1
Operation Guide 3170
• Monthly alarm
Set the day, hour and minutes for the alarm time. This type of setting causes the alarm
to sound every month at time you set, on the day you set.
To set an alarm time
1. In the Alarm Mode, use D to scroll through the alarm
screens until the one whose time you want to set is
displayed.
Press .
•To set a one-time alarm, display one of the screens indicated by an alarm number
from 2 through 5. To set the snooze alarm, display the screen indicated by 1.
2. After you select an alarm, hold down A until the hour setting of the alarm time
starts to flash, which indicates the setting screen.
•This operation automatically turns on the alarm.
3. Press C to move the flashing in the sequence shown below to select other
settings.
Hour Minutes Month Day
4. While a setting is flashing, press D to increase it.
•To set an alarm that does not include a month (Daily alarm, Monthly alarm),
set x for the month. Press D until the x mark appears (between 12 and 1) while
month setting is flashing.
•To set an alarm that does not include a day (Daily alarm, 1-Month alarm),
set xx for the day. Press D until the
xx mark appears (between the end of the
month and 1) while the day setting is flashing.
•When setting the alarm time using the 12-hour format, take care to set the time
correctly as a.m. or p.m. (P indicator).
5. Press A to exit the setting screen.
Alarm Operation
The alarm tone sounds at the preset time for 10 seconds, regardless of the mode the
watch is in. In the case of the snooze alarm, the alarm operation is performed a total
of seven times, every five minutes, until you turn the alarm off or change it to a one-
time alarm.
•To stop the alarm tone after it starts to sound, press any button.
•Performing any one of the following operations during a 5-minute interval between
snooze alarms cancels the current snooze alarm operation.
Displaying the Timekeeping Mode setting screen
Displaying the alarm
1
setting screen
To test the alarm
•In the Alarm Mode, hold down to sound the alarm.D
To turn Alarms
2
through
5
and the Hourly Time Signal on and off
1. In the Alarm Mode, use D to select a one-time alarm
(alarm number 2 through 5) or the Hourly Time Signal
(:00).
2. Press A to toggle it on and off.
•The on/off status of Alarms 2
through 5 and the Hourly
Time Signal is shown by indicators along the bottom of
the displays.
•The alarm on indicators and Hourly time Signal on
indicator are displayed in all modes.
•While an alarm is sounding, the applicable alarm on
indicator flashes on the display.
Timekeeping
Use the Timekeeping Mode to set and view the current
time and date.
To set the time and date
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Press C to move the flashing in the sequence shown
below to select other settings.
Seconds Hour Minutes
Day Month Year
3. When the setting you want to change is flashing, press D to change it as
described below.
MA0905-EA
About This Manual
•Button operations are indicated using the letters shown
in the illustration.
•Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
Timekeeping Mode Alarm Mode Stopwatch ModeCountdown Timer
Mode
Dual Time Mode
Press .
General Guide
•Press C to change from mode to mode.
•In any mode, press B to illuminate the display.
•In any mode, hold down for about two seconds to return to the TimekeepingC
Mode.
PM indicator
Day of week
Seconds
Hour : Minutes
Month – Day
To change this setting
Seconds
Hour, Minutes, Year, Month, Day
Perform this button operation
Press .D to reset to 00
Press D to increase the setting.
•Pressing while the seconds are in the range of 30 to 59 resets them to andD00
adds 1 to the minutes. In the range of 00 to 29, the minutes are unchanged.
4. Press A to exit the setting screen.
•The day of the week is automatically displayed in accordance with the date (year,
month, and day) settings.
•The year can be set in the range of 2000 to 2099.
•The watch’s built-in full automatic calendar automatically makes allowances for
different month lengths and leap years. Once you set the date, there should be no
reason to change it except after you have the watch’s battery replaced.
To toggle between 12-hour and 24-hour timekeeping
In the Timekeeping Mode, press to toggle between 12-hour timekeeping andD
24-hour timekeeping.
•With the 12-hour format, the P (PM) indicator appears to the left of the hour digits for
times in the range of noon to 11:59 p.m. and no indicator appears to the left of the
hour digits for times in the range of midnight to 11:59 a.m.
•With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without
any indicator.
•The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
applied in all other modes.
Alarms
You can set up to five independent multi-function alarms
with hour, minutes, month, and day. When an alarm is
turned on, the alarm tone sounds when the alarm time is
reached. One of the alarms can be configured as a
snooze alarm or a one-time alarm, while the other four are
one-time alarms.
You can also turn on an Hourly Time Signal that causes
the watch to beep twice every hour on the hour.
•There are five alarms numbered
1 through 5. You can
configure Alarm
1 as a snooze alarm or a one-time
alarm. Alarms 2 through 5 can be used as one-time
alarms only.
•All of the operations in this section are performed in the
Alarm Mode, which you enter by pressing C.
Alarm Types
The alarm type is determined by the settings you make, as described below.
• Daily alarm
Set the hour and minutes for the alarm time. This type of setting causes the alarm to
sound everyday at the time you set.
• Date alarm
Set the month, day, hour and minutes for the alarm time. This type of setting causes
the alarm to sound at the specific time, on the specific date you set.
• 1-Month alarm
Set the month, hour and minutes for the alarm time. This type of setting causes the
alarm to sound everyday at time you set, only during the month you set.
Alarm number
Alarm date
(Month Day) –
Alarm time
(Hour : Minutes)
Hourly time signal
on indicator
Alarm on indicator
2
Operation Guide 3170
Backlight
The backlight uses an LED (light-emitting diode) and a
light guide panel that cause the entire display to glow for
