Operation Guide 5510

E-9

To set the digital time and date

1. In the Timekeeping Mode, hold down A until the

seconds start to flash, which indicates the setting

screen.

2. Press C to move the flashing in the sequence shown

below to select other settings.

Seconds

Day

DST Hour

Month

Minutes

Year

Seconds

E-8

Timekeeping

Use the Timekeeping Mode to set and view the current

time and date. This watch features separate digital and

analog timekeeping. The procedures for setting the digital

time (page E-9) and analog time (page E-13) are different.

Setting the Digital Time and Date

Use the Timekeeping Mode to set and view a digital

display of the current time and date. When setting the

digital time, you also can configure settings for the

summer time (Daylight Saving Time or DST).

PM indicator

Minutes

Seconds

Month – Day

Day of week

Hours

E-7

Recall Mode

Dual Time Mode

Countdown Timer

Mode

Alarm Mode

E-6

General Guide

• Press C to change from mode to mode.

• In any mode (except when a setting screen is on the display), press

B to illuminate

the face of the watch.

Stopwatch Mode

Hand Setting Mode

Timekeeping Mode C

E-5

Illumination ……………………………………………………………………………E-41

To illuminate the display manually ……………………………………………E-41

To specify the illumination duration……………………………………………E-42

To turn the auto light switch on and off ………………………………………E-44

Reference ………………………………………………………………………………E-45

To turn the button operation tone on and off …………………………………E-46

Specifications …………………………………………………………………………E-51

E-4

Recall Mode ……………………………………………………………………………E-24

To recall stopwatch time records………………………………………………E-25

To delete a log …………………………………………………………………E-27

Countdown Timer………………………………………………………………………E-28

To use the countdown timer ……………………………………………………E-29

To configure countdown start time and auto-repeat settings ………………E-30

Alarms ……………………………………………………………………………………E-32

To set an alarm time ……………………………………………………………E-34

To test the alarm ………………………………………………………………E-36

To select the operation of Alarm ……………………………………………E-37

To turn Alarms and on and off ……………………………………………E-38

To turn the hourly time signal on and off ……………………………………E-38

Dual Time ………………………………………………………………………………E-39

To set the Dual Time ……………………………………………………………E-39

E-3

Contents

General Guide ………………………………………………………………………… E-6

Timekeeping …………………………………………………………………………… E-8

To set the digital time and date ……………………………………………… E-9

To toggle between 12-hour and 24-hour timekeeping ………………………E-11

To toggle the Timekeeping Mode digital time between DST and

Standard Time ………………………………………………………………E-12

To adjust the analog time ………………………………………………………E-13

Stopwatch ………………………………………………………………………………E-15

To measure elapsed time ………………………………………………………E-18

To measure elapsed time with lap times ……………………………………E-19

To measure elapsed time with split times ……………………………………E-20

E-2

• Each section of this manual provides you with the information you need to perform

operations in each mode. Further details and technical information can be found in

the “Reference” section.

E-1

About This Manual

• Button operations are indicated using the letters shown

in the illustration.

• Depending on the model of your watch, display text

appears either as dark figures on a light background, or

light figures on a dark background. All sample displays

in this manual are shown using dark figures on a light

background.

• Note that the product illustrations in this manual are

intended for reference only, and so the actual product

may appear somewhat different than depicted by an

illustration.

Operation Guide 5510

E-19

To measure elapsed time with lap times

1. When the stopwatch display shows all zeros, press

A to display the lap time screen (indicated by /LAP).

2. Press D to start an elapsed time measurement.

• At the time, both the upper and lower displays will

show identical times.

3. Press A to record the time of the first lap.

• This freezes the current lap time in the upper part of

the digital display for about eight seconds, while

measurement of total elapsed time and the next lap

time continue internally. The lap number of the

displayed time appears in the lower digital display.

• After eight seconds, the ongoing elapsed time

measurement re-appears in the lower digital display.

