Operation Guide 5176
MO1011-EA
E-1
ENGLISH
Congratulations upon your selection of this CASIO watch.
Applications
The built-in sensors of this watch measure barometric pressure, temperature and
altitude. Measured values are then shown on the display. Such features make this
watch useful when hiking, mountain climbing, or when engaging in other such outdoor
activities.
E-2
Warning !
•
The measurement functions built into this watch are not intended for taking
measurements that require professional or industrial precision. Values produced
by this watch should be considered as reasonable representations only.
• Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any
damage or loss suffered by you or any third party arising through the use of
this product or its malfunction.
E-3
About This Manual
• Depending on the model of your watch, display text
appears either as dark fi gures on a light background, or
light fi gures on a dark background. All sample displays
in this manual are shown using dark fi gures on a light
background.
• Button operations are indicated using the letters shown
in the illustration.
• Note that the product illustrations in this manual are
intended for reference only, and so the actual product
may appear somewhat different than depicted by an
illustration.
E-4
Things to check before using the watch
1. Check the Home City and the daylight saving time (DST) setting.
Use the procedure under “To confi gure Home City settings” (page E-14) to confi gure
your Home City and daylight saving time settings.
Important!
Proper World Time Mode data depend on correct Home City, time, and date settings
in the Timekeeping Mode. Make sure you confi gure these settings correctly.
2. Set the current time.
See “Confi guring Current Time and Date Settings” (page E-17).
The watch is now ready for use.
E-5
Contents
E-3 About This Manual
E-4 Things to check before using the watch
E-9 Mode Reference Guide
E-13 Timekeeping
E-14 Confi guring Home City Settings
E-14 To confi gure Home City settings
E-16 To change the Daylight Saving Time (summer time) setting
E-17 Confi guring Current Time and Date Settings
E-18 To change the current time and date settings
E-22 Hand Home Position Correction
E-22 To adjust home positions
E-6
E-23 Barometer/Thermometer
E-23 To enter and exit the Barometer/Thermometer Mode
E-28 To calibrate the pressure sensor and the temperature sensor
E-30 Altimeter
E-31 To take an altimeter reading
E-34 To specify a reference altitude value
E-39 Specifying Temperature, Barometric Pressure, and Altitude Units
E-39 To specify temperature, barometric pressure, and altitude units
E-41
Precautions Concerning Simultaneous Measurement of Altitude and
Temperature
E-42 Checking the Current Time in a Different Time Zone
E-42 To enter the World Time Mode
E-42 To view the time in another time zone
E-43 To specify standard time or daylight saving time (DST) for a city
E-7
E-44 Using the Stopwatch
E-44 To enter the Stopwatch Mode
E-44 To perform an elapsed time operation
E-44 To pause at a split time
E-45 To measure two fi nishes
E-46 Using the Countdown Timer
E-46 To enter the Countdown Timer Mode
E-46 To specify the countdown start time
E-48 To perform a countdown timer operation
E-48 To stop the alarm
E-49 Using the Alarm
E-49 To enter the Alarm Mode
E-50 To set an alarm time
E-51 To test the alarm
E-52 To turn an alarm and the Hourly Time Signal on and off
E-52 To stop the alarm
E-8
E-53 Illumination
E-53 To turn on illumination
E-53 To change the illumination duration
E-55 Button Operation Tone
E-55 To turn the button operation tone on and off
E-57 Troubleshooting
E-61 Specifi cations
E-9
Mode Reference Guide
Your watch has 7 “modes”. The mode you should select depends on what you want to do.
To do this: Enter this mode: See:
• View the current time and date in the Home City
•
Confi gure Home City and daylight saving time (DST) settings
• Confi gure time and date settings
Timekeeping Mode E-13
View the barometric pressure and temperature at your
current location Barometer/
Thermometer Mode E-23
• View the altitude at your current location
• Determine the altitude differential between two locations
(reference point and current location)
Altimeter Mode E-30
View the current time in one of 48 cities (31 time zones)
around the globe World Time Mode E-42
Use the stopwatch to measure elapsed time Stopwatch Mode E-44
Use the countdown timer
Countdown Timer Mode
E-46
Set an alarm time Alarm Mode E-49
Operation Guide 5176
E-10
Selecting a Mode
• The illustration below shows which buttons you need to press to navigate between
modes.
