1
Operation Guide 3254
MA1008-EA
About This Manual
Depending on the model of your watch, display text appears •
either as dark figures on a light background or light figures
on a dark background. All sample displays in this manual are
shown using dark figures on a light background.
Button operations are indicated using the letters shown •
in the illustration.
Each section of this manual provides you with the •
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
General Guide
Press •C to change from mode to mode.
In any mode (except when a setting screen is on the display), press •B to illuminate
the display.
Timekeeping Mode World Time Mode Stopwatch Mode Countdown Timer Mode Alarm Mode
Press .C
Timekeeping
Use the Timekeeping Mode to set and view the current
time and date.
Read this before you set the time and date !
The times displayed in the Timekeeping Mode and World
Time Mode are linked. Because of this, make sure you
select a city code for your Home City (the city where you
normally use the watch) before you set the time and date.
To view the current Home City code setting, press •A
while in the Timekeeping Mode.
For full information on city codes, see the “City Code •
Table”.
To set the time and date
In the Timekeeping Mode, hold down 1. until the A
seconds start to flash, which indicates the setting
screen.
Press 2. to move the flashing in the sequence shown C
below to select other settings.
Seconds MinutesHourDSTCity Code
Day 12/24-Hour FormatYearMonth
When the setting you want to change is flashing, use 3. and to change it as D B
described below.
Screen To do this: Do this:
Reset the seconds to Press D.
Change the city code Use D (east) and B
(west).
Toggle between Daylight Saving Time ( ) and
Standard Time ( ) Press D.
Change the hour or minutes Use D (+) and B (–).
Toggle between 12-hour ( ) and 24-hour
( ) timekeeping Press D.
Change the year, month, or day Use D (+) and B (–).
See “Daylight Saving Time (DST)” for details about the DST setting. •
Press 4. to exit the setting screen.A
Resetting the seconds to • while the current count is in the range of 30 to 59
causes the minutes to be increased by 1. In the range of 00 to 29, the seconds are
reset to without changing the minutes.
With the 12-hour format, the •P (PM) indicator appears to the left of the hour digits for
times in the range of noon to 11:59 p.m. and no indicator appears to the left of the
hour digits for times in the range of midnight to 11:59 a.m.
With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without •
any indicator.
The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is •
applied in all modes.
The year can be set in the range of 2000 to 2099. •
The watch’s built-in full automatic calendar makes allowances for different month •
lengths and leap years. Once you set the date, there should be no reason to change
it except after you have the watch’s battery replaced.
The day of the week is automatically displayed in accordance with the date (year, •
month, and day) settings.
Daylight Saving Time (DST)
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
PM indicator
Day of week
Day
Seconds
Hour : Minutes
To toggle the Timekeeping Mode time between DST and Standard Time
In the Timekeeping Mode, hold down 1. until the A
seconds start to flash, which indicates the setting
screen.
Press 2. twice to display the DST setting screen.C
Press 3. to toggle between Daylight Saving Time (D)
and Standard Time ( ).
Press 4. to exit the setting screen.A
The •DST indicator is displayed on the Timekeeping Mode
and Alarm Mode screen while Daylight Saving Time is
turned on.
World Time
World Time shows the current time in 48 cities (29 time
zones) around the world.
All of the operations in this section are performed in the •
World Time Mode, which you enter by pressing .C
To view the time in another city code
In the World Time Mode, press (eastward) to scroll D
through the available city codes. Holding down the button
scrolls at high speed.
For full information about city codes, see the “City Code •
Table”.
If the current time shown for a city is wrong, check your •
Timekeeping Mode time and Home City code settings
and make the necessary changes.
To toggle a city code time between Standard Time and Daylight Saving Time
In the World Time Mode, use 1. to display the city code D
(time zone) whose Standard Time/Daylight Saving Time
setting you want to change.
Hold down 2. for about one second to toggle between A
Daylight Saving Time (DST indicator displayed) and
Standard Time (DST indicator not displayed).
