Operation Guide 5627
E-9
Digital Time and Date
Use the Timekeeping Mode to set and view a digital display of the current time and
date. When setting the digital time, you can also configure settings for summer time
(Daylight Saving Time or DST).
To set the digital time and date
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Press C to move the flashing in the sequence shown
below to select the other settings.
Seconds MinutesDST
C C
C
Hour
C
Day Year
C
C
Month
C
E-8
Timekeeping
This watch features separate digital and analog
timekeeping. The procedures for setting the digital time
(page E-9) and analog time (page E-16) are different.
x The Moon phase indicator (page E-42) shows the
current Moon phase in accordance with the current
date as kept in the Timekeeping Mode.
x The fishing level indicator indicates the times when
fish can be expected to be feeding. For more
information, see “Fishing/Moon Mode” (page E-19).
Important!
x Be sure to configure the current time and date, and
your Home Site data (data for the site where you
use the watch) correctly before using the functions
of this watch. See “Home Site Data” (page E-13) for
more information.
Hour : Minutes Seconds
PM indicator
Fishing level indicator
Day of week Month – Day
Moon phase indicator
E-7
C C
CC
Dual Time Mode Hand Setting Mode
Countdown Timer Mode Alarm Mode
E-6
General Guide
x Press C to change from mode to mode.
x In any mode (except when a setting screen is on the display), press B to
illuminate the face of the watch.
Timekeeping Mode Stopwatch Mode Fishing/Moon Mode
C C C
E-5
To test the alarm ...................................................................................................E-35
To turn Alarms 2 and 3, and the Hourly Time Signal on and off .......................E-36
To select the operation of Alarm 1 ......................................................................E-37
To set the Dual Time .............................................................................................E-38
To illuminate the face of the watch .....................................................................E-40
To specify the illumination duration ....................................................................E-41
To turn the button operation tone on and off .................................................... E-44
E-4
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To set the digital time and date .............................................................................E-9
To toggle the Timekeeping Mode digital time
between DST and Standard Time .................................................................... E-12
To configure Home Site data ...............................................................................E-14
To toggle between 12-hour and 24-hour timekeeping ...................................... E-16
To adjust the analog time .....................................................................................E-17
To view the current fishing level and Moon data ...............................................E-21
To specify a date ...................................................................................................E-23
To measure times with the stopwatch ................................................................E-26
To use the countdown timer ................................................................................ E-28
To set up the countdown timer ............................................................................E-29
To set an alarm time .............................................................................................E-33
E-3
Contents
General Guide ..........................................................................................................E-6
Timekeeping ............................................................................................................E-8
Fishing/Moon Mode ..............................................................................................E-19
Stopwatch .............................................................................................................. E-25
Countdown Timer ..................................................................................................E-27
Alarms.....................................................................................................................E-31
Dual Time ...............................................................................................................E-38
Illumination .............................................................................................................E-40
Reference ............................................................................................................... E-42
Specifications ........................................................................................................E-47
Operating Precautions ..........................................................................................E-50
User Maintenance .................................................................................................E-61
E-2
About This Manual
x Button operations are indicated using the letters
shown in the illustration.
x For the sake of simplicity, the sample displays in this
manual do not show the analog hands of the watch.
x Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
x To ensure that this watch provides you with the years
of service for which it is designed, be sure to carefully
read and follow the instructions under “Operating
Precautions” and “User Maintenance”.
E-1
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of
your purchase, be sure to read this manual carefully and keep it on hand for later
reference when necessary.
Important!
The fishing level indicator and moon phase indicator produced by this watch are
all based on calculations that use the watch’s current time, date, and Home Site
settings. Because of this, you should make sure that the current date and time, and
your Home Site data are all correct before using the indicators.
x When fishing, always take proper precautions to ensure your own personal
safety and the personal safety of others around you.
x Note that the fishing level indicator and moon phase indicator are all based on
calculated values. They are provided only for reference purposes.
x See the “Timekeeping” section of this manual for information about setting the
current time and date, and about specifying your Home Site.
MA1909-EA © 2019 CASIO COMPUTER CO., LTD.
Operation Guide 5627
E-19
Fishing/Moon Mode
The Fishing/Moon Mode displays an indicator that shows,
as one of five levels, the suitability of a specific date and
time (minute 00 to minute 59 of a particular hour) for
fishing. This mode also can be used to display Moon Data
(Moon age and Moon phase) for a specific date.
x If you doubt that the fishing level indicator or current
Moon data is wrong for some reason, check the
current Timekeeping Mode settings (time, date, and
Home Site), and correct them if required.
x See “Moon Phase Indicator” (page E-42) for
information about the Moon phase indicator.
x All of the operations in this section are performed in
the Fishing/Moon Mode, which you enter by pressing
C (page E-6).
Time
Fishing level indicator
Year Month – Day
Moon phase indicator
E-18
4. Press A to exit the setting screen.
x The watch will automatically adjust the minute hand slightly to match its internal
second count when you exit the setting screen.
x To return to the Timekeeping Mode, press C.
