Sida 1/14

Operation Guide 3189/3252

E-2

Procedure Lookup

The following is a handy reference list of all the operational procedures contained in

this manual.

To set the time and date ......................................................................................... E-7

To input a new Data Bank record ........................................................................ E-12

To recall Data Bank records ................................................................................ E-15

To edit a Data Bank record .................................................................................. E-16

To delete a Data Bank record .............................................................................. E-16

To view the time in another city code ................................................................. E-17

To toggle a city code time between Standard Time and

Daylight Saving Time ........................................................................................ E-18

MA1012-EA

About This Manual

•Depending on the model of your watch, display text

appears either as dark figures on a light background or

light figures on a dark background. All sample displays

in this manual are shown using dark figures on a light

background.

•Button operations are indicated using the letters shown

in the illustration.

•Each section of this manual provides you with the

information you need to perform operations in each

mode. Further details and technical information can be

found in the “Reference” section.

E-1

Contents

General Guide ......................................................................................................... E-4

Timekeeping ............................................................................................................ E-6

Data Bank .............................................................................................................. E-11

World Time ............................................................................................................ E-17

Day Counter .......................................................................................................... E-19

Alarms .................................................................................................................... E-23

Stopwatch .............................................................................................................. E-28

Countdown Timer ................................................................................................. E-30

Reference .............................................................................................................. E-32

Specifications ....................................................................................................... E-35

E-3

To set the target date ............................................................................................ E-20

To set an alarm time ............................................................................................. E-24

To test the alarm ................................................................................................... E-25

To turn an alarm on and off ................................................................................. E-26

To turn the Hourly Time Signal on and off ......................................................... E-27

To use the countdown timer ................................................................................ E-30

To set the countdown start time .......................................................................... E-31

To turn the button operation tone on and off ..................................................... E-32

E-4

General Guide

•Press C to change from mode to mode.

•Pressing L in any mode illuminates the display.

Timekeeping Mode World Time ModeData Bank Mode

Press .

E-5

•If you do not perform any operation for a few minutes while a setting screen (with

flashing digits) is on the display, the watch exits the setting screen automatically.

•If you do not perform any operation for a few minutes in the Alarm Mode, Day

Counter Mode, or Data Bank Mode, the watch reverts to the normal timekeeping

screen automatically.

Countdown

Timer Mode

Alarm Mode Stopwatch ModeDay Counter Mode

E-6

Timekeeping

Use the Timekeeping Mode to set and view the current

time and date.

•Pressing A in the Timekeeping Mode will display the

currently selected Home City.

•Press to toggle between 12-hour and 24-hourD

formats.

•With 12-hour format, times between midnight and noon

are indicated by A (am), while times between noon and

midnight are indicated by P (pm).

•The and A P indicators do not appear when you are

using 24-hour format.

Year

Day of week

Seconds

Month – Day

Hour

PM indicator

Minutes

E-7

To set the time and date

1. While in the Timekeeping Mode, hold down A until the second’s digits flash on the

display, which indicates the setting screen.

2. Press C to move the flashing in the sequence shown below.

DSTSeconds

MonthDay

City code

Minutes

Year

Hour

E-8

3. While the seconds setting is selected (flashing), press D to reset it to 00. If you

press D while the seconds setting is in the range of 30 to 59, the seconds are

reset to 00 and 1 is added to the minutes. If the seconds setting is in the range of

00 to 29, the minutes count is unchanged.

•While the DST* setting is selected (DST on indicator is flashing), press D to

toggle it on ( ) and off (On OF).

•The DST on/off setting you select for the Timekeeping Mode affects the World

Time Mode.

•While the city code setting is selected, use D B and to scroll through the

available codes until the one you want to use as your home time city is displayed.

•For full information on city codes, see the “City Code Table” at the back of this

manual.

4. While any other setting is selected (flashing), press D B to increase it or press to

decrease it. Holding down D or B scrolls at high speed.

5. Press A to exit the setting screen.

•The day of the week is set in accordance with the date automatically.

•The date can be set within the range of January 1, 2000 to December 31, 2099.