The DST indicator is on the display whenever you display •
a city code for which Daylight Saving Time is turned on.
Note that the DST/Standard Time setting affects only •
the currently displayed city code. Other city codes are
not affected.
In the World Time Mode, you can switch the city code you currently have selected •
as your Timekeeping Mode Home City between Standard Time and DST. The
setting you select in the World Time Mode will also be applied in the Timekeeping
Mode.
DST indicator
On/Off status
City code
Current time in the zone of
the selected city code
DST indicator
2
Operation Guide 3254
Stopwatch
The stopwatch lets you measure elapsed time, split
times, and two finishes.
The display range of the stopwatch is 59 minutes, •
59.99 seconds.
The stopwatch continues to run, restarting from zero •
after it reaches its limit, until you stop it.
The stopwatch measurement operation continues even •
if you exit the Stopwatch Mode.
Exiting the Stopwatch Mode while a split time is frozen •
on the display clears the split time and returns to
elapsed time measurement.
All of the operations in this section are performed in the Stopwatch Mode, which you •
enter by pressing .C
To measure times with the stopwatch
Elapsed Time
D D D D A
Start Stop Re-start Stop Clear
Split Time
D A A D A
Start Split
( displayed)SPL
Split release Stop Clear
Two Finishes
D A D A A
Start Split
First runner
finishes.
Display time of
first runner.
Stop
Second runner
finishes.
Split release
Display time of
second runner.
Clear
Countdown Timer
The countdown timer can be set within a range of one
minute to 24 hours. An alarm sounds when the countdown
reaches zero.
The countdown operation continues even if you exit the •
Countdown Timer Mode.
All of the operations in this section are performed in the •
Countdown Timer Mode, which you enter by pressing .C
To use the countdown timer
Press while in the Countdown Timer Mode to start the countdown timer.D
When the end of the countdown is reached, the alarm sounds for 10 seconds or until •
you stop it by pressing any button. The countdown time is automatically reset to its
starting value after the alarm stops.
Press •D D while a countdown operation is in progress to pause it. Press again to
resume the countdown.
To completely stop a countdown operation, first pause it (by pressing •D), and then
press . This returns the countdown time to its starting value.A
To set the countdown start time
In the Countdown Timer Mode, hold down 1. until the A
hours of the countdown start time start to flash, which
indicates the setting screen.
Press 2. to move the flashing between the hours and C
minutes.
While a setting is flashing, use 3. (+) or (–) to D B
change it.
To set the starting value of the countdown time to 24 •
hours, set .
Press 4. to exit the setting screen.A
Alarms
You can set five independent Daily Alarms. When an
alarm is turned on, the alarm tone sounds when the alarm
time is reached. One of the alarms is a snooze alarm,
while the other four are one-time alarms.
You can turn on an Hourly Time Signal that causes the
watch to beep twice every hour on the hour.
There are six screens in the Alarm Mode. Four are for •
one-time alarms (indicated by numbers from
through ), one is for a snooze alarm (indicated by
), and one is for the Hourly Time Signal (indicated
by ).
All of the operations in this section are performed in the •
Alarm Mode, which you enter by pressing .C
To set an alarm time
In the Alarm Mode, use 1. to scroll through the alarm D
screens until the one whose time you want to set is
displayed.
To set a one-time alarm, display one of the screens indicated by an alarm number •
from through . To set the snooze alarm, display the screen
indicated by .
The snooze alarm repeats every five minutes. •
After you select an alarm, hold down 2. until the hour setting of the alarm time A
starts to flash, which indicates the setting screen.
