Sida 1/9

Operation Guide 5520

E-9

Illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-69

To illuminate the face . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-69

To change the illumination duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-69

Adjusting Hand Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-71

To adjust hand alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-72

Button Operation Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-74

To turn the button operation tone on and off . . . . . . . . . . . . . . . . . . . . . . . . . E-74

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-75

Main Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-78

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-79

Operating Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-83

E-8

To perform a countdown timer operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-60

To stop the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-60

Using the Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-61

To enter the Alarm Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-61

To set an alarm time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-61

To test the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-62

To turn an alarm and the Hourly Time Signal on and off . . . . . . . . . . . . . . . . . E-63

To stop the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-64

Dual Time Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-65

To enter the Dual Time Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-65

To set the Dual Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-65

To swap Timekeeping Mode and Dual Time Mode times . . . . . . . . . . . . . . . . E-67

E-7

To specify a daily step goal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-33

To check your step count history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-36

To reset the daily step goal attainment day count . . . . . . . . . . . . . . . . . . . . . . E-48

To turn Step Reminder on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-50

To clear the flashing “ ” notification . . . . . . . . . . . . . . . . . . . . . . . . . . . E-51STEP!!

Using the Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-52

To enter the Stopwatch Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-53

To perform an elapsed time operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-53

To perform lap time measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-54

To recall lap data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-56

Countdown Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-58

To enter the Countdown Timer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-58

To configure the countdown timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-59

E-6

Contents

About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-3

Mode Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-11

Timekeeping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-17

Adjusting the Digital Time and Date Settings . . . . . . . . . . . . . . . . . . . . . . . . .E-18

To configure the digital time and date settings . . . . . . . . . . . . . . . . . . . . . . . . E-18

To change the Daylight Saving Time (summer time) setting . . . . . . . . . . . . . . E-22

Pedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-23

To check step count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-28

To reset today’s step count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-31

E-5

◆

Stopwatch ..................... Page E-52

Use the stopwatch to measure elapsed

times and lap times. Memory for up to

30 lap time records.

◆

Timer .............................. Page E-58

The timer counts down from a preset

start time. An alarm sounds when the

end of the countdown is reached.

◆

Alarm .............................. Page E-61

When the alarm time is reached, the

watch sounds an alert.

◆

Dual time ....................... Page E-65

You can view the current time in your

current location and in one more time

zone.

E-4

◆ Step count data storage

........................................ Page E-35

x Today’s and past seven day’s daily

data

x This week’s and past three week’s

weekly data

x Count of the days you attained your

daily step count goal (GOAL)

◆ Step count attainment

notification

........................................ Page E-35

A GOAL indicator flashes when you

attain your daily step goal. Your step

goal progress is also displayed (Step

goal progress).

E-3

Features

Your watch provides you with the features and functions described below.

◆

Pedometer .................... Page E-23

Count the steps you

take.

◆

Over-sitting prevention

........................................ Page E-49

A Step Reminder displays an indicator

and sounds an alert whenever the

watch determines that you have not

walked for a specific amount of time.

This helps to ensure that you are

getting enough exercise on a regular

basis.

E-2

About This Manual

Depending on the model of your watch, display text

appears either as dark figures on a light background, or

light figures on a dark background. All sample displays

in this manual are shown using dark figures on a light

background.

Button operations are indicated using the letters shown

in the illustration.

Note that the product illustrations in this manual are

intended for reference only, and so the actual product

may appear somewhat different than depicted by an

illustration.

E-1

ENGLISH

Congratulations upon your selection of this CASIO watch.

To ensure that this watch provides you with the years of service for which it is

designed, carefully read and follow the instructions in this manual, especially the

information under “Operating Precautions” and “User Maintenance”.

Be sure to keep all user documentation handy for future reference.

Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any

damage or loss suffered by you or any third party arising through the use of your

watch or its malfunction.

Operation Guide 5520

E-19

2. Press to move the flashing in the sequence shown below to select the other C

settings.

Seconds

CDST

(page E-22)

12/24-Hour Format

Hour

C C

Illumination Duration

(page E-69) Minutes

C C

Button Operation Tone On/Off

(page E-74) CDay CMonth CYear

E-18

Adjusting the Digital Time and Date Settings

Use the procedure below to adjust the digital time and date settings.

To configure the digital time and date settings

1. In the Timekeeping Mode, hold down until the A

seconds digits start to flash (about two seconds).

x This enables setting of the seconds.

E-17

Timekeeping

Use the Timekeeping Mode to set and view the current

time and date.

Each press of A cycles the digital display contents as

shown below.

Date, day of

the week

Date, step count

graph Steps

Hour, minute,

second

AAA

PM indicator

Hour

Minutes

Day of the week

Month-Day

Seconds

E-16

2. Holding down again as you press will cause the hands to return to their B C

normal positions (normal timekeeping).

