Operation Guide 3426
E
About This Manual
Depending on the model of your watch, display text
appears either as dark fi gures on a light background or
light fi gures on a dark background. All sample displays
in this manual are shown using dark fi gures on a light
background.
Button operations are indicated using the letters shown
in the illustration.
Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
To ensure that this watch provides you with the years of
service for which it is designed, be sure to carefully read
and follow the instructions under “Operating Precautions”
and “User Maintenance”.
Be sure to keep all user documentation handy for future
reference.
MA1310-EA
© 2013 CASIO COMPUTER CO., LTD.
E-1
Contents
General Guide .......................................................................................................... E-4
Timekeeping ............................................................................................................. E-6
Stopwatch .............................................................................................................. E-11
Preset Timer ........................................................................................................... E-16
Countdown Timer .................................................................................................. E-20
World Time ............................................................................................................. E-26
Alarm ...................................................................................................................... E-28
Illumination ............................................................................................................E-31
Reference ............................................................................................................... E-32
Specifi cations ........................................................................................................E-38
Operating Precautions .........................................................................................E-m1
User Maintenance ...............................................................................................E-m11
E-2
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To set the time and date ......................................................................................... E-7
To toggle the Timekeeping Mode time between DST and Standard Time .........E-9
To toggle between 12-hour and 24-hour timekeeping .......................................E-10
To measure times with the stopwatch ................................................................. E-12
To set the event time ............................................................................................. E-14
To start timing at the beginning of an event ....................................................... E-14
To pause timing ..................................................................................................... E-15
To reset elapsed time measurement to zero ....................................................... E-15
To perform a preset timer operation .................................................................... E-17
To confi gure countdown timer settings .............................................................. E-21
To perform a countdown timer operation ........................................................... E-24
E-3
To view the time for another city code ................................................................ E-26
To toggle a city code time
between Standard Time and Daylight Saving Time ........................................ E-27
To set the alarm time ............................................................................................. E-28
To stop the alarm tone after it starts to sound .................................................. E-29
To switch the Daily Alarm and Hourly Time Signal on and off ......................... E-30
To test the alarm .................................................................................................... E-30
To illuminate the display ....................................................................................... E-31
To turn the button operation tone on and off ..................................................... E-34
E-4
General Guide
Press to change from mode to mode.C
In any mode (except when a setting screen is on the display), press to illuminate B
the display.
C
Timekeeping Mode
C C
Stopwatch Mode Preset Timer Mode
E-5
C
C C
Countdown Timer Mode World Time Mode Alarm Mode
E-6
Timekeeping
Use the Timekeeping Mode to set and view the current
time and date.
Read This Before You Set the Time and Date !
The times displayed in the Timekeeping Mode and World
Time Mode are linked. Because of this, make sure you
select a city code for your Home City (the city where you
normally use the watch) before you set the time and date.
For full information on city codes, see the “City Code
Table” at the back of this manual.
Hour : Minutes
PM indicator
Day of week
Seconds
Month – Day
E-7
To set the time and date
1. In the Timekeeping Mode, hold down until the A
seconds start to fl ash, which indicates the setting
screen.
2. Press to move the fl ashing in the sequence shown C
below to select other settings.
Seconds DST City Code Hour
C C C C
C
Day Month Year Minutes
CCC
E-8
3. When the setting you want to change is fl ashing, use and to change it as D B
described below.
Screen To do this: Do this:
Reset the seconds to Press .D
Toggle between Daylight Saving Time ( )
and Standard Time ( )
Change the city code Use (east) and (west). D B
Change the hour or minutes Use (+) and (–).D B
Change the year
Change the month or day
See “Daylight Saving Time (DST)” on page E-9 for details about the DST setting.
4. Press to exit the setting screen.A
E-9
Daylight Saving Time (DST)
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
To toggle the Timekeeping Mode time between DST and Standard Time
1. In the Timekeeping Mode, hold down until the A
seconds start to fl ash, which indicates the setting
screen.
2. Press to display the DST setting screen.C
3. Press to toggle between Daylight Saving Time (D
displayed) and Standard Time ( displayed).
4. Press to exit the setting screen.A
The indicator is on the display while Daylight Saving DST
Time is turned on.
DST indicator
Operation Guide 3426
E-10
To toggle between 12-hour and 24-hour timekeeping
In the Timekeeping Mode, press to toggle between 12-hour timekeeping and D
24-hour timekeeping.
With the 12-hour format, the (PM) indicator appears for times in the range of noon P
to 11:59 p.m. and no indicator appears to the left of the hour digits for times in the
range of midnight to 11:59 a.m.
With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without
any indicator.
The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
applied in all other modes.
The indicator is not displayed with the Timekeeping Mode time on the Preset P
Timer Mode, Countdown Timer Mode, World Time Mode, and Alarm Mode screens.
E-11
Stopwatch
The stopwatch lets you measure elapsed time. The upper
display and lower display can be used for offi cial timing of
an event or game.
The measurement range of the upper display is
59 minutes 59 seconds.
The measurement range of the lower display is
99 minutes 59 seconds.
