Operation Guide ANALOG (HK-W)

MA0801-EA

[

Modules 1362, 1398, 1770, 2799, 3378, 4370

]

To set the time

Pull out the crown. Set the hands by

rotating the crown. Push the crown

back in on a time signal to resume

timekeeping.

■For watch with the elapsed time bezel

Rotate the elapsed time bezel to align the

mark with the minute hand.

After certain amount of time elapsed, read the

graduation on the elapsed time bezel which

the minute hand points to.

The elapsed time is indicated.

•Some water resistant models are equipped

with a screw lock crown.

•With such models, you must unscrew the

crown in the direction noted in the illustration

to loosen it before you can pull it out. Do not

pull too forcibly on such crowns.

•Also note that such watches are not water

resistant while their crowns are loosened. Be

sure to screw the crowns back in as far as

they will go after making any setting.

Elapsed time bezel

Crown

[Days of the Week]

English Spanish

SUN DOM

MON LUN

TUE MAR

WED MIER

THU JUEV

FRI VIER

SAT SAB

SUN

Crown

(Normal position)

First click

(Day, day of week setting)

Second click

(Time setting)

First click

(Day setting)

Second click

(Time setting)

Crown

(Normal position)

[Modules 1782,

4328, 4747]

•Your watch may differ somewhat from the one shown in the illustration.

[Modules 705, 706, 1300, 1311, 1330,

1344, 1360, 1399, 1747, 1771, 4394, 5049]

To set the time

1. When the second hand is at

12 o’clock, pull out the crown

to stop it.

2. Set the hands by rotating the

crown. Move the minute hand

four or five minutes past the

setting you want, and then

back them up to the setting.

3. Push the crown back in on a

time signal to resume

timekeeping.

[Modules 707, 708, 1331, 1332, 1342, 1345,

1346, 1787, 2717, 2718, 2719, 2725, 2731,

2748, 2749, 2783, 2784, 3363, 3711, 3712,

4393, 5025, 5044]

To set the time

1. When the second hand is at

12 o’clock, pull out the crown to the

second click to stop it.

Set the hands by rotating the crown.

Move the minute hand four or five

minutes past the setting you want,

and then back them up to the setting.

3. Push the crown back in on a time

signal to resume timekeeping.

To set the day

•Avoid setting the day between 8:00

p.m. and 2:00 a.m. The day may not

change in the following day if you do.

1. Pull out the crown to the first click.

2. Set the day by rotating the crown.

3. Push the crown back in to its normal

position.

[Modules 709, 1333, 1347, 3716]

To set the time

1. When the second hand is at

12 o’clock, pull out the crown to the

second click to stop it.

2. Set the hands by rotating the crown.

Move the minute hand four or five

minutes past the setting you want,

and then back them up to the

setting.

3. Push the crown back in on a time

signal to resume timekeeping.

To set the day and day of the

week

•Avoid setting the day and day of the

week between 8:00 p.m. and 4:00

a.m. The day and day of the week

may not change in the following day if

you do.

1. Pull out the crown to the first click.

2. Set the day by rotating the crown

counterclockwise.

3. Set the day of the week by rotating

the crown clockwise. Confirm that

the correct language (English or

Spanish) is selected.

4. Push the crown back in to its normal

position.

[Module 4746]

Crown

(Normal position)

First click (Day setting)

Crown