• In any mode (except when a setting screen, with fl ashing digits is on the display),
press B to illuminate the display.
World Time
Mode
Barometer/
Thermometer Mode
Stopwatch Mode
Countdown
Timer Mode
World Time
Mode
Barometer/
Thermometer Mode
Stopwatch Mode
Countdown
Timer Mode
E-11
Alarm Mode Hand Setting Mode
Altimeter Mode
Timekeeping Mode
Alarm Mode Hand Setting Mode
Altimeter Mode
Timekeeping Mode
E-12
General Functions (All Modes)
The functions and operations described in this section can be used in all of the modes.
Auto Return Features
• The watch returns to the Timekeeping Mode automatically if you do not perform any
button operation for two or three minutes in the Alarm Mode.
• The watch will return to the Timekeeping Mode automatically if you do not perform
any operation for about one hour after entering the Barometer/Thermometer Mode.
•
If you leave a setting screen with fl ashing digits on the display for two or three minutes
without performing any operation, the watch exits the setting screen automatically.
Initial Screens
When you enter the World Time Mode or Alarm Mode, the data you were viewing
when you last exited the mode appears fi rst.
Scrolling
The B and D buttons are used on the setting screen to scroll through data on the
display. In most cases, holding down these buttons during a scroll operation scrolls
through the data at high speed.
E-13
Timekeeping
Use the Timekeeping Mode to set and view the current
time and date.
• In the Timekeeping Mode, the graphic in the center of
the display indicates the passage of seconds.
PM indicator
Day of week
Month Day
Seconds
Graphic
Hour hand
Hour : Minutes
Minute hand
PM indicator
Day of week
Month Day
Seconds
Graphic
Hour hand
Hour : Minutes
Minute hand
E-14
Confi guring Home City Settings
There are two Home City settings: actually selecting the Home City and selecting
either standard time or daylight saving time (DST).
To confi gure Home City settings
1. In the Timekeeping Mode, hold down A until the
currently selected city code (Home City) starts to fl ash.
This is the city code setting screen.
• Before the city code starts to fl ash, the message
SET Hold will appear on the display. Keep A
depressed until SET Hold disappears and the city
code starts to fl ash.
• The watch will exit the setting mode automatically if
you do not perform any operation for about two or
three minutes.
• For details about city codes, see the “City Code Table”
at the back of this manual.
PM indicator
City code
Seconds
Hour : Minutes
PM indicator
City code
Seconds
Hour : Minutes
E-15
2. Press D (East) and B (West) to select the city code
you want to use as your Home City.
• Keep pressing D or B until the city code you want to
select as your Home City appears on the display.
3. Press C to display the DST setting screen.
4.
Press
D
to toggle between Daylight Saving Time (On)
and Standard Time (
OFF).
• Note that you cannot switch between standard time
and daylight saving time (DST ) while UTC is
selected as your Home City.
5.
After all the settings are the way you want, press A to return to the Timekeeping Mode.
• The indicator appears to indicate that Daylight Saving Time is turned on.DST
Note
• After you specify a city code, the watch will use UTC* offsets in the World Time
Mode to calculate the current time for other time zones based on the current
time in your Home City.
* Coordinated Universal Time, the world-wide scientifi c standard of timekeeping.
The reference point for UTC is Greenwich, England.
Setting
DST indicator
Setting
DST indicator
E-16
To change the Daylight Saving Time (summer time) setting
1. In the Timekeeping Mode, hold down A until the
currently selected city code (Home City) starts to fl ash.
This is the city code setting screen.
• Before the city code starts to fl ash, the message
SET Hold will appear on the display. Keep A
depressed until SET Hold disappears and the city
code starts to fl ash.
2. Press C to display the DST setting screen.
3. Press D to toggle between Daylight Saving Time (
On)
and Standard Time (
OFF).
4. After all the settings are the way you want, press
A to
return to the Timekeeping Mode.
• The DST indicator appears to indicate that Daylight
Saving Time is turned on.
Setting
DST indicator
Setting
DST indicator
E-17
Confi guring Current Time and Date Settings
You can use the procedure below to adjust the current time and date settings if they
are off.