The stopwatch continues to run, restarting from zero after
it reaches its limit, until you stop it.
The stopwatch measurement operation continues even if
you exit the Stopwatch Mode.
All of the operations in this section are performed in
the Stopwatch Mode, which you enter by pressing C
(page E-4).
Timekeeping Mode time
Initial Stopwatch Mode
Screen
E-12
This time measurement (1/100 second)
cannot be paused.
Elapsed Time Screen
Minutes Seconds
Press to pause and D
resume elapsed time
measurement.
Minutes Seconds
This time measurement
cannot be paused.
It shows the total elapsed
time since the timing
operation started.
To measure times with the stopwatch
Elapsed Time
DDDD Hold down A
Start Stop*1Resume Stop*1Reset
*1 Elapsed time measurement in the lower display continues.
E-13
Using the Watch for Offi cial Timing of a Sport Event
After you set a game or event time, the watch will sound an alarm when the time in
the lower display reaches that time.
If the event is interrupted for some reason, you can press to pause and resume D
timing in the upper display. The lower display shows the total elapsed time since the
start of the timing operation. You can calculate the total amount of time that play was
interrupted (lost time or injury time) by subtracting the upper display time from the
lower display time.
E-14
To set the event time
1. In the Stopwatch Mode, hold down until the current A
event time setting starts to fl ash in the lower display.
This is the setting screen.
If the current event time is not displayed, use the
procedure under “To reset elapsed time measurement
to zero” (page E-15) to display it.
2. While a setting is fl ashing, use (+) and (–) to D B
change it.
You can set the event time in the range of 1 minute to
60 minutes, in 1-minute units.
“ ” indicates there is no event time set.
3. Press to exit the setting screen.A
To start timing at the beginning of an event
When the current time in the lower display reaches the event start time, press to D
start timing.
This will display elapsed time measurement in the upper and lower displays.
E-15
To pause timing
1. Press .D
This stops elapsed time measurement in the upper display.
Elapsed time measurement in the lower display continues.
2. To resume elapsed time measurement in the upper display, press again.D
When the preset event time is reached
The watch will sound an alarm when the elapsed time measurement in the lower
display (total elapsed time since timing started) reaches the preset event time.
Elapsed time measurement continues to be performed even after the preset event
time is reached.
To reset elapsed time measurement to zero
1. Press . This stops elapsed time measurement in the upper display.D
Elapsed time measurement in the lower display continues.
2. Hold down until the initial Stopwatch Mode screen appears.A
E-16
Preset Timer
The watch includes a number of different preset times that
you can select for the countdown start time.
An alarm sounds when the countdown reaches zero.
The following are the preset start times, all in minutes:
10, 12, 15, 20, 25, 30, 35, 40, 45.
You can also select auto-repeat, which automatically
restarts from the preset start time you selected, whenever
zero is reached.
All of the operations in this section are performed in the
Preset Timer Mode, which you enter by pressing C
(page E-4).
Preset timer time
Timekeeping Mode time
E-17
To perform a preset timer operation
1. In the Preset Timer Mode, use to scroll through the A
preset times until the one you want to use is displayed.
10 minutes 12 minutes 15 minutes 20 minutes
AAA
A
A25 minutes
45 minutes 40 minutes 35 minutes 30 minutes
AAA
A
E-18
To turn on auto-repeat, hold down while a start time A
selection screen is displayed. The number of repeats
will appear in the lower display.
Frequent use of auto-repeat and the alarm can run
down battery power.
2. Press to start the countdown timer.D
Press while a countdown operation is in progress to D
pause it. Press again to resume the countdown.D
Number of repeats
Auto-repeat on indicator
E-19
When the end of the countdown is reached, the alarm sounds for 10 seconds or until
you stop it by pressing any button.
When the end of the countdown is reached while auto-repeat is turned off, the watch
will go into an elapsed time operation and display how much time has elapsed
since the end of the countdown was reached. The elapsed time operation will stop
automatically when it reaches 60 minutes. At that time the countdown timer start
time selection screen will appear.
When the end of the countdown is reached while auto-repeat is turned on, a new
countdown starts from the selected preset start time. The number of repeats is
displayed in the lower display. The number of repeats display changes to “ ” when
the count reaches 100.
To stop a countdown operation completely, fi rst pause it (by pressing ), and then D
press . This will display the initial Preset Timer Mode screen.A
Operation Guide 3426
E-20
Countdown Timer
With the countdown timer, you can set up to nine start
times, which are counted down in sequence one after the
other.
The countdown timer can be used for interval training (for
example, three minutes running with , 1 minute rest
with , fi ve minutes running with ) or for timing an
multi-period event (for example, 45 minutes of play with
, 15 minutes rest with , 45 minutes play with ).
The watch performs an alert operation (beeper) when any
timer reaches zero.
An alert operation (about one second) is performed
when any countdown timer (except for the last one in the
series) reaches zero. When the last countdown timer in
the series reaches zero, an alert operation is performed
for about fi ve seconds.
Countdown timer
number
Start time
(Minutes Seconds)
Timekeeping Mode time
E-21
You can turn on an auto-repeat feature that restarts the timer sequence from the
beginning when the end of the last timer is reached.
