Operation Guide 5381/5482

E-9

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-61

Main Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-63

Speciﬁ cations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-64

Operating Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-67

User Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-78

E-8

Using the Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-52

To set an alarm time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-52

To test the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-53

To turn an alarm and the Hourly Time Signal on and off . . . . . . . . . . . . . . . . . E-54

To stop the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-54

Illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-55

To turn on illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-55

To change the Illumination Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-55

Adjusting Hand Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-57

To adjust hand positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-57

Button Operation Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-59

To turn the button operation tone on and off . . . . . . . . . . . . . . . . . . . . . . . . . E-59

E-7

Using the Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-46

To enter the Stopwatch Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-46

To perform an elapsed time operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-47

To pause at a split time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-47

To measure two ﬁ nishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-47

Countdown Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-49

To enter the Countdown Timer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-49

To conﬁ gure the countdown timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-50

To perform a countdown timer operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-51

To stop the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-51

E-6

Thermometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-25

To take a temperature reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-25

To switch a temperature reading unit between Celsius (°C) and

Fahrenheit (°F) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-26

Checking Tide Levels and Moon Ages (Tide/Moon) . . . . . . . . . . . . . . . . . . . . E-31

Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-41

Checking the Current Time in a Different Time Zone . . . . . . . . . . . . . . . . . . . E-42

To enter the World Time Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-43

To view the time in another time zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-43

To specify standard time or daylight saving time (DST) for a city . . . . . . . . . . . E-44

To swap your Home City and World Time City . . . . . . . . . . . . . . . . . . . . . . . . E-45

E-5

Contents

About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-3

Things to check before using the watch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-4

Mode Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-10

Timekeeping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-17

Conﬁ guring Home City Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-18

To conﬁ gure Home City settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-18

To change the Daylight Saving Time (summer time) setting . . . . . . . . . . . . . . E-20

Adjusting the Current Time and Date Settings . . . . . . . . . . . . . . . . . . . . . . . . E-21

To conﬁ gure the digital time and date settings . . . . . . . . . . . . . . . . . . . . . . . . E-21

E-4

Things to check before using the watch

1. Check the Home City and the daylight saving time (DST) setting.

Use the procedure under “To conﬁ gure Home City settings” (page E-18) to conﬁ gure

your Home City and daylight saving time settings.

Important!

x Proper World Time Mode data depend on correct Home City, time, and date

settings in the Timekeeping Mode. Make sure you configure these settings

correctly.

2. Set the current time.

x See “Adjusting the Current Time and Date Settings” (page E-21).

The watch is now ready for use.

E-3

About This Manual

x The operational procedures for Modules 5381 and 5482 are identical. All of the

illustrations in this manual show Module 5381.

x Depending on the model of your watch, display text appears either as dark ﬁ gures

on a light background, or light ﬁ gures on a dark background. All sample displays in

this manual are shown using dark ﬁ gures on a light background.

x Button operations are indicated using the letters shown in the illustration.

x Note that the product illustrations in this manual are intended for reference only,

and so the actual product may appear somewhat different than depicted by an

illustration.

Module 5381 Module 5482

E-2

Warning!

x The measurement functions built into this watch are not intended for taking

measurements that require professional or industrial precision. Values produced

by this watch should be considered as reasonable representations only.

x Note that the tide and Moon data calculated by this watch are approximate and

are intended as general information only. Never try to use it for marine navigation

or any other purposes requiring accurate measurements.

x Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any

damage or loss suffered by you or any third party arising through the use of your

watch or its malfunction.

E-1

ENGLISH

Congratulations upon your selection of this CASIO watch.

To ensure that this watch provides you with the years of service for which it is

designed, carefully read and follow the instructions in this manual, especially the

information under “Operating Precautions” and “User Maintenance”.

Be sure to keep all user documentation handy for future reference.

Operation Guide 5381/5482

E-19

3. After the setting is the way you want, press to return to the Timekeeping A

Mode.

Note

x After you specify a city code, the watch will use UTC* offsets in the World Time

Mode to calculate the current time for other time zones based on the current time

in your Home City.

* Coordinated Universal Time, the world-wide scientiﬁ c standard of timekeeping.

The reference point for UTC is Greenwich, England.