Changing the digital Home City data should cause the analog time setting to change
accordingly. If the analog time does not indicate the digital time, check the home
positions of the hands and make adjustments if necessary (page E-22).
E-18
To change the current time and date settings
1. In the Timekeeping Mode, hold down A until the
currently selected city code (Home City) starts to fl ash.
This is the city code setting screen.
• Before the city code starts to fl ash, the message
SET Hold will appear on the display. Keep A
depressed until SET Hold disappears and the city
code starts to fl ash.
2. Use D and B to select the city code you want.
• Select your Home City code before changing any
other setting.
• For full information on city codes, see the “City Code
Table” at the back of this manual.
City code
PM indicator
Seconds
Hour : Minutes
City code
PM indicator
Seconds
Hour : Minutes
E-19
3.
Press C to move the fl ashing in the sequence shown below to select the other settings.
Barometer
unit
Temperature
unit
Illumination
Duration
Button Operation
Tone On/Off Day
City
Code DST
Altitude
unit
12/24-Hour
Format Seconds Hour Minute Year Month
• The following steps explain how to confi gure timekeeping settings only.
4. When the timekeeping setting you want to change is fl ashing, use B and/or D to
change it as described below.
Screen To do this: Do this:
Change the city code Use D
(East) and
B (West).
Toggle between Daylight Saving Time (
On)
and Standard Time (OFF
). Press D.
Operation Guide 5176
E-20
Screen To do this: Do this:
Toggle between 12-hour (
12H) and 24-hour
(24H) timekeeping. Press D.
Reset the seconds to
00 Press D.
Change the hour or minute Use D (+) and B
(–).
Change the year, month, or day
5. Press A to exit the setting screen.
E-21
Note
• For information about selecting a Home City and confi guring the DST setting, see
“Confi guring Home City Settings” (page E-14).
• While 12-hour format is selected for timekeeping, a P (PM) indicator will appear for
times from noon to 11:59 p.m. No indicator appears for times from midnight to
11:59 a.m. With 24-hour format, time is displayed from 0:00 to 23:59, without any
P
(PM) indicator.
• The watch’s built-in full automatic calendar makes allowances for different month
lengths and leap years. Once you set the date, there should be no reason to
change it except after you have the watch’s battery replaced.
E-22
Hand Home Position Correction
The hour and minute hands of the watch can be thrown off by exposure to strong
magnetism or impact. The watch is designed to correct the hour and minute hand
positions manually.
• All of the operations in this section are performed in the Hand Setting Mode, which
you enter by pressing C (page E-11).
To adjust home positions
1. In the Hand Setting Mode, hold down A for about two
seconds until 0:00 appears on the display.
• This is the home position adjustment mode.
2. Check the positions of the hour and minute hands.
• The hands are in the correct home positions if they are
pointed at 12 o’clock. If they aren’t, use
D (clockwise)
and B (counterclockwise) to adjust their positions.
3. Press A to exit the setting screen.
• This will cause the hour and minute hands to move to
the current Timekeeping Mode time.
Hour and minute hands
Correct hour and
minute hand positions
Hour and minute hands
Correct hour and
minute hand positions
E-23
Barometer/Thermometer
This watch uses a pressure sensor to measure air pressure (barometric pressure) and
a temperature sensor to measure temperature.
To enter and exit the Barometer/Thermometer Mode
1. While in the Timekeeping Mode, press C to enter the
Barometer/Thermometer Mode.
• BARO will appear on the display, indicating
that barometric pressure and temperature
measurements are in progress. The measurement
results will appear on the display after about fi ve
seconds.
• After you press C, the watch will take readings every
fi ve seconds for the fi rst three minutes, and then
every two minutes after that.
Temperature
Current time
Barometric
pressure
Pressure
differential
pointer
Temperature
Current time
Barometric
pressure
Pressure
differential
pointer
E-24
2. Press C fi ve times to return to the Timekeeping Mode.
•
The watch will return to the Timekeeping Mode automatically if you do not perform
any operation for about one hour after entering the Barometer/Thermometer Mode.
Barometric Pressure
• Barometric pressure is displayed in units of 1 hPa (or 0.05 inHg).
•
The displayed barometric pressure value changes to
- - - if a measured barometric
pressure falls outside the range of 260 hPa to 1,100 hPa (7.65 inHg to 32.45 inHg).