4. Repeat step 3 to record more lap times.

5. Press D to stop the stopwatch.

Lap time

Elapsed time

E-18

More than 10 hours

More than one hour

Minutes

Seconds

1/100 second Hours

Minutes

Seconds

Minutes

Hours

Seconds

1/100 second Hours

Minutes

Seconds

To measure elapsed time

Note

• You can perform the following steps starting from either the lap time screen or the

split time screen.

1. Press D to start the stopwatch.

2. Press D again to stop the stopwatch.

• You can resume the measurement operation by pressing D

3. Press A to clear the stopwatch to all zeros.

E-17

• See “To measure elapsed time with lap times” (page E-19) and “To measure elapsed

time with split times” (page E-20) for more information about each type of measurement.

• You can perform elapsed time measurement starting from either the lap time screen

or the split time screen (page E-19 and E-20). Whenever you enter the Stopwatch Mode,

the screen (lap time or split time) that was displayed when you last exited the mode

will appear first.

• During a stopwatch elapsed time operation, the upper display initially shows

minutes, seconds, and a 1/100-second value. This changes to hours, minutes, and

seconds when the time in the upper display exceeds 60 minutes.

• The lower display initially shows hours, minutes, seconds, and a 1/100-second

value. This changes to hours, minutes, and seconds when the time in the lower

display exceeds 10 hours.

E-16

• The stopwatch measurement operation continues even if you exit the Stopwatch

Mode.

• For information about how stopwatch times are stored in memory, see “Memory

Management” (page E-22).

Viewing the Stopwatch Digital Displays

The information that appears in the watch’s upper and lower digital displays depends

on whether you are measuring lap times or split times.

Lap Time Measurement

Upper Display: Lap time

Lower Display: Elapsed time

Split Time Measurement

Upper Display: Lap time

Lower Display: Elapsed time (Split time appears here for eight seconds as it is stored

in memory.)

E-15

Stopwatch

The stopwatch lets you measure elapsed time, lap times,

and split times. Lap times and split times can be stored in

memory.

• The display range of the stopwatch is 99 hours,

59 minutes, 59 seconds.

• All of the operations in this section are performed in the

Stopwatch Mode, which you enter by pressing

(page E-6).

Note

• “Lap time” is the time spent to cover a specific segment

of a race, such as one lap around a track. “Split time” is

the time spent from the beginning of a race up to a

certain point.

• The stopwatch continues to run, restarting from zero

after it reaches its limit, until you stop it.

Minutes

Seconds

1/100

second

Hours

Remaining

free records

E-14

• High-speed hand movement will stop automatically after the time advances 12

hours or if an alarm (daily alarm, Hourly Time Signal, or countdown beeper) starts

to sound.

4. Press A to exit the setting screen.

• The minute hand will be adjusted slightly to match the seconds when you exit the

setting screen.

• To return to the Timekeeping Mode, press

E-13

Setting the Analog Time

Perform the procedure below when the time indicated by the analog hands does not

match the time of the digital display.

To adjust the analog time

1. In the Timekeeping Mode, press C six times to enter

the Hand Setting Mode (page E-6).

2. Hold down A until the current digital time starts to

flash, which indicates the setting screen.

3. Use D to adjust the analog setting.

• Press D once to advance the hands 20 seconds.

• Hold down D to advance the hands at high speed.

• To lock high speed hands movement, hold down D to start it and then press B

to lock. The hands will continue to advance for one 12-hour cycle or until you

press any button to stop them.

E-12

Daylight Saving Time (DST) Setting

Daylight Saving Time (summer time) advances the time setting by one hour from

Standard Time. Remember that not all countries or even local areas use Daylight

Saving Time.

To toggle the Timekeeping Mode digital time between DST and Standard Time

1. In the Timekeeping Mode, hold down A until the

seconds start to flash, which indicates the setting

screen.

2. Press C once and the DST setting screen appears.

3. Press D to toggle between Daylight Saving Time (

displayed) and Standard Time ( displayed).

4. Press A to exit the setting screen.

• The DST

indicator appears on the Timekeeping,

Alarm, and Hand Setting Mode screens to indicate

that Daylight Saving Time is turned on.

