of midnight to 11:59 a.m.

•With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without

any indicator.

•The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is

applied in all other modes.

•The A and P indicators are not displayed with the Timekeeping Mode time on the

Countdown Timer Mode and Dual Time Mode screens.

Daylight Saving Time (DST) Setting

Daylight Saving Time (summer time) advances the time setting by one hour from

Standard Time. Remember that not all countries or even local areas use Daylight

Saving Time.

E-11

To toggle the Timekeeping Mode between DST and Standard Time

1. In the Timekeeping Mode, hold down A until the

seconds start to flash, which indicates the setting

screen.

2. Press once and the DST setting screen appears.C

3. Press D to toggle between Daylight Saving Time (ON

displayed) and Standard Time ( displayed).OF

4. Press to exit the setting screen.A

•The DST indicator appears on the Timekeeping and

Alarm Mode screens to indicate that Daylight Saving

Time is turned on.

DST indicator

On/Off status

E-12

Stopwatch

The stopwatch lets you measure elapsed time, lap times,

split times, and two finishes. Lap times and split times can

be stored in memory.

•The display range of the stopwatch is 99 hours,

59 minutes, 59 seconds.

•All of the operations in this section are performed in the

Stopwatch Mode, which you enter by pressing C (page

E-6).

Note

•“Lap time” is the time spent to cover a specific segment

of a race, such as one lap around a track. “Split time” is

the time spent from the beginning of a race up to a

certain point.

•The stopwatch continues to run, restarting from zero

after it reaches its limit, until you stop it.

Minutes Seconds

1/100

secondHours

Remaining

free records

E-13

•The stopwatch measurement operation continues even if you exit the Stopwatch

Mode.

•For information about how stopwatch times are stored in memory, see “Memory

Management” (page E-19).

Viewing the Stopwatch Displays

The information that appears in the watch’s upper and lower displays depends on

whether you are measuring lap times or split times.

Lap Time Measurement

Upper Display: Lap time

Lower Display: Elapsed time

Split Time Measurement

Upper Display: Lap time

Lower Display: Elapsed time (Split time appears here for eight seconds as it is stored

in memory.)

•See “To measure elapsed time with lap times” (page E-15) and “To measure elapsed

time with split times” (page E-17) for more information about each type of measurement.

E-14

•You can perform elapsed time measurement starting from either the lap time screen

or the split time screen (pages E-15 and E-17). Whenever you enter the Stopwatch

Mode, the screen (lap time or split time) that was displayed when you last exited the

mode will appear first.

•During a stopwatch elapsed time operation, the upper display initially shows

minutes, seconds, and a 1/100-second value. This changes to hours, minutes, and

seconds when the time in the upper display exceeds 60 minutes.

•The lower display initially shows hours, minutes, seconds, and a 1/100-second

value. This changes to hours, minutes, and seconds when the time in the lower

display exceeds 10 hours.

▲

More than 10 hours

More than one hour

Minutes

Seconds

1/100 second Hours

Minutes

Seconds

Hours

Minutes

Seconds

1/100 second

Hours

Minutes

Seconds

E-15

To measure elapsed time

Note

•You can perform the following steps starting from either the lap time screen or the

split time screen.

1. Press D to start the stopwatch.

2. Press D again to stop the stopwatch.

•You can resume the measurement operation by pressing D.

3. Press B to clear the stopwatch to all zeros.

To measure elapsed time with lap times

When the stopwatch display shows all zeros, press

to display the lap time screen (indicated by LAP/ ).

2. Press D to start an elapsed time measurement.

•At the time, both the upper and lower displays will

show identical times.

3. Press B to record the time of the first lap.

E-16

•This freezes the current lap time in the upper part of

the display for about eight seconds, while

measurement of total elapsed time and the next lap

time continue internally. The lap number of the

displayed time appears in the lower display.

•After eight seconds, the ongoing elapsed time

measurement re-appears in the lower display.

4. Repeat step 3 to record more lap times.

5. Press D to stop the stopwatch.

6. Press B to clear the stopwatch to all zeros.

•Lap numbers are incremented automatically starting

from whenever you press in step 3 of the above1B

procedure. The maximum lap number is 99. Recording

a lap after that causes the lap number count to restart

from .00

Lap number

Elapsed time

Lap time

E-17

To measure elapsed time with split times

1. When the stopwatch display shows all zeros, press B

to display the split time screen (indicated by SPL/ ).