The barometric pressure value will reappear as soon as the measured barometric
pressure is within the allowable range.
Temperature
• Temperature is displayed in units of 0.1°C (or 0.2°F).
• The displayed temperature value changes to
--.- °C (or °F) if a measured
temperature falls outside the range of –10.0°C to 60.0°C (14.0°F to 140.0°F). The
temperature value will reappear as soon as the measured temperature is within the
allowable range.
E-25
Display Units
You can select either hectopascals (hPa) or inchesHg (inHg) as the display unit for the
measured barometric pressure, and Celsius (°C) or Fahrenheit (°F) as the display unit
for the measured temperature value. See “To specify temperature, barometric
pressure, and altitude units” (page E-39).
Barometric Pressure Differential Pointer
This pointer indicates the relative difference between
the most recent barometric pressure reading and the
current barometric pressure value displayed in the
Barometer/Thermometer Mode (page E-23).
Barometric
pressure
differential
pointer
Barometric
pressure
differential
pointer
E-26
Reading Barometric Pressure Differential Pointer
Pressure differential is indicated in the range of ±5 hPa, in 1-hPa units.
If the pointer is located here: It means this:
CLOUDY (–) Pressure is falling and weather will tend to deteriorate.
FINE (+) Pressure is rising and weather will tend to improve.
• The nearby screen shot, for example, shows what the pointer would indicate when
the calculated pressure differential is approximately – 3 hPa (approximately – 0.09
inHg).
−0.15
0.15
inHg valueshPa values
Current pressure less than most
recent measured pressure
Current pressure greater than
most recent measured pressure
E-27
• Barometric pressure is calculated and displayed using hPa as the standard. The
barometric pressure differential also can be read in inHg units as shown in the
illustration (1 hPa = 0.03 inHg).
Pressure Sensor and Temperature Sensor Calibration
The pressure sensor and temperature sensor built into the watch are calibrated at the
factory and normally require no further adjustment. If you notice serious errors in the
pressure readings and temperature readings produced by the watch, you can calibrate
a sensor to the reading of another device to correct the errors.
Important!
• Incorrectly calibrating the temperature sensor can result in incorrect readings.
Carefully read the following before doing anything.
–
Compare the readings produced by the watch with those of another reliable and
accurate thermometer.
– If adjustment is required, remove the watch from your wrist and wait for 20 or 30
minutes to give the temperature of the watch time to stabilize.
E-28
To calibrate the pressure sensor and the temperature sensor
1.Take a reading with another measurement device to
determine the exact current barometric pressure or
temperature.
2. With the watch in the Timekeeping Mode, press C to
enter the Barometer/Thermometer Mode.
3. Hold down A until the current temperature value starts
to fl ash on the display. This is the setting screen.
• Before the temperature value starts to fl ash, the
message SET Hold will appear on the display.
Keep A depressed until SET Hold disappears.
4. Press C to move the fl ashing between the temperature
value and barometric pressure value, to select the one
you want to calibrate.
E-29
5.
Use D (+) and B (–) to adjust the calibration value in the units shown below.
Temperature 0.1°C (0.2°F)
Barometric Pressure 1 hPa (0.05 inHg)
• To return the currently fl ashing value to its initial factory default setting, press
B
and D at the same time. will appear at the fl ashing location for about one OFF
second, followed by the initial default value.
6. Press A to return to the Barometer/Thermometer Mode screen.
Barometer and Thermometer Precautions
• The pressure sensor built into this watch measures changes in air pressure, which
you can then apply to your own weather predictions. It is not intended for use as a
precision instrument in offi cial weather prediction or reporting applications.
• Sudden temperature changes can affect pressure sensor readings.
• Temperature measurements are affected by your body temperature (while you are
wearing the watch), direct sunlight, and moisture. To achieve a more accurate
temperature measurement, remove the watch from your wrist, place it in a well
ventilated location out of direct sunlight, and wipe all moisture from the case. It
takes approximately 20 to 30 minutes for the case of the watch to reach the actual
surrounding temperature.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | Collection SGW-400H-1BVER |
Behöver du hjälp?
Om du behöver hjälp med Casio Collection SGW-400H-1BVER ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
