Operation Guide 3484
E-9
Changing the Current Home City Time and Date Settings
1. Use D to display the current Home City Time (T-1)
screen.
2. Hold down A until the seconds start to flash, which
indicates the setting screen.
3. Press C to move the flashing in the sequence shown
below to select other settings.
Seconds DST Minutes
C C
C
Hour
C
Illumination Duration
Setting
12/24-Hour
Format
C
C
Year
C
City Code
C
C
Month
C
Day
4. When the setting you want to change is flashing, use D and B to change it as
described below.
E-8
x You can change the current time setting for your Home City Time (T-1) only.
x For Local Times (T-2, T-3, T-4), you only can change the city code and DST
setting.
E-7
Switching Between Time Screens
Each press of D cycles the time screens in the sequence shown below.
D D D
A
D
Displayed for one second
x While the Home City Time (T-1) screen is displayed, pressing A will switch the
day of the week/month-day indication to the currently selected Home City code
and the T-1 indicator for about one second.
E-6
Timekeeping
The Timekeeping Mode’s Multi Time feature gives you
quick and easy access to the current time and date in
four different cities, numbered from T-1 (Time 1) through
T-4 (Time 4). T-1 is your Home City Time, and T-2,
T-3, and T-4 are Local Times. Local Times are kept in
synchronization with your Home City Time (T-1).
x The graphic area B indicates the current Home City
Time (T-1). For details on reading the graphic areas,
see “Graphic Areas” (page E-30).
Day of week
Month – Day
Graphic area A
Seconds
Hour : Minutes
PM indicator
Graphic area B
E-5
C
Countdown Timer
Mode
Stopwatch Mode
C
Alarm Mode
C
E-4
General Guide
x Press C to change from mode to mode.
x In any mode (except when a setting screen is on the display), press B to
illuminate the display.
Timekeeping Mode World Time Mode
C C
E-3
To measure times with the stopwatch ................................................................E-29
To turn the button operation tone on and off ....................................................E-32
To turn off Auto Display ........................................................................................ E-35
To turn on Auto Display ........................................................................................E-35
E-2
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To toggle the Timekeeping Mode time between DST and Standard Time ......E-12
To turn on illumination ..........................................................................................E-15
To view the time for another city code................................................................E-16
To toggle a city code time
between Standard Time and Daylight Saving Time .......................................E-17
To change your Home Time city to the current World Time city ......................E-18
To set an alarm time .............................................................................................E-20
To test the alarm ...................................................................................................E-22
To turn an alarm on and off ..................................................................................E-23
To turn the Hourly Time Signal on and off ..........................................................E-24
To configure the countdown timer ...................................................................... E-26
To use the countdown timer ................................................................................E-27
E-1
Contents
General Guide ..........................................................................................................E-4
Timekeeping ............................................................................................................E-6
World Time .............................................................................................................E-16
Alarms.....................................................................................................................E-19
Countdown Timer ..................................................................................................E-25
Stopwatch .............................................................................................................. E-28
Reference ............................................................................................................... E-30
Specifications ........................................................................................................E-36
Operating Precautions ..........................................................................................E-38
User Maintenance .................................................................................................E-48
E
About This Manual
x Button operations are indicated using the letters
shown in the illustration.
x Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
x To ensure that this watch provides you with the years
of service for which it is designed, be sure to carefully
read and follow the instructions under “Operating
Precautions” and “User Maintenance”.
x Be sure to keep all user documentation handy for
future reference.
MA1909-EA © 2019 CASIO COMPUTER CO., LTD.
Operation Guide 3484
E-19
Alarms
Your watch has a total of five alarms, each of which you
can configure as a daily alarm or one-time alarm.
x Daily Alarm: Sounds at the preset time each day.
x One-time Alarm: Sounds once at the preset time and
then is disabled automatically.
You can also turn on an Hourly Time Signal that causes
the watch to beep twice every hour on the hour.
x All of the operations in this section are performed
in the Alarm Mode, which you enter by pressing C
(page E-5).
x Alarms operate in coordination with the current Home
City Time.
Alarm time
(Hour : Minutes)
Alarm number
E-18
To change your Home Time city to the current World Time city
1. In the World Time Mode, use D to display the city you want to make your new
Home Time city.
2. Press A and B at the same time.
x This makes the World Time city you selected in step 1 your new Home Time
city.