Note

This operation can be performed in any mode. In the case of a setting mode

(setting flashing on the screen), the hour and minute hands will move out of the

way, and the second hand will move to 12 o’clock automatically even if you do not

perform the above operation.

Watch button functions are the same regardless of whether the hands are move

out of the way or at their normal positions.

Changing to another mode will cause the hands to move back to their normal

positions.

The hands also will move back to their normal positions automatically if no

operation is performed for about one hour.

E-15

Moving the Hands Out of the Way for Better Viewing

You can use the procedure below to temporarily move the hour and minute hands

out of the way to better view what is on the display.

1. While holding down , press B C.

The watch will beep twice and the hour and minute hands will move to a position

where they do not block the digital display.

Example: When the current time is 8:25

Flashes while the hands are

moved out of the way.

E-14

General Functions (All Modes)

The functions and operations described in this section can be used in all of the

modes.

x Auto Return Features

If you leave a screen with flashing digits on the display for two or three minutes

without performing any operation, the watch automatically exits the setting screen.

The watch will automatically return to the Timekeeping Mode if you do not perform

any operation for a certain amount of time, as described below.

Mode Approximate Elapsed Time

Alarm 3 minutes

Step count history screen 2 minutes

x Scrolling

The and buttons are used on the setting mode to scroll through data on the B D

display. In most cases, holding down these buttons during a scroll operation scrolls

through the data at high speed.

E-13

Countdown Timer Mode Alarm Mode Dual Time Mode

C C

E-12

Selecting a Mode

Press C to cycle between the modes as shown below.

To return to the Timekeeping Mode from any other mode, hold down C for about

two seconds.

In any mode (except a setting mode), press to illuminate the display.B

Timekeeping Mode Stopwatch Mode

C C

E-11

Mode Reference Guide

The mode you should select depends on what you want to do.

To do this: Enter this mode: See:

View the current time and date

Configure daylight saving time (DST) settings

Configure time and date settings

Record or view your step count with the pedometer

Daily step goal and step reminder settings

Timekeeping Mode E-17

E-23

x Measure elapsed time

x Record lap times (up to 30) Stopwatch Mode E-52

Use the countdown timer Countdown Timer Mode E-58

x Set an alarm time

To turn an alarm or the hourly time signal on or off

Alarm Mode E-61

xDisplay a second time

xConfigure settings for a second time Dual Time Mode E-65

E-10

User Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-94

Operation Guide 5520

E-29

STEPS mark

Step count Hour, minute, second

E-28

Checking Step Count

To check step count

1. In the Timekeeping Mode, use to cycle through step count information as A

shown below.

A A

Timekeeping Mode

Date, day of the Week

Date, step count graph

E-27

While you are walking, the step indicators alternately flash on the display at

one-second intervals. Both step indicators are displayed without flashing while you

are not moving, and both indicators are cleared from the display while the sensor is

stopped, in order to conserve battery power.

Step indicators

E-26

Pedometer Details

Step Count

The step counter can count from 0 to 999,999 steps. If the step count exceeds

999,999, the maximum value (999,999) remains on the display.

The step count is not displayed at the beginning of a walk in order to avoid

miscounting of non-walking movements. It appears only after you have continued

walking for about 10 seconds, with the number of steps you took during that time

added to the total.

The step count is automatically reset to zero at midnight each day.

You can also manually reset the daily step count that is displayed in the

Timekeeping Mode. Note that doing so does not reset the daily step count on the

history screen. This makes the displayed step count zero and counts steps from

there. This comes in handy when you want to count the number of steps between

twopoints. See “To reset today’s step count” (page E-31).

E-25

Normal daily non-walking activities (cleaning, etc.)

Wearing the watch on your dominant hand

Walking for less than 10 seconds

Watch hand movement (by the hand shift function, etc.)

Power Saving

To save power, sensor operation stops automatically if there is no movement

detected by the watch and you do not perform any operation for two to three

minutes.

E-24

Important!

If the band is loose, the pedometer will count steps, but step count accuracy may

be reduced.

If you are experiencing problems getting relatively accurate step counts

Any of the conditions below may make proper measurement impossible.

Wearing slippers, sandals, or other footwear that encourages a shuffling gait

Walking on tile, carpeting, snow, or other surface that causes a shuffling gait

Irregular walking (in a crowded location, in a line where walking stops and starts at

short intervals, etc.)

x Extremely slow walking or extremely fast running

x Pushing a shopping cart or baby stroller

In a location where there is a lot of vibration, or riding in a car or other vehicle

Frequent movement of the hand or arm (clapping, fanning movement, etc.)

Walking while holding hands, walking with a cane or stick, or engaging in any other

movement in which your hand and leg movements are not coordinated with each

other.

E-23

Pedometer

The watch has a built-in 3-axis accelerometer that counts the steps you take.