This operation turns on the alarm automatically. •
Press 3. to move the flashing between the hour and minute settings.C
While a setting is flashing, use 4. (+) and (–) to change it.D B
When setting the alarm time using the 12-hour format, take care to set the time •
correctly as a.m. (indicator not displayed) or p.m. ( indicator).P
Press 5. to exit the setting screen.A
Seconds
1/100 secondMinutes
Minutes
SecondsHours
Alarm number
Alarm time
(Hour : Minutes)
On/Off status
Alarm Operation
The alarm sounds at the preset time for about 10 seconds, regardless of the mode the
watch is in. In the case of the snooze alarm, the alarm operation is performed a total
of seven times, every five minutes, or until you turn the alarm off.
To stop the alarm tone after it starts to sound, press any button. •
Performing any one of the following operations during a 5-minute interval between •
snooze alarms cancels the current snooze alarm operation.
Displaying the Timekeeping Mode setting screen
Displaying the snooze alarm setting screen
To test the alarm
In the Alarm Mode, hold down to sound the alarm.D
To turn an alarm on and off
Alarm on
indicator
Snooze alarm indicator
On/Off status
In the Alarm Mode, use 1. to select an alarm.D
Press 2. to toggle it on (A displayed) and off
( displayed).
Turning on a one-time alarm ( • through )
displays the alarm on indicator on its Alarm Mode screen.
Turning on the snooze alarm ( •) displays the alarm
on indicator and snooze alarm indicator on the Alarm
Mode snooze alarm screen.
In all modes, the alarm on indicator is shown for any •
alarm that is currently turned on.
The alarm on indicator flashes while the alarm is •
sounding.
The snooze alarm indicator flashes during the 5-minute •
intervals between alarms.
To turn the Hourly Time Signal on and off
Hourly time signal
on indicator
On/Off status
In the Alarm Mode, use 1. to select the Hourly Time D
Signal ( ).
Press 2. to toggle it on (A displayed) and off
( displayed).
The Hourly Time Signal on indicator is shown on the •
display in all modes while the Hourly Time Signal is
turned on.
Illumination
This watch has an EL (electro-luminescent) panel that
causes the entire display to glow for easy reading in the
dark.
Illumination Precautions
The electro-luminescent panel that provides illumination •
loses power after very long use.
Illumination may be hard to see when viewed under direct •
sunlight.
The watch may emit an audible sound whenever the display is illuminated. This •
is due to vibration of the EL panel used for illumination, and does not indicate
malfunction.
Illumination automatically turns off whenever an alarm sounds. •
Frequent use of illumination runs down the battery. •
To illuminate the display
In any mode (except when a setting screen is on the display), press to turn on B
illumination.
You can use the procedure below to select either 1.5 seconds or 3 seconds as the •
illumination duration. When you press , the illumination will remain on for about B
1.5 seconds or 3 seconds, depending on the current illumination duration setting.
To specify the illumination duration
In the Timekeeping Mode, hold down 1. until the A
seconds start to flash, which indicates the setting
screen.
While the seconds are flashing, press 2. to toggle the B
illumination duration between 1.5 seconds ( ) and
3 seconds ( ).
Press 3. to exit the setting screen.A
Reference
This section contains more detailed and technical information about watch operation.
It also contains important precautions and notes about the various features and
functions of this watch.
Button Operation Tone
MUTE indicator The button operation tone sounds any time you press one
of the watch’s buttons. You can turn the button operation
tone on or off as desired.
Even if you turn off the button operation tone, the alarm, •
Hourly Time Signal, and Countdown Timer Mode alarm
all operate normally.
To turn the button operation tone on and off
In any mode (except when a setting screen is on the display), hold down to toggle C
the button operation tone on (MUTE indicator not displayed) and off (MUTE indicator
displayed).
Holding down •C to turn the button operation tone on or off also causes the watch’s
current mode to change.
The MUTE indicator is displayed in all modes when the button operation tone is •
turned off.
Auto Return Features
If you leave the watch in the Alarm Mode for two or three minutes without performing •
any operation, it automatically changes to the Timekeeping Mode.