E-17
To toggle a city code time between Standard Time and Daylight Saving Time
1. In the World Time Mode, use D (east) to display the
city code (time zone) whose Standard Time/Daylight
Saving Time setting you want to change.
2. Hold down A for about one second to toggle Daylight
Saving Time ( displayed) and Standard Time ( DST DST
not displayed).
x The indicator is on the display whenever you DST
display a city code for which Daylight Saving Time is
turned on.
x Note that the DST/Standard Time setting affects only
the currently displayed city code. Other city codes are
not affected.
x Note that you cannot switch between Standard Time
and Daylight Saving Time while UTC is selected as
the city code.
DST indicator
E-16
World Time
World Time shows the current time in 48 cities (31 time
zones) around the world.
x All of the operations in this section are performed in
the World Time Mode, which you enter by pressing C
(page E-4).
To view the time for another city code
In the World Time Mode, press D to scroll eastwardly
through city codes.
x For full information about city codes, see the “City
Code Table” at the back of this manual.
x If the current time for a city is wrong, check your
Timekeeping Mode time and time zone settings and
make the necessary changes.
City code
Current time and date
in the zone of the
selected city code
E-15
Illumination
An LED (light-emitting diode) illuminate the display for easy reading in the dark.
Illumination Precautions
x The illumination provided by the light may be hard to see when viewed under
direct sunlight.
x Illumination automatically turns off whenever an alarm sounds.
x Frequent use of illumination runs down the battery.
To turn on illumination
In any mode (except when a setting screen is on the display), press B to turn on
illumination.
x When you press B, the illumination will remain on for about 1.5 seconds or
3seconds, depending on the current illumination duration setting (page E-9).
E-14
4. Press D to toggle between Daylight Saving Time ( displayed) and Standard On
Time ( displayed). OFF
5. After the settings are the way you want, press A.
Changing Your Home City Time
Use the following procedure to change your current Home City Time to any one of
the three Local Times.
1. In the Timekeeping Mode, press D to display the Local Time which you want to
make your Home City Time.
2. Press A and B at the same time.
x This makes the Local Time you selected in step 1 your new Home City Time.
E-13
12/24-Hour Format
x With the 12-hour format, the P (PM) indicator appears to the left of the hour
digits for times in the range of noon to 11:59 p.m. and no indicator appears to
the left of the hour digits for times in the range of midnight to 11:59 a.m.
x With the 24-hour format, times are displayed in the range of 0:00 to 23:59,
without any indicator.
x The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
applied in all other modes.
Changing the City Setting of a Local Time
You can select any one of the city codes in the table at the back of this manual as a
Local Time city.
1. Display the Local Time whose city setting you want to change, and then hold down
A for about two seconds until the current city code starts to flash.
2. Use D (east) and B (west) to select the city code you want.
3. Press C to display the DST setting screen.
E-12
To toggle the Timekeeping Mode time between DST and Standard Time
1. Use D to display the current Home City Time (T-1)
screen.
2. Hold down A until the seconds start to flash, which
indicates the setting screen.
3. Press C to display the DST setting screen.
4. Press D to toggle between Daylight Saving Time ( On
displayed) and Standard Time ( displayed).OFF
5. Press A to exit the setting screen.
x The indicator appears on the Timekeeping screen DST
to indicate that Daylight Saving Time is turned on.
On/Off status
DST indicator
E-11
5. Press A to exit the setting screen.
x The day of the week is displayed automatically in accordance with the date
(year, month, and day) settings.
Daylight Saving Time (DST)
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
E-10
Screen To do this: Do this:
Reset the seconds to 00 Press D.
Toggle between Daylight Saving Time
( )On OFF) and Standard Time ( Press D.
Change the city code Use D (east) and B (west).
Change the hour or minutes Use D (+) and B (–).
Toggle between 12-hour ( ) and 24-12H
hour (24H) timekeeping. Press D.
Change the year Use D (+) and B (–).
Change the month or day Use D (+) and B (–).
Toggle the setting between 1.5 seconds
( )1) and 3 seconds (3Press D.
x See “Daylight Saving Time (DST)” on page E-11 for details about DST setting.