You can specify a daily step goal and keep track of your step goal progress.

A Step Reminder function helps to keep you from sitting too much.

Pedometer Precautions

While the watch is on your wrist, the pedometer may detect non-step movements

and count them as steps. Also, abnormal arm movements while walking may

cause a miss count of steps.

Wearing the Watch

OK NG To ensure proper step count measurement,

wear the watch as shown in the illustration

nearby.

Wear the watch on your wrist, with the band

tightened securely.

E-22

To change the Daylight Saving Time (summer time) setting

1. In the Timekeeping Mode, hold down until the A

seconds digits start to flash (about two seconds).

x This enables setting of the seconds.

2. Press to display the DST setting mode.C

3. Press to toggle between Daylight Saving Time (DON)

and Standard Time ( ).OFF

4. After the setting is the way you want, press to A

return to the Timekeeping Mode.

The indicator appears to indicate that DaylightDST

Saving Time is turned on.

Note

Daylight Saving Time (summer time) advances the time setting by one hour from

Standard Time. Remember that not all countries or even local areas use Daylight

Saving Time.

DST indicator

E-21

Note

Resetting the seconds to 00 while the current count is in the range of 30 to 59

causes the minutes to be increased by 1.

The watch’s built-in full automatic calendar makes allowances for different month

lengths and leap years. Once you set the date, there should be no reason to

change it except after you have the watch’s battery replaced.

The day of the week changes automatically when the date changes.

While the 12-hour format is selected for timekeeping, a (PM) indicator will appearP

for times from noon to 11:59 p.m. No indicator appears for times from midnight to

11:59 a.m. With 24-hour format, time is displayed from 0:00 to 23:59, without any

P (PM) indicator.

E-20

3. When the timekeeping setting you want to change is flashing, use and/or D B

to change it as described below.

Screen To do this: Do this:

Reset the seconds to 00 Press D.

Toggle between 12-hour ( ) and 24-hour 12H

(24H) timekeeping Press D.

Change the hour or minute Use (+) and (–).D B

Change the year Use (+) and (–).D B

Change the month or day Use (+) and (–).D B

4. Press to exit the setting mode.A

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	Baby-G BGS-100SC-1AER
Färg på produkten:	Zwart
Bredd:	294 mm
Djup:	180 mm
Höjd:	44 mm
Förpackningens bredd:	400 mm
Djuppackning:	250 mm
Förpackningshöjd:	80 mm
Strömförsörjning:	100 - 240V, 50/60Hz
Kraftkälla:	AC
LED-indikatorer:	Ja
Instruktioner:	Ja
Typ av förpackning:	Doos
Anslutningsteknik:	Bedraad
Medföljande kablar:	AC
Strömförbrukning (max):	9.26 W
Certifiering:	FCC, CE, RoHs
Nätverksstandard:	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Förvaringstemperatur:	-40 - 70 °C
Nätverksprotokoll som stöds:	CSMA/CD, TCP/IP
Förvaringsfuktighet:	5 - 90 procent
Rackmontering:	Ja
Nätverksfunktioner:	Gigabit Ethernet
Drifttemperaturens omfång:	32 - 104 °F
Strömförsörjning ingår:	Ja
Auto MDI/MDI-X:	Ja
Power over Ethernet (PoE):	Nee
Stapelbar:	Ja
Max. överföringshastighet:	1 Gbit/s
Dataöverföringshastigheter som stöds:	10/100 Mbps
Växlingskapacitet:	32 Gbit/s
MAC-ställbar:	8000 entries
10G-stöd:	Nee
Dataflödeshantering:	Ja
Växlingstyp:	Unmanaged
Antal grundläggande switchande RJ-45 Ethernet-portar:	16
Antal Gigabit Ethernet (koppar) portar:	16
Nätkontakt:	DC-in ingang
Mått (B x D x H):	294 x 180 x 44 mm
Bandbreedte:	32 Gbit/s
Typ grundläggande switchande RJ-45 Ethernet-portar:	Gigabit Ethernet (10/100/1000)
Stöd för Jumbo Frames:	Ja
Full duplex:	Ja
Koppar Ethernet-kabelteknik:	10BASE-T, 100BASE-TX, 1000BASE-TX, 1000BASE-T
Värmeavledning:	31.6 BTU/h
Automatisk förhandling:	Ja
AC-ingångsspänning:	220 V
AC-ingångsfrekvens:	50 Hz
Drifttemperatur (TT):	0 - 40 °C
Relativ luftfuktighet i drift (VV):	10 - 90 procent
Harmoniserad systemkod (HS):	85176990
Anslutningslysdioder:	Ja
Frakthastighet:	23.8 Mpps
Jumbo ramar:	10000
Lagra och vidarebefordra:	Ja
Kabeltyper som stöds:	Cat3, Cat4, Cat5, Cat5e