E-18

Conﬁ guring Home City Settings

There are two Home City settings: actually selecting the Home City, and selecting

either standard time or daylight saving time (DST).

To conﬁ gure Home City settings

1. In the Timekeeping Mode, hold down until AADJ

appears.

x This indicates the city code setting mode.

x The hour and minute hands automatically move out of

the way at this time (page E-15).

2. Press (East) and (West) to select the city codeD B

you want to use as your Home City.

x Keep pressing or until the city code you wantD B

to select as your Home City appears on the display.

x For details about city codes, see the “City Code

Table” at the back of this manual.

City Code

E-17

Timekeeping

Use the Timekeeping Mode to set and view the current

time and date.

x Each press of A cycles the digital display contents as

shown below.

Month-Day Day of the Week Seconds Hour : Minutes

AAA

PM indicator

Hour

Month-Day

Minutes

Tide indicator

(Page E-32)

E-16

2. Holding down again as you press will cause the hands to return to their B C

normal positions (normal timekeeping).

Note

x This operation can be performed in any mode. In the case of a setting mode

(setting ﬂ ashing on the screen), the hands will move out of the way automatically,

even if you do not perform the above operation.

x Watch button functions are the same regardless of whether the hands are move

out of the way or at their normal positions.

x Changing to another mode will cause the hands to move back to their normal

positions.

x The hands also will move back to their normal positions automatically if no

operation is performed for about one hour.

E-15

Moving the Hands Out of the Way for Better Viewing

You can use the procedure below to temporarily move the hour and minute hands

out of the way to better view what is on the display.

1. While holding down , press B C.

x This will cause the hour and minute hands to move to a location where they do

not block your view of the tide indicator and/or digital display.

Example: When the current time is 8:20

Flashes while the hands are moved out of the way.

E-14

General Functions (All Modes)

The functions and operations described in this section can be used in all of the

modes.

x Auto Return Features

The watch will automatically return to the Timekeeping Mode if you do not perform

any operation for a certain amount of time, as described below.

Mode Approximate Elapsed Time

Thermometer, Alarm, Tide/Moon

2 to 3 minutes

Time or other setting mode

(information ﬂ ashing on the display)

Tide Change After the tide change indication process is complete

x Scrolling

The and buttons are used on the setting mode to scroll through data on the B D

display. In most cases, holding down these buttons during a scroll operation scrolls

through the data at high speed.

E-13

Stopwatch Mode

Countdown Timer

Mode

World Time Mode

Alarm Mode

Counter Mode Tide/Moon Mode

C C

CCC

E-12

Selecting a Mode

x Press C to cycle between the modes as shown below.

x To return to the Timekeeping Mode from any other mode, hold down C for about

two seconds.

x In any mode (except a setting mode), press to illuminate the display.B

Timekeeping Mode

Thermometer

Mode

Tide Change

Mode

* The mode that appears ﬁ rst is the one that was selected when you last used the Thermometer

or Tide Change mode.

E-11

To do this: Enter this mode: See:

Use the stopwatch to measure elapsed time Stopwatch Mode E-46

Use the countdown timer Countdown Timer Mode E-49

Set an alarm time Alarm Mode E-52

E-10

Mode Reference Guide

The mode you should select depends on what you want to do.

To do this: Enter this mode: See:

x View the current date in the Home City

x Conﬁ gure Home City and daylight saving time (DST)

settings

x Conﬁ gure time and date settings

x View the current tide level

Timekeeping Mode E-17

Take temperature readings Thermometer Mode E-25

View tide changes over the next 12 hours Tide Change Mode E-33

Count objects Counter Mode E-41

View tide level and moon age for a speciﬁ ed date

and time Tide/Moon Mode E-35

View the current time in one of 48 cities

(31 time zones) around the globe World Time Mode E-42

Operation Guide 5381/5482

E-29

1. Enter the Thermometer Mode (page E-12).

2. Hold down for at least two seconds until the temperature A

value disappears from the display.

x When you release the temperature value will start to ﬂA ash.

x The hour and minute hands automatically move out of the way at

this time (page E-15).