Operation Guide 3484
E-29
To measure times with the stopwatch
Elapsed Time
D D D D A
Start Stop Resume Stop Reset
Split Time
D A A D A
Start Split
( displayed)SPL
Split release Stop Reset
Two Finishes
D A D A A
Start Split
First runner
finishes.
Display time of first
runner.
Stop
Second runner
finishes.
Split release
Display time of
second runner.
Reset
E-28
Stopwatch
The stopwatch lets you measure elapsed time, split times,
and two finishes.
x The display range of the stopwatch is 23 hours,
59minutes, 59.99 seconds.
x The stopwatch continues to run, restarting from zero
after it reaches its limit, until you stop it.
x The stopwatch measurement operation continues even
if you exit the Stopwatch Mode.
x Exiting the Stopwatch Mode while a split time is frozen
on the display clears the split time and returns to
elapsed time measurement.
x All of the operations in this section are performed in
the Stopwatch Mode, which you enter by pressing C
(page E-5).
1/100 second
Hours
Minutes
Seconds
E-27
4. Press A to exit the setting screen.
To use the countdown timer
Press D while in the Countdown Timer Mode to start the
countdown timer.
x When the end of the countdown is reached, the alarm
sounds for ten seconds or until you stop it by pressing
any button. The countdown time is reset to its starting
value automatically when the alarm sounds.
x Press D while a countdown operation is in progress
to pause it. Press D again to resume the countdown.
x To stop a countdown operation completely, first pause
it (by pressing D), and then press A. This returns the
countdown time to its starting value.
E-26
To configure the countdown timer
1. While the countdown start time is on the display in the
Countdown Timer Mode, hold down A until the current
countdown start time starts to flash, which indicates the
setting screen.
2. Press C to move the flashing in the sequence shown
below to select other settings.
Hours Minutes Seconds
C
C
C
3. When the setting you want to change is flashing, use D (+) and B (–) to change
the flashing item.
x To specify a countdown start time of 24 hours, set 0:00 00.
E-25
Countdown Timer
The countdown timer can be set within a range of
one second to 24 hours. An alarm sounds when the
countdown reaches zero.
x All of the operations in this section are performed
in the Countdown Timer Mode, which you enter by
pressing C (page E-5).
1/10 second
Hours
Minutes
Seconds
E-24
To turn the Hourly Time Signal on and off
1. In the Alarm Mode, use D to select the Hourly Time
Signal.
2. Press A to toggle it on and off.
x The Hourly Time Signal on indicator is shown on the
display in all modes while this function is turned on.
Hourly time signal
on indicator
E-23
To turn an alarm on and off
1. In the Alarm Mode, use D to select an alarm.
2. Press A to cycle through the alarm settings as shown below.
ALM OFF A A
ALM 1-On AALM On
Alarm Off One-Time Alarm On Daily Alarm On
x In all modes, the alarm on indicator is shown for the alarm that is currently
turned on.
x The alarm on indicator flashes while the alarm is sounding.
E-22
Alarm Operation
The alarm tone sounds at the preset time for 10 seconds, regardless of the mode the
watch is in.
x Alarm and Hourly Time Signal operations are performed in accordance with the
Timekeeping Mode time.
x To stop the alarm tone after it starts to sound, press any button.
To test the alarm
In the Alarm Mode, hold down D to sound the alarm.
E-21
3. Press C to move the flashing in the sequence shown below to select other
settings.
Hour Minutes
One-time Alarm/Daily Alarm Selection
C
C C
4. While a setting is flashing, use D and
B to change it as described below.
Screen To do this: Do this:
Change the hour and
minutes.
Use D (+) and B (–).
x With the 12-hour format, set the time
correctly as a.m. or p.m. ( indicator).P
/ Toggle between One-time
Alarm and Daily Alarm.
Press D.
One-time Alarm on: 1-On
Daily Alarm on: On
5. Press A to exit the setting screen.
E-20
To set an alarm time
1. In the Alarm Mode, use D to scroll through the alarm
screens until the alarm number you want to set is
displayed.
–1 –2
:00
D DD
–3
–5
D D
–4
D
2. After you select an alarm, hold down A until the hour setting of the alarm time
starts to flash, which indicates the setting screen.
x This operation turns on the One-time Alarm automatically.
Alarm on indicator
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | Collection DW-291H-9AVEF |
Behöver du hjälp?
Om du behöver hjälp med Casio Collection DW-291H-9AVEF ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
