To Set Time and Date

[Setting date]

1. Pull the crown out to the first

click.

2. Set the date by turning the

crown.

Avoid setting the date between

the hour of 8:00 p.m. and 1:00

a.m. (The date display may not

change in the following day).

3. Push the crown in to the normal

position.

[Setting time and day of the week]

1. Pull the crown out to the second

click when the second hand is

at 12 o’clock position and the

second hand stops.

2. Set the hands by turning the

crown. As you do, the day of the

week changes accordingly.

•After setting day of the week,

carefully set the time, making

sure to distinguish between AM

and PM.

3. In accordance with a time

signal, push the crown in.

24-Hour Hand

The 24-Hour Hand indicates the

current hour of the day, making

one complete rotation every 24

hours.

■For watch with the elapsed time bezel

Rotate the elapsed time bezel to align the

mark with the minute hand.

After certain amount of time elapsed, read the

graduation on the elapsed time bezel which

the minute hand points to.

The elapsed time is indicated.

Specifications

Accuracy at normal

Module No. temperature Battery type Battery life

1343 ±20 seconds per month SR916SW Approx. 3 years

1794/2364 ±20 seconds per month SR621SW Approx. 2 years

5071/5072 ±20 seconds per month SR621SW Approx. 3 years

ENGLISH

Elapsed time bezel

•Be sure to keep all user documentation handy for future reference.

•Your watch may differ somewhat from the one shown in the illustration.

Notes

•Some water resistant models are equipped

with a screw lock crown.

•With such models, you must unscrew the

crown in the direction noted in the illustration

to loosen it before you can pull it out. Do not

pull too forcibly on such crowns.

•Also note that such watches are not water

resistant while their crowns are loosened. Be

sure to screw the crowns back in as far as

they will go after making any setting.

Operating Precautions

Water Resistance

•The following applies to watches with WATER RESIST or WATER

RESISTANT marked on the back cover.

1343 1794 2364 5071 5072

ANALOG (3H3E)

[Module 1794/5072]

Crown

(Normal position)

First click

(Setting

date)

Second click

(Setting time

and day of

the week)

Date

24-Hour Hand

Day of

the week

Crown

(Normal position)

First click

(Setting

date)

Second click

(Setting time

and day of

the week)

Date

24-Hour Hand

Day of

the week

[Module 1343/2364/5071]

•Do not use this watch for scuba diving or other types of diving that

requires air tanks.

•Watches that do not have WATER RESIST or WATER RESISTANT

marked on the back cover are not protected against the effects of

sweat. Avoid using such a watch under conditions where it will be

exposed to large amounts of sweat or moisture, or to direct

splashing with water.

•Even if a watch is water-resistant, do not operate its buttons or

crown while it is submersed in water or wet.

•Even if a watch is water-resistant, avoid wearing it in the bath or in

areas where detergents (soap, shampoo, etc.) are being used. Such

conditions can reduce water resistance.

•After submersion in seawater, use plain water to rinse all salt and

dirt from the watch.

•In order to maintain water resistance, have the gaskets of your

watch replace periodically (about once every two or three years).

•A trained technician will know how to check your watch for proper

water resistance whenever you have its battery replaced. Battery

replacement requires the use of special tools. Always request

battery replacement from your original retailer or from an authorized

CASIO Service Center.

•Some water-resistant watches come with fashionable leather bands.

Avoid swimming, washing, or any other activity that causes direct

exposure of a leather band to water.

•The inside surface of the watch glass may fog when the watch is

exposed to a sudden drop in temperature. No problem is indicated if

the fogging clears up relatively quickly. If the fogging does not clear

or if water has gotten into the watch, take the watch in for repair

immediately.

•Continued use of the watch with water inside can result in damage

to electronic and mechanical components, the face of the watch, etc.

Band

•Tightening the band too tightly can cause you to sweat and make it

hard for air to pass under the band, which can lead to skin irritation.

Do not fasten the band too tightly. There should be enough room

between the band and your wrist so you can insert your finger.

•Deterioration, rust, or corrosion of the band can cause it to break,

which may result in the watch falling off your wrist and becoming

lost. Be sure to take good care of the band and keep it clean. Should

you notice any breakage, discoloration, looseness or other problem

with the band, immediately contact your original retailer or an

authorized CASIO Service Center to have it checked, repaired, or

replaced. Note that you will be charged for any repair or replacement

of the band.