All of the operations in this section are performed in the Countdown Timer Mode,
which you enter by pressing (page E-5).C
To confi gure countdown timer settings
1. In the Countdown Timer Mode, hold down until the A
countdown timer number starts to fl ash.
This is the setting screen.
2. Use (+) and (–) to scroll through the countdown D B
timer numbers until the one you want to set is displayed.
E-22
DDDD
BBBB
BBB
DDD
DB
BD
3. Press to move the fl ashing in the sequence shown below to select other C
settings.
Countdown timer numbers Minutes Seconds Auto-repeat
CCC
C
E-23
4. While a setting is fl ashing, use and to change it as described below.D B
Screen To do this: Do this:
Change the countdown timer number Use (+) and (–). D B
Change the minutes ( )
Change the seconds ( , 5-second units)
Toggle auto-repeat on ( ) and off ( ) Press .D
Any timer whose start time is will not be used during the countdown timer
operation.
There is no auto-repeat for individual countdown timers. In the Countdown Timer
Mode, auto-repeat repeats the entire set of timers.
E-24
5. Set the times of all of the timers that you want.
6. Press to exit the setting screen.A
When auto-repeat is turned on, the number of repeats will
appear in the lower display.
Frequent use of auto-repeat and the alarm can run down
battery power.
To perform a countdown timer operation
In the Countdown Timer Mode, press to start the countdown of the lowest D
numbered countdown timer that has a start time setting that is not zero.
To pause the countdown timer that is currently counting down, press . Press D D
again to resume the countdown.
During a countdown timer operation, any countdown timer whose start time is zero
( ) is skipped.
Number of repeats
Auto-repeat on indicator
E-25
The fi rst countdown timer of the series is the lowest numbered one with a start time
that is not zero. The fi nal countdown timer of the series is the highest numbered one
with a start time that is not zero.
While auto-repeat is turned off, the watch beeps when each countdown timer
reaches zero. An alarm will sound for about fi ve seconds when the fi nal countdown
timer reaches zero.
While auto-repeat is turned on, the watch beeps once when each countdown timer
reaches zero. A fi ve-second alert operation is performed when the fi nal countdown
timer reaches zero, unless the start time of the fi nal countdown timer is 10 seconds
or less. In such a case, the alert operation for the fi nal countdown timer is only one
second long.
Timing restarts from the fi rst timer when the fi nal countdown timer reaches zero. The
number of repeats is displayed in the lower display. The number of repeats display
changes to “ ” when the count reaches 100.
An ongoing countdown timer operation continues to be performed even if you exit
the Countdown Timer Mode.
To stop a countdown timer operation, fi rst press to pause the countdown of the D
current timer, and then press . This will display Countdown Timer 1 (A).
E-26
World Time
World Time shows the current time in 48 cities (29 time
zones) around the world.
When you enter the World Time Mode, the data you were
viewing when you last exited the mode appears fi rst.
All of the operations in this section are performed in
the World Time Mode, which you enter by pressing C
(page E-5).
To view the time for another city code
In the World Time Mode, press to scroll eastward D
through city codes.
For full information about city codes, see the “City Code
Table” at the back of this manual.
If the current time for a city is wrong, check your
Timekeeping Mode time and Home city code settings and
make necessary changes.
City code
Current time in the zone of
the selected city code
Timekeeping Mode time
E-27
To toggle a city code time between Standard Time and Daylight Saving Time
1. In the World Time Mode, use to display the city code D
(time zone) whose Standard Time/Daylight Saving Time
setting you want to change.
2. Hold down for about one second to toggle between A
Daylight Saving Time ( displayed) and Standard Time
( not displayed).
The indicator is on the display whenever you display DST
a city code for which Daylight Saving Time is turned on.
Note that the DST/Standard Time setting affects only
the currently displayed city code. Other city codes are
not affected.
DST indicator
E-28
Alarm
When the Daily Alarm is turned on, the alarm sounds for
10 seconds at the preset time each day. When the Hourly
Time Signal is turned on, the watch beeps every hour on
the hour.
All of the operations in this section are performed in the
Alarm Mode, which you enter by pressing (page E-5).C
To set the alarm time
1. Hold down while in the Alarm Mode until the hour A
digits start to fl ash on the display. The hour digits fl ash
because they are selected.
This operation automatically turns on the alarm.
Alarm time
(Hour : Minutes)
Hourly time signal on
indicator
Timekeeping
Mode time
Alarm on indicator
E-29
2. Press to change the selection in the following sequence.C
Hour Minutes
C
3. While a setting is ashing, use and to change it as described below.D B
Screen To do this: Do this:
Change the hour and minutes Use (+) and (–).D B
With the 12-hour format, set the time
correctly as a.m. or p.m. ( indicator).P
4. After you set the alarm time, press to return to the Alarm Mode.A
To stop the alarm tone after it starts to sound
Press any button.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | Collection AE-1300WH-4AVEF |
Behöver du hjälp?
Om du behöver hjälp med Casio Collection AE-1300WH-4AVEF ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