E-9

•The watch’s built-in full automatic calendar makes allowances for different month

lengths and leap years automatically. Once you set the date, there should be no

reason to change it except after replacement of the watch’s battery.

* See “Daylight Saving Time (DST) Setting” (page E-18) for details about the DST

setting.

Operation Guide 3189/3252

E-10

Backlight Precautions

The backlight uses an EL (electro-luminescent) panel that causes the entire display to

glow for easy reading in the dark.

In any mode, press L to illuminate the display for about two seconds.

•The electro-luminescent panel that provides illumination loses power after very long

use.

•The illumination provided by the backlight may be hard to see when viewed under

direct sunlight.

•The watch may emit an audible sound whenever the display is illuminated. This is

due to vibration of the EL panel used for illumination, and does not indicate

malfunction.

•The backlight turns off automatically whenever an alarm sounds.

•Frequent use of the backlight shortens the battery life.

E-11

Data Bank

Mode indicator Name area

Remainin

free records Number area

Alternate at

the 1-second

interval.

The Data Bank Mode lets you store up to 25 records, each with a name (up to eight

characters) and a phone number (up to 12 digits). Entering the Data Bank Mode displays

a screen that shows the mode name (DB) and remaining memory capacity (number of

records) for a few moments. After that, the record you were viewing the last time you

exited the Data Bank Mode will appear. Anytime you input a new record, all records will

be sorted automatically into alphabetic sequence on the name.*

* A to Z, 0 to 9, symbols (, or -)

E-12

To input a new Data Bank record

1. In the Data Bank Mode, use D (+) and B (–) to scroll through the Data Bank

records and display the one you want to input data.

2. Hold down A until a cursor appears on the name area.

3. Use D and B to scroll through characters at the current cursor position.

Characters scroll in the sequence shown below.

(Space) A to Z 0 to 9 (Period) . - (Hyphen)

Press .

• Holding down D B or scrolls at high speed.

E-13

4. When the character you want is at the current cursor position, press C to move the

cursor to the right.

1st digit 8th digit

12th digit 1st digit

Name area

Number area

Press .

5. Repeat the steps 3 and 4 to input the rest of the characters.

•You can input up to eight characters for the name, though only three characters

are visible at a time.

•If the name you input has fewer than eight characters, use C to move the cursor

to the eighth space (which means you would press three times after inputtingC

a five-character name).

6. After you input the name, use C to move the cursor to the number area.

•Pressing C while the cursor is located at the eighth character of the name area

advances to the number area. Pressing while the cursor is located at the 12thC

digit of the number area returns to the name area.

E-14

7. Use D and B to scroll through characters (hyphen, numbers, space) at the

current cursor position on the number area. Characters scroll in the sequence

shown below.

(Space)

0 to 9 - (Hyphen)

Press .

•Holding down D B or scrolls characters at high speed.

8. When the character you want is at the cursor position, press C to move the cursor

to the right.

9. Repeat steps 7 and 8 to input the rest of the numbers you want.

•You can input up to 12 digits for the number.

E-15

10. After inputting the name and number of the record, press A to store it and exit

the setting screen.

•The display can show only three name characters at a time. Longer names scrolls

continuously from right to left. The symbol “ ” indicates that the character to the

left is the last, and the character to the right is the first.

To recall Data Bank records

In the Data Bank Mode, use (+) and (–) to scroll through Data Bank records onD B

the display.

•Holding down B D or scrolls at high speed.

E-16

To edit a Data Bank record

In the

Data Bank

Mode, scroll through the records and display the one you want to edit.

2. Hold down A until the cursor appears in the display.

3. Use C to move the cursor to the character you want to change.

4. Use D and B to change the character.

•See step 3 of “To input a new Data Bank record” for information on inputting name

characters, and step 7 for inputting number characters.

5. After making the changes that you want, press A to store them and exit the setting

screen.

To delete a Data Bank record

1. In the Data Bank Mode, scroll through the records and display the one you want to

delete.

2. Hold down A until the cursor appears in the display.

3. Press B and D at the same time. The message “CLR” appears in the display,

indicating that the record was deleted.

•After the record is deleted, the cursor appears in the name area, ready for input.