2. Press D to start an elapsed time measurement.

•At the time, both the upper and lower displays will

show identical times.

3. Press B to record the time of the first split.

•The current split time appears in the lower display for

about eight seconds, as the total elapsed time, next

lap time, and next split time continue to be timed

internally by the watch. The split number of the

displayed time appears in the upper display.

•After eight seconds, the ongoing lap time

measurement appears in the upper display and the

ongoing elapsed time measurement appears in the

lower display.

4. Repeat step 3 to record more split times.

5. Press D to stop the stopwatch.

6. Press B to clear the stopwatch to all zeros.

Split time

Split number

Split Time Recording

(Displayed for eight seconds

after B is pressed.)

Lap time

Elapsed time

E-18

•Split numbers are incremented automatically starting from 1 whenever you press B

in step 3 of the above procedure. The maximum split number is 99. Recording a split

time after that causes the split number count to restart from 00.

To time first and second place finishes

1. When the stopwatch display shows all zeros, press B to display the split time

screen (indicated by SPL/ ).

2. Press D to start a time measurement.

3. Press B when the first finisher crosses the finish line.

•This freezes the time of the first finisher in the lower part of the display for about

eight seconds. After that, the display returns to elapsed time measurement.

4. Press D when the second finisher crosses the finish line.

•The second finisher’s time will appear in the lower display.

•The difference between the first finisher’s and the second finisher’s time will

appear in the upper display.

5. Press B to clear the stopwatch to all zeros.

E-19

Memory Management

A new log is created each time you press D in the Stopwatch Mode to start a new

elapsed time measurement operation. A log contains a log title screen, and records of

all the lap or split times you record during the current elapsed time measurement

operation.

•The capacity of the watch’s memory is 60 records.

•If you are adding records to the only log in memory and watch memory becomes

full, adding another record causes the oldest record in the log to be deleted

automatically to make room for the new record.

•If you are adding records to a log when there are multiple logs in memory and watch

memory becomes full, adding another record causes the oldest log in memory and

all of its records to be deleted automatically to make room for new records.

Operation Guide 3408

E-20

Stopwatch Button

Operation

From all-zeros, press

D to start.

Press B to display

lap/split time.

Press to stopD

elapsed time

measurement and then

press B to reset.

Data Storage Description

Creates a new log. Stores the date the button was

pressed, and the new log number.

Creates a new record with each button operation. Stores

the lap and split times and total elapsed time at each point

the button is pressed.

Resets the elapsed time to all zeros without recording

How stopwatch data is stored

The following table shows how stopwatch data is stored when you perform stopwatch

button operations.

•See “Recall Mode” (page E-21) for details on how to recall time records from

memory.

E-21

Recall Mode

Use the Recall Mode to recall and delete logs and records

you stored in the Stopwatch Mode. You can use the Recall

Mode to view both lap and split time records.

•When you enter the Recall Mode, the newest log

recorded in the Stopwatch Mode will appear first. If there

are no logs in memory, xxxxxxxxxxxxxxxxxxxx appears on the display.

•You can use the Recall Mode to check memory data

even while a stopwatch elapsed time measurement

operation is in progress. However, the time data that is

currently being measured will not appear in the Recall

Mode.

•You can convert a lap time saved in the Stopwatch

Mode to a split time (page E-22).

Day of week

Month – Day

Log number

Log Title Screen

E-22

To recall stopwatch time records

1. In the Stopwatch Mode, check to make sure that the displays reset to all zeros

(page E-15).

•If all zeros are not displayed, reset the stopwatch.

2. Use the A button to select either the lap time screen (to view lap time records) or

the split time screen (to view split time records) (pages E-15 and E-17).

•To convert a lap time saved in the Stopwatch Mode to a split time, select the split

time screen.

3. Press the C button to enter the Recall Mode.

4. Use the A button to scroll through the log title screens from the newest to the

oldest until the title screen of the log whose records you want to view is displayed.

5. Press D to scroll through the records contained in the log you selected in step 4,

from the oldest to the newest.

E-23

•Whether you will be able to view lap time records or split time records will depend on

the screen you selected in step 2, above.

Press D.

▲

Lap number

Split number

Log number

Log Title Screen

First record Last record

▲

Lap time

Split time

▲

E-24

To delete a log

1. In the Recall Mode, display the title screen of the log you want to delete.

2. Hold down B and D until CLR stops flashing on the display.

•This deletes the log and all the records inside it.