easy reading in the dark.
•See “Backlight Precautions” for other important
information about using the backlight.
To turn on the backlight
In any mode, press to illuminate the display for aboutB
one second.
Stopwatch
The stopwatch lets you measure elapsed time, split times,
and two finishes.
•The display range of the stopwatch is 23 hours,
59 minutes, 59.99 seconds.
•The stopwatch continues to run, restarting from zero
after it reaches its limit, until you stop it.
•The stopwatch measurement operation continues even
if you exit the Stopwatch Mode.
•Exiting the Stopwatch Mode while a split time is frozen
on the display clears the split time and returns to
elapsed time measurement.
•All of the operations in this section are performed in the
Stopwatch Mode, which you enter by pressing .C
To measure times with the stopwatch
Elapsed time
Start Stop Re-start Stop Clear
Start Split
( displayed)SPL
Split release Stop Clear
Start Split Stop Split release Clear
Split time
Two Finishes
First runner
finishes.
Display time of
first runner.
Second runner
finishes.
Display time of
second runner.
To turn auto-repeat on and off
1. In the Countdown Timer Mode, hold down A until the
hours setting of the countdown start time starts to flash,
which indicates the setting screen.
2. Press B to toggle auto-repeat on ( displayed) and
off ( not displayed).
•Note that pressing B in the above operation also turns
on the backlight.
•When the end of the countdown is reached while
auto-repeat is on, the alarm sounds, but the countdown
restarts from the beginning without stopping. You can
stop the countdown by pressing and manually resetD
to the start time by pressing A.
•The auto-repeat indicator appears in the Countdown
Timer Mode only.
Dual Time
The Dual Time Mode lets you keep track of time in a different time zone.
•In the Dual Time Mode, the seconds count is synchronized with the seconds count
of the Timekeeping Mode.
To set the Dual Time
1. Press C to enter the Dual Time Mode.
2. In the Dual Time Mode, hold down A until the hour
setting starts to flash, which indicates the setting
screen.
3. Press C to change the selection in the following
sequence.
Hour Minutes
4. Press D to increase the setting.
5. Press A to exit the setting screen.
Countdown Timer
The countdown timer can be set within a range of
one minute to 24 hours. An alarm sounds when the
countdown reaches zero.
•You can also select auto-repeat, which automatically
restarts the countdown from the original value you set
whenever zero is reached.
•All of the operations in this section are performed in the
Countdown Timer Mode, which you enter by pressing
C.
To use the countdown timer
Press while in the Countdown Timer Mode to start theD
countdown timer.
•When the end of the countdown is reached and auto-repeat is turned off, the alarm
sounds for 10 seconds or until you stop it by pressing any button. The countdown
time is automatically reset to its starting value after the alarm stops.
•The countdown timer measurement operation continues even if you exit the
Countdown Timer Mode.
•Press D while a countdown operation is in progress to pause it. Press D again to
resume the countdown.
•To completely stop a countdown operation, first pause it (by pressing ), and thenD
press A. This returns the countdown time to its starting value.
To set the countdown start time
1. In the Countdown Timer Mode, hold down A until the
hours setting of the countdown start time starts to flash,
which indicates the setting screen.
2. Press C to move the flashing between the hours and
minutes settings.
3. While a setting is flashing, use D to increase it.
•To set the starting value of the countdown time to
24 hours, set 0:00.
4. Press A to exit the setting screen.
To select the operation of Alarm
1
1. In the Alarm Mode, use D to select Alarm
1.
2. Press A to cycle through the available settings in the sequence shown below.
Snooze on indicator ( ) and Alarm1 on indicator
One-time
alarm on
Alarm off
Snooze
alarm on
Press .
•The snooze on indicator ( ) and Alarm1 on indicator are displayed in all modes.
•The snooze on indicator ( ) flashes during the 5-minute intervals between
alarms.
•The alarm indicator (Alarm
1 on and/or snooze on) flashes while the alarm is
sounding.
Seconds
Minutes
Hours
1/100 second
Seconds
Minutes
Hours
Auto-repeat indicator
Seconds
Hour : Minutes
Reference
This section contains more detailed and technical information about watch operation.
It also contains important precautions and notes about the various features and
functions of this watch.
Auto return features
If you leave a screen with flashing digits for two or three minutes without performing
any operation, the watch automatically saves any settings you have made up to that
point and exits the setting screen.
Data and Setting Scrolling
The D button is used to scroll through setting screen data on the display. Holding
down this button during a scroll operation scrolls through the data at high speed.
Backlight Precautions
•The illumination provided by the backlight may be hard to see when viewed under
direct sunlight.
•The backlight automatically stops illuminating whenever an alarm sounds.
•Frequent use of the backlight shortens the battery life.
Specifications
Accuracy at normal temperature: ±30 seconds a month
Timekeeping: Hour, minutes, seconds, p.m. (P), month, day, day of the week
Time system: Switchable between 12-hour and 24-hour formats
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Alarms:
5 Multi-function∗alarms (Four one-time alarms; one snooze/one-time alarm);
Hourly Time Signal
∗
Alarm type: Daily alarm, Date alarm, 1-month alarm, Monthly alarm
Countdown Timer
Measuring unit: 1 second
Input range: 1 minute to 24 hours (1-minute increments and 1-hour increments)
Other: Auto-repeat function
Stopwatch
Measuring unit: 1/100 of a second
Measuring capacity: 23:59' 59.99''
Measuring modes: Elapsed time, split time, two finishes
Dual Time: Hour, minutes, seconds, p.m. (P)
Other: Backlight (light-emitting diode)
Battery: One lithium battery (Type: CR2025)
Approximately 10 years on type CR2025 (assuming alarm operation 10 sec./day,
and one backlight operation 1.5 sec./day)