4. Input a new record or press A to exit the setting screen.

E-17

World Time

World Time shows the current time in 30 cities (29 time

zones) around the world.

•All of the operations in this section are performed in the

World Time Mode, which you enter by pressing C

(page E-4).

To view the time in another city code

In the World Time Mode, press to scroll through cityD

codes (time zones) to the east or to scroll to the west.B

•For full information about city codes, see the “City Code

Table” at the back of this manual.

•If the current time shown for a city is wrong, check your

Timekeeping Mode time and Home City code settings

and make the necessary changes.

Current time in the zone

of the selected city code

City code

Mode indicator

E-18

Daylight Saving Time (DST) Setting

Daylight Saving Time (summer time) advances the time setting by one hour from

Standard Time. Remember that not all countries or even local areas use Daylight

Saving Time.

To toggle a city code time between Standard Time and Daylight Saving Time

1. In the World Time Mode, use B and D to display the

city code (time zone) whose Standard Time/Daylight

Saving Time setting you want to change.

2. Hold down A for about one second to toggle between

Daylight Saving Time ( indicator displayed) andDST

Standard Time (DST indicator not displayed).

DST indicator

•The DST indicator will appear on the display whenever you display a city code for

which Daylight Saving Time is turned on.

•Note that the DST/Standard Time setting affects only the currently displayed city

code. Other city codes are not affected.

E-19

Day Counter

The Day Counter Mode lets you count the number of days

from the Timekeeping Mode’s current date to a specific

target date.

This watch has five day counters. You can assign text

titles up to eight characters long to each of the five Day

Counters. Whenever the date specified by any one of the

day counters matches the date of the Timekeeping Mode

(regardless of the day counter’s year setting), the DAYS

indicator flashes on the Timekeeping Mode screen. In the

Day Counter Mode, the DAYS indicator flashes on the

screen of the particular day counter whose date matches

the date of the Timekeeping Mode.

•The day counter on the display when you exit the Day

Counter Mode appears first the next time you enter the

Day Counter Mode.

Year – Month – Day

Target date

Text

DAYS indicator

Numbers of days

Mode indicator

Operation Guide 3189/3252

E-20

Recalling Day Counter Data

In the Day Counter Mode, use (+) and (–) to scroll through the day counters.D B

To set the target date

1. In the Day Counter Mode, use D (+) and B (–) to

display the day counter you want to set.

2. Hold down A until the flashing cursor appears in the

text area. This indicates the input screen.

3. Press C to move the flashing in the sequence shown

below.

1st digit

Day

8th digit

YearMonth

Press .

E-21

4. While the cursor is in the text area, use D B and to scroll through characters at

the current cursor position. Characters scroll in the sequence shown below. Holding

down D or B scrolls at high speed.

(Space) A to Z 0 to 9 (Period) . - (Hyphen)

Press .

5. While the cursor is in the date area, press D B and to scroll through digits at the

current cursor position. Holding down scrolls at high speed.D or B

•Press B and D at the same time, and the message “CLR” will appear in the

display. The characters in the text area are cleared and today’s date is set as the

target date. You then can make any changes in the date you want.

E-22

6. After you make the settings you want, press A to exit the input screen.

•The date can be set within the range of January 1, 1950 to December 31, 2049.

•The text area display can show only three characters at a time. Longer text scrolls

continuously from right to left. The symbol “ ” indicates that the character to the

left is the last, and the character to the right is first.

E-23

Alarms

You can set five independent Daily Alarms. When an

alarm is turned on, the alarm tone sounds when the alarm

time is reached.

You can turn on an Hourly Time Signal that causes the

watch to beep twice every hour on the hour.

•There are six screens in the Alarm Mode. Five are for

daily alarms (indicated by numbers from

x1 through

x5), and one is for the Hourly Time Signal (indicated by

•All of the operations in this section are performed in the

Alarm Mode, which you enter by pressing (pageC

E-5).

Alarm time

(Hour : Minutes)

Alarm number

Mode indicator

Alarm on

indicator

E-24

To set an alarm time

1. In the Alarm Mode, use D to scroll through the alarm screens until the one whose

time you want to set is displayed.