•Deleting a single log slides all newer logs (ones with higher log numbers) upwards to

fill the empty space. This cause the log numbers of all the newer logs to be reduced

by 1. If there are six logs currently in memory (numbered 01 through 06) and you

delete log 03, the numbers of logs that previously were numbered 04, 05, and 06 will

change to 03, 04, and 05.

E-25

Countdown Timer

You can set the countdown timer within a range of one

minute to 24 hours. An alarm sounds when the countdown

reaches zero.

•You also can select auto-repeat, which automatically

restarts the countdown from the original value you set

whenever zero is reached.

•All of the operations in this section are performed in the

Countdown Timer Mode, which you enter by pressing

C (page E-7).

SecondsHours

Minutes

Timekeeping

Mode time

Auto-repeat

on indicator

E-26

To use the countdown timer

Press while in the Countdown Timer Mode to start the countdown timer.D

•When the end of the countdown is reached and auto-repeat is turned off, the alarm

sounds for 10 seconds or until you stop it by pressing any button. The countdown

time is reset automatically to its starting value after the alarm stops.

•When auto-repeat is turned on, the countdown will restart automatically without

pausing when it reaches zero. The alarm sounds when the countdown reaches zero.

•The countdown timer measurement operation continues even if you exit the

Countdown Timer Mode.

•Press D while a countdown operation is in progress to pause it. Press again toD

resume the countdown.

•To stop a countdown operation completely, first pause it (by pressing D), and then

press B. This returns the countdown time to its starting value.

E-27

To configure countdown start time and auto-repeat settings

1. While the countdown start time is on the display in the

Countdown Timer Mode, hold down A until the hour

setting of the countdown start time starts to flash, which

indicates the setting screen.

•If the countdown start time is not displayed, use the

procedure under “To use the countdown timer” (page

E-26) to display it.

2. Press C to move the flashing in the sequence shown

below, and select the setting you want to change.

Start Time

(Minutes)

Auto-Repeat

On/Off

Start Time

(Hours)

On/Off status

Auto-repeat on indicator

E-28

3. Perform the following operations, depending on which setting currently is selected

on the display.

•While the start time setting is flashing, use D B (+) and (–) to change it.

•Set 0:00 to specify 24 hours.

•While the auto-repeat on/off setting (0N or 0F) is flashing on the display, press

D to toggle auto-repeat on (0N) and off (0F).

4. Press A to exit the setting screen.

•The auto-repeat on indicator ( ) is displayed on the Countdown Timer Mode

screen while this function is turned on.

•Frequent use of auto-repeat and the alarm can run down battery power.

E-29

Alarms

You can set up to three independent multi-function alarms

with hour, minutes, month, and day. When an alarm is

turned on, the alarm tone sounds when the alarm time is

reached. One of the alarms can be configured as a

snooze alarm or a one-time alarm, while the other two are

one-time alarms.

You also can turn on an Hourly Time Signal that causes

the watch to beep twice every hour on the hour.

•There are three alarm screens numbered 1 3 through .

The hourly time signal screen is indicated by :00.

•All of the operations in this section are performed in the

Alarm Mode, which you enter by pressing C (page E-7).

Alarm time

(Hour : Minutes)

Alarm number

Alarm date

(Month – Day)

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	Baby-G BG-6903-7BER
Färg på produkten:	Wit
Husmaterial:	Kunststof
Internationell säkerhetskod (IP):	IP65
Typ av förpackning:	Doos
Processorfrekvens:	560 MHz
Frekvensband:	5.15 - 5.85 GHz
Typ av strömkälla:	Power over Ethernet (PoE)
Medföljande kablar:	AC
Certifiering:	CE, FCC
Internminne:	64 MB
Internminnestyp:	DDR2
Hållbarhetscertifikat:	RoHS
Typ processor:	Ja
Antal per paket:	1 stuk(s)
Inspänning:	24 V
Kabelteknik:	10/100Base-T(X)
Nätverksstandard:	IEEE 802.11a, IEEE 802.11n
Typ av antenn:	Richtantenne
Antennförstärkningsnivå (max):	27 dBi
Förvaringstemperatur:	-40 - 70 °C
Förvaringsfuktighet:	5 - 95 procent
Flashminne:	8 MB
Drifttemperatur (TT):	-40 - 70 °C
Relativ luftfuktighet i drift (VV):	10 - 90 procent
H-plan (3 dB strålbredd):	9 °
E-plan (3 dB strålbredd):	7 °
Antennförstärkning (5 GHz):	23 dBi