If you leave a screen with flashing digits or a cursor on the display for two or three •
minutes without performing any operation, the watch automatically saves any
settings you have made up to that point and exits the setting screen.
3
Operation Guide 3254
Scrolling
The and buttons are used in various modes and setting screens to scroll B D
through data on the display. In most cases, holding down these buttons during a scroll
operation scrolls at high speed.
Initial Screens
When you enter the World Time or Alarm Mode, the data you were viewing when you
last exited the mode appears first.
World Time
The seconds count of the World Time is synchronized with the seconds count of the •
Timekeeping Mode.
All World Time Mode times are calculated from the current Home City time in the •
Timekeeping Mode using UTC time differential values.
The UTC differential is a value that indicates the time difference between a •
reference point in Greenwich, England and the time zone where a city is located.
The letters “UTC” is the abbreviation for “Coordinated Universal Time”, which is the •
world-wide scientific standard of timekeeping. It is based upon carefully maintained
atomic (cesium) clocks that keep time accurately to within microseconds. Leap
seconds are added or subtracted as necessary to keep UTC in sync with the Earth’s
rotation.
Specifications
Accuracy at normal temperature: ±30 seconds a month
Timekeeping: Hour, minutes, seconds, a.m./p.m. (P), day, day of the week
Time format: 12-hour and 24-hour
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Other: Home City code (can be assigned one of 48 city codes); Daylight Saving
Time (summer time)/Standard Time
World Time: 48 cities (29 time zones)
Other: Daylight Saving Time/Standard Time
Stopwatch
Measuring unit: 1/100 second
Measuring capacity: 59’59.99”
Measuring modes: Elapsed time, split time, two finishes
Countdown Timer
Measuring unit: 1 second
Input range: 1 minute to 24 hours (1-minute increments and 1-hour increments)
Alarms: 5 daily alarms (4 one-time alarms: 1 snooze alarm); Hourly Time Signal
Illumination: EL Backlight (electro-luminescent panel); Selectable illumination
duration
Other: Button operation tone on/off
Battery: One lithium battery (Type: CR1616)
Approximately 3 years on type CR1616 (assuming alarm operation 10 seconds per
day, and one illumination operation 1.5 seconds per day)
City Code Table
City
Code City UTC Offset/
GMT Differential
PPG Pago Pago –11
HNL Honolulu –10
ANC Anchorage –9
YVR Vancouver
–8SFO San Francisco
LAX Los Angeles
DEN Denver –7
MEX Mexico City –6
CHI Chicago
MIA Miami –5
NYC New York
CCS* Caracas –4
YYT St. Johns –3.5
RIO Rio De Janeiro –3
RAI Praia –1
LIS Lisbon 0
LON London
BCN Barcelona
+1
PAR Paris
MIL Milan
ROM Rome
BER Berlin
ATH Athens
+2
JNB Johannesburg
IST Istanbul
CAI Cairo
JRS Jerusalem
MOW Moscow +3
JED Jeddah
City
Code City UTC Offset/
GMT Differential
THR Tehran +3.5
DXB Dubai +4
KBL Kabul +4.5
KHI Karachi +5
MLE Male
DEL Delhi +5.5
DAC Dhaka +6
RGN Yangon +6.5
BKK Bangkok +7
SIN Singapore
+8HKG Hong Kong
BJS Beijing
SEL Seoul +9
TYO Tokyo
ADL Adelaide +9.5
GUM Guam +10
SYD Sydney
NOU Noumea +11
WLG Wellington +12
•Based on data as of December 2009.
•The rules governing global times
(UTC offset and GMT differential) and
summer time are determined by each
individual country.
In December 2007, Venezuela *
changed its offset from –4 to –4.5.
Note, however, that this watch displays
an offset of –4 (the old offset) for the
CCS (Caracas, Venezuela) city code.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | BGD-121-2ER |
Behöver du hjälp?
Om du behöver hjälp med Casio BGD-121-2ER ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