3. Use (+) and (–) to calibrate the temperature value.D B

Calibration unit: 0.1°C (or 0.2°F)

Calibration range: –10.0 to 60.0°C (or 14.0 to 140.0°F)

Important!

x To cancel a temperature reading correction setting, hold down and at theD B

same time. The watch will beep.

4. Press to return to the Thermometer Mode.A

E-28

Correcting the Temperature Reading

The temperature sensor of this watch is adjusted at the factory and so further

adjustment is not required by you. However, if you notice that the readings

produced by the watch are different from readings produced by another instrument,

you can use the procedure in this section to make corrections. You also can use

this procedure to clear a correction.

Important!

x The watch will not be able to produce correct temperature readings if you make a

mistake during the correction procedure. Check to make sure that the value you

use for correction produces correct temperature readings.

x Before performing the following procedure, remove the watch from your wrist and

leave it for about 20 or 30 minutes to allow the case temperature to become the

same as the air temperature.

E-27

3. Press C.

x This will cause the current measurement

unit to ﬂ ash.

4. Use to select the measurement unit you D

want.

5. Press to return to the Thermometer Mode.A

Important!

x When ( ) is selected as the Home City, the temperature unit is setTYO TOKYO

automatically to Celsius (°C). These settings cannot be changed.

E-26

Measurement unit: 0.1°C (or 0.2°F)

Measurement range*: –10.0 to 60.0°C (or 14.0 to 140.0°F)

* - -.- is displayed in place of the temperature when reading is outside the allowable

range.

2. Press to return to the Timekeeping Mode.C

To switch a temperature reading unit between Celsius (°C) and Fahrenheit (°F)

1. Enter the Thermometer Mode (page E-12).

2. Hold down for at least two seconds until the temperature value disappears A

from the display.

x When you release the temperature value will start to ﬂA ash.

x The hour and minute hands automatically move out of the way at this time (page

E-15).

E-25

Thermometer

This watch uses a temperature sensor to take temperature readings.

x You can select either Celsius (°C) or Fahrenheit (°F) as the temperature

measurement unit (page E-26).

To take a temperature reading

1. In the Timekeeping Mode, press . This will enter theD

Thermometer Mode, which is indicated by on TEMP

the display.

x If does not appear when you press TEMP D, press

it again (page E-12).

x The temperature reading will appear about one

second after TEMP.

x The reading is updated at ﬁ ve-second intervals for two

to three minutes. After that, the watch automatically

returns to the Timekeeping Mode.

Temperature

E-24

Note

x Resetting the seconds to 00 while the current count is in the range of 30 to 59

causes the minutes to be increased by 1.

x The watch’s built-in full automatic calendar makes allowances for different month

lengths and leap years. Once you set the date, there should be no reason to

change it except after you have the watch’s battery replaced.

x The day of the week changes automatically when the date changes.

E-23

3. When the timekeeping setting you want to change is ﬂ ashing, use D and/or B

to change it as described below.

Screen To do this: Do this:

Toggle between 12-hour ( ) and 24-hour 12H

(24H) timekeeping Press D.

Reset the seconds to 00 Press D.

Change the hour or minute Use (+) and (–).D B

Change the year Use (+) and (–).D B

Change the month or day Use (+) and (–).D B

4. Press to exit the setting mode.A

E-22

2. Press to move the ﬂ ashing in the sequence shown below to select the other C

settings.

City Code

(page E-18)

CDST

(page E-20)

12/24-Hour Format

Seconds

CHour

Illumination Duration

(page E-55) Minutes

C C

Button Operation Tone On/Off

(page E-59) C

Day

Month

Year

E-21

Adjusting the Current Time and Date Settings

Use the procedure below to adjust the digital time and date settings.

Changing the digital time should cause the analog time setting to change

accordingly.

To conﬁ gure the digital time and date settings

1. In the Timekeeping Mode, hold down until AADJ

appears.

x This indicates the city code setting mode.

x The hour and minute hands automatically move out of

the way at this time (page E-15).

E-20

To change the Daylight Saving Time (summer time) setting

1. In the Timekeeping Mode, hold down until AADJ

appears.

x This indicates the city code setting mode.

x The hour and minute hands automatically move out of

the way at this time (page E-15).