Temperature

•Never leave the watch on the dashboard of a car, near a heater, or

in any other location that is subject to very high temperatures. Do

not leave the watch where it will be exposed to very low

temperatures, either. Temperature extremes can cause the watch to

lose or gain time, to stop, or otherwise malfunction.

Impact

•Your watch is designed to withstand impact incurred during normal

daily use and light activity such as playing catch, tennis, etc.

Dropping the watch or otherwise subjecting it to strong impact,

however, can lead to malfunction.

Note that watches with shock-resistant designs (G-SHOCK, Baby-G,

G-ms) can be worn while operating a chain saw or engaging in other

activities that generate strong vibration, or while engage in

strenuous sports activities (motocross, etc.).

Magnetism

•The hands of analog and combination (analog-digital) watches are

moved by a motor that uses magnetic force. When such a watch is

close to a device (audio speakers, magnetic necklace, cell phone,

etc.) that emits strong magnetism, the magnetism can cause

timekeeping to slow down, speed up, or stop, resulting in the

incorrect time being displayed.

Electrostatic Charge

•Exposure to very strong electrostatic charge can cause the watch to

display the wrong time. Very strong electrostatic charge even can

damage electronic components.

Chemicals

•Do not allow the watch to come into contact with thinner, gasoline,

solvents, oils, or fats, or with any cleaners, adhesives, paints,

medicines, or cosmetics that contain such ingredients. Doing so can

cause discoloration of or damage to the case, resin band, leather

band, and other parts.

Storage

•If you do not plan to use the watch for a long time, wipe it thoroughly

free of all dirt, sweat, and moisture, and store it in a cool, dry place.

Resin Components

•Allowing the watch to remain in contact with other items or storing it

together with other items for long periods while it is wet can cause

the color of the other items to transfer to the resin components of the

watch. Be sure to dry off the watch thoroughly before storing it and

make sure it is not in contact with other items.

•Leaving the watch where it is exposed to direct sunlight (ultraviolet

rays) for long periods or failure to clean dirt from the watch for long

periods can cause it to become discolored.

•Friction caused by certain conditions (frequent external force,

sustained rubbing, impact, etc.) can cause discoloration of painted

components.

•If there are printed figures on the band, strong rubbing of the printed

area can cause discoloration.

•Failure to clean dirt from the watch for long periods can cause

fluorescent color to fade. Wash dirt off with water as soon as

possible and then dry the watch.

•Semi-transparent resin parts can become discolored due to sweat

and dirt, and if exposed to high temperatures for long periods.

•Contact an authorized CASIO Service Center to have resin components

replaced. Note that you will be charged for replacement costs.

Natural Leather and Imitation Leather Bands

•Allowing the watch to remain in contact with other items or storing it

together with other items while it is wet for long periods can cause

the color of the other items to transfer to the natural leather or

imitation leather band of the watch. Be sure to dry off the watch

thoroughly before storing it and make sure it is not in contact with

other items.

•Leaving a leather band where it is exposed to direct sunlight

(ultraviolet rays) for long periods or failure to clean dirt from a leather

band for long periods can cause it to become discolored.

Important!

•Subjecting a natural leather or imitation leather band to rubbing or

dirt can cause color transfer and discoloration.

Metal Components

•Failure to clean dirt from a metal band can lead to formation of rust,

even if the band is stainless steel or plated. If the watch is exposed

to sweat or water, wipe it thoroughly with a soft, absorbent cloth and

then store it in a well-ventilated location to dry.

•To clean the band, use a soft toothbrush or similar tool to scrub it

with a weak solution of water and a mild neutral detergent. Take care

to avoid getting solution on the watch case.

Bacteria and Odor Resistant Band

•The bacteria and odor resistant band protects against odor

generated by the formation of bacteria from sweat, which ensures

good comfort and hygiene. In order to ensure maximum bacteria and

odor resistance, keep the band clean. Use an absorbent soft cloth to

wipe the band clean of dirt, sweat, and moisture. The bacteria and

odor resistant band suppresses the formation of organisms and

bacteria. It does not protect against rash due to allergic reaction, etc.

Note that CASIO COMPUTER CO., LTD. assumes no responsibility

for any damage or loss suffered by you or any third party arising

through the use of this product or its malfunction.

User Maintenance

Caring for Your Watch

•A dirty or rusty case or band can soil the sleeve of your clothing,

cause skin irritation, and even interfere with watch performance. Be

sure to keep the case and band clean at all times. Rust tends to

form easily after the watch is exposed to seawater and then left

without cleaning.