Alarm 2Alarm 1

:00 (Hourly Time Signal)

Alarm 3

Alarm 5

Alarm 4

•To set a one-time alarm, display one of the screens indicated by an alarm number

from x1 through x5.

2. After you select an alarm, hold down A until the hour setting of the alarm time

starts to flash, which indicates the setting screen.

•This operation turns on the alarm automatically.

3. Press C to move the flashing between the hour and minute settings.

E-25

4. While a setting is flashing, use D B (+) and (–) to change it.

•When setting the alarm time using the 12-hour format, take care to set the time

correctly as a.m. ( indicator) or p.m. (A P indicator).

5. Press A to exit the setting screen.

Alarm Operation

The alarm sounds at the preset time for about 10 seconds, regardless of the mode the

watch is in.

•To stop the alarm tone after it starts to sound, press any button.

To test the alarm

In the Alarm Mode, hold down to sound the alarm.D

E-26

To turn an alarm on and off

1. In the Alarm Mode, use D to select an alarm.

2. Press B to toggle it on (the alarm on indicator

displayed) and off (the alarm on indicator not

displayed).

•Turning on a daily alarm (

x1 through x5

) displays the

alarm on indicator on its Alarm Mode screen.

•In all modes, the alarm on indicator is shown for any

alarm that is currently turned on.

Alarm on indicator

E-27

To turn the Hourly Time Signal on and off

1. In the Alarm Mode, use D to select the Hourly Time

Signal ( ).

2. Press B to toggle it on (the hourly time signal on

indicator displayed) and off (the hourly time signal on

indicator not displayed).

•The Hourly Time Signal on indicator is shown on the

display in all modes while the Hourly Time Signal is

turned on.

Hourly time

signal on indicator

E-28

Stopwatch

The stopwatch lets you measure elapsed time, split times,

and two finishes.

•The display range of the stopwatch is 23 hours,

59 minutes, 59.99 seconds.

•The stopwatch continues to run, restarting from zero

after it reaches its limit, until you stop it.

•The stopwatch measurement operation continues even

if you exit the Stopwatch Mode.

•Exiting the Stopwatch Mode while a split time is frozen

on the display clears the split time and returns to

elapsed time measurement.

•All of the operations in this section are performed in the

Stopwatch Mode, which you enter by pressing (pageC

E-5).

Mode indicator

Hours : Minutes

Seconds

1/100 second

E-29

Elapsed time measurement

Stop Re-start Stop Clear

Start

Split

( displayed)SPL

Split release Stop Clear

Start Split Stop Split release Clear

Split time measurement

Split time and 1st-2nd place times

First runner

finishes.

Display time of

first runner.

Second runner

finishes.

Display time of

second runner.

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	Baby-G BG169R-4
Färg på produkten:	Black, Red
Vikt:	135 g
Bredd:	117 mm
Djup:	62.6 mm
Höjd:	37.3 mm
Sladdlängd:	1.8 m
Förpackningens bredd:	120 mm
Djuppackning:	45 mm
Förpackningshöjd:	200 mm
Kraftkälla:	Kabel
Instruktioner:	Ja
Typ av förpackning:	Doos
Vormfaktor:	Ambidextrous
Avsedd för:	Gamen
Ergonomisk design:	Ja
siffra:	1
Rekommenderad användning:	PC/notebook
Förvaringstemperatur:	-15 - 60 °C
Antal knappar:	8
Förbindelse:	USB Type-A
Förvaringsfuktighet:	0 - 85 procent
Ytfärg:	Monochromatisch
Rulla typ:	Wiel
Rörelseupplösning:	3500 DPI
Typ av knappar:	Drukknoppen
Rörelsedetekteringsteknik:	Laser
Skrolla:	Ja
Antal scrollhjul:	1
Drifttemperatur (TT):	0 - 45 °C
Relativ luftfuktighet i drift (VV):	0 - 85 procent
Exponering:	Ja
Programmerbara musknappar:	Ja
Justerbar rörelseupplösning:	Ja
Antal rörelseupplösningslägen:	4