E-17
To adjust the analog time
1. In the Timekeeping Mode, press C six times to enter
the Hand Setting Mode (page E-7).
2. Hold down A until the current digital time starts to
flash, which indicates the analog setting screen.
3. Press D to advance the analog time setting by
20seconds.
x Holding down D advances the analog time setting
at high speed.
x If you need to advance the analog time setting a long way, hold down D
until the time starts advancing at high speed, and then press B. This locks
the highspeed hand movement, so you can release the two buttons. High-
speed hand movement continues until you press any button. It will also stop
automatically after the time advances 12 hours or if an alarm (multi-function
alarm, Hourly Time Signal, or countdown beeper) starts to sound.
E-16
To toggle between 12-hour and 24-hour timekeeping
In the Timekeeping Mode, press D to toggle between 12-hour timekeeping and
24-hour timekeeping.
x With the 12-hour format, the P (PM) indicator appears to the left of the hour
digits for times in the range of noon to 11:59 p.m. and no indicator appears to
the left of the hour digits for times in the range of midnight to 11:59 a.m.
x With the 24-hour format, times are displayed in the range of 0:00 to 23:59,
without any indicator.
x The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
applied in all other modes.
x The P indicator is not displayed with the Timekeeping Mode time on the
Countdown Timer Mode and Dual Time Mode screens.
Setting the Analog Time
Perform the procedure below when the time indicated by the analog hands does not
match the time of the digital display.
E-15
4. When the setting you want to change is flashing, use D and B to change it as
described below.
Setting Screen Button Operations
UTC Differential
Use D (+) and B (–) to change the setting.
x You can specify a value in the range of –12.0 to
+14.0, in 0.5-hour units.
Longitude Value
Use D (+) and B (–) to change the setting.
x You can specify a value in the range of 0° to 180°,
in 1-degree units.
East Longitude/
West Longitude
Use D to switch between east longitude ( ) and E
west longitude ( ).W
x When the digital time DST setting is on, the UTC differential can be set in a
range of –11.0 to +15.0 in 0.5-hour units.
5. Press A to exit the setting screen.
E-14
To configure Home Site data
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Press A again to display the UTC differential setting
screen.
3. Press C to move the flashing in the sequence shown
below to select other settings.
UTC
Differential
Longitude
Value
East Longitude/
West Longitude
C
C
C
UTC differential
E-13
Home Site Data
Moon phase, the fishing level indicator, and Fishing/Moon Mode data will not
be displayed properly unless Home Site data (UTC differential and longitude) is
configured correctly.
x The UTC differential is a value that indicates the time difference between
a reference point in Greenwich, England and the time zone where a city is
located.
x The letters “UTC” is the abbreviation for “Coordinated Universal Time”,
which is the world-wide scientific standard of timekeeping. It is based upon
carefully maintained atomic (cesium) clocks that keep time accurately to within
microseconds. Leap seconds are added or subtracted as necessary to keep
UTC in sync with the Earth’s rotation.
x The “Site Data List” at the back of this manual provides UTC differential,
latitude, and longitude information around the world.
x The following is the initial factory default Home Site data (Tokyo, Japan) when
you first purchase the watch, and whenever you have the battery replaced.
Change these settings to match the area where you normally use the watch.
UTC differential (+9.0); Longitude (East 140 degrees)
E-12
To toggle the Timekeeping Mode digital time between DST and Standard Time
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Press C once to display the DST setting screen.
3. Press D to toggle between Daylight Saving Time ( On
displayed) and Standard Time ( displayed).OF
4. Press A twice to exit the setting screen.
x The indicator appears on the Timekeeping, DST
Fishing/Moon, Alarm, and Hand Setting Mode screens
to indicate that Daylight Saving Time is turned on. In
the case of the Fishing/Moon Mode, the DST indicator
appears on the fishing level screen only.
On/Off status
DST indicator
E-11
x Resetting the seconds only (without changing the DST, hour, or minute setting)
causes the analog minute hand setting to be adjusted automatically.
x See “Digital Time Daylight Saving Time (DST) Setting” below for details about
the DST setting.
x The day of the week is displayed automatically in accordance with the date
(year, month, and day) settings.
Digital Time Daylight Saving Time (DST) Setting
Daylight Saving Time (summer time) advances the digital time setting by one hour
from Standard Time. Remember that not all countries or even local areas use
Daylight Saving Time.
E-10
3. When the setting you want to change is flashing, use B and D to change it as
described below.
Screen To do this: Do this:
Reset the seconds to 00 Press D.
Toggle between Daylight Saving Time
( )On OF) and Standard Time ( Press D.
Change the hour or minutes
Use D (+) and B (–).Change the year
Change the month or day
4. Press A twice to exit the setting screen.
x The first press of A displays the UTC differential setting screen. Pressing A
again exits the setting screen.