2. Press to display the DST setting mode.C

3. Press to toggle between Daylight Saving Time (DON)

and Standard Time ( ).OFF

x Note that you cannot switch between daylight saving

time and standard time while UTC is selected as your

Home City.

4. After the setting is the way you want, press to A

return to the Timekeeping Mode.

x The indicator appears to indicate that DaylightDST

Saving Time is turned on.

DST indicator

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	BGA-180-4B
Bredd:	170 mm
Djup:	170 mm
Blåtand:	Nee
Wi-Fi-standarder:	Niet ondersteund
Grafikadapter:	HD Graphics
Ethernet LAN:	Ja
Maximal upplösning:	2048 x 1536 Pixels
Typ av strömkälla:	ATX
Medföljande kablar:	SATA
Antal USB 2.0-portar:	4
VGA (D-Sub) port(ar):	1
Antal HDMI-portar:	1
Mikrofon, linjeingång:	Ja
Antal Ethernet LAN (RJ-45)-portar:	1
Hörlursutgångar:	5
Certifiering:	FCC, CE, WHQL, ErP/EuP Ready
HDCP:	Ja
HDMI-version:	1.4a
DVI-D-portar:	1
Antal portar USB 3.2 Gen 1 (3.1 Gen 1) Typ A:	2
Processoruttag:	LGA 1155 (Socket H2)
Systembuss:	5 GT/s
PCI Express-kortplatsversion:	3.0
PCI Express-konfigurationer:	1x16
Processorfabrikant:	Intel
Maximalt internminne:	16 GB
Inbyggd grafikadapter:	Ja
Kompatibla operativsystem:	Windows 7, Vista, XP 32/64-bit
Ljudutgångskanaler:	7.1 kanalen
Nätverksfunktioner:	Gigabit LAN
Snabbinstallationsguide:	Ja
ETC:	Nee
Ethernet-gränssnittstyp:	Gigabit Ethernet
Chipset moderkort:	Intel B75
Typ av minnesplats:	DIMM
Ljudchip:	Realtek ALC892
Medföljande drivrutiner:	Ja
PCI Express x16-platser:	1
Grafikkortsfamilj:	Intel
S/PDIF-utgång:	Ja
Typ av kylning:	Passief
Minneskanal:	Dubbelkanaals
Gränssnitt för lagringsenheter som stöds:	SATA II, SATA III
PS/2-port(ar):	1
Komponent för:	PC
Minnesspänning:	1.5 V
LAN-kontroller:	Realtek RTL8111E
Maximalt minne grafikadapter:	1760 MB
OpenGL version:	3.2
DirectX version:	11
Antal SATA III-kontakter:	1
Icke-ECC:	Ja
Vakna på LAN:	Ja
Kompatibla processorer:	Intel Core i3, Intel Core i5, Intel Core i7
Antal eSATA-portar:	1
Minnestyper som stöds:	DDR3-SDRAM
Max. antal SMP-processorer:	1
Wifi:	Nee
Moderkort chipset familj:	Intel
Moderkorts formfaktor:	mini ITX
Antal minnesplatser:	2
Minnesklockhastigheter som stöds:	1066,1333,1600 MHz
BIOS-typ:	EFI AMI
BIOS-minnesstorlek:	64 Mbit
ACPI-version:	1.1
Stöd för parallell bearbetning:	Niet ondersteund
Anslutning för CPU-kylare:	Ja
Anslutningar för husfläktar:	1
ATX-strömkontakt (24-stift):	Ja
USB 2.0-anslutningar:	1
Anslutning för ljudpanel på framsidan:	Ja
PC hälsomonitor:	CPU, FAN, Temperature
USB 3.2 Gen 1 (3.1 Gen 1) anslutningar:	1
Chassiintrångsanslutning:	Ja
Grafikkontroll:	Intel HD Graphics 2500/4000
Antal SATA II-kontakter:	3
Diskret grafikstöd:	Ja
Typ av styrenhetsanslutning:	Intel B75
Minnesmodulkapacitet som stöds:	1GB, 2GB, 4GB, 8GB
Dual Link DVI:	Ja
Rensa CMOS-bygel:	Ja
Anslutningar för EATX nätaggregat:	1