•Sometimes a smudge like pattern may appear on the surface of a

resin band. This will not have any affect on your skin or clothing.

Wipe the band with a cloth to clean it.

•Keep a leather band clean by wiping it with a dry cloth. Both resin

bands and leather band can become worn and cracked over time

when subjected to normal daily use.

•Should your band become badly cracked or worn, be sure to have it

replaced with a new one. Request band replacement from your

original retailer or an authorized CASIO Service Center. Note that

you will be charged for band replacement costs, even if your watch

is still covered by its warranty.

•Remember that you wear your watch next to your skin, just like a

piece of clothing. Because of this, you should always keep your

watch clean. Use a soft, absorbent cloth to wipe off any dirt, sweat,

water, or other foreign matter from the case and band.

Dangers of Poor Watch Care

Rust

•Though the stainless steel used for the watch is highly rust-resistant,

rust can form if the watch is not cleaned after it becomes dirty.

Failure of oxygen to come into contact with the metal because it is

dirty causes breakdown of the oxidization layer on the metal surface,

which leads to the formation of rust.

•Even if the surface of the metal appears clean, sweat and rust in

crevasses can soil the sleeves of clothing, cause skin irritation, and

even interfere with watch performance.

Premature Wear

•Leaving sweat or water on a resin band or storing it an area subject

to high moisture can lead to premature wear, cuts, and breaks.

Skin Irritation

•Individuals with sensitive skin or in poor physical condition may

experience skin irritation when wearing a watch. Such individuals

should keep their leather band or resin band particularly clean, or

switch to a metal band. Should you ever experience a rash or other

skin irritation, immediately remove the watch and contact a skin care

professional.

Battery Replacement

•Leave battery replacement up to your original retailer or authorized

CASIO Service Center.

•Have the battery replaced only with the type specified by in this

manual. Use of another type of battery can cause malfunction.

•When replacing the battery, also request a check for proper water

resistance. Note that you will be charged separately for water

resistance inspection.

Initial Battery

•The battery that comes loaded in your watch when you purchase it is

used for function and performance testing at the factory.

•This type of test battery may go dead quicker than the normally

rated battery life as noted in the User’s Guide. Note that you will be

charged for replacement of this battery, even if replacement is

required within the watch’s warranty period.

Low Battery Power

•Low battery power is indicated by large timekeeping error, when

display contents are dim, or when the display does blank.

•Operation while battery power is low can result in malfunction.

Replace the battery as soon as possible.

Marking

Example

of Daily

Use

Atmospheres

10BAR

Yes

Atmospheres

20BAR

Yes

Atmospheres

5BAR

Yes

BAR mark

Yes

Enhanced Water Resistance

Under Daily Use

On watch front or

on back cover

Hand washing, rain

Water-related work,

swimming

Windsurfing

Skin diving

Water

Resistance

Under

Daily Use

MA0807-EA

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	Collection LRW-250H-4A2VEF
Färg på produkten:	Zwart
Inbyggd display:	Nee
Vikt:	9240 g
Bredd:	327 mm
Djup:	321.2 mm
Höjd:	217.5 mm
Ljudnivå:	34.6 dB
Förpackningens vikt:	13780 g
LED-indikatorer:	Ja
Medföljande kablar:	AC, SAS
Monteringsalternativ för kabellås:	Ja
Kabellåsspårtyp:	Kensington
USB-anslutning:	Nee
Antal fans:	2 ventilator(en)
Bostadstyp:	Tower
Antal matningar:	1
Strömförsörjningsenhetskapacitet (PSU):	350 W
Lagringsenheter installerade:	Nee
Installerad lagringsenhet:	Nee
Total installerad lagringskapacitet:	0 TB
Maximal lagringskapacitet som stöds:	- TB
Internt kylsystem:	Ja
Enhetsklass:	Kleine & middelgrote bedrijven
Gränssnitt för lagringsenheter som stöds:	SAS, Serial ATA II, Serial ATA III
Överföringshastighet:	6 Gbit/s
Antal lagringsenheter som stöds:	10
AC-ingångsspänning:	110 - 240 V
AC-ingångsfrekvens:	47 / 63 Hz
Strömförbrukning (typiskt):	169.52 W
Drifttemperatur (TT):	0 - 40 °C
Relativ luftfuktighet i drift (VV):	5 - 95 procent
Typer av lagringsenheter som stöds:	HDD & SSD
Körplatslås:	Ja
SAS värdportar kvantitet:	2