On/Off status

DST indicator

E-11

4. Press A to exit the setting screen.

• The day of the week is displayed automatically in accordance with the date

(year, month, and day) settings.

• See “Daylight Saving Time (DST) Setting” below for details about the DST setting.

To toggle between 12-hour and 24-hour timekeeping

In the Timekeeping Mode, press D to toggle between 12-hour timekeeping and

24-hour timekeeping.

• With the 12-hour format, the P (PM) indicator appears to the left of the hour digits

for times in the range of noon to 11:59 p.m. and the A (AM) indicator appears to the

left of the hour digits for times in the range of midnight to 11:59 a.m.

• With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without

any indicator.

• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is

applied in all other modes.

• The A and P indicators are not displayed with the Timekeeping Mode time on the

Countdown Timer Mode and Dual Time Mode screens.

E-10

3. When the setting you want to change is flashing, use D and B to change it as

described below.

Screen: To do this: Do this:

Reset the seconds to Press D.

Toggle between Daylight Saving Time

( ) and Standard Time ( ) Press D.

Change the hour or minute Use

D (+) and B (–).

Change the year, month, or day Use

D (+) and B (–).

Operation Guide 5510

E-29

To use the countdown timer

Press D while in the Countdown Timer Mode to start the countdown timer.

• When the end of the countdown is reached and auto-repeat is turned off, the alarm

sounds for 10 seconds or until you stop it by pressing any button. The countdown

time is reset automatically to its starting value after the alarm stops.

• When auto-repeat is turned on, the countdown will restart automatically without

pausing when it reaches zero. The alarm sounds when the countdown reaches

zero.

• The countdown timer measurement operation continues even if you exit the

Countdown Timer Mode.

• Press D while a countdown operation is in progress to pause it. Press D again to

resume the countdown.

• To stop a countdown operation completely, first pause it (by pressing D), and then

press A. This returns the countdown time to its starting value.

E-28

Countdown Timer

You can set the countdown timer within a range of one

minute to 24 hours. An alarm sounds when the countdown

reaches zero.

• You also can select auto-repeat, which automatically

restarts the countdown from the original value you set

whenever zero is reached.

• All of the operations in this section are performed in the

Countdown Timer Mode, which you enter by pressing

C (page E-7).

Seconds

Hours

Minutes

Timekeeping Mode time

Auto-repeat

on indicator

E-27

To delete a log

1. In the Recall Mode, display the title screen of the log you want to delete.

2. Hold down B and D until stops flashing on the display.

• This deletes the log and all the records inside it.

• Deleting a single log slides all newer logs (ones with higher log numbers)

upwards to fill the empty space. This cause the log numbers of all the newer logs

to be reduced by 1. If there are six logs currently in memory (numbered 01

through ) and you delete log , the numbers of logs that previously were 06 03

numbered , , and will change to , , and .04 05 06 03 04 05

E-26

Press D.

Lap number

Split number

Log number

Log Title Screen

First record Last record

Lap time

Split time

• Whether you will be able to view lap time records or split time records will depend

on the screen you selected in step 2, above.

E-25

To recall stopwatch time records

1. In the Stopwatch Mode, check to make sure that the displays are reset to all zeros

(page E-19).

• If all zeros are not displayed, reset the stopwatch.

2. Use the A button to select either the lap time screen (to view lap time records) or

the split time screen (to view split time records) (page E-19 and E-20).

• To convert a lap time saved in the Stopwatch Mode to a split time, select the split

time screen.

3. Press the C button to enter the Recall Mode.

4. Use the A button to scroll through the log title screens from the newest to the

oldest until the title screen of the log whose records you want to view is displayed.

5. Press D to scroll through the records contained in the log you selected in step 4,

from the oldest to the newest.

E-24

Recall Mode

Use the Recall Mode to recall and delete logs and records

you stored in the Stopwatch Mode. You can use the

Recall Mode to view both lap and split time records.

• When you enter the Recall Mode, the newest log

recorded in the Stopwatch Mode will appear first. If

there are no logs in memory, appears on the

display.