Operation Guide 5627
E-29
To set up the countdown timer
1. While the countdown start time is on the display in the
Countdown Timer Mode, hold down A until the hour
setting of the countdown start time starts to flash, which
indicates the setting screen.
x If the countdown start time is not displayed, use
the procedure under “To use the countdown timer”
to display it.
2. Press C to move the flashing in the sequence shown
below to select other settings.
Hours Minutes Auto-repeat
C
C
C
E-28
To use the countdown timer
Press D while in the Countdown Timer Mode to start the countdown timer.
x When the end of the countdown is reached and auto-repeat is turned off, the
alarm sounds for 10 seconds or until you stop it by pressing any button. The
countdown time is automatically reset to its starting value after the alarm stops.
x When auto-repeat is turned on, the countdown will restart automatically without
pausing when it reaches zero. The alarm sounds to signal when the countdown
reaches zero.
x The countdown timer measurement operation continues even if you exit the
Countdown Timer Mode.
x Press D while a countdown operation is in progress to pause it. Press D
again to resume the countdown.
x To completely stop a countdown operation, first pause it (by pressing D), and
then press A. This returns the countdown time to its starting value.
x Fishing level indicator images appear and disappear in time with the countdown
timer measurement operation.
E-27
Countdown Timer
You can set the countdown timer within a range of one
minute to 24 hours. An alarm sounds when the countdown
reaches zero.
x You can also select auto-repeat, which automatically
restarts the countdown from the original value you set
whenever zero is reached.
x All of the operations is this section are performed in
the Countdown Timer Mode, which you can enter
using C (page E-7).
Minutes
Hours
Timekeeping Mode time
Seconds
E-26
To measure times with the stopwatch
Elapsed Time
D D D D A
Start Stop Resume Stop Reset
Split Time
D A A D A
Start Split
( displayed)SPL
Split release Stop Reset
Two Finishes
D A D A A
Start Split
First runner
finishes.
Display time of first
runner.
Stop
Second runner
finishes.
Split release
Display time of
second runner.
Reset
E-25
Stopwatch
The stopwatch lets you measure elapsed time, split times,
and two finishes.
x The display range of the stopwatch is 23 hours,
59minutes, 59.99 seconds.
x The stopwatch continues to run, restarting from zero
after it reaches its limit, until you stop it.
x The stopwatch measurement operation continues even
if you exit the Stopwatch Mode.
x Exiting the Stopwatch Mode while a split time is frozen
on the display clears the split time and returns to
elapsed time measurement.
x Fishing level indicator images appear and disappear in
time with the stopwatch time measurement operation.
x All of the operations in this section are performed in
the Stopwatch Mode, which you enter by pressing C
(page E-6).
Minutes
Hours
1/100 second
Seconds
E-24
3. While a setting is flashing, use D (+) or B (–) to change it.
x You can specify a date in the range of January 1, 2000 to December 31,
2099.
4. Press A
to exit the setting screen.
5. Use A to display either the fishing level screen or the Moon Data screen.
E-23
x You can also specify a particular date (year, month, day) to view its fishing level
and Moon data. See “To specify a date” (page E-23) for more information.
x When you enter the Fishing/Moon Mode, the screen (fishing level or Moon data)
that was displayed the last time you exited the mode appears first.
To specify a date
1. In the Fishing/Moon Mode, hold down A until the
year setting starts to flash, which indicates the setting
screen.
2. Press C to move the flashing in the sequence shown
below to select the other settings.
Year Month Day
C
C
C
Year
Month – Day
E-22
A
Time Moon age
Fishing level indicator Year Month – Day
Moon phase indicator
Fishing Level Screen Moon Data Screen
x While the fishing level screen is displayed, press D to advance to the next
hour.
x While the Moon Data screen is displayed, press D to advance to the next day.
E-21
x The fishing level indicator changes in accordance with the Moon data.
x In the Timekeeping Mode, the FISH indicator flashes whenever the fishing level
of the current time is 4 or 5.
To view the current fishing level and Moon data
In the Fishing/Moon Mode, press A to toggle between the fishing level screen and
the Moon Data screen.
x The fishing level indicator shows the level for the displayed time. The initial
fishing level screen shows the level for 6:00 a.m. The Moon data screen shows
the Moon age and Moon phase for the current date.
E-20
Fishing Level Indicator
The fishing level indicator shows the relative favorability of a fishing time (calculated
in accordance with Moon transit and phase) as shown in the table below.
Level 5 Level 4 Level 3 Level 2 Level 1
Moon Transit
Moon Phase
Upper
Lower West East Other
New moon*
Full moon Level 5 Level 4 Level 3
First quarter
Last quarter Level 4 Level 3 Level 2
Other Level 3 Level 2 Level 1
* These indicators
actually appear
during Moon ages
13.0 to 16.6 (Full
Moon and phase
immediately
preceding it) and
27.7 to 1.8 (New
Moon and phase
immediately
preceding it).
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | Collection WSC-1250H-1AVEF |
Behöver du hjälp?
Om du behöver hjälp med Casio Collection WSC-1250H-1AVEF ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