Produktspecifikationer

Varumärke: Casio
Kategori: Titta
Modell: Collection W-213-1AVES

Behöver du hjälp?

Om du behöver hjälp med Casio Collection W-213-1AVES ställ en fråga nedan och andra användare kommer att svara dig


Titta Casio Manualer

Casio

Casio Edifice EQB-1000TR-2AER Bruksanvisning

24 Oktober 2024
Casio

Casio Collection MTP-1259PD-7BEF Bruksanvisning

24 Oktober 2024
Casio

Casio G-Shock GA-810B-1A9ER Bruksanvisning

24 Oktober 2024
Casio

Casio Collection SGW-450HD-1BER Bruksanvisning

24 Oktober 2024
Casio

Casio Edifice EQB-1000XD-1AER Bruksanvisning

24 Oktober 2024
Casio

Casio Collection MTP-1222A-2AVEF Bruksanvisning

24 Oktober 2024
Casio

Casio G-Shock GMW-B5000G-2ER Bruksanvisning

24 Oktober 2024
Casio

Casio Radio Controlled WV-200E-1AVEF Bruksanvisning

24 Oktober 2024
Casio

Casio Collection LWS-2000H-2AVEF Bruksanvisning

24 Oktober 2024
Casio

Casio Pro Trek PRW-60YBM-1AER Bruksanvisning

24 Oktober 2024

Titta Manualer

Nyaste Titta Manualer

Lorus

Lorus W207 Bruksanvisning

27 Oktober 2024
Invicta

Invicta Specialty 31308 Bruksanvisning

27 Oktober 2024
Timex

Timex Ironman TW5M244009J Bruksanvisning

26 Oktober 2024
Timex

Timex MK1 TW2R68800VQ Bruksanvisning

26 Oktober 2024
Braun

Braun BN0021 Bruksanvisning

24 Oktober 2024
Braun

Braun AW60 Bruksanvisning

24 Oktober 2024
Braun

Braun BN0042 Bruksanvisning

24 Oktober 2024
Skmei

Skmei 0984A Bruksanvisning

22 Oktober 2024
Suunto

Suunto SPARTAN ULTRA 1.2 Bruksanvisning

21 Oktober 2024
Skmei

Skmei 0955 Bruksanvisning

21 Oktober 2024