• You can use the Recall Mode to check memory data

even while a stopwatch elapsed time measurement

operation is in progress. However, the time data that is

currently being measured will not appear in the Recall

Mode.

• You can convert a lap time saved in the Stopwatch

Mode to a split time (page E-25).

Day of week

Month – Day

Log number

Log Title Screen

E-23

How stopwatch data is stored

The following table shows how stopwatch data is stored when you perform stopwatch

button operations.

Stopwatch Button Operation Data Storage Description

From all-zeros, press D to start. Creates a new log. Stores the date the button was

pressed, and the new log number.

Press A to display lap/split time.

Creates a new record with each button operation. Stores

the lap and split times and total elapsed time at each

point the button is pressed.

Press D to stop elapsed time

measurrement and then press

to reset.

Resets the elapsed time to all zeros without recording

data.

• See “Recall Mode” (page E-24) for details on how to recall time records from memory.

E-22

Memory Management

A new log is created each time you press D in the Stopwatch Mode to start a new

elapsed time measurement operation. A log contains a log title screen, and records of

all the lap or split times you record during the current elapsed time measurement

operation.

• The capacity of the watch’s memory is 60 records.

• If you are adding records to the only log in memory and watch memory becomes

full, adding another record causes the oldest record in the log to be deleted

automatically to make room for the new record.

• If you are adding records to a log when there are multiple logs in memory and

watch memory becomes full, adding another record causes the oldest log in

memory and all of its records to be deleted automatically to make room for new

records.

E-21

3. Press A to record the time of the first split.

• The current split time appears in the lower display for

about eight seconds, as the total elapsed time, next

lap time, and next split time continue to be timed

internally by the watch. The split number of the

displayed time appears in the upper display.

• After eight seconds, the ongoing lap time

measurement appears in the upper display and the

ongoing elapsed time measurement appears in the

lower display.

4. Repeat step 3 to record more split times.

5. Press D to stop the stopwatch.

6. Press A to clear the stopwatch to all zeros.

• Split numbers are incremented automatically starting from whenever you press 1

A in step 3 of the above procedure. The maximum split number is . 99

Recording a split time after that causes the split number count to restart from .00

Split time

Split number

Split Time Recording

(Displayed for eight

seconds after

A is pressed.)

E-20

6. Press A to clear the stopwatch to all zeros.

• Lap numbers are incremented automatically starting

from 1 whenever you press A in step 3 of the above

procedure. The maximum lap number is

99.

Recording a lap after that causes the lap number

count to restart from 00.

To measure elapsed time with split times

1. When the stopwatch display shows all zeros, press A

to display the split time screen (indicated by /SPL).

2. Press D to start an elapsed time measurement.

• At the time, both the upper and lower displays will

show identical times.

Lap time

Lap number

Lap time

Elapsed time

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	Baby-G BGA-240BC-4AER
Färg på produkten:	Grijs
Vikt:	119 g
Bredd:	155 mm
Djup:	60 mm
Höjd:	172 mm
Förpackningens vikt:	308 g
Förpackningens bredd:	175 mm
Djuppackning:	68 mm
Förpackningshöjd:	232 mm
Laddare:	Ja
Typ av förpackning:	Blister
Automatisk avstängning:	Ja
Kontinuerlig ljuduppspelningstid:	8 uur
Anslutningsteknik:	Draadloos
Frekvensband:	2.4 GHz
Snabbstartsguide:	Ja
Bärmetod:	Hoofdband
Rekommenderad användning:	Oproepen/muziek
Typ av headset:	Stereofonisch
Impedans:	- Ohm
Placera högtalare hörlurar:	Circumaural
Hörlurars frekvensområde:	20 - 20000 Hz
Anslutningsområde:	10 m
Mikrofontyp:	Ingebouwd
Stöder Mac-operativsystem:	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Batteriladdningsindikering:	Ja
Reseväska:	Ja
Mikrofonfrekvens:	- Hz
Typ produkt:	Headset
Batteriteknik:	Lithium
RF-anslutning:	Ja
